USB4000 Fiber Optic Spectrometer
Installation and Operation Manual
Document Number 211-00000-000-02-0908
Offices:
Ocean Optics, Inc. World Headquarters
830 Douglas Ave., Dunedin, FL, USA 34698
Phone
727.733.2447
Fax
727.733.3962
8 a.m.– 8 p.m. (Mon-Thu), 8 a.m.– 6 p.m. (Fri) EST
E-mail:
Info@OceanOptics.com
Orders@OceanOptics.com
TechSupport@OceanOptics.com (Technical support)
(General sales inquiries)
(Questions about orders)

Advertisement

Table of Contents
loading

Related Manuals for Ocean Optics USB4000

Summary of Contents for Ocean Optics USB4000

  • Page 1 USB4000 Fiber Optic Spectrometer Installation and Operation Manual Document Number 211-00000-000-02-0908 Offices: Ocean Optics, Inc. World Headquarters 830 Douglas Ave., Dunedin, FL, USA 34698 Phone 727.733.2447 727.733.3962 8 a.m.– 8 p.m. (Mon-Thu), 8 a.m.– 6 p.m. (Fri) EST E-mail: Info@OceanOptics.com (General sales inquiries) Orders@OceanOptics.com...
  • Page 2 Every effort has been made to make this manual as complete and as accurate as possible, but no warranty or fitness is implied. The information provided is on an “as is” basis. Ocean Optics, Inc. shall have neither liability nor responsibility to any person or entity with respect to any loss or...

  • Page 3: Table Of Contents

    Interface Options ......................4 Breakout Box ..........................4 Shipment Components ....................4 Additional Equipment Needed ..................5 Other Accessories Available ................... 5 Chapter 2: Installing the USB4000 .............7 Overview ......................... 7 USB4000 Installation....................... 7 USB Mode ..........................7 Serial Port Mode........................8 Connect Spectroscopic Accessories ................
  • Page 4 Table of Contents Chapter 3: Troubleshooting ...............9 Overview ......................... 9 USB4000 Connected to Computer Prior to SpectraSuite Installation......9 Windows Operating Systems ....................9 Remove the Unknown Device from Windows Device Manager ........... 9 Remove Improperly Installed Files..................10 Mac Operating Systems ......................10 Linux Operating Systems ......................

  • Page 5: About This Manual

    About This Manual Document Purpose and Intended Audience This document provides the users of USB4000 Spectrometers with instructions for setting up, calibrating and performing experiments with their spectrometer. What’s New in This Document This version of the USB4000 Fiber Optic Spectrometer Installation and Operation Manual adds the USB-ADP-BB adapter for the Breakout Box.

  • Page 6: Upgrades

    Resources CD that ships with the product. Upgrades Occasionally, you may find that you need Ocean Optics to make a change or an upgrade to your system. To facilitate these changes, you must first contact Customer Support and obtain a Return Merchandise Authorization (RMA) number.

  • Page 7: Chapter 1: Introduction

    New features consist of the 3648-element detector with shutter, high-speed electronics, and interface capabilities to Linux, Macintosh and Windows operating systems. The USB4000 is responsive from 200-1100 nm, but the specific range and resolution depends on your grating and entrance slit selections.

  • Page 8: Features

    22-pin connector for interfacing to external products Programmable for Standalone Operation CE Certification System Requirements You can use the USB4000’s USB connectivity with any computer that meets the following requirements: • Operating system is one of the following: Windows – 98/Me/2000/XP •...

  • Page 9: Eeprom Utilization

    Modular Light Sources and Sampling Accessories Ocean Optics offers a complete line of spectroscopic accessories for use with the USB4000. Most of our spectroscopic accessories have SMA connectors for application flexibility. Accordingly, changing the sampling system components is as easy as unscrewing a connector and replacing an accessory. Available accessories include the following: •...

