System Elements

Encoder Function

The function of the ZyPer4K Encoder Device (Encoder) is to accept audio and video data over a
variety of interface types, and translate that data to a format suitable for transmission over a
standard 10G Ethernet network.
Video data is segmented, encrypted, prepared for transmission, and sent by the Encoder unit.
No unit other than those so designated by the control entity shall be able to receive the video
stream sent by an Encoder.
The format of the IP data is fully in compliance with industry-standard IEEE 802.3 Ethernet
networking practices. Any switch or device capable of passing 10G Ethernet traffic can be
employed to carry ZyPer4K A/V traffic.
Other ports on the Encoder devices are for the carriage of USB, IR, RS232 and audio data as
well as a 1Gbit/second utility port for general purpose connectivity of devices to the 10G bulk
data infrastructure.
Common Interfaces on all Encoders:
• Power Input (12VDC)
• RS232 Input/Output
• 1Gbit/sec Utility Ethernet Port
•
Analog Audio Input
•
Infrared Input
•
Infrared Output
•
HDMI Input
In total there are 16 different, unique Encoder types that can be ordered.
HDMI Fiber
HDMI Fiber with USB
HDMI Copper
HDMI Copper with USB
User Manual
HD-SDI Fiber
HD-SDI Fiber with USB
HD-SDI Copper
HD-SDI Copper w/USB
Page
Optional Interfaces on Encoder Units:
Ethernet Bulk Media Interface:
10G Fiber or 10G Copper
USB:
(none) or
USB Type-B Interface
Extended Media Input:
(none) or
HDSDI or
DisplayPort or
Analog (YPrPb/VGA/S-Video)
DisplayPort Fiber
DisplayPort Fiber w/USB Analog Fiber w/USB
DisplayPort Copper
DisplayPort Copper w/
USB
2 of 40
Analog Fiber
Analog Copper
Analog Copper with
USB
