User's
Manual
UT55A/UT52A
Digital Indicating Controllers
User's Manual
IM 05P01C31-01EN
IM 05P01C31-01EN
6th Edition

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UT55A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for YOKOGAWA UT55A

Summary of Contents for YOKOGAWA UT55A

  • Page 1 User’s Manual UT55A/UT52A Digital Indicating Controllers User’s Manual IM 05P01C31-01EN IM 05P01C31-01EN 6th Edition...
  • Page 2 Product Registration Thank you for purchasing YOKOGAWA products. YOKOGAWA provides registered users with a variety of information and services. Please allow us to serve you best by completing the product registration form accessible from our homepage. http://www.yokogawa.com/ns/reg/...

  • Page 4: Introduction

    This manual describes how to use UT55A/UT52A functions other than UT55A/UT52A’s communication function and ladder sequence function. Please read through this user’s manual carefully before using the product. Note that the manuals for the UT55A/UT52A comprise the following seven documents: ● Printed manual Manual Name...

  • Page 5: Trademarks

    Trademarks ● Our product names or brand names mentioned in this manual are the trademarks or registered trademarks of Yokogawa Electric Corporation (hereinafter referred to as YOKOGAWA). ● Microsoft, MS-DOS, Windows, Windows XP, Windows Vista, and Windows 7 are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. ● Adobe, Acrobat, and Postscript are either registered trademarks or trademarks of Adobe Systems Incorporated. ● Ethernet is a registered trademark of XEROX Corporation in the United States. ● Modbus is a registered trademark of Schneider Electric.
  • Page 6 • Be sure to use the spare parts approved by YOKOGAWA when replacing parts or consumables. • This product is not designed or manufactured to be used in critical applications that directly affect or threaten human lives.

  • Page 7: Handling Precautions For The Main Unit

    • YOKOGAWA makes no warranties regarding the product except those stated in the WARRANTY that is provided separately. • The product is provided on an “as is” basis. YOKOGAWA assumes no liability to any person or entity for any loss or damage, direct or indirect, arising from the use of the product or from any unpredictable defect of the product.

  • Page 8: Checking The Contents Of The Package

    UT55A/UT52A Main Unit The UT55A/UT52A main units have nameplates affixed to the side of the case. Check the model and suffix codes inscribed on the nameplate to confirm that the product received is that which was ordered.

  • Page 9: Model And Suffix Codes Of Ut55A (For Standard Model)

    Type 2 code "1" and Type 3 code "0." When “-0” is specified for the Type 1 code, the /HA option can be specified. When the /CT option is specified, the UT55A does not conform to the safety standards (UL and CSA) and CE marking.

  • Page 10: Model And Suffix Codes Of Ut52A (For Standard Model)

    Model and Suffix Codes of UT52A (for Standard model) [Style:S4] Optional Model Suffix code suffix Description code Digital Indicating Controller (provided with retransmission output or 15 V DC UT52A loop power supply, 3 DIs, and 3 DOs) (Power supply: 100-240 V AC) Type 1: Standard type Position proportional type Basic control Heating/cooling type None Remote (1 additional aux. analog) input, 1 additional DI, and RS-485 Type 2: communication (Max. 38.4 kbps, 2-wire) Functions Remote (1 additional aux.

  • Page 11: Model And Suffix Codes Of Ut55A (For Detailed Model)

    The /L4 and /LC4 options for E4 terminal area can be specified only when the E3 terminal area option is not specified or specified any of /CH3, /X3, /Y3 or /W3. When the /CT option is specified, the UT55A does not conform to the safety standards (UL and CSA) and CE marking. viii...

  • Page 12: Model And Suffix Codes Of Ut52A (For Detailed Model)

    Model and Suffix Codes of UT52A (for Detailed model) [Style:S4] Optional Model Suffix code suffix Description code Digital Indicating Controller (provided with 3 DIs, and 3 DOs) (Power supply: UT52A 100-240 V AC) Fixed code -NNN Always "-NNN” English German Display language (*1) French Spanish White (Lithg gray) Case color Black (Light charcoal gray) Analog output (current/voltage pulse) Relay output (c-contact)
  • Page 13 Accessories The product is provided with the following accessories according to the model and suffix codes. Check that none of them are missing or damaged. For UT55A For UT52A Product Name Quantity Remark Part number: L4502TP (For fixing the upper Brackets...
  • Page 14 • LL50A Parameter Setting Software Model Suffix code Description LL50A Parameter Setting Software • Terminal cover For UT55A, Model: UTAP001 For UT52A, Model: UTAP002 For UT55A For UT52A • Brackets Part number L4502TP (2 pieces for fixing the upper and lower parts) • User’s Manual (A4 size) * User’s Manual can be downloaded from a website.

  • Page 15: Symbols Used In This Manual

    Symbols Used in This Manual This symbol is used on the instrument. It indicates the possibility of injury to the user or damage to the instrument, and signifies that the user must refer to the user’s manual for special instructions. The same symbol is used in the user’s manual on pages that the user needs to refer to, together with the term “WARNING” or “CAUTION.” WARNING Calls attention to actions or conditions that could cause serious or fatal injury to the user, and indicates precautions that should be taken to prevent such occurrences.

  • Page 16: How To Use This Manual

    For the ladder sequence and communication functions, see the respective manuals. This user’s manual is organized into Chapters 1 to 19 as shown below. This manual mainly uses the illustrations of the UT55A for describing the operations and functions. The basic operations are the same for the UT52A, so please read them in the same way.
  • Page 17 Blank Page...

