Summary of Contents for Axminster BS100
-
Page 1: Belt Sander
Code 508210 AXMINSTER Trade SERIES BS100 100mm Belt Sander... -
Page 2: Table Of Contents
INDEX 1 Description and main features ..........3 1.1 Forward........................3 1.2 Who should use the instruction ................3 1.3 Intended use and limitation of use…………………………………………………….3 2 Safety regulations............... 4 2.1 Forward........................4 2.2 Labels on the machine ...................4 2.3 Workers’ qualifications and dress................5 2.4 Basic safety requirements ..................5 2.5 Special safety regulations for abrasive finishing machines........7 2.6 Safety regulations for set-up...................7... -
Page 3: Description And Main Features
Description and main features 1.1 Forward The instruction provides the caution proceeding, operation and services instruction for belt grinder including the following models: JSG75, JSG75A, JSG100, JSG100A, JSG150, JSG150A, JSG220 and JSG220A. The incorrect operation and services may cause accidents. Before using the machine, user should read the operation manual carefully;... -
Page 4: Safety Regulations
2 Safety regulations 2.1 Forward The section of the instruction contains requirements that will help you use the machine safely. The requirements concerning the installation, operation and maintenance of the machine will be repeated in the instruction, along with further information that is not included in the safety section. -
Page 5: Workers' Qualifications And Dress
2.3 Workers’ qualifications and dress Only an expert skilled in the field or a worker instructed and trained by such expert may operate the machine, regardless of the sex. While working on the machine the operator must get familiar with these instructions and comply with any safety rules, regulations and provisions in force in the respective country. - Page 6 person in charge of service. In the case that you are not going to work on the machine, turn off the machine. Before doing any maintenance work inside the machine or cleaning the machine, switch off the machine and unplug the plug from power supply Do not neglect performance of regular inspections in accordance with the instructions for use.
-
Page 7: Special Safety Regulations For Abrasive Finishing Machines
Stay alert, watch what you are doing, and use common sense. Do not use the machine when you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating the machine may result in injury. The dust generated by certain products can be injurious to your health. -
Page 8: Safety Regulations For Operation
check their functioning. Function tests shall be done before commissioning. These include the verification of running conditions of belts, running speed and stop button. 2.7 Safety regulations for operation Do not put the machine into operation before you get acquainted with the contents of the instructions for use. -
Page 9: Sound Level
3.2 Sound level 3.2.1 Test conditions The test was conducted when the machine is running with load. The motors work at their rated conditions. 3.2.2 Result of measurement For the noise test, new band belt is used. The material is Q235, with the dimension of 40X60mm. -
Page 10: Transportation Before Unpacking
4.2 Transportation before unpacking As standard, the machine is packed in a robust wooden box. The following figure shows the method can be used to transport the packing box. Fig. 4-1 transportation sketch (Before unpacking) 4.3 Confirmation after unpacking When open the packing box, please pay attention to the following items. If you have any question, please contact directly with our company. -
Page 11: Installation Of Machines
If it is necessary to transport the machine after using, please protect cables firstly and discharge the scrap iron. Remove the protective coating from all unpainted surfaces. After cleaning, cover the unpainted surfaces with a good quality household floor paste wax. 5 Installation of machines 5.1 Preparation before installation 5.1.1 Requirement of operating site... -
Page 12: Installation
Fig. 5-1 Min. installation space 5.2.2 Installation The machine is delivered in a wooden case. The machine should be placed on a level groundsill or table and secured by four bolts (M10). Fig. 5-2 Installation dimensions 5.2.3 Connection of electrical suppl We recommend using cable of at least H07RN 1.5mm to connect with the plug. -
Page 13: Trial Running And Operation
Fig. 5-3 Dust collection sketch 6 Trial running and operation 6.1 Structure Belt grinder is consisted of main body and its racks. The main body can swivel and be adjusted in a certain angle range around the racks. It is in operation by a grinding wheel which is directly driven by a motor. -
Page 14: Trial Running
Belt tension release lever Plug, stop&start button 6.3 Trial running Before using the machine, the insulation resistance between parts and outside cover must be measured. Refer to EN 60204-1:2006 for detail information. - Ensure the stability of the machine before using the machine. - Turn the band wheel and other parts by hand to watch whether it feels smoothly and deftly, and listen whether there is bumping sound. -
Page 15: Adjusting
6.5 Adjusting 6.5.1 Angle Adjust The handle of the belt grinder is in loose condition in a certain angle range, then turn the handle firm to avoid unexpected accident. 6.5.2 Belt slant Adjust If the belt is deviated, adjust the belt deviation by rotating the hand wheel after loosening the screw. -
Page 16: Maintenance
7 Maintenance Before maintenance, unplug the plug firstly from the incoming power source. Adjustment, lubrication and maintenance points must be carried out while machinery is at a standstill. Normal maintenance of the contact wheel and the steering roller is needed. The outside cover of belt grinder and the grinding scrap and dust in outlet should be frequently cleaned and keep these places tidy. - Page 17 Normal wear and tear, misuse, abuse and neglect are excluded and the machine should not have been engineering machines, Axminster Air compressors and Air Tools, and bench top grinders - no modified in any way. Please do not attempt to service the product without first contacting us; we are registration necessary just proof of purchase.
