Summary of Contents for FLIR M100SERIES
- Page 1 M100 / M200 SERIES INSTALLATION & OPERATION INSTRUCTIONS English (en-US) Date: 03-2017 Document number: 71001-2 © 2017 Raymarine UK Limited...
- Page 3 Export Administration Regulations (EAR). FLIR trade secrets contained herein are subject to disclosure restrictions as a matter of law. Diversion contrary to US law is prohibited. US Department of Commerce authorization is not required prior to export or transfer to foreign persons or parties unless otherwise prohibited.
-
Page 5: Table Of Contents
Contents Chapter 1 Important information ..............9 Cleaning the thermal camera................10 Inspecting the thermal camera................11 Water ingress...................... 11 Disclaimer......................11 EMC installation guidelines................11 Suppression ferrites.................... 12 Connections to other equipment............... 12 Declaration of conformity ................... 12 Product disposal ....................12 Warranty registration................... - Page 6 Chapter 4 Cables and connections............35 4.1 General cabling guidance ................36 Cable types and length..................36 Routing cables......................36 Strain relief ......................36 Circuit isolation ......................36 Cable shielding......................37 4.2 Connections overview.................. 38 Connecting cables....................38 4.3 Power connection ..................40 Power cable extension....................
- Page 7 7.2 Cleaning the thermal camera ..............83 Chapter 8 System checks and troubleshooting ........85 8.1 Thermal camera troubleshooting ..............86 8.2 FLIR Maritime product support and servicing .......... 87 Chapter 9 Technical specification............. 89 9.1 M100/M200 Series cameras............... 90 Technical specification ....................
-
Page 9: Chapter 1 Important Information
It is the user’s responsibility to use official government charts, notices to mariners, caution and proper navigational skill when operating this or any other FLIR product. Important information... -
Page 10: Cleaning The Thermal Camera
Caution: Service and maintenance This product contains no user serviceable components. Please refer all maintenance and repair to authorized FLIR dealers. Unauthorized repair may affect your warranty. Caution: Sun covers •... -
Page 11: Inspecting The Thermal Camera
FLIR. FLIR is not responsible for damages or injuries caused by your use or inability to use the product, by the interaction of the product with products manufactured by others, or by errors in information utilized by the product supplied by third parties. -
Page 12: Suppression Ferrites
Connections to other equipment Requirement for ferrites on non-FLIR cables If your FLIR equipment is to be connected to other equipment using a cable not supplied by FLIR, a suppression ferrite MUST always be attached to the cable near the FLIR unit. -
Page 13: Imo And Solas
To the best of our knowledge, the information in this document was correct at the time it was produced. However, FLIR cannot accept liability for any inaccuracies or omissions it may contain. In addition, our policy of continuous product improvement may change specifications without notice. -
Page 15: Chapter 2 Document And Product Information
Chapter 2: Document and product information Chapter contents • 2.1 Document information on page 16 • 2.2 Product overview on page 18 Document and product information... -
Page 16: Document Information
• use your product along with an appropriate video monitor, joystick control unit (JCU), web browser, or multifunction display (MFD). • troubleshoot problems and obtain technical support if required. This and other FLIR product documents are available to download in PDF format from www.flir.com/marine/support. Applicable products... -
Page 17: Document Illustrations
Note: If you want to view the image from your camera on a monitor, the camera’s digital IP-video output must be converted to analog component-video using a decoder unit. Suitable video decoder units are available separately. Document illustrations Your product may differ slightly from that shown in the illustrations in this document, depending on product variant and date of manufacture. -
Page 18: Product Overview