  • Page 18: Table Of Contents

    Waste Electrical and Electronic Equipment (WEEE), Directive 2002/96/EC ....... iv Checking the Contents of the Package ................v Model and Suffix Codes of UT55A (for Standard model) ............ vi Model and Suffix Codes of UT52A (for Standard model) ........... vii Model and Suffix Codes of UT55A (for Detailed model) ............ viii Model and Suffix Codes of UT52A (for Detailed model) ............
  • Page 19 Contents 6.1.2 Operation Display Transitions in Loop Control with PV Switching and Loop Control with PV Auto-selector ................6-5 Standard Type ........................6-5 Position Proportional Type ....................6-6 Heating/cooling Type ......................6-7 6.1.3 Operation Display Transitions in Cascade Control ..........6-8 Standard Type ........................6-8 Position Proportional Type ....................6-10 Heating/cooling Type ......................6-12 Setting Target Setpoint ....................6-19 Operation in the Operation Display ..................6-19 Operation in Parameter Setting Display ................6-20 Performing and Canceling Auto-tuning ................
  • Page 20 Auto-selector, and Position Proportional Loop Control with PV Auto-selector ..8-47 n Loop Control with PV Auto-selector (2 inputs) Function Block Diagram ......8-49 n Heating/cooling Loop Control with PV Auto-selector (2 inputs) Function Block Diagram ..8-51 n Position Proportional Loop Control with PV Auto-selector (2 inputs) Function Block Diagram ...8-52 n Loop Control with PV Auto-selector (4 inputs) Function Block Diagram (only for UT55A) ..8-55 n Heating/cooling Loop Control with PV Auto-selector (4 inputs) Function Block Diagram (only for UT55A)......................8-57 n Position Proportional Loop Control with PV Auto-selector (4 inputs) Function Block Diagram (only for UT55A) .....................8-59 8.1.8 Loop Control with PV-hold Function, Heating/cooling Loop Control with PV-hold Function, and Position Proportional Loop Control with PV-hold Function ..8-61 n Loop Control with PV-hold Function Function Block Diagram ........8-63 n Heating/cooling Loop Control with PV-hold Function Function Block Diagram ....8-64 n Position Proportional Loop Control with PV-hold Function Function Block Diagram ..8-66 Setting Control Type (CNT) .................... 8-68 8.2.1...
  • Page 21 Contents Suppressing Hunting (Super2 Function) ..............8-100 Suppressing Integral Action (Anti-reset Wind-up) ............8-102 Performing Non-linear PID Control ................8-103 8.9 Adjusting Auto-tuning Operation .................. 8-104 Chapter 9 Auxiliary Control Functions Setting SP Limiter ......................9-1 Changing SP at a Fixed Rate (SP Ramp-Rate Setting Function) ........9-2 9.3 Forcing SP to Track PV (PV Tracking) ................
  • Page 22 Contents 12.2 Setting Contact Output Function ...................12-11 12.2.1 Setting Function of Contact Output ..............12-11 12.2.2 Changing Contact Type of Contact Output ............. 12-17 Chapter 13 Display, Key, and Security Functions 13.1 Setting Display Functions ....................13-1 13.1.1 Setting Active Color PV Display Function ............13-1 13.1.2 Masking Arbitrary Display Value in Operation Display ........13-4 13.1.3 Registering SELECT Display (Up to 5 Displays) ..........13-5 13.1.4 Changing Event Display ...................
  • Page 23 Contents 16.2.3 Replacing Parts ....................16-15 16.3 Periodic Maintenance ....................16-16 16.4 Disposal ........................16-17 Chapter 17 Installation and Wiring 17.1 Installation Location ......................17-1 17.2 Mounting Method ......................17-3 17.3 External Dimensions and Panel Cutout Dimensions ............17-4 17.4 Wiring ..........................17-5 17.4.1 Important Information on Wiring ............... 17-5 17.4.2 PV Input Wiring ....................
  • Page 24 Contents 19.1.16 Environmental Conditions ................. 19-9 Appendix Input and Output Table Appendix 1 Input and Output Table (for Standard model) ............ App-1 Appendix 2 Input and Output Table (for Detailed model) ............. App-4 Revision Information Index IM 05P01C31-01EN...
  • Page 25 Blank Page...

  • Page 26: Chapter 1 Introduction To Functions

    Chapter 1 Introduction to Functions 1.1 Quick Setting Function The Quick setting function is a function to easily set the basic function of the controller. Check the contents. Buy and Unpacking Installation and Wiring: Chapter 17 Installation and Wiring Install and wire a controller, and then turn on the power. Q: What should I do to perform control immediately? Setup First, I want to set the input and output. A: Use the Quick setting function to perform the setup easily.

  • Page 27: Input/Output Function

    1.2 Input/Output Function PV Input (equipped as standard) PV input is a universal input to arbitrarily set the type and range for the thermocouple (TC), resistance-temperature detector (RTD), and DC voltage/current. ► Chapter 7 Input (PV, Remote, and Auxiliary Analog) Functions Current Voltage pulse Relay contact / Triac 2-wire trans- Motor-operated valve mitter Control Output (equipped as standard) Control output (OUT) is a universal output to arbitrarily set the type for the current, voltage pulse, and relay/triac.
  • Page 28 (OUT) and the like as an analog signal to, for example, the recorder. ► Chapter 10 Output (Control and Retransmission) Functions External device such as recorder etc. UT55A/UT52A Current Contact Input Up to 23 contact inputs can be incorporated. The operation modes can be switched.

  • Page 29: Control Functions

    Control Functions Control Mode The UT55A/UT52A are controllers equipped with 8 control modes. Some control modes require a remote input (RSP) terminal. For the auxiliary functions of control modes, see the respective sections. Control mode schematic diagram Description “Single-loop control” provides the basic control function having one control computation unit.
  • Page 30 1.3 Control Functions Control mode schematic diagram Description PV2 (RSP) “Cascade control” uses two control computation units and permits Cascade control using just a Cascade control single controller. Remote input (RSP) terminal is required for PID1 Loop-2 PV input. ► 8.1.4 Cascade Control, Cascade Heating/ PID2 cooling Control, and Cascade Position Proportional Control OUT from host “Loop control for backup”...
  • Page 31 1.3 Control Functions PID Control PID control is a general control using the PID control-related parameters. ► 8.2.1 PID Control Recorder UT55A/UT52A Alarms Retransmission output 4-20 mA DC Electric furnace Thyristor Heating/cooling Control Heating/cooling control is available only for Heating/cooling type. In Heating/cooling control, the controller outputs the result of control computation after splitting it into heating-purpose and cooling-purpose signals.
  • Page 32 1.3 Control Functions Two-position Two-level Control Two-position two-level control has two target setpoints to control ON and OFF respectively. ► 8.2.4 Two-position Two-level Control Output Hysteresis Hysteresis Main SP Sub-SP Initial value: Reverse Initial value: Direct (offset from main SP) Sample PI Control Sample PI control is useful for processes with long dead times where the results of the control output are not quickly reflected on the PV.

  • Page 33: Display And Key Functions

    To intended use of the operator, the display level of the parameter can be set. ► Chapter 18 Parameters User Function Keys The UT55A has user function keys (F1, F2, and Fn). The UT52A has a user function key (Fn). Assign a function to a user function key to use it as an exclusive key.

  • Page 34: Ladder Sequence Function

    Ladder Sequence Function To use the ladder sequence function, it is necessary to create a ladder program using LL50A Parameter Setting Software and download it to a controller. ► Ladder sequence function: LL50A Parameter Setting Software User’s Manual Ladder program IM 05P01C31-01EN...

