Halogen Light Source with Attenuator
and TTL-Shutter
HL-2000-FHSA / HL-2000-FHSA-LL / HL-2000-FHSA-HP
A
Installation and Operation Manual
Document Number 000-10000-070-02-0505
Offices:
Ocean Optics, Inc.
830 Douglas Ave., Dunedin, FL, USA 34698
Phone 727.733.2447
Fax
727.733.3962
8 a.m.– 8 p.m. (Mon-Thu), 8 a.m.– 6 p.m. (Fri) EST
Ocean Optics B.V. (Europe)
Geograaf 24, 6921 EW DUIVEN, The Netherlands
Phone 31-(0)26-3190500
F ax
31-(0)26-3190505
E-mail:
Info@OceanOptics.com
Info@OceanOpticsBV.com
Orders@OceanOptics.com
TechSupport@OceanOptics.com (Technical support)
Product
(General sales inquiries)
(European sales inquiries)
(Questions about orders)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ocean Optics HL-2000-FHSA
Summary of Contents for Ocean Optics HL-2000-FHSA
- Page 1 Halogen Light Source with Attenuator and TTL-Shutter HL-2000-FHSA / HL-2000-FHSA-LL / HL-2000-FHSA-HP Product Installation and Operation Manual Document Number 000-10000-070-02-0505 Offices: Ocean Optics, Inc. 830 Douglas Ave., Dunedin, FL, USA 34698 Phone 727.733.2447 727.733.3962 8 a.m.– 8 p.m. (Mon-Thu), 8 a.m.– 6 p.m. (Fri) EST Ocean Optics B.V.
- Page 2 Every effort has been made to make this manual as complete and as accurate as possible, but no warranty or fitness is implied. The information provided is on an “as is” basis. Ocean Optics, Inc. shall have neither liability nor responsibility to any person or entity with respect to any loss or...
- Page 3 Important Safety Notices 1. Do not remove or modify any installed safety device on this equipment. Doing so will void your warranty and create an unsafe operating environment. 2. Dangerous voltages are present in this device. There are NO user serviceable parts inside. 3.
- Page 4 Important Safety Notices 000-10000-070-02-0505...
-
Page 5: Table Of Contents
Chapter 1: Setup..................1 Overview.......................... 1 Unpacking the HL-2000-FHSA ..................1 Contents .......................... 2 Setting Up the HL-2000-FHSA Light Source ..............2 Enabling Automatic Shutter Control ................3 Optimizing the Optical Power Output ................4 Attenuating the Optical Power Output ................5 HL-2000-FSHA Diagrams.................... - Page 6 Table of Contents 000-10000-070-02-0505...
-
Page 7: About This Manual
This document provides you with an installation section to get your system up and running. What’s New in this Document This version of the Halogen Light Source with Attenuator and TTL-Shutter HL-2000-FHSA / HL-2000- FHSA-LL / HL-2000-FHSA-HP Installation and Operation Manual adds our partnership agreement. -
Page 8: Upgrades
About This Manual Upgrades Occasionally, you may find that you need Ocean Optics to make a change or an upgrade to your system. To facilitate these changes, you must first contact Customer Support and obtain a Return Merchandise Authorization (RMA) number. Please contact Ocean Optics for specific instructions when returning a product. -
Page 9: Chapter 1: Setup
The following sections provide instructions on unpacking and setting up your HL-2000-FHSA Light Source. Before using the HL-2000-FHSA for the first time check for transport damage. Be sure to adhere to all warnings on the unit and in this manual. -
Page 10: Contents
► Procedure Perform the steps below to set up your HL-2000-FHSA Light Source: 1. Plug the power supply into a wall outlet. Power Supply 2. Plug the other end of the power supply cable into the socket of HL-2000-FHSA. 000-10000-070-02-0505... -
Page 11: Enabling Automatic Shutter Control