2.2 Product overview M100/M200 The M100/M200–Series is a maritime thermal imaging system for use on nearly any kind of vessel. It provides a clear image in low-light and no-light conditions. For example, a thermal camera can help you navigate at night or identify obstacles in areas of low visibility or even total darkness. -
Page 19: Chapter 3 Planning The Installation
Chapter 3: Planning the installation Chapter contents • 3.1 Installation checklist on page 20 • 3.2 Compatible multifunction displays on page 21 • 3.3 Parts supplied on page 22 • 3.4 Tools required on page 26 • 3.5 Typical systems on page 27 •... -
Page 20: Installation Checklist
3.1 Installation checklist Installation includes the following activities: Installation Task Plan your system. Obtain all required equipment and tools. Site all equipment. Route all cables. Drill cable and mounting holes. Make all connections into equipment. Secure all equipment in place. Power on and test the system. -
Page 21: Compatible Multifunction Displays
3.2 Compatible multifunction displays Note: A Raymarine® LightHouse™-compatible multifunction display (MFD) is not required to use a M100/M200-Series camera. However certain camera features may not be accessible without one. This product is compatible with the following Raymarine® LightHouse™ multifunction displays. •... -
Page 22: Parts Supplied
3.3 Parts supplied System kits M100/M200–Series thermal cameras are supplied individually, or as part of a system kit. In addition to the thermal camera, system kits include a joystick control unit (JCU) for controlling the camera. The content of each system kit is listed below. For a list of the individual parts supplied with each camera, see M100/M200–Series camera. - Page 23 Item Description Quantity Thermal camera Thermal camera base-seal Documentation pack Thermal camera fasteners: nuts, dome 3 of each nuts, spring washers, flat washers, and threaded studs Self-adhesive decals (for ball-down mounting only) Planning the installation...
- Page 24 Item Description Quantity Top-down riser kit (includes riser, riser base seal, and riser mounting template) *Right-angled RayNet-to-RayNet cable (10 m) RayNet-to-RJ45 adapter cable (100 *Right-angled 3-pin power cable (10 m) 1 *The supplied right-angled RayNet and Power cables are suitable for mounting on surfaces up to 25.4 mm (1.0 inch) thick.
-
Page 25: Jcu–3
Note: Your M100/M200-Series thermal camera is also compatible with the following joystick control units, provided with other FLIR and Raymarine camera systems: • JCU-1 (part no. 500-0385-00) — joystick control unit for FLIR M-Series and Raymarine T-Series cameras • JCU-2 (part no. 500-0398-00) — joystick control unit for FLIR M400-Series,... -
Page 26: Tools Required
3.4 Tools required The following tools are required for installation. Item Description Drill 10 mm spanner Drill bit of appropriate size* Jigsaw (only required for JCU installation) Pozi-drive screwdriver (only required for JCU installation) Thread-lock 50 mm (2 inch) Hole saw Note: * The appropriate drill bit size is dependent on the thickness and material of the mounting surface. -
Page 27: Typical Systems
3.5 Typical systems Note: For information on how to connect the product, refer to the Chapter 4 Cables and connections section. For information on available cables and accessories, refer to the Chapter 10 Spares and accessories section. • Basic Web browser system: You can connect the product directly to an IP-capable device, such as a laptop or PC, using the supplied RayNet cable and RayNet-to-RJ45 adapter cable. -
Page 28: Warnings And Cautions
3.6 Warnings and cautions Important: Before proceeding, ensure that you have read and understood the warnings and cautions provided in the Chapter 1 Important information section of this document. -
Page 29: General Location Requirements
3.7 General location requirements Important considerations when choosing a suitable location for your product. This product is suitable for mounting below decks. The product should be mounted where it will be: • protected from physical damage and excessive vibration. • well ventilated and away from heat sources. When choosing a location for the product, consider the following points to ensure reliable and trouble-free operation: •... -
Page 30: Camera Orientation
3.8 Camera orientation The camera can be mounted in 2 orientations informally known as “Ball up” and “Ball down”. The default image orientation is for the ball-up configuration; if the camera is to be mounted in the ball-down configuration then the video image must be flipped. Ball-up: The camera is mounted on top Ball-down: The camera is suspended of the mounting surface. -
