User Manual
Sartorius Cubis Series
Precision and Analytical Balances
Electronic Semimicro, Micro,
MSA Models

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MSA6.6S and is the answer not in the manual?

Questions and answers

Related Manuals for Sartorius MSA6.6S

Summary of Contents for Sartorius MSA6.6S

  • Page 1 User Manual Sartorius Cubis Series Precision and Analytical Balances Electronic Semimicro, Micro, MSA Models...

  • Page 2: Table Of Contents

    Contents Contents Notes on Using this Manual ..... . 3 Weighing in Percent ......102 Safety Instructions .

  • Page 3: Notes On Using This Manual

    Read the safety precautions carefully. This manual is part of the product. Keep it in a safe and easily accessible location. If the manual should be lost or misplaced, please contact Sartorius for a replacement or download the latest manual from our website: www.sartorius.com...

  • Page 4: Safety Instructions

    The operator shall be solely responsible for any modifications to the equipment and for connecting any cables or equipment not supplied by Sartorius. Information on operational quality is available upon request from Sartorius. You should only use peripherals and options supplied by Sartorius.
  • Page 5 Do not open the balance housing. If the seal is broken, this will result in forfeiture of all claims under the manufacturer’s warranty. The device may only be opened by specialized personnel trained by Sartorius. Disconnect the balance from the wall outlet prior to moving the device.

  • Page 6: Intended Use

    Safety Precautions Intended Use Cubis models are high-resolution balances. They were specially Cubis models are designed specially for use in research, developed for exact determination of material mass in liquid, education and day-to-day laboratory tasks in science and paste, powder or solid form. industry.

  • Page 7: Overview Of Models

    General View of the Equipment and Equipment Supplied General View of the Equipment and Equipment Supplied Balances with a readability of 0,01 mg Pos. Description Upper sliding draft shield panel/Handle Back panel Weighing pan Pan support (not for MSx225.../MSx125... models) Shield plate Pan retainer Right sliding panel/Handle...

  • Page 8: Getting Started

    Getting Started Getting Started Unpacking the Equipment Open the box. Use both hands to lift the balance, with the packaging, out of the cardboard box. Place the packaging with the balance on the floor. Remove the top part of the packaging. Cubis MSA User Manual...
  • Page 9 Getting Started Balance with Draft Shield Remove the packages (containing draft shield panels, weighing pan, pan support, AC adapter, etc.) from the lower packaging and place them to one side. Use both hands to lift the balance out of the packaging. Exercise caution to avoid glass breakage.
  • Page 10 Getting Started Assembly Installing the Analytical Draft Shield, Assembling the Balance (Draft shield designation: DA, DI, and DU) Fit parts onto the balance as shown in the picture. 1. Shield plate 2. Pan support (not for MSx225.../MSx125... models) 3. Weighing pan Slide the upper draft shield panel into the guide rails from the rear.
  • Page 11 Getting Started Installing the Draft Shield on Milligram Balances, Balance Assembly (Draft shield designation: DE) Fit parts onto the balance as shown in the picture. 1. Shield plate 2. Pan support 3. Weighing pan Assembly of Milligram Balances without Glass Draft Shield (DR Option): Balance Assembly Fit all components listed below onto the balance in the order given: 1.
  • Page 12 Getting Started Slide the upper draft shield panel into the guide rails from the rear while pressing the locking tab. Slide the side draft shield panel into the guide rails from the rear while pressing the locking tab. 1. Right draft shield panel 2.
  • Page 13 Getting Started Place the pan support diagonally and press down lightly. 1. Pan support Carefully turn the pan support clockwise until the two buttons engage. The pan support is now attached. 2. Insert the shield plate/draft shield. 3. Place the weighing pan on the pan support. y This completes the balance assembly.
  • Page 14 Connect the weigh cell and electronics module using the connection cable. Please check the plug contacts to ensure a proper connection. MSx6.6S/3.6P/2.7S: Connecting the Weigh Cell to the Evaluation Unit MSA6.6S/3.6P/2.7S: MSx6.6S/3.6P/2.7S: Install the following parts in the order listed: 1. MSA2.7S model: bush 2.
  • Page 15 Getting Started Setting up a filter weighing pan for left-handed users: Remove the draft shield cover Unscrew the pin and move from the right to the left side Turn draft shield parts approx. 90 degrees to the left (loosen knurled screw) Cubis MSA User Manual...

  • Page 16: Transporting The Balance

    Getting Started Moving the Balance Transporting the Device over Short Distances Exercise caution to avoid glass breakage. Never lift and carry the balance by its draft shield. Carry as shown in the illustration. Carry as shown in the illustration. Storage and Shipping Conditions –...

  • Page 17: Installation Instructions

    – If the stated supply voltage or the plug design of the power cord does not comply with your country’s standard, please inform the nearest Sartorius representative or your dealer. – The power connection must be made in accordance with the regulations applicable in your country.
  • Page 18 Getting Started Analytical and precision balances: 1. Plug the DC supply cable of the AC adapter into the power socket of the balance and tighten the threaded fitting. Balances with a readability of 0.01 mg 1. Plug the DC supply cable of the AC adapter into the power socket of the electronics module and tighten the threaded fitting.
  • Page 19 Getting Started Leveling the Balance, Setting the Level Indicator Leveling the balance compensates for slant or unevenness at the place of installation. The balance must be perfectly horizontal to ensure consistent, reproducible weighing results. All models are equipped with an electronic tilt angle detection feature. If the balance is not level, all balance models issue an alert on the display.

  • Page 20: Anti-Theft Locking Device

    Getting Started Connecting Electronic Devices (Peripherals) Make absolutely sure that the device is unplugged from the power supply before connecting/disconnecting any peripheral device (printer, scanner, PC) to or from the data port. A device connected to the power supply should never be opened. Anti-theft Locking Device (Accessory) Balances with a readability of 0.01 mg An anti-theft locking device can be installed to the back of the balance if...
  • Page 21 Getting Started Modifying the Balance Setting Up the Display and Control Unit at the Place of Use The display and control unit can be removed for all models to enable the operator to customize the work space. Removing the Retainer with the Display and Control Unit Remove all items (such as weights) from the draft shield.
  • Page 22 Getting Started Remove the upper draft shield panel. Models with the analytical draft shield (left illustration). 1. Press on the locking tab. 2. Remove the panel. Models with the milligram draft shield (right figure): 1. Press on the locking tab. 2.
  • Page 23 Getting Started Replace the upper and side shield panel. 1. Upper draft shield panel 2. Right draft shield panel 3. Left draft shield panel Level the balance. Leveling the balance compensates for slant or unevenness at the place of installation. The balance must be perfectly horizontal to ensure consistent, reproducible weighing results.
  • Page 24 Getting Started Remove the two retaining screws. Remove the display and re-insert both screws back into their holes. Carefully pull the cable connected between the display and control unit from the retainer. Determine the required cable length. Return the balance to an upright position and fit the parts onto the balance. 1.
  • Page 25 Getting Started Semi-microbalances: Attaching the Display and Control Unit to the Electronics Module (MSx225.../MSx125... models) The display and control unit can also be attached to the electronics module if required for operation. Turn over the balance and place it on a soft surface. Remove the connection cable from the cable channel: Remove two screws from beneath the weigh cell and detach the plate.

