Physical and Environmental

The following parameters apply to all encoders and decoders unless specifically stated
otherwise.
Type
A/C Adapter
ZyPer4K unit power
consumption
Dimensions (LxWxH)
maximum envelope
Weight
Operating Temperature 0° C to +40° C (32° F to 104° F)
Non-Operating Temp
Humidity (op/storage)
Coating
User Manual
Parameter
100-1240VAC 50-60Hz 0.7-0.45A draw on AC Mains
Output Max: 12VDC 2.5A
12VDC at 1.2A max 12W nominal (Encoder without extended media option)
12VDC at 1.6A max 16W nominal (Encoder with extended media option)
12VDC at 1.2A max 12W nominal (Decoder)
163mm x 175mm** x 43mm* (Decoder or Encoder with no extended input
option)
166mm x 228mm** x 43mm* (Encoder with extended input option)
*subtract 6mm from height if rubber feet are removed
** add 48mm to overall width if both mounting ears are installed
880g (Decoder, Encoder with no extended input option)
1070g (Encoder with extended input option)
-20° C to +80° C (-4° F to +176° F)
20% to 90% (Non-Condensing)
White, satin anti-microbial powder coat
