1.
USB2000+ Fiber Optic Spectrometer
Installation and Operation Manual
Document Number 270-00000-000-02-0108
Offices:
E-mail:
Ocean Optics, Inc. World Headquarters
830 Douglas Ave., Dunedin, FL, USA 34698
Phone
727.733.2447
Fax
727.733.3962
8 a.m.– 8 p.m. (Mon-Thu), 8 a.m.– 6 p.m. (Fri) EST
Info@OceanOptics.com
Orders@OceanOptics.com
TechSupport@OceanOptics.com (Technical support)
(General sales inquiries)
(Questions about orders)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USB2000 Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ocean Optics USB2000 Plus

Summary of Contents for Ocean Optics USB2000 Plus

  • Page 1 USB2000+ Fiber Optic Spectrometer Installation and Operation Manual Document Number 270-00000-000-02-0108 Offices: Ocean Optics, Inc. World Headquarters 830 Douglas Ave., Dunedin, FL, USA 34698 Phone 727.733.2447 727.733.3962 8 a.m.– 8 p.m. (Mon-Thu), 8 a.m.– 6 p.m. (Fri) EST E-mail: Info@OceanOptics.com (General sales inquiries) Orders@OceanOptics.com...
  • Page 2 Every effort has been made to make this manual as complete and as accurate as possible, but no warranty or fitness is implied. The information provided is on an “as is” basis. Ocean Optics, Inc. shall have neither liability nor responsibility to any person or entity with respect to any loss or...

  • Page 3: Table Of Contents

    Table of Contents About This Manual ......................iii Document Purpose and Intended Audience................iii Document Summary........................iii Product-Related Documentation ....................iii Upgrades ......................... iv Service ..........................iv Chapter 1: Introduction ..............1 Product Overview ......................1 Features .......................... 2 System Requirements ..................... 2 EEPROM Utilization ........................
  • Page 4 Table of Contents Chapter 3: Troubleshooting ...............9 Overview ......................... 9 USB2000+ Connected to Computer Prior to SpectraSuite Installation ......9 Windows Operating Systems ....................9 Remove the Unknown Device from Windows Device Manager ........... 9 Remove Improperly Installed Files..................10 Mac Operating Systems ......................

  • Page 5: About This Manual

    USB2000+ Spectrometer. Product-Related Documentation You can access documentation for Ocean Optics products by visiting our website at http://www.oceanoptics.com. Select Technical → Operating Instructions, then choose the appropriate document from the available drop-down lists. Or, use the Search by Model Number field at the bottom of the web page.

  • Page 6: Upgrades

    Resources CD that ships with the product. Upgrades Occasionally, you may find that you need Ocean Optics to make a change or an upgrade to your system. To facilitate these changes, you must first contact Customer Support and obtain a Return Merchandise Authorization (RMA) number.

  • Page 7: Chapter 1: Introduction

    The USB2000+, like all USB devices, can be controlled by our SpectraSuite software, a completely modular, Java-based spectroscopy software platform that operates on Windows, Macintosh and Linux operating systems. Ocean Optics USB2000+ Fiber Optic Spectrometer Typical Set-up 270-00000-000-02-0108...

  • Page 8: Features

    About SpectraSuite SpectraSuite is the latest generation of operating software for all Ocean Optics spectrometers. It is a completely modular, Java-based spectroscopy software platform that operates on Windows, Macintosh and Linux operating systems. The software can control any Ocean Optics USB spectrometer and device, as well as any other manufacturer’s USB instrumentation using the appropriate drivers.

  • Page 9: Sampling System Overview

    Sampling System Overview How Sampling Works Ocean Optics components function in a sampling system as follows: 1. The user stores reference and dark measurements to correct for instrument response variables. 2. The light from the light source transmits through an optical fiber to the sample.

