- Page 1 IPC Series PANEL-PC 40 Series Fanless, ARM Cortex-A8 User’s Manual CONTEC CO., LTD.
- Page 2 Check Your Package Thank you for purchasing the CONTEC product. The product consists of the items listed below. Check, with the following list, that your package is complete. If you discover damaged or missing items, contact your retailer. Product Configuration List PT-40NVF-DC353111 Pcs.
-
Page 3: Copyright
No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document. -
Page 4: Table Of Contents
Limited One-Year Warranty ....................... 3 How to Obtain Service ........................3 Liability ............................... 3 Safety Precautions ..........................4 Safety Information ........................4 Caution on the PT-40 Series......................4 SYSTEM REFERENCE Specifications ............................7 Power Requirements ........................... 9 Power Consumption ........................9 Physical Dimensions ......................... - Page 5 APPENDIX Battery ............................... 23 LIST OF OPTIONS PT-40 User’s manual...
-
Page 6: Introduction
Windows Embedded Compact 7 (Japanese version) ® PT-40NVF-DC353111(memory 256MB, SD 512MB) * In order to create Windows applications, "CONTEC SDK for CE 700" is also necessary. For details, see the software manual. Features Contributes to reductions in energy usage This product uses an SoC "AM3354" that is equipped with an ARM® processor (600MHz, T.I. -
Page 7: Supported Os
Equipped with "CONTEC Manager", a tool that supports system development This product is equipped with "CONTEC Manager", a tool that provides assistance for system development by way of functions such as an FTP server function, a scheduling function, an automatic time adjustment function that uses NTP, and the Auto RUN function. -
Page 8: Customer Support
You can download updated driver software and differential files as well as sample programs available in several languages. Note! For product information Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information. Limited One-Year Warranty CONTEC products are warranted by CONTEC CO., LTD. -
Page 9: Safety Precautions
Do not disassemble or modify the product or replace any of its parts. Doing so may lead to electric shock, fire, or product failures. In addition, CONTEC may not be able to provide servicing for the product if you modify it. - Page 10 Avoid installation in a location where people may come into contact with that section. CONTEC does not provide any guarantee for the integrity of data on Storage medium. Be sure to disconnect the power cable from the outlet before connecting cables to and disconnecting cables from the connectors and before configuring hardware settings such as switches.
-
Page 11: Ferrite Core
1. Introduction About VCCI Class A and EMC Directive Class A secondary conditions In order to comply with the above standards, attach the included ferrite core to the LAN cable. To attach the ferrite core, open it, wrap the cable around the core once in a location that is close to the connector, and then close the ferrite core. -
Page 12: System Reference
2. System Reference System Reference Specifications Table 2.1. Functional Specifications < 1 / 2 > Model PT-40NVF-DC353111 ARM® Cortex-A8:600MHz Main memory On-board DDR3 SDRAM 256MB Graphic Controller Built in CPU Video RAM Main memory shared LCD type LCD type 5.7 inch TFT color LCD,VGA(640 x 480), 260,000 colors Backlight LED method, ON/OFF software can control Touch panel... - Page 13 2. System Reference Table 2.2. Installation Environment Requirements Model PT-40NVF-DC353111 Operating temperature *5 0 - 50°C Storage temperature -10 - 60°C Operating humidity 20 - 85%RH(No condensation) Floating dust particles Not to be excessive Corrosive gas None AC line / ±2kV ,*6 Line noise Signal line / ±1kV (IEC61000-4-4 Level 3, EN61000-4-4 Level 3) Noise...
-
Page 14: Power Requirements
2. System Reference Measurement direction ( θ = 0 Left ( φ = -90 θ ( φ = 180 φ Module Bottom ( φ = 0 Right ( φ = 90 Figure 2.1. Definition of viewable range CAUTION The above optical specification data shows optical characteristics of the liquid crystal in the display; the data does not represent the actual view on the display or its viewing angles. -
Page 15: Physical Dimensions
2. System Reference Physical Dimensions PT-40NVF-DC353111 4-M4 DC-IN [mm] Ensure that the mounting screw tips do not protrude past the surface to a depth of more than 15mm. Figure 2.2 PT-40NVF-DC353111 Physical Dimensions PT-40 User’s manual... -
Page 16: Hardware Setup
3. Hardware Setup 3. Hardware Setup Before Using the Product for the First Time Follow the next steps to set up this product: STEP1 By referring to the information in this chapter, install, connect and set this product. STEP2 Connect cables. Connect the cable of necessary external devices, such as keyboard and a mouse, to this product using appropriate cables. -
Page 17: Hardware Setup
3. Hardware Setup Hardware Setup Before you start, be sure that the power is turned off. Remove only those screws that are explained. Do not move any other screw. Attaching of FG (1) Use screws to attach the FG. (The screws are attached to the product when it is shipped.) Do not apply excessive force when tightening the screws. - Page 18 3. Hardware Setup CAUTION The FG pin of this product is connected to the GND signal of the DC power connector (DC-IN). Note that the connection cannot be cut off. Screw holes may be damaged if screws are tightened with a torque greater than the specified torque. The specified tightening torque is 5 - 6kgf⋅cm.