Page 31: Product Dimensions
3.9 Product dimensions M100/M200 Series Planning the installation... -
Page 32: M100/M200 Series With Optional Top-Down Riser
M100/M200 Series with optional top-down riser Note: Base diameter with riser base-seal fitted is 190 mm (7.48 in). -
Page 33: Jcu-3
JCU-3 Product dimensions Dimension Measurement 34.8 mm (1.37 in) 10.5 mm (0.41 in) 28.4 mm (1.12 in.) 31.7 mm (1.25 in.) 50.7 mm (2.00 in.) 80.0 mm (3.15 in.) 119.0 mm (4.69 in.) 133.0 mm (5.24 in.) 41.0 mm (1.61 in.) 55.0 mm (2.17 in.) Planning the installation... -
Page 35: Chapter 4 Cables And Connections
Chapter 4: Cables and connections Chapter contents • 4.1 General cabling guidance on page 36 • 4.2 Connections overview on page 38 • 4.3 Power connection on page 40 • 4.4 Network connections on page 44 Cables and connections... -
Page 36: General Cabling Guidance
• Unless otherwise stated use only standard cables of the correct type, supplied by FLIR. • Ensure that any non-FLIR cables are of the correct quality and gauge. For example, longer power cable runs may require larger wire gauges to minimize voltage drop along the run. -
Page 37: Cable Shielding
Cable shielding Ensure that all data cables are properly shielded that the cable shielding is intact (e.g. hasn’t been scraped off by being squeezed through a tight area). Cables and connections... -
Page 38: Connections Overview
4.2 Connections overview 1. Power and drain 2. RayNet connection to: a. RayNet connector on Raymarine network switch or LightHouse™-powered Raymarine multifunction display (using RayNet-to-RayNet cable), OR b. RJ45 connector on third-party network switch, PC/laptop computer, or IP video decoder (available separately), using the supplied RayNet-to-RJ45 adapter cable. Note: The supplied right-angled RayNet and Power cables are suitable for mounting on surfaces up to 25.4 mm (1.0 inch) thick. - Page 39 5. Ensure any bare ended wire connections are suitably insulated to prevent corrosion due to water ingress. Cables and connections...
-
Page 40: Power Connection
4.3 Power connection Power must be supplied to the camera from an appropriate power source. Power connection requirements • 12 or 24 Vdc nominal supply voltage • Isolated power supply • Connected via an appropriately rated thermal breaker or fused switch. Power connection colors Item Color... - Page 41 It covers common vessel power arrangements, but does NOT cover every scenario. If you are unsure how to provide the correct level of protection, please consult an authorized FLIR dealer or a suitably qualified professional marine electrician. Implementation — direct connection to battery •...
-
Page 42: In-Line Fuse And Thermal Breaker Ratings
Ensure that you observe the separate grounding advice provided in the product’s documentation. More information FLIR recommends that best practice is observed in all vessel electrical installations, as detailed in the following standards: • BMEA Code of Practice for Electrical and Electronic Installations in Boats •... -
Page 43: Grounding - Dedicated Drain Wire
Grounding — Dedicated drain wire The power cable supplied with this product includes a dedicated shield (drain) wire for connection to a vessel's RF ground point. It is important that an effective RF ground is connected to the system. A single ground point should be used for all equipment. -
Page 44: Network Connections
4.4 Network connections Your thermal camera has a single RayNet network connector. This connects the camera to your vessel’s wider IP network. This could be an existing third-party Ethernet network, or a dedicated Raymarine RayNet network. The details of the network connections between the camera, video display (web browser, analog video monitor, or LightHouse™-powered Raymarine multifunction display), control unit (for example, a JCU-3 controller) and the rest of your installation depend on: •... - Page 45 Item Description Laptop (or other Ethernet-connected device running a web browser) M100/M200–Series camera RayNet-to-RJ45 adapter cable RayNet-to-RayNet cable Single-camera system with web browser and an optional JCU Note: Power connections are not shown in this illustration. The camera and the other devices shown require their own dedicated power connection.
