Page 1: Quick Installation Guide
Analog IP Gateway GXW-400x Quick Installation Guide SW version 1.0.0.17 www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030... - Page 2 Overview The new GXW-400x series has a compact and quiet design (no fans) and offers superb audio quality, rich feature functionality, strong security protection, and good manageability. It is auto- configurable, remotely manageable and scalable.
- Page 3 APPLICATION Diagram There are three scenarios where the GXW-400x series can be effectively used to enable any business to leverage the benefits of VoIP and the Internet. Scenario One: GXW- 400x FXS Gateway Configuration PBX Scenario, VoIP Anywhere in the world...
- Page 4 Your PC will be assigned an IP address like 192.168.2.100 Launch web browser and type http://192.168.2.1 at Address of web browser. This will let you to connect to build-in web server of GXW-400x. ou can logi n using either admin or 123 as the password. GXW- 400x...
- Page 5 After you login, you will see six different tabs (Status, Basic Settings, Advanced Settings, Profile 1, Profile 2 and FXS Ports) on the top of the screen. By clicking on each tab, you can open that page for configuration. In order to enter your SIP Server/ SIP Proxy/Registrar information, click on Profile 1.
- Page 6 PBX system. C. Pr eferred VOCODER (Codec) The GXW-400x supports a broad ra nge of voice codecs. Under Profile webpages, you can choose your preferred order of different codecs: PCMU (or G711u), PCMA (or G711a), G729A/B, G723, G726-32, iLBC, G728 and G729E.
- Page 7 www.grandstream.com 1297 Beacon Street info@grandstream.com rookline, MA 02446 Tel: +1 (617) 566 – 9300 Fax: +1 (617) 247 – 1987 andstream Networks, Inc. is an award-winning designer and manufacturer of next generation IP voice & video products for broadband networks. Our products are consistently recognized by industry experts for their innovation, affordability and superior value.
