Furuno NAVpilot-700 Installation Instructions Manual page 2

1. Materials
Name
IPS Interface Unit
VOLVO IPS Gateway
YAMAHA HM Gateway YAMAHA-HM-GATEWAY
Cable Assy.
Self-tapping Screw
Fuse
2. IPS Interface Unit (IF-700IPS)
2.1 LED status and meaning
The LED on the IPS interface unit indicates the status of the unit.
The LED status and meaning are shown below.
LED Lamp Status
Off
Flashes
Flashes twice, and then
goes off for two seconds
Type
IF-700IPS
AUTOPILOT-GATEWAY
MJ-A7SPF0005-020C
4x16 SUS304
FGMB 125V 1A PBF
IPS interface unit IF-700IPS
The IPS interface unit is OFF. The unit is powered by the processor
unit (FAP-7002). Turn on the processor unit.
The IPS interface unit operates normally.
Communication error between the gateway unit and IPS interface
unit. Check the connection between the gateway unit and IPS inter-
face unit.
Code No.
-
-
-
000-159-699-10
000-162-605-10
000-157-478-10
LED (green)
Status/Action
2
Qty Remarks
1
Gateway unit
for FAP-6300
1
Gateway unit
for FAP-6310
1 2 m
4
1 Spare parts