  • Page 35: Communication Functions

    ► UTAdvanced Series Communication Interface (RS-485, Ethernet) User’s Manual ► UTAdvanced Series Communication Interface (Open Network) User’s Manual RS-485 Communication (Modbus communication, PC link communication, and Ladder communication) The UT55A/UT52A can communicate with PCs, PLCs, touch panels, and other devices. RS-485/ Model: ML2 of YOKOGAWA is recommended. RS-232C converter...
  • Page 36 Max. 1200 m, number of connected slaves: 31 Modbus Slave Modbus Slave Modbus Slave Modbus Slave DeviceNet Communication The UT55A can be used as the slave devices for DeviceNet communication. Read-out of PV, operation or alarm status, and SP setting can be done by accessing the remote I/O on the master unit of DeviceNet. DeviceNet Master DeviceNet communication DeviceNet Slave / Modbus Master Modbus/RTU communication Max.
  • Page 37 1.6 Communication Functions CC-Link Communication The UT55A can be used as the slave devices for CC-Link communication. Read-out of PV, operation or alarm status, and SP setting can be done by accessing the remote I/O on the master unit of CC-Link. CC-Link Master CC-Link communication CC-Link Slave / Modbus Master Modbus/RTU communication Max. 1200 m, number of connected slaves: 31...
  • Page 38 Maintenance port is used to connect with the dedicated cable when using LL50A Parameter Setting Software (sold separately). The parameters can be set without supplying power to the UT55A/UT52A. Likewise, the ladder program can also be downloaded. LL50A Parameter Setting Software...

  • Page 39: Definition Of Main Symbols And Terms

    1.7 Definition of Main Symbols and Terms Main Symbol PV: Measured input value SP: Target setpoint OUT: Control output value RSP: Remote setpoint A/M: AUTO/MAN C/A/M: CAS/AUTO/MAN AUTO: Automatic MAN: Manual CASCADE, CAS: Cascade REMOTE, REM: Remote LOCAL, LCL: Local E1, E2, E3, and E4: Terminal areas ► 17.4 Wiring Engineering Units Input range (scale): the PV range low limit is set to 0%, and the high limit is set to 100% for conversion.

  • Page 40: Chapter 2 Ut55A/Ut52A Operating Procedures

    Chapter 2 UT55A/UT52A Operating Procedures 2.1 UT55A/UT52A Operating Procedures Installation Install and wire a controller. and Wiring Installation and Wiring: Chapter 17 Power ON Control mode setup Section 8.1 Control type setup Section 8.2 Control mode: Single-loop control only Control type setup Quick setting function: Input/output setup...
  • Page 41 Blank Page...

  • Page 42: Chapter 3 Part Names

    Chapter 3 Part Names 3.1 Names and Functions of Display Parts See the next page. IM 05P01C31-01EN...
  • Page 43 3.1 Names and Functions of Display Parts UT55A (9) Deviation indicator (1) PV display (2) Group display (4) Data display (3) Symbol display (10) Status indicator (5) Bar-graph display (11) Security indicator (6) Event indicator (7) Key navigation indicator (12) Ladder operation indicator (13) Loop 2 indicator...
  • Page 44 Position proportional control); in Heating/cooling control, upper bar (heating-side control output), lower bar (cooling-side control output) UT55A: Lit when the alarms 1 to 8 occur. (Initial value: 1 to Event indicator UT52A: Lit when the alarms 1 to 4 occur. (orange) Event displays other than alarms can be set by the parameter.

  • Page 45: Names And Functions Of Keys

    3.2 Names and Functions of Keys UT55A (1) DISPLAY key (4) Light-loader interface (2) PARAMETER key (5) A/M key (3) SET/ENTER key (6) User function keys Up/Down/Left/Right arrow keys UT52A (6) User function keys (1) DISP key (4) Light-loader interface (2) PARA key (5) A/M key...
  • Page 46 A/M key time the key is pressed. The user can assign a function key. The UT55A has F1, F2, and Fn keys. User function keys The UT52A has only the Fn key. The user can assign a function to the key. The function is set by the parameter.
  • Page 47 3.2 Names and Functions of Keys Maintenance Port (Power supply is not required for the UT55A/UT52A). The maintenance port is used to connect with the dedicated cable when using LL50A Parameter Setting Software (sold separately). The parameters can be set without supplying power to the UT55A/UT52A. Maintenance port Upper surface Upper surface UT52A UT55A CAUTION When using the maintenance port, do not supply power to the controller.

  • Page 48: List Of Display Symbols

    3.3 List of Display Symbols The following shows the parameter symbols, menu symbols, alphanumeric of guide, and symbols which are displayed on the UT55A/UT52A. Figure (common to all display area) PV display (14 segments): Alphabet Symbol display and Data display (11 segments): Alphabet (lower-case) IM 05P01C31-01EN...
  • Page 49 3.3 List of Display Symbols Group display (7 segments): Alphabet None PV display (14 segments): Symbol Space ‘ IM 05P01C31-01EN...

  • Page 50: Brief Description Of Setting Details (Parameters)

    Brief Description of Setting Details (Parameters) This manual describes the Setting Details as follows in addition to the functional Description. Setting Details (Display Example) Parameter Display Name Setting range Menu symbol symbol level Set a display value of setpoint of PV alarm, SP alarm, deviation alarm, output alarm, or velocity Alarm-1 to -8 alarm.
  • Page 51 Blank Page...

  • Page 52: Chapter 4 Basic Operation

    Chapter 4 Basic Operation Overview of Display Switch and Operation Keys The following shows the transition of Operation Display, Operation Parameter Setting Display, and Setup Parameter Setting Display. The “Operation Parameter Setting Display” has the parameters for setting the functions necessary for the operation. The “Setup Parameter Setting Display” has the parameters for setting the basic functions of the controller.
  • Page 53 4.1 Overview of Display Switch and Operation Keys The display pattern of the UT55A/UT52A is as follows; the Menu Display and Parameter Setting Display. For the Operation Display, see Chapter 6, “Monitoring and Control of Regular Operations.” Display Description The Menu Display is segmented by the function and optional terminal position.
  • Page 54 4.1 Overview of Display Switch and Operation Keys Display Shown at the End (the Lowest Level) of the Parameter Setting Display As shown in the figure below, the END Display is shown to indicate the end of the Menu Display and Parameter Setting Display. There are no setting items. The scrolling guide of END is displayed. END is displayed. Basic Key Operation Sequence ● To move to the Setup Parameter Setting Display Hold down the PARAMETER (or PARA) key and the Left arrow key simultaneously for 3...

