Chapter 4: Operating the Vaporizer
Principle of
operation
Isoflurane Vaporizer with
pin-indexed filler
V1.0
VisualSonics Vevo Compact Anesthesia System Operator Manual
Need help? Call us toll-free: 1-866-416-4636 or E-mail us: support@visualsonics.com
Chapter 4: Operating the Vaporizer: Principle of operation
Control dial
Inlet
release button
Sight glass
Control dial
Lower
Draining tunnel
retaining
screw
Outlet
Upper
retaining
screw
Filling
tunnel
Filler
plug
Drain
valve
17