  • Page 26: Below-Balance Weighing

    Getting Started Attach the display and control unit to the electronics module: Reattach the two retaining screws. Open the slot for the connection cable on the electronics module: Remove the screws from beneath the electronics module and detach the plate. Connect the display and control unit to the electronics module: Plug in the connection cable.
  • Page 27 Getting Started 2. Push the cover of the below-cell weighing port to one side. 3. Carefully screw on the below-cell weighing hook. Do not screw it in too tightly, as this could damage the thread or the balance. Install a draft protection shield. Attach the sample (e.g., using a suspension wire) to the hook.
  • Page 28 Getting Started Using the Cable Opening of the Draft Shield Models with an analytical draft shield have an opening for passing a cable (for example, for a temperature sensor) through to the interior of the weighing chamber. 1. Lift the locking tab on the rear panel of the analytical draft shield. 2.

  • Page 29: Using The Balance

    Using the Balance Using the Balance Turning the Balance On/Off Make sure the balance has been installed and put into operation in accordance with the installation instructions. Press the on/off key A on the control unit. y The start screen appears briefly on the display, then the user interface appears. On subsequent starts, the most recently active user profile and task are opened (if at least one user profile has been set up).

  • Page 30: Using The Display And Control Unit

    Using the Balance The System Settings (Menu) contains all basic settings and parameters used to operate the balance that affect the entire balance operation. They can also be used for creating new tasks. The Wizard You can choose between two display types in several menus: The overview lists all parameters with their set options.

  • Page 31: Quick Guide: First Weighing

    Using the Balance Display and Control Unit The tilt angle of the display and control unit can be set as desired to enable optimal readability for changing working conditions. The color and brightness of the display can also be changed to match the illumination in the room (see “User Management” and “System Settings”).

  • Page 32: User Interface (Touch Screen)

    Using the Balance User Interface (Touch Screen) Many operating steps are carried out via the display using the touch screen. The display varies depending on whether the application software is in operating mode or a menu is currently open (setup mode). Display in Operating Mode Function display: Current task (here: Step 1 of 2) Verified balances feature the...

  • Page 33: Using The Touch Screen

    Using the Balance Display in Setup Mode Interaction area with instructions on how to proceed The orientation line shows the current path Working environment with selectable options Toolbar with the available buttons Symbol indicating which menu (TASK, USER or MENU) is currently open Scroll bar to page through the selection area Using the Touch Screen Equipment may be damaged by objects with points or sharp edges...

  • Page 34: Activating/Switching Users

    Using the Balance Entering Text and Numbers A keyboard will appear whenever you have to enter text and numbers. A cursor appears in the entry line above the keyboard. Select the desired character with a light touch. y The entered text will appear in the entry line. Press the shift button to change the input mode between uppercase letters, lowercase letters, numbers and the complete character set with special characters.

  • Page 35: System Settings (Menu)

    System Settings (Menu) System Settings (Menu) This menu summarizes all the balance settings relevant to the device. Basic settings can be made here that immediately affect the device. Changed settings do not affect previously defined tasks and user profiles. All system settings are user-independent, i. e. they are valid for all users.

  • Page 36: Leveling The Balance (Q-Level)

    System Settings (Menu) Leveling the Balance (Q-Level) It is essential for exact weighing results that the balance is absolutely level. The front leveling feet can be used to level out small tilts of the floor. Depending on the model, the balance is equipped either with leveling feet that can be operated manually or motorized leveling feet.

  • Page 37: Configuring Calibration/Adjustment

    System Settings (Menu) Configuring Calibration/Adjustment Setting options are divided into the following sections: – Defining calibration/adjustment functions – Defining external check weights – Setting isoCAL fully automatic adjustment function Enter the desired settings in all submenus. To save settings, touch Save Factory settings are marked with an *.

  • Page 38: Timer-Controlled Actions

    System Settings (Menu) Timer-controlled Actions You can program the following actions so that they are run automatically at pre- specified times: – Display a message and execute a command (see example below) – Execute a command – Show a message (e. g. a prompt as a reminder) The available actions are displayed.
  • Page 39 System Settings (Menu) Enter the text you want to be displayed during the action (e. g. Timer-controlled adjustment). Enter the time when the action should be performed for the first time. Define the time interval at which you want the action to be performed repeatedly (e.

  • Page 40: Displaying Device Information

    System Settings (Menu) y The programmed action is displayed in the list of actions. Here you can edit them again at any time. Displaying Device Information You can view various information here. Select the information that you want to view. Viewing Basic Information Here you can find all information about manufacturer, model, serial number, host name and IP address used.

  • Page 41: Alibi Memory

    System Settings (Menu) Alibi Memory The alibi memory contains (stores) weighing results with date and time and process number. This takes place every time a print event is triggered (e. g. by pressing P). Tare and input values are also saved. The alibi memory can therefore be used as a replacement for a log printer.
  • Page 42 System Settings (Menu) Searching for Data Records by Date y An overview appears in the display. Limit the search by selecting year, month or day. Touch Next y The desired data are displayed. Using the buttons, you can display more data records from the Prev.
  • Page 43 System Settings (Menu) y The desired data record appears in the display. Viewing Information on the Alibi Memory and Available Memory Space All important status information on the alibi memory are shown here. You can view the percentage of storage capacity utilized and an estimation of the number of data records that can still be stored.

