Extech Instruments 7630 Operation Manual page 32

AC Power
Range
High / Low
Resolution
Limit Setting
Range
AC Power
Resolution
Display
Accuracy
Power Factor
Range
High / Low
Resolution
Limit Setting
Range
Power Factor
Resolution
Display
Accuracy
Leakage
Range
Current
High/Low
Resolution
Limit Setting
Range
Leakage
Current Resolution
Display
Accuracy
Range
Delay Timer
Setting
Resolution
Range
Dwell Timer
Setting
Resolution
Range
Timer display Resolution
Accuracy
It is applied to control Transformer Box (1931 / 1931S) or AC Power Source(6700 / 6800 / 6400
Power Control
Series)
Opt.752 option products
6800 Series Digital AC Power Source (6805, 6810, 6820, 6830, 6840 )
6700 Series Programmable AC Power Source (6705, 6710, 6720, 6730, 6740 )
6400 Series AC Power Source (6403, 6405, 6410)
1931 Series Transformer Box Multi - Tape of 1.0, 1.06 & 1.1 times of input voltage (500VA / 1KVA / 1.8KVA /
3.6KVA)
1931S Series Transformer Box Multi - Tape of 0.8, 0.85, 0.9, 1.0, 1.06 & 1.1 times of input voltage (500VA / 1KVA /
1.8KVA / 3.6KVA)
Opt. 753 HV & GB Link Module
Max. ACW 3500VAC, DCW 3500VDC & Max. Ground Bond 40A
Opt. 754 High Measurement Range 35mArms / 75mApeak
IEC60990 Fig4 U2, IEC 60950 - 1, IEC60335-1, IEC60598 - 1, IEC60065, IEC61010
MD1
IEC60990 Fig4 U1
IEC60990 Fig5 U3, IEC60598-1
MD2
IEC60990 Fig5 U1
MD3 IEC 60601 - 1
MD5 UL544NP, UL484 , UL923, UL471, UL867, UL697
If the opt.754 function is enabled, the MD module MD4, MD6 & MD7 will be disabled.
26
0 - 10KW
1W
0.0 - 1000.0W / 1000 - 10000W
0.1W / 1W
± (5% of reading + 9 counts)
0.000 - 1.000
0.001
0.000 - 1.000
0.001
± (8% of reading + 2 counts), V > 60VAC & PF > 0.2
0.00 - 10.00mA
0.01mA
0.00 - 10.00mA
0.01mA
± (2% of reading + 2 counts)
0.5 - 999.9s
0.1s
0, 0.1 - 999.9s (0 = Continuous)
0.1s
0.0 - 999.9s
0.1s
± (0.1% of reading + 0.05s)