-
Page 46: Raynet Systems With Lighthouse™-Powered Raymarine Multifunction Displays (Mfds)
Note: Power connections are not shown in this illustration. The camera and the other devices shown require their own dedicated power connection. Item Description Ethernet network switch M100/M200–Series camera Joystick control unit (JCU-3) Analog video monitor IP video decoder (available separately) RayNet-to-RayNet cable RayNet-to-RJ45 adapter cable RJ45-to-RJ45 Ethernet cable... - Page 47 Single-camera system with Raymarine MFD and JCU Note: Power connections are not shown in this illustration. The camera and the other devices shown require their own dedicated power connection. Item Description Raynet network switch M100/M200–Series camera Joystick control unit (JCU-3) Raymarine MFD RayNet-to-RayNet cable Cables and connections...
- Page 48 Multi-camera system with video monitor, two Raymarine MFDs, two JCUs, and a web browser...
- Page 49 Note: Power connections are not shown in this illustration. The camera and the other devices shown require their own dedicated power connection. Item Description Raynet network switch M100/M200–Series camera Joystick control unit (JCU-3) Analogue video monitor IP video decoder (available separately) Laptop (or other Ethernet-connected device running a web browser) Raymarine MFD RayNet-to-RayNet cable...
-
Page 51: Chapter 5 Mounting
Chapter 5: Mounting Chapter contents • 5.1 Camera mounting on page 52 • 5.2 JCU–3 Mounting on page 59 Mounting... -
Page 52: Camera Mounting
5.1 Camera mounting Location requirements When planning the installation location, consider the following points: • The camera is waterproof, and appropriate for above decks mounting. • When mounting the camera in a ball-down position, ensure that the camera is installed with adequate drainage so that standing water does not collect in the base. •... - Page 53 1. Using the template supplied, mark and drill the holes for mounting the camera. Mounting holes care points: • Check the dimensions of any printed template (to ensure that the template is printed to the correct scale) prior to drilling any holes. Mounting...
-
Page 54: Mounting The Camera With The Optional Top-Down Riser (Part Number A80509)
• Note the camera forward markings on the camera base, and make sure the template is oriented properly relative to the bow of the vessel. This is affected by whether the camera is to be mounted ball-up or ball-down. 2. Install the 3x threaded studs into the base of the camera with thread-locking compound. - Page 55 2. Install the 3x threaded studs into the base of the camera. Do not use thread locking compound, as this may damage the plastic riser. 3. Slide the camera-base seal over the threaded studs, and push it firmly into place on the camera’s base.
- Page 56 4. Place the camera on top of the riser, so the threaded studs extend through the three holes in the riser’s top surface. Check that the camera-base seal remains firmly in place. • Note the camera forward marking on the top surface of the riser. You must ensure that the riser is mounted so that the camera is oriented properly relative to the bow of the vessel.
- Page 57 You must ensure a watertight seal between the riser base and the mounting surface. You may use a marine-grade sealant as an alternative to the supplied mounting gasket. Mounting...
- Page 58 Note: • If it is not possible to route the camera cables through the mounting surface, cut a hole in the side of the riser, and route the cables through the riser sidewall. You may need to loop the cables around within the riser base, so that they can be passed through the hole you have cut in the side of the riser.
-
Page 59: Mounting
5.2 JCU–3 Mounting Note: The JCU-3 joystick control unit is supplied with M100/M200 Series camera system kits, and separately as an optional accessory. JCU-3 units are not supplied with cameras purchased individually. See System kits for more information about system kits and parts supplied. Location requirements When planning the installation location, consider the following points: •... -
Page 60: Flush Mounting The Keypad
Flush mounting the keypad Flush mounting provides a sleek installation where the product and dash are flush, with only the buttons and Rotary controller protruding from the dash. Flush mounting requires the mounting surface to be rebated. 1. Check the selected location for the unit. A clear, flat area with suitable clearance behind the panel is required. -
Page 61: Surface Mounting The Keypad
Surface mounting the keypad Surface mounting provides a uniform installation where the products protrude, usually by the thickness of the bezel, from the mounting surface. 1. Check the selected location for the unit. A clear, flat area with suitable clearance behind the panel is required. - Page 62 2. Slide the keypad mat’s shorter edge, with the 2 locking tabs, into the end of the keypad that has 2 notches to accept the tabs. 3. Close the opposite end of the keypad mat into the keypad, ensuring that the tab slides into the notch provided, push all of the tabs on the longer sides into their notches (you should hear a click as each tab engages).