-
Page 19: Hardware Setup
3. Hardware Setup Hardware Setup (1) Cut out a panel according to the following dimensions to mount the main unit. ± 0.3 ± 0.3 4-φ3.5 [mm] Figure 3.3. Dimensions of Panel Opening (2) Place the included waterproof packing between the main body and the panel, and then insert the included waterproof screws from outside of the panel to fix the product in place. - Page 20 3. Hardware Setup When using VESA standard 100mm mounting holes The main body has mounting holes according to VESA standard 100mm. When using a VESA standard 100mm stand or the like, attach it as shown the following figure. (The dust proofing and waterproofing specifications are not fulfilled when you attach the product to a VESA stand.
-
Page 21: Installation Requirements
3. Hardware Setup Installation Requirements Be sure that the ambient temperature is within the range specified in the installation environment requirement by making space between the product and device that generates heat or exhaust air. Installed angle which is recommended Installed angle of this product which is recommended is -45°... - Page 22 3. Hardware Setup Distances between this product and its vicinity 50mm 以上 50mm 以上 50mm 以 50mm 以上 DC-IN 50mm 以上 Figure 3.7. Distances between this product and its vicinity CAUTION Do not install this product into the fully-sealed space except the case in which the internal temperature is adjustable by equipment such as air conditioner.
- Page 23 3. Hardware Setup Ambient temperature In this product, the ambient temperature is decided from the multiple measurement points as shown below. When making use of the product, the air current should be adjusted to prevent that all the temperatures measured at the measurement points exceed the specified temperature. *1 50mm more 50mm more 50mm more...
-
Page 24: Each Component Function
4. Each Component Function 4. Each Component Function Component Name SERIAL DC-IN DC-IN Figure 4.1. Component Name Table 4.1. Component Function Name Function Ethernet 100BASE-TX/10BASE-T RJ-45 connector USB port connector SERIAL Serial port connector (9pin D-SUB/male) DC-IN DC power input connector PT-40 User’s manual... -
Page 25: Dc Power Input Connector : Dc-In
4. Each Component Function DC Power Input Connector : DC-IN To supply the power, always use the power supply listed below. Rated input voltage : 12VDC Range of input voltage : 10.8 - 13.2VDC Power capacity : 12V 1.0A or more Table 4.2. -
Page 26: 100M Ethernet : Lan
4. Each Component Function 100M Ethernet : LAN This product is equipped with 1 ports for 100M Ethernet. Network type : 100BASE-TX/10BASE-T Transmission speed * : 100M/10M bps Max. network path length : 100m/segment Table 4.3. Fast Ethernet Connector Function Pin No. -
Page 27: Usb Ports: Usb
4. Each Component Function USB Ports: USB This product is equipped with 1 port for USB 2.0 interface. Table 4.4. USB Connector Pin No. Function USB_VCC USB- USB+ USB_GND Serial Port Interface: SERIAL SERIAL (RS-232C Ports) The product has 1 ports of RS-232C compliant serial ports supporting up to a baud rate of 115,200bps with a 16-byte transmission-dedicated data buffer and a 16-byte reception-dedicated data buffer. - Page 28 5. Appendix 5. Appendix Battery Battery Specification This product uses the following battery. - Type : Lithium primary battery - Model : CR2032 - Maker : HITACHI MAXELL - Nominal voltage : 3V - Nominal capacity : 240mAh - Lithium content : 1g or less Removing the battery when disposing of the product Before disposing of the product, follow the instructions given below to remove the battery.
- Page 29 5. Appendix PT-40 User’s manual...
- Page 30 6. List of Options 6. List of Options AC adapter PWA-36AWD1 : AC adapter (Input: 100-240VAC, Output: 12VDC 3A) PT-40 User’s manual...
- Page 32 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [12022016] [05262015] Management No. NA04124 [12022016_rev2] Parts No. LYSP282...
