PREPARATION

Filter Installation

Be sure to install filters before plugging the unit.
Upper tabs (one each
at right and left)
Back Panel
HEPA Filter
E-8
Remove the
back panel
to take the
filters out.
Active Carbon & Silica Gel Deodorizing Filter
Take filters (2 types)
out of plastic bags
HEPA Filter
Tag surface should be
attached to the front side
Tag
Active Carbon &
Silica Gel
Deodorizing Filter
Click
Lower tabs (one each at
right and left)
Install the filters
in order from the
HEPA Filter to the
Active Carbon &
Silica Gel
Deodorizing
Filter.
No difference on both sides
Mount the
back panel
• The filters (2 types) are
found in the main unit.
• Pull the tag of the HEPA
filter out to the Active
Carbon & Silica Gel
Deodorizing Filter to
make it easy to remove it.
HEPA Filter
Tag
Active Carbon & Silica Gel
Deodorizing Filter