-
Page 63: Chapter 6 System Operation And Setup
Chapter 6: System operation and setup Chapter contents • 6.1 Thermal camera image on page 64 • 6.2 Operation and features overview on page 66 • 6.3 Camera control on page 67 • 6.4 Image adjustments on page 69 • 6.5 JCU–3 controls overview on page 70 •... -
Page 64: Thermal Camera Image
6.1 Thermal camera image The thermal camera provides a video image which is shown on your primary video display, web browser, or LightHouse™-powered Raymarine multifunction display (MFD). The IP-video feed provides: • Thermal image. • Status icons / system information. You should take time to familiarize yourself with the thermal image. - Page 65 Icon Description Park indicator. Shown as confirmation after you have requested to park the camera. Motor stalled. Shown instead of camera direction indicator if the motor is stalled. Zoom indicator. Shown whenever you have zoomed the camera. System operation and setup...
-
Page 66: Operation And Features Overview
6.2 Operation and features overview The camera features can be accessed using a web browser running on an IP-capable device (for example, a laptop or PC) attached to the same network as the camera, using a dedicated JCU (Joystick control unit), or using the thermal camera application of a compatible LightHouse™-powered Raymarine multifunction display. -
Page 67: Camera Control
6.3 Camera control Pan, tilt and zoom The camera controls allow for pan and tilt (elevation) of the camera, as well as zoom (magnification) of the thermal image. • Pan continuously through 360° (M200 Series only). • Tilt (elevate) to ±90° relative to the horizon. •... -
Page 68: Thermal Camera Surveillance Mode
Thermal camera surveillance mode In surveillance mode the camera pans left and right continuously. The camera continues to pan until surveillance mode is disabled, or the JCU (Joystick Control Unit) is used to move the camera. When this occurs the camera does not automatically resume surveillance mode and the mode must be enabled again if required. -
Page 69: Image Adjustments
6.4 Image adjustments Thermal camera scene presets Scene presets enable you to quickly select the best image setting for the current environmental conditions. During normal operation the thermal camera automatically adjusts itself to provide a high-contrast image optimized for most conditions. The Scene presets provide 4 additional settings that may provide better imagery in certain conditions. -
Page 70: Controls Overview
6.5 JCU–3 controls overview USER 1 • User configurable button (configured via camera web page). USER 2 • User configurable button (configured via camera web page). 3, 4, 5 UNI-CONTROLLER – Use the uni-controller to control the camera: • Press ring (4) up, down left right – Pan / Tilt camera (pan available on M200–Series only). - Page 71 ZOOM-IN • Press to zoom thermal camera in SCENE • Press to cycle through image scene presets (day; night; docking; high contrast) COLOR • Long-press to cycle through color palettes (WhiteHot; RedHot; Fusion; FireIce) • Short-press to toggle polarity of selected color palette (for example: WhiteHot >...