4. Turn the Halogen lamp on using the power switch on the rear of the HL-2000-FHSA. HL-2000-FHSA Rear View Enabling Automatic Shutter Control The HL-2000-FHSA is equipped with a 15-pin TTL port on the rear of the unit that allows an external source to control the shutter of the HL-2000-FHSA. 000-10000-070-02-0505... -
Page 12: Optimizing The Optical Power Output
Optimizing the Optical Power Output The HL-2000-FHSA is adjusted at the factory to provide maximum power into a 200µm fiber. If a lower optical power is required or a different fiber (bundle) diameter is used, you can adjust the optical power of HL-2000-FSHA Diagrams the unit. -
Page 13: Attenuating The Optical Power Output
3. Shift the SMA socket to optimize the optical power of the HL-2000-FHSA. 4. Tighten the blocking screw to secure the SMA socket position. Attenuating the Optical Power Output The HL-2000-FHSA allows you to attenuate the optical output of the unit by adjusting the attenuation screw. ►... -
Page 14: Hl-2000-Fsha Diagrams
1: Setup HL-2000-FSHA Diagrams Power Connector Power Supply Figure 1: HL-2000-FHSA Power Supply 000-10000-070-02-0505... - Page 15 1: Setup Attenuation Screw Rear Screw Power Switch 15-Pin TTL Connector Power Socket Rear Screw Rear Screw Shutter Mode Switch Figure 2: HL-2000-FHSA Rear View Filter Holder Fixture Screw SMA Connector Figure 3: HL-2000-FHSA Side View 000-10000-070-02-0505...
- Page 16 1: Setup Cooling Fan Bottom Blocking Screw Plate Screw SMA Connector Figure 4: HL-2000-FHSA Bottom View 000-10000-070-02-0505...
-
Page 17: Chapter 2: Hl-2000-Fhsa Specifications
Chapter 2 HL-2000-FHSA Specifications This section provides information on the operating environment, physical controls, and dimensions of the HL-2000-FHSA, as well as pinouts for the DB-15 connector. It also provides a parts list. Specifications HL-2000-FHSA HL-2000-FHSA-LL HL-2000-FHSA-HP Wavelength range 360 nm – 1700 nm Stability 0.5 %... -
Page 18: Pinout Information
2: HL-2000 Specifications Pinout Information The following table contains pinout information for the HL-2000-FHSA Light Source: Description Ground TTL Signal – Shutter control na = not applicable 000-10000-070-02-0505... -
Page 19: Pinout Diagram
Pinout Diagram Parts List Spare Parts / Order Information Catalog Number Halogen light source with filter holder/shutter and attenuator HL-2000-FHSA Halogen light source, fan cooled, long life HL-2000-FHSA-LL Halogen light source High-Power with Attenuator and TTL-Shutter HL-2000-FHSA-HP Halogen spare bulb 2.960K/ 1.500 hrs HL-2000-B Halogen spare bulb 2.800K / 10.000 hrs... - Page 20 2: HL-2000 Specifications 000-10000-070-02-0505...
-
Page 21: Appendix A: Bulb Replacement
Replacing the Bulb ► Procedure Refer to Figure 5 and perform the steps below to replace the bulb in the HL-2000-FHSA Light Source: 1. Unplug the power connector from the power socket on the HL-2000-FHSA. 2. Loosen the screws on the rear of the unit with the provided 2.5mm Allen wrench. - Page 22 A: Bulb Replacement 9. Slide the electronics board back into the HL-2000-FHSA, taking particular care to ensure that the wires do not come into contact with the fan blades. Connection Block Rear / Electronics Board Lamp Housing Fan Wires Figure 5: HL-2000-FHSA Bulb Replacement Diagram...
-
Page 23: Index
Index bulb package contents, 2 replacement, 13 parts list, 11 bulb replacement pinout diagram, 14 diagram, 11 pinouts, 10 product-related documentation, iii diagrams, 6 bottom view, 8 setup, 1 bulb replacement, 14 shutter control, 3 pinout, 11 specifications, 9 power supply, 6 rear view, 7 side view, 7 document... - Page 24 Index 000-10000-070-02-0505...
