Configure a display device
You can use your computer's operating system to configure a display device.
Use Windows to configure your display devices
1. Right-click on some empty space on your Windows Desktop and select Screen
Resolution from the menu that appears.
2. Adjust the display order, screen resolution, orientation and display mode as needed.
Use macOS to configure your display devices
1. Click the Apple Menu and select System Preferences.
2. Click Displays to open the Display preferences windows.
3. Adjust the display order, screen resolution, orientation and display mode as needed.
Supported resolutions
The following resolutions are supported on each display that's connected through the
docking station:
2048x1152, 1920x1080, 1680x1050, 1366x768, 1280x800, 1280x768, 1280x720,
1600x1200, 1400x1050, 1280x1024, 1024x768, 800x600, 640x480.
LED indicator
There is an LED indicator located on the front of the docking station. For more
information about what the LED behavior indicates, see the table below.
LED
Power LED
Instruction Manual
Behavior
LED is illuminated
LED is off
5
Meaning
The docking station is
plugged in and powered on.
The docking station is not
powered on and/or is not
plugged in.
