LIVE SETTINGS

Resolution Settings, Camera Mode settings and Camera Settings can be configured.
●Resolution Settings
Item
Resolution/
Frame rate
※The available frame rate varies depending on the selected resolution.
Image format
●Camera Mode
Item
Color mode
Setting Frame rate
value
USB3.0 USB2.0
VGA 30fps
XGA 30fps
720p 60fps
30fps
QVGA 30fps
1080p 60fps
30fps
3.0M 30fps
4K 30fps
13.0M 21fps
MJPG The image format of the MX-1 is MJPG.
Setting
value
Normal To display the image in color.
Gray To display the background in black and the light
color in gray.
The brightness or darkness of the image and the
Negative
color of the image will be reversed.
B&W To display the image in black and white.
※The image shows the initial settings.
（USB3.0）
30fps
30fps
The image quality increases in the
order as indicated by the arrow, while
30fps
the network load also increases. As
the network load increases, the
30fps
image distortion tends to occur,
preventing smooth video playback.
30fps
18fps
These settings are not available
when connecting with the USB2.0.
Description
12