  • Page 55: How To Set Parameters

    4.2 How to Set Parameters The following operating procedure describes an example of setting alarm setpoint (A1). Operation Hold down the PARAMETER key for 3 seconds in the Operation Display to call up the [MODE] Menu Display. Press the Right arrow key to display the [SP] Menu Display. Press the SET/ENTER key to display the [SP] Parameter Setting Display.
  • Page 56 4.2 How to Set Parameters Press the SET/ENTER key to blink the setpoint. Press the Up or Down arrow key to change the setpoint. (Change the setpoint using the Up/Down arrow keys to increase and decrease the value and the Left/Right arrow keys to move between digits.) Press the SET/ENTER key to register the setpoint (the setpoint stops blinking).
  • Page 57 4.2 How to Set Parameters How to Set Parameter Setpoint Numeric Value Setting Display the Parameter Setting Display. Press the SET/ENTER key to move to the setting mode (the setpoint blinks). Press the Left arrow key to move one digit to the left. (Press the Right arrow key to move one digit to the right.) Press the Up or Down arrow key to change the setpoint.
  • Page 58 4.2 How to Set Parameters Time (minute.second) Setting Example of 17 minutes 59 seconds Display the Parameter Setting Display. Press the SET/ENTER key to move to the setting mode (the setpoint blinks). Press the Left arrow key to move one digit to the left. (press the Right arrow key to move one digit to the right.) Press the Up or Down arrow key to change the setpoint.
  • Page 59 Blank Page...

  • Page 60: Chapter 5 Quick Setting Function App

    Chapter 5 Quick Setting Function 5.1 Setting Using Quick Setting Function Description The Quick setting function is a function to easily set the basic function of the controller. The Quick setting function starts when the power is turned on after wiring. The Quick setting function can be used only when the control mode is Single-loop control. In other control modes, set the functions without using the Quick setting function. The following lists the items to set using the Quick setting function. (1) Control type (PID control, Heating/cooling control, etc.) (2) Input function (PV input, range, scale (at voltage/current input), etc.) (3) Output function (control output type and cycle time) IM 05P01C31-01EN...
  • Page 61 5.1 Setting Using Quick Setting Function Flowchart of Quick Setting Function Power ON Decide whether or not to use the Quick setting function. Press the UP arrow key to select YES. Press the SET/ENTER key to start the Quick setting function. Press the Down arrow key to select NO. Press the SET/ENTER key not to start the Quick setting function.
  • Page 62 5.1 Setting Using Quick Setting Function Setting Example Set the following parameters to set to PID control, thermocouple Type K (range: 0.0 to 500.0ºC), and current control output. No need to change the parameters other than the following parameters. Set QSM = YES to enter the quick setting mode. (1) Set CNT = PID. (2) Set IN = K1. (3) Set UNIT = C (initial value). (4) Set RH = 500.0. (5) Set RL = 0.0. (6) Set OT = 00.02 Set EXIT = YES to quit the quick setting mode.
  • Page 63 5.1 Setting Using Quick Setting Function Input Function Parameter Display Name Setting range Menu symbol symbol level OFF: Disable K1: -270.0 to 1370.0 ºC / -450.0 to 2500.0 ºF K2: -270.0 to 1000.0 ºC / -450.0 to 2300.0 ºF K3: -200.0 to 500.0 ºC / -200.0 to 1000.0 ºF J: -200.0 to 1200.0 ºC / -300.0 to 2300.0 ºF T1: -270.0 to 400.0 ºC / -450.0 to 750.0 ºF T2: 0.0 to 400.0 ºC / -200.0 to 750.0 ºF...
  • Page 64 5.1 Setting Using Quick Setting Function Input Function (Continued) Parameter Display Name Setting range Menu symbol symbol level 0: No decimal place PV input scale 1: One decimal place decimal point EASY 2: Two decimal places position 3: Three decimal places 4: Four decimal places Maximum value of EASY PV input scale -19999 to 30000, (SL<SH), Minimum value of | SH - SL | ≤ 30000...

  • Page 65: Restarting Quick Setting Function

    5.2 Restarting Quick Setting Function Once functions have been built using the Quick setting function, the Quick setting function does not start even when the power is turned on. The following methods can be used to restart the Quick setting function. ● Set the parameter QSM (Quick setting mode) to ON and turn on the power again. ● Set the parameter IN (PV input type) to OFF and turn on the power again. CAUTION The parameters related to the range or scale are initialized if the PV input type is changed. Changing the control mode (CTLM) allows you to restart the Quick setting function. However, be careful because some parameters will be initialized. Setting Details Parameter Display Name Setting range Menu symbol symbol level PV input type EASY OFF: Disable OFF: Disable...

  • Page 66: Chapter 6 Monitoring And Control Of Regular Operations

    Chapter 6 Monitoring and Control of Regular Operations 6.1 Monitoring and Control of Operation Displays 6.1.1 Operation Display Transitions in Single-loop Control, Cascade Primary- loop Control, Cascade Secondary-loop Control, Loop Control for Backup, and Loop Control with PV-hold Function. (The displays only for the Standard type are displayed in Cascade primary-loop control.) ► Display/Non-display of Operation Display: 13.3.5 Setting Display/Non-display of Operation Display ► Registration of SELECT Display: 13.1.3 Registering SELECT Display (Up to 5 displays) Standard Type SP Display (SP can be changed.) OUT Display (OUT can be changed in MAN mode.)

  • Page 67: Position Proportional Type

    6.1 Monitoring and Control of Operation Displays Position Proportional Type SP Display (SP can be changed.) Valve Position Display (display only) Position Proportional Computation Output Display (Factory default: non-display) Program Pattern Number Display (Display only) Parameter RMS = PROG PID Number Display (display only) (Factory default: non-display) Analog Input Displays (display only) (Factory default: non-display) PV: PV analog input,...

