Interroll MultiControl
Initial startup and operation
LED indicators when using the magnetic sensor
When the magnetic sensor recognizes the magnet, the "Fault" LED is permanently lit. If the
setting via the magnetic sensor is activated, the LEDs "Ready" and "Com" are also flashing at
1 Hz.
LED State
Sensor 1 On
I/O 1 On
RD 1 On
RD 1 + On
Sensor 3
RD 1 + On
I/O 3
RD 1 + On
RD 3
RD 2 On
Sensor 2 On
I/O 2 On
I/O 2 + On
I/O 4
Sensor 3 Flashes 1 Hz Loading EtherCAT stack
I/O 3 Flashes 1 Hz Loading PROFINET stack
RD 3 Flashes 1 Hz Loading EtherNet/IP stack
Together with the following displays, the LEDs "Ready" and "Com" are flashing at 2 Hz, the
"Fault" LED is off.
LED State
RD 1 On
Sensor 3 Flashes 2 Hz
RD 1 On
I/O 3 Flashes 2 Hz
RD 1 On
RD 3 Flashes 2 Hz
I/O 2 On
I/O 4 Flashes 2 Hz
Meaning
Function 1: Cancel
Function 2: Set sensors
Function 3: Set bus type
Selection 1 for function 3: EtherCAT
Selection 2 for function 3: PROFINET
Selection 3 for function 3: EtherNet/IP
Function 4: Teach-In procedure
Function 5: Switch LED indicators on or off
Function 6: Reset MultiControl to factory settings
Confirmation for function 6: Reset MultiControl to factory settings
Meaning
"EtherCAT" selection active, magnetic sensor not (any longer)
actuated
"PROFINET" selection active, magnetic sensor not (any longer)
actuated
"EtherNet/IP" selection active, magnetic sensor not (any longer)
actuated
Confirmation for function 6: Reset selected, magnetic sensor not
(any longer) actuated