  • Page 44: Device Parameters

    System Settings (Menu) Device Parameters Here you can change the following equipment settings and update the software. All settings are user-independent. – Balance parameters – Data output – Date and time – Display and control unit properties – Touch screen adjustment –...
  • Page 45 System Settings (Menu) Setting up Q-Level Leveling Function You can configure the leveling function here. Leveling notice : The prompt to perform leveling is omitted. : As soon as leveling is required, the tag Level me appears and flashes. : As soon as leveling is required, the tag Level me appears and flashes.
  • Page 46 System Settings (Menu) Configuring Data Output (Print Parameters) Here you can configure all settings for printing and data output. Several of these settings depend on the interface configuration (see chapter Interfaces). Factory settings are marked with an *. In order to receive detailed information on the individual setting options, touch Info.
  • Page 47 System Settings (Menu) Adjusting the TouchScreen Here you can customize the marker button on the touch screen (finger pressure, angle of touch, etc.). Follow the instructions on the display. Configuring Interfaces and Network Settings Here you can configure interfaces (serial ports and network) and make settings for the network.
  • Page 48 System Settings (Menu) Configuring the Network Interface (Ethernet) For more information on network operation, see chapter Interfaces, section Network Interface. Select operating mode for the network interface. (extended Sartorius communication/ (Sartorius standard protocol)/ Select connection type. connection Configure the local TCP port.
  • Page 49 System Settings (Menu) Select the ported hardware device or control function. During checkweighing, the control outputs have no function when set to: – Foot switch YPE01RC – Control inputs Define the settings for the control inputs/outputs. Off, no function/TARE key/PRINT key/Cal./adj. key/Zeroing/taring To save the settings, touch Save.
  • Page 50 System Settings (Menu) Configuring “Print to file” Purpose: – Transferring a print file in TXT or CSV format to a SD card or FTP server. – Viewing a print file directly in an Internet Browser. Select Specify the file format. Print to CSV file: In addition to the SBI output (like in the TXT file), three additional columns are also written to the file: ID, Value and Unit.
  • Page 51 System Settings (Menu) Configuring data transfer settings for a FTP server Specify the data transfer settings to a FTP server. Enter the following parameters for the FTP server: IP address, port, FTP user name, FTP password, subdirectory also optional. The user must have the rights to create directories on the FTP server For more information about displaying a print record via an Internet browser, go to Interfaces, “Remote Control of the Balance from a PC via Ethernet”...
  • Page 52 System Settings (Menu) Restoring Factory Settings You can reset all settings individually to the factory settings at any time. Use the cursor softkeys to navigate through the submenu to Mark any settings you want to reset and select Confirm the reset when prompted. Installing the Motorized Draft Shield (Optional) On balances equipped with a motorized draft shield, the control unit has buttons on the right and left sides.
  • Page 53 System Settings (Menu) Models with a rotation draft shield (MSx6.6S/3.6P/2.7S): Same function Separate function (one opening angle) (2 opening angles) Defining the Manually select the – opening width desired opening angle Touch the O key 1) Touch the left O key: 1) Open to the previously selected opening angle Opens 260°...
  • Page 54 System Settings (Menu) Configure the automatic mode for the draft shield. : Automatic mode is off. : The draft shield doors are closed in automatic mode while the function is executed, and then the doors re-open. : The draft shield doors are closed in automatic mode while the function is executed.
  • Page 55 System Settings (Menu) Installing the Ionizer (Optional) If your balance is equipped with an ionizer module, you can configure the basic settings for the ionizer module here. During any Electrostatic Charge Eliminator task, you can change these settings as needed. Define ionizer function.

  • Page 56: Task Management

    You can also load preconfigured tasks to the balance: 1) Unpack the desired ZIP archive file to the root directory (Root Dir) of a SD card after download from the Sartorius homepage or from the included CD. 2) In the Balance menu, submenu “Import/Export data”: Execute “Import files from the SD card.”...

  • Page 57: Using Applications With The Factory Settings

    Task Management Using Applications with the Factory Settings Each application comes with specific factory settings. If you want to apply these settings unchanged, you can do this quickly during configuration: Open Task Management and touch Select y An application list is displayed. Select the application you want to assign to the new task.
  • Page 58 Task Management The basic process for task configuration is as follows: 1. Create new task. 2. Select application. 3. Review all of the following prompts and configure your own settings as required. 4. Perform steps 2 and 3 for additional applications if you would like to combine multiple applications.
  • Page 59 Task Management Example: Creating a task Open Task Management and touch y The list of options is displayed. To define a new task, touch y An application list is displayed. To view all applications, use the scroll bar on the right. Select the application you want to assign to the new task.
  • Page 60 You will be routinely prompted for the printer settings with every new task you create and can be modify them. Printout (example): Print events: Printout content (record) Print elements ------------------ Start task GLP header 21.02.2011 09:17 SARTORIUS Mod. MSA 224S Ser.-Nr. 12-34-56 ------------------ Laboratory Start task Operator name technician In this example: Product...
  • Page 61 Task Management Configuring Printouts in the System Settings (Menu). The settings can only be modified as long as no task has been activated (ready to start) in the operating mode. Make sure that basic weighing is active in the operating mode. Toggle to the System Settings menu.
  • Page 62 Task Management Standard printout parameters when the balance is first delivered When the balance is first delivered, two interfaces are configured: The peripheral port (Com A) is configured for one printout, the US interface (Com B) is configured for data with a PC per SBI protocol. Interfaces: Com A (peripherals port) and Com B (US/PC) Protocol for Com A: Print (pre-set by the interface configuration) Standard for output to Com A: Standard 1 (measured value only)
  • Page 63 Task Management Example: Automatic printout to peripherals port; remote display operating mode y At a pre-set interval, automatic printouts should be sent to the ported peripheral device as remote display. Interface: Com A (peripherals port) Protocol: Remote display (toggling to the interface configuration possible) SBI Printout: Automatic printout Criterion: Without stability, at stability or after load change Format: 22 characters (for applications)
  • Page 64 Task Management Print events You can define one or several events that trigger a printout. The number of selectable print events depends on the selected application. Basic Weighing: , after calibration/adjustment For Calculating applications the following is additionally possible: For logging applications the following is additionally: The application-specific print events cannot be configured in the Basic menu but only when you create a new task.
  • Page 65 Task Management Automatic Tare after Printing Should the balance be tared automatically after each printout? Setting Options for SBI Output SBI Output Mode How should SBI printout be output? : Printout generated by pressing the PRINT P key or by ESC command via the interface : The printout is generated automatically in the weighing cycle Stability Parameter for Printout...

  • Page 66: Combining Applications Into One Task

    Task Management Combining Applications into one Task You can combine applications that are saved in the balance into one task. The following rules need to be followed (see table below): – An application can only be combined with applications from different groups. –...

  • Page 67: Executing Tasks

    Task Management Executing Tasks After all required settings have been configured, you can now start and execute a task. If you haven’t already done so, go to Task Management. y The task selection is displayed. Touch the desired task. If the desired task is already selected (dark background and arrow on the left), touch Start y The program switches to operating mode and the selected task is activated.

  • Page 68: Weighing

    Weighing Weighing Purpose: Weight determination within the scope of the device-specific weighing capacity (see Specifications). Combination options: Mass unit conversion, second tare memory and individual identifiers, (SQmin function, DKD measurement uncertainty). Configure Task: My Weighing Weighing without combining it another application: The settings for Weighing are displayed.
  • Page 69 Task Management Opening and closing the rotation draft shield (models MSx6.6S/3.6P/2.7S): Defining the opening width: Touch y The settings for the opening angle are displayed. Check the settings and change as required. Draft shield opens according to the opening angle setting. Cubis MSA User Manual...

  • Page 70: Mass Unit Conversion

    Mass Unit Conversion Mass Unit Conversion Purpose: The weight value can be displayed in up to a maximum of five different units in succession (see table below). However, the desired weight units must be assigned beforehand (1 through 5). Combination options: Second tare, (SQmin function, DKD measurement uncertainty) Not all units programs can be selected on balances used as legal measuring instruments.
  • Page 71 Mass Unit Conversion Configure Task: Mass Unit Conversion Select the desired number of units (max. 5) to be used to display the weighing results. y Now you will be prompted to enter the display accuracy and weight units of all the desired units one by one.
  • Page 72 Mass Unit Conversion Execute Task: Mass Unit Conversion If you haven’t already done so, go to Application Management. y The task selection is displayed. Touch the desired task. If the desired task is already selected, press Follow the instructions on the display. To change the displayed unit, touch Select the unit to be used to display the weighing results.