  • Page 68: Heating/Cooling Type

    6.1 Monitoring and Control of Operation Displays Heating/cooling Type SP Display (SP can be changed.) Heating/cooling OUT Display (OUT can be changed in MAN mode.) C: cooling-side output, H: heating-side output Program Pattern Number Display (Display only) Parameter RMS = PROG PID Number Display (display only) (Factory default: non-display) Analog Input Displays (display only) (Factory default: non-display)

  • Page 69: Single-Loop Two-Position Two-Level Control

    6.1 Monitoring and Control of Operation Displays Single-loop Two-position two-level control SP Display (SP can be changed.) OUT Display (Main setting-side OUT can be changed in MAN mode.) OUT Display (Sub-setting-side OUT can be changed in MAN mode.) プログラムパターン番号表示画面 （表示のみ） パラメータRMS=PROG PID Number Display (display only) (Factory default: non-display) Heater Break Alarm-1 Current Display (display only) (Only for Heater break alarm option) Heater Break Alarm-2 Current Display (display only)

  • Page 70: Operation Display Transitions In Loop Control With Pv Switching And Loop Control With Pv Auto-Selector

    6.1 Monitoring and Control of Operation Displays 6.1.2 Operation Display Transitions in Loop Control with PV Switching and Loop Control with PV Auto-selector ► Display/non-display of Operation Display: 13.3.5 Setting Display/Non-display of Operation Display ► Registration of SELECT Display: 13.1.3 Registering SELECT Display (Up to 5 Displays) Standard Type SP Display (SP can be changed.) OUT Display (OUT can be changed in MAN mode.) Program Pattern Number Display (Display only) Parameter RMS = PROG PID Number Display (display only)

  • Page 71: Position Proportional Type

    6.1 Monitoring and Control of Operation Displays Position Proportional Type SP Display (SP can be changed.) Valve Position Display (display only) Position Proportional Computation Output Display (Factory default: non-display) Program Pattern Number Display (Display only) Parameter RMS = PROG PID Number Display (display only) (Factory default: non-display) Analog Input Displays (display only) PV: PV analog input, RSP: RSP analog input (E1-terminal area),...

  • Page 72: Heating/Cooling Type

    6.1 Monitoring and Control of Operation Displays Heating/cooling Type SP Display (SP can be changed.) Heating/cooling OUT Display (OUT can be changed in MAN mode.) C: cooling-side output, H: heating-side output Program Pattern Number Display (Display only) Parameter RMS = PROG PID Number Display (display only) (Factory default: non-display) Analog Input Displays (display only) PV: PV analog input,...

  • Page 73: Operation Display Transitions In Cascade Control

    6.1 Monitoring and Control of Operation Displays 6.1.3 Operation Display Transitions in Cascade Control ► Display/non-display of Operation Display: 13.3.5 Setting Display/Non-Display of Operation Display ► Registration of SELECT Display: 13.1.3 Registering SELECT Display (Up to 5 Displays) Standard Type When the operation mode is Cascade: Loop-1 SP Display (SP can be changed.) PV display: Loop-1 PV Loop-2 OUT Display (display only) PV display: Loop-1 PV...
  • Page 74 6.1 Monitoring and Control of Operation Displays When the operation mode is AUTO or MAN: Loop-2 SP Display (SP can be changed.) PV display: Loop-2 PV LP2 lamp is lit. Loop-2 OUT Display (OUT can be changed.) PV display: Loop-2 PV LP2 lamp is lit. Program Pattern Number Display (Display only) Parameter RMS = PROG PV display: Loop-1 PV Loop-1 PID Number Display (display only)

  • Page 75: Position Proportional Type

    6.1 Monitoring and Control of Operation Displays Position Proportional Type When the operation mode is Cascade: Loop-1 SP Display (SP can be changed.) PV display: Loop-1 PV Valve Position Display (display only) PV display: Loop-1 PV LP2 lamp is lit. Position Proportional Computation Output Display (Factory default: non-display) PV display: Loop-1 PV LP2 lamp is lit.
  • Page 76 6.1 Monitoring and Control of Operation Displays When the operation mode is AUTO or MAN: Loop-2 SP Display (SP can be changed.) PV display: Loop-2 PV LP2 lamp is lit. Valve Position Display (display only) PV display: Loop-2 PV LP2 lamp is lit. Position Proportional Computation Output Display (Factory default: non-display) PV display: Loop-2 PV LP2 lamp is lit.

  • Page 77: Heating/Cooling Type

    6.1 Monitoring and Control of Operation Displays Heating/cooling Type When the operation mode is Cascade: Loop-1 SP Display (SP can be changed.) PV display: Loop-1 PV Loop-2 Heating/cooling OUT Display (OUT can be changed.) PV display: Loop-1 PV C: cooling-side OUT, H: heating-side OUT LP2 lamp is lit. Program Pattern Number Display (Display only) Parameter RMS = PROG PV display: Loop-1 PV...
  • Page 78 6.1 Monitoring and Control of Operation Displays When the operation mode is AUTO or MAN: Loop-2 SP Display (SP can be changed.) PV display: Loop-2 PV LP2 lamp is lit. Loop-2 Heating/cooling OUT Display (OUT can be changed.) PV display: Loop-2 PV C: cooling-side OUT, H: heating-side OUT LP2 lamp is lit.
  • Page 79 6.1 Monitoring and Control of Operation Displays Details of the Operation Display The following is the Operation Display types and each display and operation description. PV display Setpoint display Operation Display Display and operation description PV display: Displays measured input value (PV). Setpoint display: Displays and changes target setpoint (SP). Symbol Target setpoint Target setpoint (SP) number The Display is switched to the SP Display if the operation mode is switched to AUTO, CAS, LCL, or REM when other Operation Display is shown.
  • Page 80 6.1 Monitoring and Control of Operation Displays (Continued) Operation Display Display and operation description PV display: Displays measured input value (PV). Setpoint display: Displays control output value and changes control output value in MAN mode. Control output Symbol Target setpoint (SP) number Displays the valve's feedback input value (at 0 to 100% valve opening) in Position proportional control. The Display is switched to the OUT Display if the operation mode is switched to MAN when other Operation Display is shown.
  • Page 81 6.1 Monitoring and Control of Operation Displays (Continued) Operation Display Display and operation description PV display: Displays measured input value (PV). Setpoint display: Displays heating-side and cooling-side control output value and changes control output value in MAN mode. Heating-side control output Symbol of heating side Cooling-side control output Symbol of cooling side Target setpoint (SP) number When the control output value is less than 100%, one digit is displayed to the right of the decimal point.
  • Page 82 6.1 Monitoring and Control of Operation Displays (Continued) Operation Display Display and operation description PV display: Displays measured input value (PV). Setpoint display: Displays PID number currently being used. PID Number Symbol PID number Display Target setpoint (SP) number Loop-1 PID number is displayed when the control mode is Cascade control and the operation mode is cascade. Loop-2 PID number is displayed when the control mode is Cascade control and the operation mode is AUTO or MAN.

