Features
(at 25°C enviromental temp.)
Setpoint
OP4 PV retransmission
(option)
One shot Fuzzy-Tuning
with automatic selection
Serial comm. (option)
Auxiliary Supply
Operational safety
General
characteristics
Description
Ramp up and down. User inhibited
Low limit
High limit
Galvanic isolation: 500 Vac/1 min
Resolution:
12bit (0.025%)
Accuracy:
0.1 %
The controller selects automatically the best
method according to the process conditions
RS485 isolated, Modbus/Jbus protocol, 1200, 2400, 4800, 9600 bit/s 2 wires
18Vdc ±20%, 30mA max. for an external transmitter supply
Detection of out of range, short circuit or sensor break with automatic
Measure input
activation of the safety strategies and alerts on display
Control output
Safety value:
Parameter and configuration data are stored in a non volatile memory for
Parameters
an unlimited time
Access protection
Password to access the configuration and parameters data
100...240Vac (-15...+10%) 50/60Hz or
Power supply
24Vac (-25...+12%) 50/60Hz and
24Vdc (-15...+25%)
Electric safety
Compliance to EN61010, installation class 2 (2.5kV) pollution class 2
Electromagnetic
Compliance to the CE standards for industrial system and equipment
compatibility
UL and cUL approvals
File 176452
IP20 terminal block
Protection EN650529
IP65 front panel
1
Dimensions
0.1...999.9 digit/min (OFF = 0)
From low range to the high limit
From low limit to the high range
Current output: 0/4...20mA 750Ω/15V max.
Step method
Natural frequency method
0...100%.
(user enabled/disabled)
/
DIN - 48 x 48, depth 120 mm, weight 130 g approx.
16
6 - Technical specification
Power consumption
2.6W max.
31