-
Page 72: Web Browser Interface
6.6 Web browser interface Web browser user interface overview This chapter describes how to use a Web browser to communicate with and configure your M100/M200-Series camera. M100/M200-Series cameras are network devices that communicate over an Ethernet network using Internet Protocol (IP). Using a Web browser, you can view video, control the camera, and change camera configuration settings. -
Page 73: Logging In To The Web Browser User Interface
E70353 1234). For example, in Windows XP, the camera is listed in Windows Explorer under “My Network Places”; in later versions of Windows, the camera is listed in Windows Explorer under “Network”. Note: If the camera is not listed in Windows Explorer under “My Network Places” (Windows XP) or “Network”... -
Page 74: Live Video Page
Menu choices are available at the top of the screen, next to the FLIR logo. The user login, can only access the Live Video page and controls, and a limited selection of Configuration settings. - Page 75 At the top of the page, the Help menu shows software version information. This page includes information about the camera, including hardware and software revision numbers, part numbers, and serial numbers. Before contacting FLIR Technical Support for assistance, make a note of the information from this page.
-
Page 76: Control Buttons
To save a still image from the video feed, click the snapshot button. The video image at the moment the snapshot button is clicked, is created as a JPEG (.jpg) file. Follow the browser prompts to save the image file; the exact prompts depend on the browser you are using. - Page 77 The following table describes the function of each button for M100/M200-Series cameras. Button Description Zoom In Click and hold to zoom-in the thermal image. The current zoom level (between x1.0 and x4.0) is shown at the bottom-right of the thermal image. Zoom Out Click and hold to zoom-out the thermal image.
-
Page 78: Configuring Jcu-3 User-Programmable Buttons (Upbs)
Button Description Toggle Scene Preset Cycle through four different image presets: Day, Night, Docking, and High Contrast. Each preset adjusts the image brightness and contrast. Depending on the time of day, weather, and other conditions, you may find that one preset produces a clearer thermal image than the others. - Page 79 Note: UPB mappings apply to individual cameras rather than to specific JCU-3 keypads. This means that, if you are using a single JCU-3 keypad to control two M100 / M200 Series cameras, UPB number 1 could be configured to initiate a different action on each camera.
-
Page 81: Chapter 7 Maintenance
Chapter 7: Maintenance Chapter contents • 7.1 Service and maintenance on page 82 • 7.2 Cleaning the thermal camera on page 83 Maintenance... -
Page 82: Service And Maintenance
7.1 Service and maintenance This product contains no user serviceable components. Please refer all maintenance and repair to authorized FLIR dealers. Unauthorized repair may affect your warranty. -
Page 83: Cleaning The Thermal Camera
7.2 Cleaning the thermal camera The camera housing and lens will require occasional cleaning. You should clean the lens when image quality degradation is noticed or excessive contaminant buildup is seen. Clean the interface between the yoke and base often to prevent accumulation of debris or salt deposits. -
Page 85: Chapter 8 System Checks And Troubleshooting
Chapter 8: System checks and troubleshooting Chapter contents • 8.1 Thermal camera troubleshooting on page 86 • 8.2 FLIR Maritime product support and servicing on page 87 System checks and troubleshooting... -
Page 86: Thermal Camera Troubleshooting
8.1 Thermal camera troubleshooting Problems with the thermal camera and their possible causes and solutions are described here. Problem Possible causes Possible solutions Video not displayed. Camera is in Standby The camera will not display video if it mode. is in Standby mode. Use the camera controls (either the thermal camera application or JCU) to “wake”... -
Page 87: Flir Maritime Product Support And Servicing
