Output

No. Category
1 Digital outputs
2 Digital outputs
3 Digital outputs
4 Digital outputs
5 Digital outputs
6 Digital outputs
7 Digital outputs
8 Digital outputs
9 Motor
10 Motor
11 Motor
12 Motor
13 Control inputs overwrite
14 Control inputs overwrite
15 Control inputs overwrite
16 Control inputs overwrite
17 Control inputs overwrite
18 Control inputs overwrite
19 Control inputs overwrite
20 Control inputs overwrite
21 Control inputs overwrite
22 Control outputs overwrite
23 Control outputs overwrite
24 Control outputs overwrite
25 Control outputs overwrite
26 Control outputs overwrite
27 Control outputs overwrite
28 Control outputs overwrite
29 Control outputs overwrite
30 Handshake Signals Overwrite 8
31 Handshake Signals Overwrite 8
32 Handshake Signals Overwrite 8
33 Handshake Signals Overwrite 8
34 Handshake Signals Overwrite 8
48
Interroll MultiControl
Appendix
Byte Bit Designation
0 .0 PLC Output1
0 .1 PLC Output2
0 .2 PLC Output3
0 .3 PLC Output4
0 .4 Reserve
0 .5 Reserve
0 .6 Reserve
0 .7 Reserve
1 Speed1
2 Speed2
3 Speed3
4 Speed4
5 .0 ControlInput1
5 .1 ControlInput2
5 .2 ControlInput3
5 .3 ControlInput4
5 .4 ControlInput5
5 .5 ControlInput6
5 .6 ControlInput7
5 .7 ControlInput8
6 DecisionInput
7 .0 ControlOutput1
7 .1 ControlOutput2
7 .2 ControlOutput3
7 .3 ControlOutput4
7 .4 ControlOutput5
7 .5 ControlOutput6
7 .6 ControlOutput7
7 .7 ControlOutput8
.0 In Up
.1 In Down
.2 In Left
.3 In Right
.4 Out Up
Type Comment
BOOL Logical state, voltage level depends on I/O
configuration (NPN/PNP type; polarity)
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
SINT Speed 0...100 (0 = stop, 100 = max. speed),
negative values indicate reversed direction of
SINT
rotation
SINT
SINT
BOOL See instructions for ZPA and ZPA+ applications
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BYTE
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
Translation of original instruction manual
Version 2.3 (01/2017) en-US
