High-Power Xenon Light Source
HPX-2000
A
Installation and Operation Manual
Document Number 000-10000-080-02-0505
Ocean Optics, Inc.
Offices:
830 Douglas Ave., Dunedin, FL, USA 34698
Phone 727.733.2447
Fax
727.733.3962
8 a.m.– 8 p.m. (Mon-Thu), 8 a.m.– 6 p.m. (Fri) EST
Ocean Optics B.V. (Europe)
Geograaf 24, 6921 EW DUIVEN, The Netherlands
Phone 31-(0)26-3190500
F ax
31-(0)26-3190505
E-mail:
Info@OceanOptics.com
Info@OceanOpticsBV.com
Orders@OceanOptics.com
TechSupport@OceanOptics.com (Technical support)
WARNING
Product
(General sales inquiries)
(European sales inquiries)
(Questions about orders)
Protective Eye Wear Must Be Worn
When Using This Instrument -
Intense Ultraviolet Radiation Present
See Important Safety Notices inside.
Advertisement
Table of Contents
Related Manuals for Ocean Optics HPX-2000
Summary of Contents for Ocean Optics HPX-2000
- Page 1 Ocean Optics, Inc. Offices: 830 Douglas Ave., Dunedin, FL, USA 34698 Phone 727.733.2447 727.733.3962 8 a.m.– 8 p.m. (Mon-Thu), 8 a.m.– 6 p.m. (Fri) EST Ocean Optics B.V. (Europe) Geograaf 24, 6921 EW DUIVEN, The Netherlands Phone 31-(0)26-3190500 F ax 31-(0)26-3190505 E-mail: Info@OceanOptics.com...
- Page 2 Every effort has been made to make this manual as complete and as accurate as possible, but no warranty or fitness is implied. The information provided is on an “as is” basis. Ocean Optics, Inc. shall have neither liability nor responsibility to any person or entity with respect to any loss or...
- Page 3 Mikropack GmbH warrants to the original user of this instrument that it shall be free of any defects resulting from faulty manufacture of this instrument for a period of 12 months from the original data of shipment. There are no warranties for the Xenon Bulb (HPX-2000-B) and the Xenon-Bulb-Module (HPX-2000-BM).
- Page 4 Important Safety Notices 000-10000-080-02-0505...
-
Page 5: Table Of Contents
Document Summary ........................iii Product-Related Documentation....................iii Upgrades ......................... iv Chapter 1: Setup .................1 Overview.......................... 1 Unpacking the HPX-2000 ....................2 Contents .......................... 2 Connecting the Fiber Optic Cable ................... 2 Chapter 2: HPX-2000 Specifications ..........3 Operating Environment....................3 HPX-2000 Components....................3 Front Panel .......................... - Page 6 Table of Contents Chapter 3: Operating Instructions .............9 Operating the Xenon Lamp ..................... 9 Starting Main Power ........................9 Starting the Lamp ........................9 Turning the Lamp Off......................... 10 Warming Up the Lamp....................... 10 Operating the TTL Shutter....................10 Automatic Operation ........................10 Manual Operation ........................
