1: Introduction

Features

Sony ILX511 2048-element linear silicon CCD array detector

Responsive from 200 to 1100 nm

 Sensitivity of up to 75 photons/count at 400 nm; 41 photons/count at 600 nm
 An optical resolution of 0.1 nm (FWHM)
Integration times from 1 ms to >60 seconds

 EEPROM storage for

Wavelength Calibration Coefficients

Linearity Correction Coefficients

Absolute Irradiance Calibration (optional)
Low power consumption of only 250 mA @ 5 VDC

16 bit, 3MHz A/D Converter

 4 triggering modes
22-pin connector for interfacing to external products

CE Certification

 RoHS compliant

System Requirements

You can use the USB2000+'s USB connectivity with any computer that meets the following
requirements:
 Microsoft Windows – Windows 2000/XP/7; 32-bit and 64-bit and Windows Vista (32-bit only)
 Apple Macintosh – OS X version 10.0 or later
 Linux – Any version released for an x86 or amd64 platform since 2010

EEPROM Utilization

An EEPROM memory chip in each USB2000+ contains wavelength calibration coefficients, linearity
coefficients, and a serial number unique to each individual spectrometer. The spectrometer operating
software application reads these values directly from the spectrometer, enabling the ability to "hot-swap"
spectrometers between computers without entering the spectrometer coefficients manually on each
computer.

About OceanView Software

OceanView is the latest generation of operating software for all Ocean Optics spectrometers. It is a
completely modular, Java-based spectroscopy software platform that operates on Windows, Macintosh
and Linux operating systems. The software can control any Ocean Optics USB spectrometer and device.
2 270-00000-000-02-201603
