LEDs of connections

40
Interroll MultiControl
Troubleshooting
LED State
Sensor 1 On
Sensor 2
Sensor 3
Sensor 4
I/O 1 On
I/O 2
I/O 3
I/O 4
RD 1 On
RD 2
RD 3
RD 4
Link A On or
Link B flashing
(for EtherCat
bus type)
Meaning
Logical switching state of displayed sensor:
Positive logic configured and logical "1" (PNP 24 V, NPN 0 V) at
input
- or -
Negative logic configured and logical "0" at input
Logical switching state of displayed input/output:
Positive logic configured and logical "1" (PNP 24 V, NPN 0 V) at
input
- or -
Negative logic configured and logical "0" at input
Displayed RollerDrive receives nominal value
Displayed network connection is OK
Version 2.3 (01/2017) en-US
Translation of original instruction manual