  • Page 10: Interface Options

    Interface Options The USB4000 has both USB and serial port connectors (with the use of an adapter), enabling you to connect the spectrometer to a computer via a USB or serial port. However, you must create custom software if using the serial port. SpectraSuite software is available if you are connecting via the USB port.

  • Page 11: Additional Equipment Needed

    1: Introduction Software and Technical Resources CD Each order ships with the Ocean Optics Software and Resources CD. This disc contains software, operating instructions, and product information for all Ocean Optics software, spectrometers, and spectroscopic accessories. You need Adobe Acrobat Reader version 6.0 or higher to view these files.
  • Page 12 1: Introduction 211-00000-000-02-0908...

  • Page 13: Chapter 2: Installing The Usb4000

    4. Insert the rectangular end of the cable into the USB port of the computer. If you installed SpectraSuite prior to connecting the USB4000, the SpectrSuite installs the USB4000 drivers. If the drivers do not successfully install (or if you connected the USB4000 to the computer before installing SpectraSuite), consult Chapter 3: Troubleshooting.

  • Page 14: Serial Port Mode

    1. Connect the serial cable adapter block to the appropriate pins of the USB4000’s 22-Pin Accessory Connector. 2. Connect one end of the 9-pin serial cable to the adapter block on the USB4000, and then connect the other end to a serial port on the computer.

  • Page 15: Chapter 3: Troubleshooting

    SpectraSuite Installation Windows Operating Systems If you connected your Ocean Optics USB4000 device to the computer prior to installing your Ocean Optics software application on a Windows platform, you may encounter installation issues that you must correct before your Ocean Optics device will operate properly.

  • Page 16: Remove Improperly Installed Files

    The system is now able to locate and install the correct drivers for the USB device. Mac Operating Systems Since there are no device files for the USB4000 Spectrometer in a Mac operating system, you should not encounter any problems if you installed the spectrometer before the SpectraSuite software.

  • Page 17: Linux Operating Systems

    3: Troubleshooting Linux Operating Systems For Linux operating systems, all you need to do is install the SpectraSuite software, then unplug and replug in the spectrometer. Technically, the driver files for Linux simply give nonprivileged users permission to use newly connected hardware. There isn’t any long-term harm to plugging in the device before installing the software.
  • Page 18 3: Troubleshooting 211-00000-000-02-0908...

  • Page 19: Appendix A: Calibrating The Wavelength Of The Usb4000

    This appendix describes how to calibrate the wavelength of your spectrometer. Though each spectrometer is calibrated before it leaves Ocean Optics, the wavelength for all spectrometers will drift slightly as a function of time and environmental conditions. Ocean Optics recommends periodically recalibrating the USB4000.

  • Page 20: Calibrating The Spectrometer

    A light source capable of producing spectral lines Note Ocean Optics’ HG-1 Mercury-Argon lamp is ideal for recalibration. If you do not have an HG-1, you need a light source that produces several (at least 4-6) spectral lines in the wavelength region of your spectrometer.
  • Page 21 A: Calibrating the Wavelength of the USB4000 Independent Values Computed Dependent from the Regression Variable Variables Output Predicted True Wavelength (nm) Pixel # Pixel # Pixel # Difference Wavelength 253.65 30625 5359375 253.56 0.09 296.73 87616 25934336 296.72 0.01 302.15...

  • Page 22: Saving The New Calibration Coefficients: Usb Mode

    Mode Ocean Optics programs wavelength calibration coefficients unique to each USB4000 onto an EEPROM memory chip in the USB4000. You can overwrite old calibration coefficients on the EEPROM if you are using the USB4000 via the USB port. Procedure ►...

  • Page 23: Appendix B: External Triggering

    In this mode, the ExtTrigIn signal acts as an enable switch. If ExtTrigIn is kept HIGH, the USB4000 will acquire spectra as if it was in the normal free running mode. If ExtTrigIn is kept LOW, the USB4000 will not acquire spectra.