You can obtain this product information using the menus within your product. Servicing and warranty FLIR offers dedicated service departments for warranty, service, and repairs. Don’t forget to visit the FLIR website to register your product for extended warranty benefits: http://customer.flir.com/Warranty/EndUserRegistration. Region... - Page 88 Region Telephone E-mail +47 692 64 Norway support.no@flir.com (FLIR Maritime subsidiary) +45 437 164 Denmark support.dk@flir.com (FLIR Maritime subsidiary)
-
Page 89: Chapter 9 Technical Specification
Chapter 9: Technical specification Chapter contents • 9.1 M100/M200 Series cameras on page 90 • 9.2 JCU-3 on page 91 Technical specification... -
Page 90: M100/M200 Series Cameras
9.1 M100/M200 Series cameras Technical specification Nominal supply voltage 12 or 24 V dc Operating voltage range -10% to +30% of nominal supply range Current Peak 5.0 A Power consumption • 15 W typical • 18 W maximum Environmental Installation environment •... -
Page 91: Technical Specification
9.2 JCU-3 Technical specification Power specification PoE class Class 1 Nominal supply voltage • PoE: 48 V dc • Alternate power: 12 V / 24 V dc • PoE: 44 V to 57 V dc Operating voltage range • Alternate power: 9 V to 32 V dc Power consumption 4 W Max with full keypad illumination Environmental specification... -
Page 93: Chapter 10 Spares And Accessories
Chapter 10: Spares and accessories Chapter contents • 10.1 M100/M200 Series camera accessories on page 94 • 10.2 Keypad spares and accessories on page 95 • 10.3 Network hardware on page 96 • 10.4 RayNet to RJ45 adapter cables on page 98 •... -
Page 94: M100/M200 Series Camera Accessories
10.1 M100/M200 Series camera accessories Accessories Item Part number Right-angled single keyway power cable, A80511 10 m (32.8 ft) Right-angled RayNet cable, 10 m (32.8 ft) A80512 RayNet adapter cable, 100 mm (3.9 in) A80513 Top-down riser for M100/M200 Series A80509 cameras JCU-3 remote control unit (with portrait... -
Page 95: Keypad Spares And Accessories
10.2 Keypad spares and accessories Spares Item Part number Portrait keypad mat spare R70509 Landscape keypad mat spare R70508 Accessories Item Part number Right angled 2 m (6.6 ft) power cable A06070 Straight 2 m (6.6 ft) power cable A06049 Spares and accessories... -
Page 96: Network Hardware
10.3 Network hardware Item Part number Notes HS5 RayNet network switch A80007 5–port switch for network connection of multiple devices featuring RayNet connectors. Equipment with RJ45 SeaTalk connectors can also be connected using suitable adapter cables. RJ45 SeaTalk network E55058 8–port switch for network connection switch of multiple SeaTalk... -
Page 97: Network Cable Connector Types
Network cable connector types There are 2 types of network cable connector — RayNet, and RJ45 SeaTalk RJ45 SeaTalk connector. RayNet connector. Spares and accessories... -
Page 98: Raynet To Rj45 Adapter Cables
10.4 RayNet to RJ45 adapter cables Description Typical use Quantity Adapter cable with a A typical use for this adapter cable is to RayNet (female) socket connect a DSM300 sonar module to a on one end, and a LightHouse MFD, using all-waterproof waterproof (female) cable connections. - Page 99 Description Typical use Quantity Adapter cable with a Connect a legacy G-Series GPM-400, RayNet (female) socket C-Series Widescreen or E-Series on one end, and an RJ45 Widescreen MFD to a RayNet network SeaTalk waterproof switch (e.g. the HS5). (male) plug on the other end.
-
Page 100: Raynet To Raynet Cables And Connectors
10.5 RayNet to RayNet cables and connectors Description Typical use Quantity Standard RayNet Suitable for connecting all RayNet connection cable with equipment directly to LightHouse a RayNet (female) socket multifunction displays featuring a RayNet on both ends. connector. Can also be used to connect RayNet equipment via a RayNet network switch (e.g. - Page 102 Index Temperature range..........91 Accessories ............. 94–95 Warranty ..............87 Water ingress............91 Box contents, See Parts supplied Cable bend radius..........36 Cable protection ..........36–37 Cable routing ............36 Compass safe distance ........29 Connecting cables ..........38 Contact details............87 Electromagnetic Compatibility ......
- Page 104 FLIR Systems, Inc. Corporate Headquarters FLIR Systems, Inc. 27700A SW Parkway Ave. Wilsonville, OR 97070, USA PH: + 1 503 498 3547 | PH: + 1 877 773 3547 | FX: + 1 503 498 3153 www. ir.com/marine...
