5.2 Interfaces

Power Supply interface, USB interface and cashbox interface are standard interfaces for the printer.
Serial or Parallel interface is a factory feature only.
The interface pin assignment is listed below.

5.2.1 USB interface

USB interface pin assignment
PIN No. Description
1
2
3
4
USB interface connector diagram

5.2.2 Cash Drawer interface

Cashbox interface pin assignment
Pin No.
1
2
3
4
5
6
Cashbox interface connector (RJ-11) diagram
VBUS
D-
D+
GND
Description
Structure GND
Cashbox drive signal
NC
DC +24V
Cashbox drive signal
Signal GND
Classic wire color
Red
White
Green
Black
Direction
---
Output
Empty
Output
Output
---
