- Page 1 Station for Laptops - Power Delivery DKWG30DPHPD DKWG30DPHPDU *actual product may vary from photos FR: Guide de l’utilisateur - fr.startech.com DE: Bedienungsanleitung - de.startech.com ES: Guía del usuario - es.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com IT: Guida per l’uso - it.startech.com...
- Page 2 (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by StarTech.com could void the user’s authority to operate the equipment.
- Page 3 Contains IC: 1000M-13100NG EU - Declaration of Conformity StarTech.com declares that the Wireless (WiGig) or USB-C Dual-Monitor Docking Station for Laptops - Power Delivery (DKWG30DPHPD & DKWG30DPHPDU) complies with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the Declaration of conformity is available on request.
-
Page 4: Table Of Contents
Table of Contents Introduction ....................1 Product diagram ............................1 Package contents ............................2 Requirements ............................. 2 About the LED indicators ..............3 About the buttons..................3 About USB 3.0 and USB 3.1 Gen 1 ............4 About USB Power Delivery 2.0 .............4 About USB-C ..................4 About the dock’s USB-C port ..............4 Attach the dock to the stand ..............5 Install the dock through WiGig (wireless) ..........5... - Page 5 Supported video resolutions ...............8 Technical support ...................9 Warranty information ................9 Instruction manual...
-
Page 6: Introduction
Introduction This laptop docking station lets you create a full-sized workstation using either wireless (WiGig®) docking technology or the included USB-C™ cable. When connected through USB Type-C™ (5Gbps) you can easily power and charge your laptop directly through its USB-C port or Thunderbolt™ 3 port. Product diagram Front view Power LED... -
Page 7: Package Contents
• 1 x stand • 1 x USB-C cable • 1 x universal power adapter • 2 x power cords (NA/JP, ANZ for DKWG30DPHPD) (EU, UK for DKWG30DPHPDU) • 1 x instruction manual Requirements • An available AC electrical outlet •... -
Page 8: About The Led Indicators
About the LED indicators Behavior Blue: The dock is powered and turned on Power Not illuminated: The dock isn’t powered and is turned off Status Amber: A WiGig connection is being set up Green: A device is connected (your host laptop) Off: No device is connected Blinking green: The firmware is being updated About the buttons... -
Page 9: About Usb 3.0 And Usb 3.1 Gen 1
USB 3.0 is also known as USB 3.1 Gen 1. This connectivity standard offers speeds up to 5Gbps. Any mention of USB 3.0 in this manual or on the StarTech.com website for DKWG30DPHPD or DKWG30DPHPDU refers to the 5Gbps USB 3.1 Gen 1 standard. -
Page 10: Attach The Dock To The Stand
Attach the dock to the stand To attach the dock to the provided stand, do the following: 1. Place the stand flush on a desk so that the rubber feet on the bottom of the stand are resting on the desk’s surface. 2. -
Page 11: Run The Intel® Wireless Dock Manager Software
shown on each display. Note: The indicated ID for the dock is unique and will vary from dock to dock. Run the Intel® Wireless Dock Manager software To connect the dock to your laptop wirelessly, you need to use Intel Wireless Dock Manager software. -
Page 12: Install The Dock Through Usb-C (Wired)
Install the dock through USB-C (wired) If you have a USB-C equipped host laptop that supports USB Power Delivery 2.0 and DP alt mode, you can connect the dock to your laptop using the provided USB-C cable. Note: The dock can connect to a host laptop’s USB-C port even if it doesn’t support USB Power Delivery 2.0 and DP alt mode. -
Page 13: Configure A Display Device
Note: This front USB 3.0 port can only fast charge connected devices that comply with USB Battery Charging Specification Revision 1.2. Configure a display device Use your Windows operating system to adjust display settings for multiple monitors. Your laptop hardware must support dual external displays. •... -
Page 14: Technical Support
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby... - Page 15 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