  • Page 73: Minimum Sample Quantity Sqmin

    Minimum Sample Quantity SQmin Minimum Sample Quantity SQmin Purpose: This application is used to compare the measured weight value directly with the defined minimum sample quantity (SQmin = sample quantity minimum). This ensures that weighing results are within tolerances defined by your quality assur- ance system.
  • Page 74 Minimum Sample Quantity SQmin Execute Task: Minimum Sample Quantity SQmin If you haven’t already done so, go to Application Management. y The task selection is displayed. Touch the desired task. If the desired task is already selected, press y When you start a task with the SQmin function, the defined SQmin value is shown on the display.

  • Page 75: Individual Identifiers

    Individual Identifiers Individual Identifiers Purpose: You can define identifiers for the following print jobs: – Printout by pressing PRINT – Task start – Task end – Initialization (for calculating applications only) – Result (for calculating applications only) – Component (for logging applications only) –...
  • Page 76 Individual Identifiers y In the example, a unique title has been defined for each identifier. y Enter the desired value (text) for each Identifier . Select the identifiers that can be entered for executing the task. Select whether or not the variable identifiers should be counted up automatically.
  • Page 77 If the desired task is already selected, press y The defined identifiers are displayed (cf. example above). Touch y Now the predefined lines are printed when the task starts: Firma: Sartorius Strasse: Weender Landstr. Ort: Goettingen Place the sample on the weighing pan and press the PRINT key y The identifier for the printout is displayed and can be changed, if necessary.

  • Page 78: Density Determination

    You can determine the density and volume of liquid, solid or pasty materials. Combination options: Checkweighing, statistics, second tare or individual identifiers. Requirements: You require the Sartorius YDK01MS density determination kit or your own customer-specific set. The basic calculations for density determination are described at the end of this chapter. Features...
  • Page 79 Density Determination Configure Task: Determining the Density of a Solid You can choose from two methods to determine the density of a solid: Buoyancy or displacement. Select the method that you want to use: Buoyancy or displacement. Select the density kit you want to use. For measuring with the YDK kit : If you want to use another kit : If you do not want to use any kit.
  • Page 80 Density Determination Configure Task: Determining Density of Liquid Select Select the measurement conditions : Measurement takes place under standard laboratory conditions (20°C room and material temperature). : If the measurement is to take place under deviating condi- tions. Enter the required values. Enter the volume of the glass plummet.
  • Page 81 Density Determination Check all settings in the overview and change individual parameters as required. y An overview of all settings is displayed. Check all settings and change as required. y A message asks whether you would like to add another application. If required, select additional applications to be combined.
  • Page 82 Density Determination Calculation Basis for Density Determination The density determination application is based on the equations: Density of sample ( ) Density of buoyancy liquid Weight of sample in air Weight of sample in liquid (for determining density of liquids, buoyancy and displacement) Weight of fill medium (for pycnometer) Weight of sample and fill medium (for pycnometer)

  • Page 83: Statistics

    Statistics Statistics Purpose: Saving and statistical analysis of weight values and other calculated values. The values are generated as results: – Transaction counter – Sum of all values – Average value – Standard deviation – Lowest value (minimum) – Highest value (maximum) –...
  • Page 84 Statistics Define when the number of measurements (items) will be defined. The item number is defined beforehand. Enter the item number when you execute the task. Define whether or not automatic taring takes place after the transfer. y An overview of all settings is displayed. Check all settings and change as required.
  • Page 85 Statistics Place the next sample on the weighing pan and touch Continue with all other samples in the same way. You can remove each last value from the statistics by touching During the task, you can have the result displayed at any time by touching y Once all intended samples have been weighed, the result is displayed.

  • Page 86: Calculation

    Calculation Calculation Purpose: This application is used to calculate the weight value using an algebraic formula that you define yourself. You can define a fixed formula or one that you can change while executing the task. On balances used as legal measuring instruments, follow the directions in the “Executing tasks”...
  • Page 87 Calculation Enter a name for the event print e. g. “Area” (max. 6 characters). Define how many decimal points should be used for the results: Enter the unit to be used for the results (max. six characters, e.g. cm y An overview of all settings is displayed. Check all settings and change as required.
  • Page 88 Calculation Examples of Calculation Formulas 1) Diameter determination for cylindrical bodies Definition: Diameter = 2 V (W / ( l Rho)) with: V = Square root W = weight value in g = 3.145 l = length of sample in cm Rho = density of sample in g/cm (e.g.
  • Page 89 Calculation Executing a Task: Calculation “Air buoyancy correction” If you haven’t already done so, go to Task Management. y The task selection is displayed. Touch the „Air buoyancy correction“ task from the Task menu. y The formula for the air buoyancy correction is already defined. Enter the density of the sample via „Variable X,“...
  • Page 90 Calculation 3) Diameter determination Purpose This application is used to determine the diameter of round wires and metal threads (cylindrical solid bodies). For example, for use in determining the diameter of filaments. The density and length of the sample is required for calculating the diameter.
  • Page 91 Calculation Executing a Task: Calculation “Diameter determination” If you haven‘t already done so, go to Task Management. y The task selection is displayed. Touch the „Diameter determination“ task from the Task menu. y The formula for diameter determination and the density of the sample (8.3 g/cm ) are preset..
  • Page 92 Calculation Execute Task: Calculation If you haven’t already done so, go to Application Management. y The task selection is displayed. Touch the desired task. If the desired task is already selected, touch Start When you want to work with a variable formula, you can now enter or change the formula.

  • Page 93: Averaging

    Averaging Averaging Purpose: This application is used for moving samples (e. g. live animals) and for weighing in unstable environments. A measurement cycle is automatically carried out with a defined number of measurements for each object to be weighed. The individual measurements are averaged and this average is displayed as the result.
  • Page 94 Averaging Enter the range of the unrest for the start of the measurement: This entry estimates the strength of unrest that is caused by the activity (e. g. animal movement). You can use the rough estimation or a more detailed estimation using percentages.
  • Page 95 Averaging Define whether or not the weighing results should be calculated with an additional factor and how this factor should be applied. You must now enter this factor. . You must enter this factor when you execute the task. Example: Each animal should receive a food supplement of 50 mg per kg of body weight.
  • Page 96 Averaging Execute Task: Averaging with Manual Start If you haven’t already done so, go to Application Management. y The task selection is displayed. Touch the desired task. If the desired task is already selected, press When you are using a variable number of measurements, enter the desired number.
  • Page 97 Averaging Execute Task: Averaging with Automatic Start If you haven’t already done so, go to Application Management. y The task selection is displayed. Touch the desired task. If the desired task is already selected, press When you are using a variable number of measurements, enter the desired number.

