OceanView is a user-customizable, advanced acquisition and display program that provides a real-time
interface to a variety of signal-processing functions. With OceanView, you have the ability to perform
spectroscopic measurements (such as absorbance, reflectance, and emission), control all system
parameters, collect and display data in real time, and perform reference monitoring and time acquisition
experiments. Consult the OceanView manual for hardware requirements when using OceanView (see
Product-Related Documentation).

Sampling System Overview

How Sampling Works

Ocean Optics components function in a sampling system as follows:
1. The user stores reference and dark measurements to correct for instrument response variables.
2. The light from the light source transmits through an optical fiber to the sample.
3. The light interacts with the sample.
4. Another optical fiber collects and transmits the result of the interaction to the spectrometer.
5. The spectrometer measures the amount of light and transforms the data collected by the
spectrometer into digital information.
6. The spectrometer passes the sample information to the spectrometer operating software.
7. The software compares the sample to the reference measurement and displays processed spectral
information.

Interface Options

The USB2000+ has both USB and serial port connectors (with the use of an adapter), enabling you to
connect the spectrometer to a computer via a USB or serial port. However, you must create custom
software if using the serial port. OceanView software is available if you are connecting via the USB port.

Shipment Components

The following information and documentation ships with the USB2000+ Spectrometer:
 Packing List
The packing list is inside a plastic bag attached to the outside of the shipment box (the invoice
arrives separately). It lists all items in the order, including customized components in the
spectrometer (such as the grating, detector collection lens, and slit). The packing list also includes
the shipping and billing addresses, as well as any items on back order.
USB Cable (USB-CBL-1)

Use this cable to connect your spectrometer to a computer running on a Windows, Mac or Linux
operating system.
