Appendix B: Specifications and Performance

Specifications

Operational characteristics
Controls
Physical properties
Calibration
V1.0 VisualSonics Vevo Integrated Rail System Operator Manual
Need help? Call us toll-free: 1-866-416-4636 or E-mail us: support@visualsonics.com
All specifications are for standard systems.
Table-top system
Flowmeter 0-4 liters per minute @
volume 55 psi
Oxygen flush 15-35 liters per minute
volume @ 55 psi
Gas supply Oxygen male DISS
connector
Gas pressure 50-55 psi
requirements
Flowmeter Single-turn metering
valve
Oxygen flush Plunger-actuated,
spring-return valve
Adjustable None
pressure
limiting (APL)
valve
Weight Approximately 32 lbs
(14.5 kg)
Dimensions 11"w x 8"d x 14"h
Material Aluminum frame; steel
handle, bolts and
screws; brass valves
and tubing; acrylic
flowmeter cover
Finish Heat-treated enamel
Vaporizers are calibrated at 21 ºC (70 ºF) and at elevated temperatures.
The variation in output with temperature, flow rate and duration of use is
Appendix B: Specifications and Performance
Mobile system
0-4 liters per minute @
55 psi
15-35 liters per minute
@ 55 psi
Oxygen male DISS
connector
50-55 psi
Single-turn metering
valve
Plunger-actuated,
spring-return valve
None
Approximately 56 lbs
(25.41 kg)
19"w x 18"d x 50"h
Aluminum frame; steel
bolts and screws; brass
valves and tubing;
acrylic flowmeter
cover; Delrin handle
Heat-treated enamel
31