  • Page 98: Formulation

    Formulation Formulation Purpose: This application is used to weigh while adding several components consecutively. The balance is tared automatically after each component. The weight values of all individual components as well as the total weight results are recorded and can be logged.
  • Page 99 Formulation For all formulations, the following applies: – The individual components can be stored manually or automatically (first reproducible value). – If automatic storage of values was selected, the minimum load is determined when the task is created. – After weighing the first component, the button is displayed.
  • Page 100 Formulation Once you fix the components, now define now the unit: (Formulation 1) (Formulations 2 and 3) (Formulations 4 and 5) Touch Enter the number of components. An overview of all settings is displayed (here, Formulation 2 as an example). Check all settings and change as required.
  • Page 101 Formulation The evaluation is displayed as soon as all components of the formulation have been added and weighed. You can also see the complete list here when you touch the scroll bar. To delete the last component, touch To go to the parameter page, touch To restart the formulation (with changed parameters), touch Print example: ---------------------...

  • Page 102: Weighing In Percent

    Weighing in Percent Weighing in Percent Purpose: This application is used to determine the percentage share or the percentage difference of the sample related to a reference weight. Options: You can enter a fixed reference weight or a reference percentage. Combination options: Checkweighing, timer controlled functions, totalizing, statistics, formulation, sec- ond tare, individual identifiers, (SQmin function, DKD measurement uncertainty)
  • Page 103 Weighing in Percent Define which percent calculation should be used. Example: Weight value = 10 g, reference weight = 50 g : The result is the percentage share of the weight value of the reference weight (Rest: Weight value/reference weight * 100%;in the example: 20%) : The result is the percentage loss between the weight value and the refer- ence weight (loss: weight value - reference weight / reference weight * 100%;...
  • Page 104 Weighing in Percent Execute Task: Weighing in Percent If you haven’t already done so, go to Application Management. y The task selection is displayed. Touch the desired task. If the desired task is already selected, touch If required, enter the reference percentage (e. g. 100%) or the reference weight. Place the sample on the weighing pan.

  • Page 105: Timer-Controlled Functions

    Timer-controlled Functions Timer-controlled Functions Purpose: This application is used to trigger individual balance functions automatically at a specific time or after specific time intervals. The time or interval must be within 24 hours (1 day). Options: You can select the following functions: - Acoustic signal - Lock in readout - Automatical printout of the display value...
  • Page 106 Timer-controlled Functions Specify whether or not there should be an automatic restart after the timer-controlled function has been triggered. The timer is restarted as soon as the timer controlled function has been carried out. y An overview of all settings is displayed. Check all settings and change as required.

  • Page 107: Totalizing

    Totalizing Totalizing Purpose: Adding up weight values and calculating values. The weight values of all individual components are recorded and can be logged. The weight values and the component counter are saved in protected memory so that an interrupted totalizing process can be continued after the balance has been turned off or after a power failure.
  • Page 108 Totalizing Define when the number of measurements (items) will be defined. The quantity of items is defined beforehand. Enter the quantity of items when you execute the task. Define whether or not automatic taring should take place after storing the value.

  • Page 109: Dkd Measurement Uncertainty

    DKD Measurement Uncertainty DKD Measurement Uncertainty Purpose: This application is used to ensure that the measurement uncertainty is displayed dynamically so that it conforms to the data documented on the DKD calibration certificate. Requirements: The function can only be used when the balance has been prepared for this before- hand by a service technician.
  • Page 110 DKD Measurement Uncertainty An overview of all settings is displayed. Check all settings and change as required. A message asks whether you would like to add another application. If required, select additional applications to be combined. y Now you will be prompted to configure the weighing and printing functions. Check all settings and change as required.

  • Page 111: Second Tare Memory (Preset Tare)

    Second Tare Memory (Preset Tare) Second Tare Memory (Preset Tare) Purpose: This application is used to define the second tare value. As soon as a second tare value is used, appears on the display for the respective net value. Options: You can either use a weight value or enter a numerical value as a second tare value.
  • Page 112 Second Tare Memory (Preset Tare) y The stored weight value is displayed as the second tare value. is also displayed next to the current weight value. To delete the tare memory, touch Entering a Numerical Value as a Second Tare Enter the tare value for (e.g.

  • Page 113: Parts Counting

    Parts Counting Parts Counting Purpose: This application is used to determine the number of objects which each have approximately equal weight. This saves you from having to count individual parts. Options: You can calculate or enter the piece weight of individual objects. Combination options: Checkweighing, timer-controlled functions, totalizing, statistics, formulation, mass unit conversion, second tare memory, individual identifiers, (SQmin function, DKD...
  • Page 114 Parts Counting Define the accuracy to be used for the weight value. : As displayed With one decimal place more than in the display With two decimal places more than in the display Only with calculation of piece weight: Define whether or not the piece weight should be updated when counting. y An overview of all settings is displayed.
  • Page 115 Parts Counting y The weight value for the reference objects is displayed. To determine the average piece weight, touch y The reference piece count and the average piece weight are displayed. You can now begin with the parts counting of unknown amounts. Place any amount of the objects on to the weighing pan.
  • Page 116 Parts Counting Execute Task: Parts Counting by Entering the Piece Weight If you haven’t already done so, go to Application Management. y The task selection is displayed. Touch the desired task. If the desired task is already selected, touch y The last used piece weight wRef is displayed. Enter the piece weight of the reference object (e.

  • Page 117: Checkweighing

    Checkweighing Checkweighing Purpose: This application is used to check a weight value using preset control values. Options: Control values can be exact target values or tolerance range limit values within which the check value must lie. The check results are shown on the display. They can also be used for further electronic editing by activating the control ports at the data output.
  • Page 118 Checkweighing Define how the ports should be activated depending on the check results : Ports are only activated when the results are within the checkweighing range. The ports are always activated with each weight value. : The ports are only activated as soon as the balance becomes stable and the results are in the checkweighing range.
  • Page 119 Checkweighing Execute Task: Checkweighing If you haven’t already done so, go to Application Management. y The task selection is displayed. Touch the desired task. If the desired task is already selected, touch Define check values by entry: Touch the input field Setp and enter the target. Touch the input field Min or Max and enter the minimum or maximum check values.
  • Page 120 Checkweighing y The test results are displayed. If the results are within tolerance, the weight results will always be displayed. In addition, they appear in green on in the graphic scale. If the results are outside of the tolerance, the weight results are displayed in red (above maximum) or yellow (below minimum) on the graphic scale.

  • Page 121: Importing/Exporting Data

    Importing/Exporting Data Importing/Exporting Data You can use an SD memory card to transport and exchange data (import/export). This card is required when you want to save data externally or when you want to exchange data with other balances. For example, you can easily copy user profiles to several balances.
  • Page 122 Importing/Exporting Data Select the menu item Insert the SD card into the slot as shown in the picture. Select whether you wish to export or import data. Export Select the data you wish to export and press If required, change the name of the export folder and touch The data is copied to the SD card.
  • Page 123 All previous data will be saved in the new format. Check your settings after importing the data (Menu, TASK and USER). If the XML files continue to cause problems, contact your local Sartorius service center. Cubis MSA User Manual...