  • Page 83: Analog Input

    6.1 Monitoring and Control of Operation Displays (Continued) Operation Display Display and operation description PV display: Displays measured input value (PV). Setpoint display: Displays PV, RSP, AIN2, or AIN4 analog input value. AIN2 auxiliary analog input value Symbol AIN2 input Analog Input Target setpoint (SP) number Display AIN4 auxiliary analog input value Symbol AIN4 input Target setpoint (SP) number PV display: Displays measured input value (PV). Setpoint display: Displays position proportional computation output value (internal computed value).

  • Page 84: Setting Target Setpoint

    6.2 Setting Target Setpoint Operation in the Operation Display Operation Bring the SP Display into view. Press the SET/ENTER key to move to the setting mode (the setpoint blinks). Press the Left arrow key to move one digit to the left. (Press the Right arrow key to move one digit to the right.) Press the Up or Down arrow key to change a setpoint.

  • Page 85: Operation In Parameter Setting Display

    6.2 Setting Target Setpoint Operation in Parameter Setting Display Setting Display Operation Display > PARAMETER or PARA key for 3 Parameter Setting Display seconds (to [MODE] Menu Display) > Right arrow key (to [SP] Menu Display ) > SET/ENTER key (The setting parameter is displayed.) Press the Right arrow key until the [SP] Menu Display appears. In the Setting Display for the target setpoint parameter, pressing the Left or Right arrow keys changes the group.

  • Page 86: Performing And Canceling Auto-Tuning

    6.3 Performing and Canceling Auto-tuning Setting Display Operation Display > PARAMETER or PARA key for 3 seconds Operation Mode Setting Display (to [MODE] Menu Display) > SET/ENTER key (The operation mode is displayed.) > Down arrow key (The operation mode is displayed.) The parameter AT is displayed when the operation mode is AUTO.
  • Page 87 6.3 Performing and Canceling Auto-tuning In Cascade control, perform Loop-2 auto-tuning in AUTO and RUN modes, then Loop-1 auto-tuning in Cascade and RUN modes. Lamp Status Status STOP lamp CAS lamp MAN lamp During auto-tuning of Loop-2 Unlit Unlit Blinking During auto-tuning of Loop-1 Unlit Blinking Description Auto-tuning is a function with which the controller automatically measures the process characteristics and sets PID constants, which are control-related parameters, to optimum values for the setpoint.
  • Page 88 6.3 Performing and Canceling Auto-tuning Tuning Point and Storage Location of Tuning Results The tuning point when performing auto-tuning is the target setpoint that is currently used for control computation. PID constants after the tuning are stored in the PID group that is specified when performing auto-tuning.

  • Page 89: Adjusting Pid Manually

    6.4 Adjusting PID Manually Setting Display Operation Display > PARAMETER or PARA key for 3 Parameter Setting Display seconds (to [MODE] Menu Display) > Right arrow key (to [PID] Menu Display ) > SET/ENTER key (The setting parameter is displayed.) > Down arrow key (The setting parameter is displayed.) In the Setting Display for the PID parameters, Displays can be arbitrarily switched using the Up, Down, Left or Right arrow...
  • Page 90 6.4 Adjusting PID Manually There are eight groups of PID parameters. In Cascade control, both Loop 1 and Loop 2 have eight groups. The PID parameters can be selected by using the following two methods: (1) SP group number selection The PID group which is set in the PID number selection (PIDN) of each SP group is used.
  • Page 91 6.4 Adjusting PID Manually Description Description and Tuning of Proportional Band The proportional band is defined as the amount of change in input (or deviation), as a percent of span, required to cause the control output to change from 0% to 100%. Because a narrower proportional band gives greater output change for any given deviation, it therefore also makes the control performance more susceptible to oscillation. At the same time, a narrower proportional band reduces the offset.
  • Page 92 6.4 Adjusting PID Manually Description and Tuning of Integral Time The integral action (I action) is a function that will automatically diminish the offset (steady-state deviation) that is inherently unavoidable with proportional action alone. The integral action continuously increases or decreases the output in proportion to the time integral of the deviation (the product of the deviation and the time that the deviation continues.) The integral action is normally used together with proportional action as proportional- plus-integral action (PI action).
  • Page 93 6.4 Adjusting PID Manually Description and Tuning of Derivative Time If the control object has a large time constant or dead time, the corrective action will be too slow with proportional action or proportional-plus-integral action alone, causing overshoot. However, even just sensing whether the deviation is on an increasing or a decreasing trend and adding some early corrective action can improve the controllability. Thus the derivative action (D action) is action that changes the output in proportion to the deviation derivative value (rate-of-change).
  • Page 94 6.4 Adjusting PID Manually Manual PID Tuning Procedure (1) In principle, auto-tuning must be used. (2) Tune PID parameters in the order of P, I, and D. Adjust a numeric slowly by observing the result, and keep notes of what the progress is. (3) Gradually reduce P from a larger value. When the PV value begins to oscillate, stop tuning and increase the value somewhat. (4) Also gradually reduce I from a larger value. When the PV value begins to oscillate (with long period), stop tuning and increase the value somewhat. (5) Gradually increase D from a smaller value. When the PV value begins to oscillate (with short period), stop tuning and lower the value slightly.

  • Page 95: Setting Alarm Setpoint

    6.5 Setting Alarm Setpoint Setting Display Operation Display > PARAMETER or PARA key for 3 Parameter Setting Display seconds (to [MODE] Menu Display) > Right arrow key (to [SP] Menu Display) > SET/ENTER key (The setting parameter is displayed.) > Down arrow key (The setting parameter is displayed.) In the setting Display for the alarm parameters, Displays can be arbitrarily switched using the Up, Down, Left or Right arrow...

  • Page 96: Selecting Target Setpoint Number (Spno)

    6.6 Selecting Target Setpoint Number (SPNO) Setting Display Operation Display > PARAMETER or PARA key for 3 seconds Parameter Setting Display (to [MODE] Menu Display) > SET/ENTER key (The setting parameter is displayed.) > Down arrow key (The setting parameter is displayed.) Setting Details Parameter Display Name...

  • Page 97: Switching Operation Modes

    6.7 Switching Operation Modes 6.7.1 Switching between AUTO and MAN Direct Operation by A/M Key Operation MAN lamp is lit in MAN mode. Each time you press the key, AUTO and MAN is switched alternately. Description AUTO/MAN switching can be performed by any of the following: (1) A/M key (2) Contact input (status or edge) (3) Communication (4) User function key AUTO...
  • Page 98 6.7 Switching Operation Modes Operation Display in AUTO and MAN Modes “OUT” is displayed on Symbol display and “Output value” is displayed on Data display in MAN mode. (The OUT Display is shown.) Sub-setting-side OUT Display is shown in Two-position two-level control. SP Display is shown in AUTO mode. Operation Display in AUTO and MAN Modes in Heating/cooling Control In MAN mode, the Display is as follows.

