Note: This front USB 3.0 port can only fast charge connected devices that comply with
USB Battery Charging Specification Revision 1.2.

Configure a display device

Use your Windows operating system to adjust display settings for multiple monitors.
Your laptop hardware must support dual external displays.
• You can set up dual monitors by using the video output ports (1x DisplayPort and
1x HDMI).

Supported video resolutions

The dock supports the following maximum resolutions.
WiGig host - maximum resolutions
Video output
configuration
DisplayPort and HDMI
(two monitors)
DisplayPort (one monitor)
HDMI (one monitor)
USB-C host - maximum resolutions
DisplayPort and HDMI
(two monitors)
DisplayPort (one monitor)
HDMI (one monitor)
Notes
• Depending on the configuration and the supported resolution of your connected
monitor(s), the dock can support video resolutions lower than specified above.
• In a multi-display configuration, set the refresh rates on each of your connected
monitors to the same values, otherwise your monitors might not display properly.
• Video output capabilities are dependent on the video card and hardware
specifications of your connected host laptop.
Instruction manual
Max DisplayPort
Resolution
1920x1200p (60Hz)
2560x1600p (60Hz)
N/A
1920x1200p (60Hz)
3840x2160p (30Hz)
N/A
8
Max HDMI Resolution
1920x1200p (60Hz)
N/A
2560x1440p (60Hz)
1920x1200p (60Hz)
N/A
3840x2160p (30Hz)