  • Page 124: Calibration And Adjustment

    Calibration and Adjustment Calibration and Adjustment Background During calibration, a check weight is used to determine how much the displayed value deviates from the actual measurement value. This deviation is compared with an entered target value and this deviation is then eliminated by a subsequent adjustment of the balance.

  • Page 125: Calibration/Adjustment Using External Check Weight

    Calibration and Adjustment y The procedure will be executed. Wait until calibration/adjustment has been completed. y The results are displayed again after the procedure is completed. To return to operating mode, touch Calibration/Adjustment Using External Check Weight An external check weight is required for this function. Please note the tolerance of the check weight being used.
  • Page 126 Calibration and Adjustment y Lastly, the results are shown on the display. To return to operating mode, touch Cubis MSA User Manual...

  • Page 127: User Management

    User Management User Management You can configure the following settings in this menu: – Creating new user profiles (only possible as administrator) – Editing user profiles (modify, copy, delete, change and delete passwords, depending on user rights) – Activate users User Management The user administration allows for defining of users with distinct sets of rights: the Administrator and multiple users.
  • Page 128 Steps 2 to 4: Setting the color and brightness of the display To select the background color, touch the desired color. The standard Sartorius factory setting for the background color is blue. y The display changes to the color selection for the user field (see “Display in Operating Mode”).
  • Page 129 (for example, if the user forgets the password) and assign a different password. The Administrator can remove the password protection so that a new password can be set, if desired. If the administrator forgets the password: Please contact your Sartorius Service Center Step 7: Check all settings Use the scroll bar or press the down arrow to view all settings.

  • Page 130: Activating Users

    User Management y The program switches to user selection. The newly created user profile is placed at the end of the list. When you want to activate a new user, just touch the button with his name. y The program switches to the operating mode and the selected user is activated.

  • Page 131: Editing User Profiles

    User Management Editing User Profiles If you have not already done so, open the User Management menu by touching the USER H key. To go to the Edit menu, touch in the user selection. y The selection of edit functions is displayed. Which options for editing user profiles are available depends on whether or not you have Administrator rights.
  • Page 132 User Management Deleting User Profiles This function can only be carried out by an administrator. Select y All available user profiles are displayed. Select the profiles that you want to delete and touch If you want to delete all profiles, touch y All profiles selected for deletion are displayed in a security prompt.

  • Page 133: Interfaces

    – Printer output – SBI (Sartorius Balance Interface): Sartorius standard protocol for output to a PC or control unit. This simple ASCII-based protocol allows you to use ESC commands from your PC to control the basic weighing functions. xBPI (eXtended Balance Processor Interface, also called X-Bus): binary protocol –...

  • Page 134: Usb Port (Pc)

    Interfaces USB Port (PC) Purpose Any Cubis balance can be connected to a PC equipped with a USB port. A virtual serial interface (virtual COM port) is set up as a device type at the USB port. This virtual serial interface is identified und operated by the application program. The protocols xBPI, SBI and SICS can be transferred via the USB port.

  • Page 135: Ps2 Interfaces For Bar Code Scanner Or Keyboard

    Interfaces Open the setting for the USB serial port in the Windows® system control panel: – START > My Computer > Control Panel – System > Hardware > Device Manager Open the Connections submenu. Double-click on USB Serial Port. Select Port Settings / Advanced. Change Latency Time Open the settings for the USB serial port, following the above instructions.

  • Page 136: Interfaces (Rs-232) 25-Pin And 9-Pin

    Interface: RS-232 cables purchased from other manufacturers often have incorrect pin assign- ments for use with Sartorius devices. Failure to do so may damage or destroy your weighing system and/or peripheral devices! Be sure to check the pin assignments before you connect cables purchased from other manufacturers.
  • Page 137 Interfaces Pin Assignment Chart for Connecting Peripherals Purpose: For Sartorius peripheral devices Female Interface Connector: 25-pin D-Submini (DB25S) with screwed fastening Required Male Connector (Recommended): 25-pin D-Submini, DB25S, with integrated shielded cable clamp and shield plate assembly (Amp type 826 985-1C) and fastening screws (Amp type 164 868-1)
  • Page 138 Interfaces Cabling Diagram 25-pin Interface Diagram for connecting a computer or other peripheral device to the balance using the RS232/V24 standard and cables up to 15 m (50 ft.) long Do not connect any other pins to the cable connector of the balance! Balance/scale Computer, 25-pin...

  • Page 139: Configuring Serial Ports

    Interfaces Configuring Serial Ports y The available interfaces are displayed. Select the interface you want to configure. Determine all settings for this interface. To save settings, touch Configuration Options for the Serial Interfaces The following operating modes are possible for these interfaces: –...
  • Page 140 Interfaces Configuration Options for the Printer Output Operating Mode You can modify all settings for this operating mode depending on the configured printer type. – Printer type: – Selected protocol: Hardware handshake – Baud rate: 300 to 19200 baud (*9600) –...
  • Page 141 Interfaces Explanations for the Setting Parameters Selected Protocol/Handshake The SBI (Sartorius Balance Interface) has transmit and receive buffers. Data transmission can be operated with a hardware or software handshake Hardware Handshake (CTS/DTR): With a hardware handshake (4-wire interface) protocol, the handshake is controlled via the CTS and DTR lines.

  • Page 142: Bluetooth® Interface (Com C, Optional)

    Interfaces Bluetooth® Interface (COM C, Optional) How to assemble the Bluetooth® module is described in the installation instructions supplied. For transmitting data via the Bluetooth module, the data output has to be configured in the System Settings as follows. Configuring the Bluetooth® Interface If appropriate, toggle to the System Settings menu.
  • Page 143 Interfaces Connecting a Bluetooth Printer Make sure that the printer to which you wish to connect is ready to operate. Select the as the device. To establish the connection, select y The balance will now search for the Bluetooth device. This process may take time.

  • Page 144: Network Interface (Ethernet)

    Interfaces Network Interface (Ethernet) Purpose This interface lets you integrate your balance into a TCP/IP-based network. System Requirements The person configuring the Ethernet interface should have basic knowledge of TCP/IP-base networks and network technologies in general. The Ethernet interface is connected to the local network via the RJ45 slot. Features Transfer rate: 10 Mbs/sec (10BASE-T, Ethernet) and 100 Mbs/sec...
  • Page 145 Interfaces Remove the cover plate (3). Insert the Ethernet cable plug (4) so that it clicks audibly into place. Reattach the cover plate (5). Turn the locking lever back to its locked position. Exercise caution to avoid glass breakage for models with a draft shield. Turn over the balance and place it on a soft surface.
  • Page 146 Interfaces Configuring Network Operation (Ethernet) Preparation: Before you can start with the configuration, you will require some information about your network. Please contact your network administrator. The important question is whether your network supports DHCP or not. DHCP With DHCP, you can automatically link a (new) balance to an existing network without having to configure it manually.
  • Page 147 Examples: For the connection type Balance = Server you only need to enter the local TCP port (e. g. for working with the Sartorius SartoCollect software for data communication) For the connection type Balance = Client, you have to enter the server TCP port and the server IP address, (e.
  • Page 148 Interfaces Selecting Functions Click on the desired function in the browser. To exit a function, click on >>Back or on the Go back key of your browser. : Use this function for remote control of the balance. The display screen on the balance is reproduced in the browser, you can operate the balance now by using the mouse and keyboard of your PC.