  • Page 99: Switching Between Cas (Cascade), Auto, And Man

    6.7 Switching Operation Modes 6.7.2 Switching between CAS (Cascade), AUTO, and MAN Setting Display Operation Mode Setting Display Operation Display > PARAMETER or PARA key for 3 seconds (to [MODE] Menu Display) > SET/ENTER key (The operation mode is displayed.) > Down arrow key (The operation mode is displayed.) Setting Details Parameter Display...
  • Page 100 6.7 Switching Operation Modes Output Action in CAS/AUTO/MAN Switch Switch Output action CAS→AUTO The control output value does not bump (bumpless). The control output value bumps to the manual preset output value. CAS→MAN Or holds the control output value from CAS mode. AUTO→CAS The control output value does not bump (bumpless). The control output value bumps to the manual preset output value.

  • Page 101: Switching Between Stop And Run

    6.7 Switching Operation Modes 6.7.3 Switching between STOP and RUN Setting Display Operation Mode Setting Display Operation Display > PARAMETER or PARA key for 3 seconds (to [MODE] Menu Display) > SET/ENTER key (The operation mode is displayed.) > Down arrow key (The operation mode is displayed.) Factory default: The parameter S.R is not displayed because STOP/RUN switch is assigned to the contact input.
  • Page 102 6.7 Switching Operation Modes Operation Display in STOP and RUN Modes “STOP” is displayed on Symbol display and “Output value” is displayed on Data display in STOP mode. Preset output value is displayed. In Two-position two-level control The display at operation start differs depending on AUTO or MAN mode. SP Display is shown in AUTO mode and OUT Display is shown in MAN mode.

  • Page 103: Switching Between Rem (Remote) And Lcl (Local)

    6.7 Switching Operation Modes 6.7.4 Switching between REM (Remote) and LCL (Local) Setting Display Operation Mode Setting Display Operation Display > PARAMETER or PARA key for 3 seconds (to [MODE] Menu Display) > SET/ENTER key (The operation mode is displayed.) > Down arrow key (The operation mode is displayed.) Setting Details Parameter Display...
  • Page 104 6.7 Switching Operation Modes SP Action in REM/LCL Switch Switch SP action LCL→REM The local target setpoint bumps to the remote target setpoint. The remote target setpoint bumps to the local target setpoint. Or forces the local REM→LCL target setpoint to track the remote target setpoint. ► Tracking: 9.4 Forcing SP to Track Remote Input (SP Tracking) Lamp Status Status REM lamp...

  • Page 105: Manipulating Control Output During Manual Operation

    6.8 Manipulating Control Output during Manual Operation Operation MAN lamp is lit. Press the Up arrow key to increase control output. Press the Down arrow key to decrease control output. In Heating/cooling control, press the Up arrow key to decrease cooling-side control output and to increase heating-side control output; press the Down arrow key to increase cooling-side control output and to decrease heating-side control output.

  • Page 106: Releasing On-State (Latch) Of Alarm Output

    6.9 Releasing On-State (Latch) of Alarm Output Description Alarm latch can be released by any of the following. (1) User function key (2) Communication (3) Contact input For the switching operation by using the above, the last switching operation is performed. Releasing the alarm latch function releases all of the latched alarm outputs. By factory default, the function is not assigned to the user function key and contact input.
  • Page 107 Blank Page...

  • Page 108: Chapter 7 Input (Pv, Remote, And Auxiliary Analog) Functions

    Chapter 7 Input (PV, Remote, and Auxiliary Analog) Functions 7.1 Setting Functions of PV Input, Remote Input, and Auxiliary Analog Input 7.1.1 Setting Input Type, Unit, Range, Scale, and Decimal Point Position Description The figure below describes the case of PV input. The remote input and auxiliary analog input can be set in the same way. Example of Temperature Input The figure below is an example of setting Type K thermocouple and a measurement range of 0.0 to 800.0 ºC. -270.0°C 1370.0°C Input type...
  • Page 109 7.1 Setting Functions of PV Input, Remote Input, and Auxiliary Analog Input Setting Details Parameter Display Name Setting range Menu symbol symbol level OFF: Disable K1: -270.0 to 1370.0 ºC / -450.0 to 2500.0 ºF K2: -270.0 to 1000.0 ºC / -450.0 to 2300.0 ºF K3: -200.0 to 500.0 ºC / -200.0 to 1000.0 ºF J: -200.0 to 1200.0 ºC / -300.0 to 2300.0 ºF T1: -270.0 to 400.0 ºC / -450.0 to 750.0 ºF T2: 0.0 to 400.0 ºC / -200.0 to 750.0 ºF...
  • Page 110 7.1 Setting Functions of PV Input, Remote Input, and Auxiliary Analog Input (Continued) Parameter Display Name Setting range Menu symbol symbol level Depends on the input type. - For temperature input - Set the temperature range Maximum value of PV EASY that is actually controlled. input range (RL<RH) - For voltage / current input - Set the range of a voltage / current signal that is applied.
  • Page 111 7.1 Setting Functions of PV Input, Remote Input, and Auxiliary Analog Input Parameter Display Name Setting range Menu symbol symbol level Minimum value of PV EASY input scale Minimum value of RSP EASY remote input range -19999 to 30000, (SL<SH), (Scaling) | SH - SL | ≤ 30000 Minimum value of AIN2 EASY AIN2 aux. analog input scale Minimum value of AIN4 EASY AIN4 aux.

  • Page 112: Setting Burnout Detection For Input

    7.1 Setting Functions of PV Input, Remote Input, and Auxiliary Analog Input 7.1.2 Setting Burnout Detection for Input Description The input value when input burnout occurs can be determined. The input value is 105.0% of the input range when the upscale is set, and -5.0% of the input range when the downscale is set. Burnout detection is activated for TC, RTD, and standard signal (0.4–2 V or 1–5 V). For standard signal, burnout is determined to have occurred if it is 0.1 V or less for the range of 0.4–2 V and 1–5V, or if it is 0.4 mA or less for the range of 4–20 mA. When input burnout occurs, the error preset output (EPO) is output as control output. ► Input error preset output: 10.12.3 Setting Output Value When Error Occurs (Input Error Preset Output) Setting Details...

