Driver Properties Setting; Printing Control; Crash Drawer Setup - Tally Dascom DM-210 User Manual

Tally Dascom DM-210/220
HHHHHHHHHHHHHHH
H
Cutting position
③ Click "OK" to save the setting, the printer prints the corresponding message.
The offset is within -43mm ～ (the distance between two adjacent black marks - 43)mm.

3.2 Driver Properties Setting

(1) Right click the printer icon
(2) Access the properties menu, select "Device settings" → "Installable option". Then you can set the printing
control, cash drawer, black mark and cutter.

3.2.1 Printing Control

Option
Bidirectional printing
Uni-direction printing

3.2.2 Crash Drawer Setup

Option
Without cash drawer
Open cash drawer after printing
Open cash drawer before printing
If offset is negative, the cutting position is above the next
black mark (shown as the left figure).
25.5mm
Once the cutting position exceeds the offset range, then
you can input negative data, i.e. setting offset for next
black mark.
and select "properties".
Function
Pirnt speed will be faster; it's a recommended option.
Print speed will be slower but vertical alignment will be better;
it's suitable for high vertical aligment request.
Function
No signal for controlling cash drawer. You can choose
this option when you do not use cash drawer.
Send signal for controlling cash drawer and open
cash drawer after printing.
Send signal for controlling cash drawer and open
cash drawer before printing.
16