  • Page 149: Data Output

    Interfaces Data Output You can define the data output parameter so that output is activated either when a print command is received or automatically synchronized with the display or at defined intervals (see application programs and autoprint settings). The print command can be transmitted by pressing P or by a software Data Output by Print Command command (Esc P).
  • Page 150 Interfaces Special Outputs Position 1 10 11 12 13 14 15 16 – – CR LF CR LF CR LF and only upon request with ESC w0 (no print command): CR LF CR LF Spaces A = C: Adjustment AB = – –: Final readout Draft shield status (optional): A = H:...
  • Page 151 Interfaces Data Output Format with 22 Characters When data is output in this format, ID codes with 6 characters will precede data with a 16-character format. These six characters identify the subsequent value. Normal Operation 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 K K K K K K + A A A A A A A A A E E E CR LF –...
  • Page 152 Interfaces ID Code the Character K Individual Identifiers The ID code depends on the P-ID1 Print ID1 model, e. g. not all units and IDs T-ID1 Task start ID1 are available for verified balances I-ID1 Initialization ID1 R-ID1 Result output ID1 C-ID1 Component ID1 Device Information, Basic Data E-ID1 Evaluation ID1...
  • Page 153 Interfaces ID Code the Character K Totalizing (Continued) nDef Default number of items Comp Weight value start Calculation Comp Current weight value Form Formula Number of the item Results using equations CompC Weight value start: Variable X calculated components Variable Y CompC Current weight value: Variable a...

  • Page 154: Data Input

    Esc ea{Art.413}_ (determine weight and tare values and save to the alibi memory together with the label) ) Additional parameters and module identifications are available in the document “SBI Interface” as a download from the Sartorius homepage. Cubis MSA User Manual...
  • Page 155 Interfaces Overview of SBI Commands Format Command Action/Function Comments ESC P Print to the interface where the prompt originated Corresp. to Menu, with/without stability ESC T “TARE“ key taring and zeroing ESC K Filter “Very stable conditions” ESC L Filter “Stable conditions” ESC M Filter “Unstable conditions”...
  • Page 156 Assign/prompt for functio n of multiple softkey lines RM38 Activate RM36-assigned softkey lines RM39 Activate/deactivate RM30-assigned softkey functions Additional Sartorius commands Send weight value at stability and store in alibi memory (with optional label) Execute application command Query parameter MN36...

  • Page 157: Updating The Software

    Purpose: To better serve our customers, Sartorius continues to improve its balance software. Sartorius makes the latest software versions available online so that you can quickly and easily remain up-to-date. Sartorius, however, makes no guarantee regarding the use of this software.
  • Page 158 All previous data will be saved in the new format. After updating your software, check your settings (Menu, TASK and USER). If the XML files continue to cause problems, contact your local Sartorius service center. y After a version check is run, the versions of the current and the new software are displayed.

  • Page 159: Error And Status Messages

    Error messages are shown on the display for 2 seconds or must be acknowledged by pressing a key. The error text provides direct suggestions on how to proceed. If the error cannot be resolved by following the suggestions, please contact Sartorius customer service.

  • Page 160: Gpl License

    The licensing conditions of the Free Software Foundation, Inc. are available in English on the included CD-ROM. You can purchase the GPL source text from Sartorius on CD under the VF no. 4043 for a shipping cost of 20. Cubis MSA User Manual...

  • Page 161: Care And Maintenance

    Care and Maintenance Service Regular servicing by a Sartorius technician will extend the service life of your balance and ensure its continued weighing accuracy. Sartorius offers its customers service contracts with regular maintenance intervals ranging from 1 month to 2 years.
  • Page 162 Care and Maintenance Carefully remove any sample residue/spilled powder using a brush or hand-held vacuum. If necessary, remove the weighing pan, shield plate and pan support. 1) Weighing pan 2) Shield plate/draft shield 3) Pan support Clean parts with a cloth or brush. Then replace the parts.
  • Page 163 Ohm as measured with a constant voltage of at least 500 volts at a 500 kOhm load. The duration and number of checks should be determined by a qualified Sartorius service technician on site based on specific ambient and operating conditions (once a year as a minimum).

  • Page 164: Shipping The Balance

    Shipping the Balance If repairs are required, use the original packaging to transport the balance. To ensure adequate protection for safe shipment, Sartorius products have been packaged to the extent necessary using environmentally friendly materials. Only the original packaging provides optimum protection for the equipment.
  • Page 165 Shipping the Balance Transporting the Parts (Large Analytical Draft Shield) Get the box for the individual parts of the balance ready. Place the bottom foam piece in the box. Place the panels in the packaging: 1) Place the upper draft shield panel into the packaging (handle upwards). 2) Place the side draft shield panel into the packaging (handle upwards).
  • Page 166 Shipping the Balance Only for weighing pan: Place the shield plate into the box. Place the pan support and weighing pan into the opening. Close the box. Only for large weighing pan: Place the following parts into the foam piece in the order given: 1) Pan support 2) Shield plate 3) Weighing pan...
  • Page 167 Shipping the Balance Transporting the Parts (Small Analytical Draft Shield) Get the box ready for the individual parts of the balance. Get the foam pieces ready. Place the balance parts on top of each other. 1) Upper draft shield panel 2) Shield plate/draft shield 3) Pan support Cubis MSA User Manual...
  • Page 168 Shipping the Balance Slide the parts into the foam. Place the panels in the packaging. 1) Place the side panel into the packaging (handle downwards). 2) Place the side panel into the packaging (handle downwards). Place the foam piece in front of the parts. Place the package into the box.
  • Page 169 Shipping the Balance Slide the shield plate into the packaging. Close the box. Place the box into the packaging. Place the top part on to the packaging. Insert the balance into the box with cushioning. Send the packaged balance. Cubis MSA User Manual...

  • Page 170: Disposal

    Sartorius will not take back equipment contaminated with hazardous materials (ABC contamination) – either for repair or disposal. Please refer to our web site (www.sartorius.com) or contact the Sartorius Service Department for more detailed information regarding repair service addresses or the disposal of your device.