  • Page 10: Additional Equipment Needed

    Please save the Wavelength Calibration Data Sheet for future reference. Software and Technical Resources CD Each order ships with the Ocean Optics Software and Resources CD. This disc contains software, operating instructions, and product information for all Ocean Optics software, spectrometers, and spectroscopic accessories.
  • Page 11 1: Introduction 270-00000-000-02-0108...

  • Page 12: Chapter 2: Installing The Usb2000

    Chapter 2 Installing the USB2000+ Overview You must install the SpectraSuite software application prior to connecting the USB2000+ Spectrometer to the computer. The SpectraSuite software installation installs the drivers required for USB2000+ installation. If you do not install SpectraSuite first, the system will not properly recognize the USB2000+. If you have already connected the USB2000+ to a computer running on a Windows platform prior to installing SpectraSuite, consult Chapter 3: Troubleshooting...

  • Page 13: Serial Port Mode

    4. Plug the 5 VDC external power supply into an outlet and connect it to the USB2000+. Connect Spectroscopic Accessories To find operating instructions for USB2000+-compatible products (such as light sources, sampling chambers, and probes), consult the Software and Technical Resources CD or the Ocean Optics website at http://www.oceanoptics.com/technical/operatinginstructions.asp USB2000+ Configuration The USB2000+ can be used with either SpectraSuite or OOIBase32 software when connected to the USB port.

  • Page 14: Configuring The Usb2000+ In Ooibase32

    2: Installing the USB2000+ Note the spectrometer(s) that you have installed are listed in the Data Sources pane. Configuring the USB2000+ in OOIBase32 Once you install the USB2000+, you must configure OOIBase32’s Configure Spectrometer options so that OOIBase32 recognizes the USB2000+ Spectrometer. Consult the OOIBase32 Spectrometer Operating Software Operating Instructions for detailed instructions on configuring the spectrometer in Product-Related Documentation).

  • Page 15: Chapter 3: Troubleshooting

    SpectraSuite Installation Windows Operating Systems If you connected your Ocean Optics USB2000+ device to the computer prior to installing your Ocean Optics software application on a Windows platform, you may encounter installation issues that you must correct before your Ocean Optics device will operate properly.

  • Page 16: Remove Improperly Installed Files

    4. Navigate to the Windows | System32 | Drivers directory. 5. Delete the EZUSB.SYS file. 6. Reinstall your Ocean Optics application and reboot the system when prompted. 7. Plug in the USB device. The system is now able to locate and install the correct drivers for the USB device.

  • Page 17: Linux Operating Systems

    3: Troubleshooting Linux Operating Systems For Linux operating systems, all you need to do is install the SpectraSuite software, then unplug and replug in the spectrometer. Technically, the driver files for Linux simply give nonprivileged users permission to use newly connected hardware. There isn’t any long-term harm to plugging in the device before installing the software.
  • Page 18 3: Troubleshooting 270-00000-000-02-0108...

  • Page 19: Appendix A: Calibrating The Wavelength Of The Usb2000

    This appendix describes how to calibrate the wavelength of your spectrometer. Though each spectrometer is calibrated before it leaves Ocean Optics, the wavelength for all spectrometers will drift slightly as a function of time and environmental conditions. Ocean Optics recommends periodically recalibrating the USB2000+.

  • Page 20: Calibrating The Spectrometer

    A light source capable of producing spectral lines Note Ocean Optics’ HG-1 Mercury-Argon lamp is ideal for recalibration. If you do not have an HG-1, you need a light source that produces several (at least 4-6) spectral lines in the wavelength region of your spectrometer.
  • Page 21 A: Calibrating the Wavelength of the USB2000+ Independent Values Computed Dependent from the Regression Variable Variables Output Predicted True Wavelength (nm) Pixel # Pixel # Pixel # Difference Wavelength 253.65 30625 5359375 253.56 0.09 296.73 87616 25934336 296.72 0.01 302.15 97344 30371328 302.40...

  • Page 22: Saving The New Calibration Coefficients: Usb Mode

    Saving the New Calibration Coefficients: USB Mode Ocean Optics programs wavelength calibration coefficients unique to each USB2000+ onto an EEPROM memory chip in the USB2000+. You can overwrite old calibration coefficients on the EEPROM if you are using the USB2000+ via the USB port.

