Control Panel and Features

Mixed
Heavy Duty
Normal
Synthetics
Delicates
P
Program
3 Sec
1
2
POWER BUTTON
1
Touch until the indicator above the Program button lights
up. Symbols appear on the control panel and sounds are
played.
PROGRAM (cycle)
2
When you turn on the dryer, the light above this button
will turn on. The program settings which you used last
will appear on the control panel. This button also lets you
set water conductivity (see "Adapting the dryer to water
conductivity" for more information).
PROGRAM/CYCLE AREA
3
An indicator next to each program/cycle lights up as you
use the knob to scroll through the list. Press the knob when
the indicator next to the desired program/cycle lights up.
CONTROL KNOB
4
Turn the knob to select a program/cycle for your laundry
load, change dryness level, set drying time or delay start
time, or select Other Options. Press the knob to confirm
your selection.
OPTIONS
5
Touch to activate additional dry options or additional
features on the dryer before touching the Start/Pause
button. Additional dry options or additional features
selected after touching the Start/Pause button may
not be activated.
To return to factory default cycle settings, unplug the dryer
for 30 seconds, then plug back in.
NOTE: Not all options are available with all cycles.
Cycle Signal
A
Use to turn on or off the signal indicating the end
of a drying cycle.
NOTE: Touch and hold the Cycle Signal button for
about one second to turn sounds on or off.
6
3
Wool
Bulky/Bedding
Air Dry
Refresh
Timed Dry
Cycle
Control
Steam
Signal
Lock
Hold 3 Sec
A
B
C
4
Delay
Start
D
5
Control Lock
B
Use to lock the controls of the dryer and avoid
an accidental change in cycle options or preferences
during a drying cycle.
Touch and hold CONTROL LOCK to lock or unlock
the controls of the dryer.
NOTE: The Control Lock function may be enabled
when recovering from a power failure. To unlock
the control, touch and hold CONTROL LOCK.
Steam
C
Touch to activate the Steam option, which adds
humidity to the end of the Heavy Duty, Normal,
or Synthetics cycle to help smooth out wrinkles.
Delay Start
D
Touch to start your program/cycle at a later time.
6
SETTINGS
Timed Dry
A
Sets the length of a Timed Dry cycle.
Dryness Level
B
When using some Automatic Cycles, you may
select a Dryness Level based on the type of load
you are drying.
NOTE: Dryness Level is for use with Automatic
Cycles only.
7
OTHER OPTIONS
Save Time
This option provides quicker drying.
Gentle
This option dries laundry more gently by reducing
the drying temperature.
Wrinkle Shield
This option helps to avoid creasing if you cannot
unload the laundry soon after the program/cycle
ends. The dryer starts to tumble the laundry
periodically a few minutes after the program/cycle
ends. This tumbling will last up to approximately
12 hours. Tumbling can be stopped any time by
touching the Power button to turn off the dryer.
9
X-Dry
Dry
Damp
Dry
Timed
Dryness
Options
Dry
Level
A
B
7
6
8
