SPECIFICATIONS
CONTROL UNIT
Display
85.2 (W) x 85.2 (H) mm
Effective Display Area
Pixel Number
160 x 160 dots
Backlight
Contrast
PROCESSOR UNIT
Rudder Angle Adjustment
STBY, Auto, Navigation*, Wind**, Fish Hunter*, Turn, Tack, NFU, FU, Dodge
Sea Condition Adjustment
Rudder Angle Settings
Deviation, Out of course*, Watch, Ship's speed*, Water temperature*, Depth*, Log*, Wind Deviation**
Alarm
INTERFACE
Ports
(NMEA0183) AAM, APB, BOD, BWC, BWR, DBT, DPT, GNS, GGA, GLL, HDG, HDT, HDM, MTW, MWV, RMC, RMB, ROT, RSA, THS, TLL, VTG, VHW,
Input
VWR, VWT, XTE, ZDA
(CAN bus)
059392,059904, 060928, 126208, 126992, 126996, 127250, 127251, 127258, 127488, 127489, 128259, 128267, 129025, 129026,
129029, 129033, 129283, 129284, 129285, 130306, 130310, 130311, 130577, 130312, 130313, 130314, 130577
Output
(NMEA0183) DBT, DPT, GGA, GLL, GNS, HDG, HDM, HDT, MTW, MWV, RMB, RMC, ROT, RSA, VHW, VTG, VWR, VWT, ZDA
(CAN bus)
059392, 059904, 060928, 126208, 126464, 126992, 126996, 127245, 127250, 127251, 127258, 128259, 128267, 129025, 129026,
129029, 129033, 129283, 129284, 129285, 130306, 130310, 130311, 130312
ENVIRONMENT
Temperature
Waterproo ng
Processor unit
Other unit
POWER SUPPLY
EQUIPMENT LIST
Standard
Control Units* (FAP-7001/7011/7021), Processor Unit FAP-7002, Installation Materials and Spare Parts
Options
Control Units, Flush Mount Kits, Hanger Kits, Cradle, Rudder Reference Units FAP6112-200*,
Remote Controllers, Cables, Connectors, Junction Box, Pump Unit, FPS8 Power Steering Module
NAVpilot-700 Control Unit
NAVpilot-711 Control Unit
(Bracket-mount)
(Bracket-mount)
FAP-7001
FAP-7011
0.9 kg 1.9 lb
0.52 kg 1.15 lb
260 10.2"
100 3.9"
150 5.9"
220 8.7"
110 4.3"
NAVpilot-700 Control Unit (Surface-mount)
0.62 kg 1.4 lb
100 3.9"
40 1.6"
41 1.6"
206 8.1"
220 8.7"
4- 3.2
26 1.0"
206 8.0"
48
Fixing hole
1.9"
Cut-out for ush mount
NAVpilot-700 Control Unit (Flush-mount)
0.64 kg 1.4 lb
216 8.5"
218 8.6"
58 2.3"
#40
#40
24 0.9"
228 9.0"
239 9.4"
10 0.4"
Cut-out for ush mount
228 9.0"
4- 3.2
Fixing hole
Monochrome LCD
85.2 (W) x 43.6 (H) mm
160 x 80 dots
8 steps
16 steps
* Navigational data required ** Wind data required
AUTO/CALM/MODERATE/ROUGH
55˚ max
* Navigation data reuired ** Wind data required
CAN bus: 1, NMEA0183: 2
-15˚C to +55˚C
IP20
IP56
12-24 VDC: 4.0 A (excluding pump)
*Specify when ordering
NAVpilot-720
Processor Unit
FAP-7021
FAP-7002
0.99 kg 2.2 lb
1.9 kg 4.2 lb
66 2.6"
3.5
110 4.3"
50.5 2"
0.1"
255 10.0"
100 3.9"
53 2.1"
52 2"
NAVpilot-711 Control Unit (Surface-mount)
0.34 kg 0.75 lb
100 3.9"
40 1.6"
41 1.6"
2-M3
4- 3.2
110 4.3"
26 1.0"
80 3.1"
2- 3.5
60 2.4"
Cut-out for ush mount
NAVpilot-711 Control Unit (Flush-mount)
0.35 kg 0.77 lb
100 3.9"
58 2.3"
24 0.9"
4- 3.2
129 5.1"
10 0.4"
4-R5
118 4.6"
Cut-out for ush mount