  • Page 24: External Hardware Trigger Delay

    HIGH. External Synchronization Trigger In this mode of the USB4000, the integration clock is essentially input into the spectrometer. The synchronized trigger must have a frequency range of 5ms to 60s (shutter mode cannot be used in External Synchronization Trigger mode). If no External Trigger Input Signal is applied, the spectrometer will not take any spectra, and the software will appear “frozen”...
  • Page 25 B: External Triggering External Synchronization Trigger The time between when ExtTrigIn goes HIGH and the beginning of the integration period is specified to be between 8µs<t <10µs. The ExtTrigIn signal does not need to have an even duty cycle, but the time SU_ST between rising edges should remain constant for a given integration time.
  • Page 26 B: External Triggering 211-00000-000-02-0908...

  • Page 27: Appendix C: Specifications

    How the USB4000 Works Below is a diagram of how light moves through the optical bench of an USB4000 Spectrometer. The optical bench has no moving parts that can wear or break; all the components are fixed in place at the time of manufacture.

  • Page 28: Usb4000 Components Table

    C: Specifications USB4000 Components Table Ocean Optics permanently secures all components in the USB4000 at the time of manufacture. Only Ocean Optics technicians can replace interchangeable components, where noted. Item Name Description SMA 905 Secures the input fiber to the spectrometer. Light from the input fiber enters the Connector optical bench through this connector.

  • Page 29: Usb4000 Specifications

    The detector’s standard window is replaced with a quartz window to enhance Detector spectrometer performance (<340 nm). This upgrade is optional. Upgrade USB4000 Specifications The following sections provide specification information for the CCD detector in the USB4000, as well as the USB4000 Spectrometer itself. CCD Detector Specifications Specification Value...
  • Page 30 C: Specifications Specification Value Detector 3648-element linear silicon CCD array Detector range 200-1100 nm Gratings 14 gratings available Entrance aperture 5, 10, 25, 50, 100 or 200 µm wide slits Order-sorting filters Installed longpass and bandpass filters Focal length 42 mm input; 68 mm output Optical resolution Depends on grating and size of entrance aperture Stray light...

  • Page 31: 22-Pin Accessory Connector Pinout

    22-Pin Connector Location of USB4000 22-Pin Accessory Connector 22-Pin Accessory Connector Pinout Diagram When facing the 22-pin Accessory Connector on the front of the vertical wall of the USB4000, pin numbering is as follows: 22-Pin Accessory Connector Pinout Diagram 211-00000-000-02-0908...

  • Page 32: 22-Pin Accessory Connector - Pin Definitions And Descriptions

    C: Specifications 22-Pin Accessory Connector – Pin Definitions and Descriptions The following table contains information regarding the function of each pin in the USB4000’s 22-Pin Accessory Connector: Function Input/Output Description Input power pin for USB4000 – When operating via USB, this pin Input or can power other peripherals –...

  • Page 33: 22-Pin Accessory Connector - Part Numbers

    * NOTE: GPIO nP and nN are for future LVDS capability 22-Pin Accessory Connector - Part Numbers The part numbers for the 22-pin accessory connector on the USB4000 Spectrometer are as follows: • The connector is a Samtec Part Number IPT1-111-01-S-D-RA.
  • Page 34 C: Specifications 211-00000-000-02-0908...

  • Page 35: Index

    Index Numbers accessory connector EEPROM, 3 diagram, 25 external triggering, 8, 17 part numbers, 27 pin definitions, 26 filter, 22 focusing mirror, 22 accessories, 5, 8 Accessories, 3 accessory connector pinout, 25 grating, 22 Adobe Acrobat Reader, 5 Installation, 7 breakout box, 4 Serial Port mode, 8 USB mode, 7...
  • Page 36 22 specifications, 23 SMA Connector, 22 Software and Resources Library CD, 5 specifications, 21 detector, 23 Wavelength Calibration USB4000, 23 about, 13 SpectraSuite, 3 Wavelength Calibration Data File, 4 spectroscopic accessories, 8 Wavelength Calibration Data Sheet, 4 System Requirements, 2...