-
Page 7: About This Manual
Or, use the Search by Model Number field at the bottom of the web page. You can also access operating instructions for Ocean Optics products on the Software and Technical Resources CD included with the system. -
Page 8: Upgrades
About This Manual Upgrades Occasionally, you may find that you need Ocean Optics to make a change or an upgrade to your system. To facilitate these changes, you must first contact Customer Support and obtain a Return Merchandise Authorization (RMA) number. Please contact Ocean Optics for specific instructions when returning a product. -
Page 9: Chapter 1: Setup
The following sections provide instructions on unpacking and setting up your HPX-2000 High-power Xenon Light Source. Before using the HPX-2000 for the first time check for transport damage. Be sure to adhere to all warnings on the unit and in this manual. -
Page 10: Unpacking The Hpx-2000
To connect the fiber optic cable to the HPX-2000, 1. Locate the cap on the front of the HPX-2000. 2. Lift the cap on the front of the HPX-2000 to expose the SMA connector. 3. Connect the fiber optic cable to the SMA connector. -
Page 11: Chapter 2: Hpx-2000 Specifications
Should be positioned so that objects do not fall on top of the unit. Additionally, ensure that no liquids are spilled into the enclosure through openings. HPX-2000 Components The following sections describe the components located on the front and rear of the HPX-2000 unit. 000-10000-080-02-0505... -
Page 12: Front Panel
TTL - operation by external TTL- signal (HIGH=OPEN, LOW=CLOSE) Covered to protect users from unintentionally looking directly at the beam of light. Used for SMA connections only. Connect the fiber cable to the HPX-2000 BEFORE turning Mechanical Protection – the lamp on to avoid unnecessary exposure to UV radiation. Avoid direct contact with SMA Connector the fiber end. -
Page 13: Rear Panel
Select regional voltage setting for lamp (AC 230-240V, 50/60Hz or AC 110-115V, Voltage Selector Switch 50/60Hz). Turn on to supply power to the HPX-2000. The Power LED lights when this switch Main Power Switch is in the On position. Contains the fuse to protect the unit against overload:... -
Page 14: Specifications
Replacement Lightsource Module complete with bulb housing optics and shutter, HPX-2000-BM for plug and play replacement on customer side Trade in of used HPX-2000-BM for Xenon bulb exchange at the supplier side HPX-2000-B Modification of device specifications and designs to improve performance may occur without notice. -
Page 15: Pinout Information
2: HPX-2000 Specifications Pinout Information The following table contains pinout information for the HPX-2000 Light Source: Description Ground TTL Signal – Shutter control na = not applicable Pinout Diagram 000-10000-080-02-0505... - Page 16 2: HPX-2000 Specifications 000-10000-080-02-0505...
-
Page 17: Chapter 3: Operating Instructions
Chapter 3 Operating Instructions Operating the Xenon Lamp The following sections provide instructions on operating the Xenon lamp in the HPX-2000 Light Source. The HPX-2000 unit must be in a horizontal position for it to work. Starting Main Power ►... -
Page 18: Turning The Lamp Off
LED blinks for about 30 seconds while the lamp cools down. Warming Up the Lamp The HPX-2000 requires 25-30 minutes of operation to reach a state of thermal equilibrium. During this warm-up period, the intensity of the output power can vary substantially. -
Page 19: Chapter 4: Troubleshooting
Chapter 4 Troubleshooting If the power supply or lamp does not seem to functioning properly, check the following: Issue Probable Cause Resolution Line power not present Check line voltage Power switches on, but no LEDs light. Fuse defective Check fuse Lifetime of the lamp is Replace the lamp module exhausted... - Page 20 4: Troubleshooting 000-10000-080-02-0505...
-
Page 21: Appendix A: Bulb Replacement
Appendix A Bulb Replacement To order replacement bulbs for the HPX-2000, order item number HPX-2000-BM. Replacing the Bulb WARNING During operation, the lamp reaches a temperature of approximately 250°C. Before changing the lamp’s bulb, please wait at least 20 minutes for cooling before touching the lamp module. - Page 22 A: Bulb Replacement 5. Remove the cap (Figure 2, #3) and the beam cover (Figure 2, #4) from the HPX-2000. 6. Remove the four recessed screws (Figure 1, #1), both front and back on both sides of the HPX-2000. 7. Remove the cover housing of the HPX-2000.
-
Page 23: Index
Index bulb replacement, 13 setup, 1 specifications, 3, 6 cable connection fiber optic, 2 troubleshooting table, 11 components, 3 TTL shutter, 10 front panel, 4 automatic operation, 10 rear panel, 5 manual operation, 10 connecting the fiber optic cable, 2 unpacking procedure, 2 document upgrades, iv... - Page 24 Index 000-10000-080-02-0505...