  • Page 171: Specifications

    (IEC/EN60320-1/C14) for connection to the power supply Other data See label on the power supply or the user manual on Balance Power supply Only via Sartorius power supply 6971987 Input voltage 15 VDC, Power consumption 15 W (max.) Ambient conditions...
  • Page 172 Specifications Model-specific Data Microbalances 0.001mg Model MSA6.6S MSA6.6S-F MSA3.6P Readability 0.001 0.001 0.001/0.002/0.005 Weighing capacity 1.1/2.1/3.1 Tare range (subtractive) –6.1 –6.1 –3.1 Repeatability ±mg 0.001 0.001 0.003/0.004/0.005 Linearity ±mg 0.004 0.004 0.004 Corner load (test load [g]) μg 4 (2 g)
  • Page 173 Specifications Model-specific Data Semi-microbalances 0.01 mg Model MSA225S MSA225P MSA125P Readability 0.01 0.01/0.02/0.05 0.01/0.1 Weighing capacity 60/120/220 60/120 Tare range (subtractive) – 220 – 220 – 120 Repeatability ±mg 0 to 6 g: 0.015 0 to 6 g: 0.015 0 to 6 g: 0.015 60 to 220g: 0.025 60 to 220g: 0.04 60 to 120g: 0.06...
  • Page 174 Specifications Model-specific Data Precision balances Models MSA5203S MSA5203P MSA3203S MSA3203P Readability 1/2/5 1/10 Weighing capacity 5200 1200/2400/5200 3200 1010/3200 Tare range (subtractive) - 5200 - 5200 – 3200 – 3200 Repeatability ±mg 1 Linearity ±mg 5 Corner load (test load [g]) 2 (2000) 2 (2000) 2 (1000)
  • Page 175 Specifications Model-specific Data Precision balances Models MSA623S MSA623P MSA323S Readability 1/2/5 Weighing capacity 150/300/620 Tare range (subtractive) – 620 – 620 – 320 Repeatability ±mg 0.7 1/2/4 Linearity ±mg 2 Corner load (test load [g]) 2 (200) 4 (200) 2 (200) Min.
  • Page 176 Specifications Model-specific Data Precision balances Models MSA6202S MSA6202P MSA5202S MSA4202S Readability 10/20/50 Weighing capacity 6200 1500/3000/ 5200 4200 6200 Tare range (subtractive) – 6200 – 6200 - 5200 – 4200 Repeatability ±mg 7 7/20/40 Linearity ±mg 20 Corner load (test load [g]) 20 (2000) 50 (2000) 10 (2000)

  • Page 177: Display Result

    Specifications Model-specific Data Verified Models with EC Type Approval Certificate: Micro- and ultramicrobalances Model MSA6.6S-0CE MSA2.7S-0CE MSA3.6P-0CE Accuracy class* For verified models: EC Type Approval Certificate D09-09-015, Type: MSX Scale interval d* 0.001 0.0001 0.001/0.002/0.005 Weighing capacity max* 1.1/2.1/3.1 Calibration value e* Min.

  • Page 178: (Min. Accuracy Class)

    Specifications Model-specific Data Verified models with EC Type Approval Certificate: Semi-microbalances 0.01 mg Model MSA225S-0CE MSA225P-0CE MSA125P-0CE Accuracy class* For verified models: EC Type-Approval Certificate D09-09-015, Type: MSX Scale interval d* 0.01 0.01/0.02/0.05 0.01/0.1 Weighing capacity max* 60/120/220 60/120 Calibration value e* Min.

  • Page 179: Display Result

    Specifications Model-specific Data Verified models with EC Type Approval Certificate: Precision balances Models MSA5203S-0CE MSA5203P-0CE MSA3203S-0CE MSA3203P-0CE Accuracy class* For verified models: EC Type-Approval Certificate D09-09-015, Type: MSX Scale interval d* 1/2/5 1/10 Weighing capacity max* 5200 1200/2400/5200 3200 1010/3200 Calibration value e* Min.
  • Page 180 Specifications Model-specific Data Verified models with EC Type Approval Certificate: Precision balances Models MSA623S-0CE MSA623P-0CE MSA323S-0CE Accuracy class* For verified models: EG-Type-Approval Certificate D09-09-015, Type: MSX Scale interval d* 1/2/5 Weighing capacity max* 150/300/620 Calibration value e* Min. load min* Tare equalization range (subtractive) 100% from max.
  • Page 181 Specifications Model-specific Data Verified models with EC Type Approval Certificate: Precision balances Models MSA6202S- MSA6202P- MSA5202S- MSA4202S- Accuracy class* For verified models: EC Type-Approval Certificate D09-09-015, Type: MSX Scale interval d* 0.01 0.01/0.02/0.05 0.01 0.01 Weighing capacity max* 6200 1500/3000/6200 5200 4200 Calibration value e*...

  • Page 182: Balance Dimensions

    Balance Dimensions Balance Dimensions Microbalances All dimensions are given in millimeters d 85 d 86.5 d 80 Cubis MSA User Manual...
  • Page 183 Balance Dimensions Filter-Microbalances All dimensions are given in millimeters d 106.5 d 84 Cubis MSA User Manual...
  • Page 184 Balance Dimensions Semi-microbalances All dimensions are given in millimeters Cubis MSA User Manual...
  • Page 185 Balance Dimensions Analytical Balances with Manual DU Draft Shield All dimensions are given in millimeters Cubis MSA User Manual...
  • Page 186 Balance Dimensions Precision Balances with a Readability of 1 mg and Manual DE Draft Shield All dimensions are given in millimeters Cubis MSA User Manual...
  • Page 187 Balance Dimensions Precision Balances with a Readability of 1 mg and Framed DR Draft Shield All dimensions are given in millimeters Cubis MSA User Manual...
  • Page 188 Balance Dimensions Precision Balances with no Draft Shield All dimensions are given in millimeters Cubis MSA User Manual...

  • Page 189: Accessories

    Sartorius OPC Server for connecting all Sartorius Cubis ® balances Requires 32-bit Microsoft Windows 2000 or XP with current service packs. (free download of a 30-day trial version from the Sartorius website) – Initial license 6289OPC – Each additional license within an order...
  • Page 190 The brand name and logo for Bluetooth wireless technology are are the property of Bluetooth SIG Inc. The use of this brand name and trademark by Sartorius is under license. Other brand names and trademarks are the property of their respective owners. Cubis MSA User Manual...

  • Page 191: Declaration Of Conformity

    Commission of the European Community for performing such verification. The legal basis for Sartorius to perform the EC verification is EC Directive No. 2009/23/EC for non-automatic weighing instruments. This Council Directive has that has been in effect since January 1, 1993 in the Internal Market.
  • Page 192 Declarations of Conformity Cubis MSA User Manual...
  • Page 193 Declarations of Conformity Cubis MSA User Manual...
  • Page 194 Declarations of Conformity Cubis MSA User Manual...
  • Page 195 Declarations of Conformity Cubis MSA User Manual...

  • Page 196: Ec Type-Approval Certificate

    Declarations of Conformity Cubis MSA User Manual...

  • Page 197: Plates And Markings

    Plates and Markings Cubis MSA User Manual...
  • Page 198 Plates and Markings Cubis MSA User Manual...
  • Page 199 Plates and Markings Cubis MSA User Manual...
  • Page 200 Plates and Markings Cubis MSA User Manual...
  • Page 201 Sartorius. The status of the information, specifications and illustrations in this manual is indicated by the date given below. Sartorius reserves the right to make changes to the technology, features, specifications and design of the equipment without notice. Status:...

This manual is also suitable for:

Msa6.6s-fMsa3.6p

Table of Contents

Save PDF
