ZyPer4K
Encoder Extended Video Input Options
DisplayPort Input Option
The ZyPer4K Encoder may be purchased with the
"DisplayPort Input Option" pre-installed at the factory.
Type
DisplayPort Option
direction Input
resolutions Same complete set of resolutions as supported by the resident HDMI
User Manual
Parameter
Single DisplayPort receptacle support v1.3 of the DisplayPort standard.
module on the core Encoder unit.
DRM HDCP2.2 only (DPCP not supported)
Audio Up to 8-channels of LPCM audio can be received on the DisplayPort
interface.
