Version information

Subindex Designation
1 Hardware
2 Application Software
3 System Software
4 Network Software

Manufacturer information

Subindex Designation
1 Serial Number
2 Manufacture Date

Diagnostic information

Subindex Designation
1 Motor voltage act. [mV]
2 Motor voltage max. [mV]
3 Motor voltage min. [mV]
4 Logic voltage act. [mV]
5 Logic voltage max. [mV]
6 Logic voltage min. [mV]
7 Temperature act. [d°C]
8 Temperature max. [d°C]
9 Temperature min. [d°C]
50
Interroll MultiControl
Appendix

Acyclical data

The SDOs are divided into indexes and subindexes. During the configuration via EtherCAT
systems, index and subindex are separated by a colon (e.g. index 0x4700, subindex A becomes
0x4700:0A). For access via PROFINET and EtherNet/IP , index and subindex must be added
(e.g. index 0x4700, subindex A becomes 0x470A).
SDO index: 0x4000
Data type Access Comment
STRING R
STRING R
STRING R
STRING R
SDO index: 0x4100
Data type Access Comment
STRING R
STRING R
SDO index: 0x4200
Data type Access Comment
INT R
INT R
INT R
INT R
INT R
INT R
INT R
INT R
INT R
Effective motor supply voltage
Maximum motor supply voltage
Minimum motor supply voltage
Effective logic supply voltage
Maximum logic supply voltage
Minimum logic supply voltage
Effective temperature
Maximum temperature
Minimum temperature
