ZyPer4K

Decoder

The function of the ZyPer4K Decoder is to accept a 10G IP feed containing the video
information to be displayed. It decrypts, decodes and formats the video and audio information
for display on the attached viewing device. There are several different variations based on the
user's desired media type and USB options.

Enclosure variants

There is one size of the ZyPer4K Decoder unit enclosure.
Input Function
HDMI Output

Common Ports

B
Port Name Index
Power A
Utility B
Network
User Manual
Box Size
Base unit: 175mm Wide x 43mm High x 144mm Deep
The following ports are common to all decoders,
regardless of the interface options.
A
Definition
12VDC from supply at 1.2A (center +, ring-)
10/100/1000Base-T Ethernet port. Used for general purpose
device attachment to network. Traffic will be switched on to
media network.
Page 11 of 40