  • Page 23: Appendix B: External Triggering

    USB2000+ will not acquire spectra. External Hardware Trigger On the USB2000+, Ocean Optics has altered the functionality of the External Hardware Trigger function and reprogrammed the Single Strobe signal function. These alterations of the USB2000 enable you to operate in the Variable Delay Mode without the presence of an external trigger signal. The USB2000+ will simulate the signal to trigger the appropriate circuitry in the spectrometer.

  • Page 24: External Synchronization Trigger

    B: External Triggering Timing Diagram for Variable Delay Mode External Synchronization Trigger In this mode of the USB2000+, the integration clock is essentially input into the spectrometer. The synchronized trigger must have a frequency range of 5ms to 60s (shutter mode cannot be used in External Synchronization Trigger mode).

  • Page 25: Appendix C: Specifications

    Appendix C Specifications Overview This appendix contains information on spectrometer operation, specifications, and system compatibility. It also includes accessory connector pinout diagrams and pin-specific information. How the USB2000+ Works Below is a diagram of how light moves through the optical bench of an USB2000+ Spectrometer. The optical bench has no moving parts that can wear or break;...

  • Page 26: Usb2000+ Components Table

    C: Specifications USB2000+ Components Table Ocean Optics permanently secures all components in the USB2000+ at the time of manufacture. Only Ocean Optics technicians can replace interchangeable components, where noted. Item Name Description SMA 905 Secures the input fiber to the spectrometer. Light from the input fiber enters the Connector optical bench through this connector.

  • Page 27: Usb2000+ Specifications

    C: Specifications USB2000+ Specifications The following table provides specification information for the USB2000+. Specification Value Spectrometer USB2000+ Grating Options 14 different gratings, UV through Shortwave NIR Detector 2048-element linear silicon CCD array; L2 Collection Lens Wavelength range 200-1100 nm Entrance aperture 5, 10, 25, 50, 100 or 200 µm wide slits or fiber (no slit) AgPlus Mirrors Provide reflectivity >95% over the visible and NIR wavelength range and...

  • Page 28: 20-Pin Accessory Connector Pinout

    C: Specifications 20-Pin Accessory Connector Pinout The USB2000+ features a 20-pin Accessory Connector, located on the front of the unit as shown: Location of USB2000+ 20-Pin Accessory Connector 20-Pin Accessory Connector Pinout Diagram When facing the 20-pin Accessory Connector on the front of the vertical wall of the USB2000+, pin numbering is as follows: 20-Pin Accessory Connector Pinout Diagram 20-Pin Accessory Connector –...
  • Page 29 C: Specifications Function Input/Output Description RS232 transmit signal – Communicates with a computer over RS232 Tx Output DB9 Pin 2 RS232 receive signal – Communicates with a computer over RS232 Rx Input DB9 Pin 3 TTL signal driven Active HIGH when the Lamp Enable Lamp Enable Output command is sent to the spectrometer...
  • Page 30 C: Specifications 270-00000-000-02-0108...

  • Page 31: Index

    Index 20-pin accessory connector features, 2 diagram, 22 filter, 20 pin definitions, 22 focusing mirror, 20 accessories, 4, 7 grating, 20 accessory connector pinout, 22 additional equipment, 4 Adobe Acrobat Reader, 4 Installation, 6 Serial Port mode, 7 USB mode, 6 installed filter, 20 Calibrating, iii, 13 Interface, 3...
  • Page 32 Index Sampling upgrades, iv System, 3 USB mode, 6 Serial Port mode, 7 service, iv setup, 6 shipment components, 3 slit, 20 Variable Delay Mode, 17 SMA Connector, 20 Software and Resources Library CD, 4 specifications, 19, 21 SpectraSuite, 2 Wavelength Calibration spectroscopic accessories, 7 System Requirements, 2...
