Halogen Light Source HL-2000 / HL-2000-LL / HL-2000-HP Product Installation and Operation Manual Document Number 000-10000-050-02-0505 Ocean Optics, Inc. Offices: 830 Douglas Ave., Dunedin, FL, USA 34698 Phone 727.733.2447 727.733.3962 8 a.m.– 8 p.m. (Mon-Thu), 8 a.m.– 6 p.m. (Fri) EST Ocean Optics B.V.
Page 2
Every effort has been made to make this manual as complete and as accurate as possible, but no warranty or fitness is implied. The information provided is on an “as is” basis. Ocean Optics, Inc. shall have neither liability nor responsibility to any person or entity with respect to any loss or...
Page 3
Important Safety Notices 1. Do not remove or modify any installed safety device on this equipment. Doing so will void your warranty and create an unsafe operating environment. 2. Dangerous voltages are present in this device. There are NO user serviceable parts inside. 3.
Page 4
Important Safety Notices 000-10000-050-02-0505...
Engineering-level documentation is located on our website at Technical → Engineering Docs. Upgrades Occasionally, you may find that you need Ocean Optics to make a change or an upgrade to your system. To facilitate these changes, you must first contact Customer Support and obtain a Return Merchandise...
Page 8
About This Manual Authorization (RMA) number. Please contact Ocean Optics for specific instructions when returning a product. 000-10000-050-02-0505...
Perform the steps below to set up your HL-2000 Light Source: 1. Plug the power supply into a wall outlet. Note The HL-2000-HP Series of light sources requires a 24 VDC power supply. Do not use the standard 12 VDC power supply. 000-10000-050-02-0505...
Optimizing the Optical Power Output The HL-2000 is adjusted at the factory to provide maximum power into a 200µm fiber. If a lower optical power is required or a different fiber (bundle) diameter is used, you can adjust the optical power of the HL-2000 Diagrams unit.
Page 11
1: Setup Rear Screw Power Socket Rear Screw Rear Screw Figure 2: HL-2000 Rear View Filter Holder (select models) SMA Connector Power Switch Figure 3: HL-2000 Side View 000-10000-050-02-0505...
Chapter 2 HL-2000 Specifications This section provides information on the operating environment, physical controls, and dimensions of the HL-2000. It also provides a parts list. Specifications HL-2000 HL-2000-LL HL-2000-HP Wavelength range 360 nm – 1700 nm Stability 0.5 % Drift <0.1% pro Hour...
2. Loosen the screws on the rear of the unit with the provided 2.5mm Allen wrench. 3. Remove the backside of the HL-2000 and remove the electronics board from the HL-2000, taking particular care not to disconnect the fan wires.
► Procedure Refer to Figure 5 and perform the steps below to replace the bulb in the HL-2000 Light Source: 1. Unplug the power connector from the power socket on the HL-2000. 2. Loosen the screws on the rear of the unit with the provided 2.5mm Allen wrench.
