more then one second. The AUD indicator will come on.
There is a service adjustment located on the top of the unit to adjust the marker volume level.
Holding the MKR button for one second activates marker test lamp, labeled "T/M" and illuminates all three
lamps simultaneously to assure the lamps (internal and external) are in working order. TST does not acti-
vate MM autopilot sense output. Releasing the button returns to the last sensitivity.
Pressing the marker mode select ("T/M") for one second will also cause the marker audio to mute for that
beacon. The next beacon received will re-activate the audio.
The Marker sensitivity is controlled with an external switch, and defaults to Low Sensitivity (LO SENSE)
when the switch is open. The sensitivity is indicated on the audio panel by a green "LOW" light in the
MKR section.

3.7 Intercom Operation

3.7.1 IntelliVox® VOX-Squelch
No adjustment of the IntelliVox® squelch control is necessary. There is no field adjustment. Through three
individual signal processors, the ambient noise appearing in all six microphones is constantly being sam-
pled. Non-voice signals are blocked. When someone speaks, only their microphone circuit opens, placing
their voice on the intercom. The system is designed to block continuous tones; therefore people humming
or whistling in monotone may be blocked after a few moments.
For consistent performance, any headset microphone must be placed within ¼-inch of your lips, preferably
against them. (ref: RTCA/DO-214, 1.3.1.1 (a)).
It is also a good idea to keep the microphone out of a direct wind path. Moving your head through a vent air
stream may cause the IntelliVox® to open momentarily. This is normal.
The IntelliVox® is designed to work with normal aircraft cabin noise levels (70 dB and above). It loves
airplane noise! Therefore, it may not recognize speech and clip syllables in a quiet cabin, such as in the
hangar, or without the engine running. This is normal.
For optimum microphone performance, PS Engineering recommends installation of a Microphone Muff Kit
from Oregon Aero (1-800-888-6910). This will not only optimize VOX performance, but will improve the
overall clarity of all your communications.
Manufacturer
Bose
David Clark
Lightspeed
Peltor
Pilot
Sennheiser
Telex
Table 3-1 Mic Muff ™ Part Numbers
3.7.2

Intercom Volume Control (7)

The inner volume control knob adjusts the loudness of the intercom for the pilot and copilot. It has no ef-
fect on selected radio levels, music input levels or passengers' volume level.
The outer volume control knob controls intercom volume for the passengers. It has no effect on radio or
music levels.
200-890-0303
PS Engineering
PMA8000C Audio Selector Panel and Intercom System
Installation and Operator's Manual
NOTE
Model
Dynamic
Electret
M87 Dynamic
H10-30
H10-20, H10-40
H10-13.4
All
7003
7004
11-20 & 11-90
Airman 750, Echelon
AIR3000
Page 3-4
Mic Muff™ Part Number
90010
90015
90020
90010
90015
90015
90015
90010
90015
90015
90015
90015
90010
Rev. 5, May 2015