  • Page 113: Compensation (Erjc)

    However, if it is necessary to rigorously compensate the values with a device other than the function of the controller, for example with a zero-compensator, the RJC function of the controller can be turned off. External Reference Junction Compensation (ERJC) For TC input, a temperature compensation value for external device can be set. The external RJC can be used only when RJC = OFF. UT55A/UT52A Terminal block Compensating lead wire Furnace UT55A/UT52A Normal wiring...

  • Page 114: Correcting Input Value

    7.1 Setting Functions of PV Input, Remote Input, and Auxiliary Analog Input 7.1.4 Correcting Input Value (1) Setting Bias and Filter Description PV Input Bias The PV input bias allows bias to be summed with input to develop a measured value for display and control use inside the controller. This function can also be used for fine adjustment to compensate for small inter- instrument differences in measurement reading that can occur even if all are within the specified instrument accuracies. PV input bias is used for normal operation. PV input value PV input bias PV value inside the controller Temperature sensed Compensation Estimated material...
  • Page 115 7.1 Setting Functions of PV Input, Remote Input, and Auxiliary Analog Input Setting Details Parameter Display Name Setting range Menu symbol symbol level -100.0 to 100.0% of PV PV input bias EASY input range span (EUS) PVS PV input filter EASY OFF, 1 to 120 s Parameter Display Name Setting range Menu symbol symbol level PV analog input bias RSP analog input bias -100.0 to 100.0% of each A.BS input range span (EUS) AIN2 aux.

  • Page 116: Setting Square Root Extraction And Low Signal Cutoff Point

    7.1 Setting Functions of PV Input, Remote Input, and Auxiliary Analog Input (2) Setting Square Root Extraction and Low Signal Cutoff Point Description This calculation is used to convert, for example, a differential pressure signal from a throttling flow meter such as an orifice and nozzle into a flow-rate signal. There is no hysteresis for low signal cutoff point. Output Output Low signal cutoff Low signal cutoff point is variable. point is variable. Input Input Output = Input Output = Input The slope equals “1”...

  • Page 117: Setting 10-Segment Linearizer

    7.1 Setting Functions of PV Input, Remote Input, and Auxiliary Analog Input (3) Setting 10-segment Linearizer Description A total of up to four 10-segment linearizers can be used for the input unit and output unit. For the position used by a ten-segment linearizer, see the function block diagram. ► Function block diagram: 8.1 Setting Control Mode (CTLM) ► Output Linearizer: 10.13 Setting 10-segment Linearizer for Output 10-segment Linearizer Bias This function is used to correct an input signal affected by sensor deterioration. The corrected values are obtained by adding the corresponding bias values to each of the 11 points of optionally set input values. When 10-segment linearizer input is A1 or less, B1 is to be added. When 10-segment linearizer input is A11 or more, B11 is to be added.
  • Page 118 7.1 Setting Functions of PV Input, Remote Input, and Auxiliary Analog Input Setting Details Parameter Name Display level Setting range Menu symbol symbol OFF: Disable PV: PV analog input RSP: RSP analog input 10-segment AIN2: AIN2 analog input Group 1, 2: STD linearizer AIN4: AIN4 analog input Group 3, 4: PRO selection PVIN: PV input OUT: OUT analog output OUT2: OUT2 analog output RET: RET analog output 10-segment...

  • Page 119: Setting Ratio Bias/Filter

    7.1 Setting Functions of PV Input, Remote Input, and Auxiliary Analog Input Initial value of eatch control mode Control mode Group-1 PYS Goup-2 PYS Group-3 and -4 PYS Single-loop control Cascade primary-loop control Cascade secondary-loop control Cascade control Loop control for backup Loop control with PV switching Loop control with PV auto-selector PVIN Loop control with PV-hold function 7.1.5 Setting Ratio bias/filter Description Ratio bias computing performs ratio computation and bias addition for remote setpoints. SP = Remote input x Remote input ratio (RT) + Remote input bias (RBS) Setting Details Parameter...

  • Page 120: Setting Input Sampling Period (Control Period)

    7.2 Setting Input Sampling Period (Control Period) Setting Details Parameter Display Name Setting range Menu symbol symbol level 50: 50 ms Input sampling period 100: 100 ms (control period) 200: 200 ms Note: 50 ms; Available when the control mode is not Cascade control (CTLM≠CAS) and the following functions are not used: "SUPER" function, "SUPER 2" function. 7-13 IM 05P01C31-01EN...

  • Page 121: Using 4-Wire Rtd As Pv Input

    7.3 Using 4-wire RTD as PV Input Description To use the 4-wire RTD, the optional suffix code /DR is required for remote input (UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7; UT52A suffix code: Type 2 = 1 or 2), or the optional suffix code /U1 is required. Normally, PV terminal input is used as PV. When RSP terminal is used as PV, use the ladder program of LL50A Parameter Setting Software (sold separately) to switch the functions of the PV terminal and RSP terminal. ► LL50A Parameter Setting Software: LL50A Parameter Setting Software User’s Manual When PV terminal is used as PV, and When RSP terminal is used as PV, RSP terminal is used as RSP.

  • Page 122: Using Larger, Smaller, Average, Or Difference Of Two To Four Inputs As Pv

    For the input difference, the difference between input 1 and input 2 is computed. Input 1: PV terminal input Input 2: RSP terminal input Input 3: AIN2 auxiliary analog input (for UT55A only) Input 4: AIN4 auxiliary analog input (for UT55A only) ► Function block diagram for Loop control with PV auto-selector; 8.1.7 Loop Control with PV Auto-...

  • Page 123: Setting Remote Input Method

    7.5 Setting Remote Input Method Description There are two methods for remote input: analog input and communication. Decide which to use among two methods in advance. Program pattern operation Analog input: Remote setting using external analog signal (RSP terminal) Communication: Remote setting via external communication. Analog input Target setpoints 1 to 8 REMOTE...

  • Page 124: Adjusting Pv Range For Loop Control With Pv Switching Or Loop Control With Pv Auto-Selector

    7.6 Adjusting PV Range for Loop Control with PV Switching or Loop Control with PV Auto-selector Description Loop control with PV switching and Loop control with PV auto-selector need to determine the PV range for control if the measurement ranges of two input signals are different. The figure below is an example of setting PV input range of 0 to 200ºC, RSP terminal input of 100 to 800ºC, and control PV range of 0 to 800ºC. ► Block diagram of Loop control with PV switching: 8.1.6 Loop Control with PV Switching, Heating/cooling Loop Control with PV Switching, and Position Proportional Loop Control with PV Switching Control PV range PV input range to be controlled (P.RL) (P.RH) RSP input (SL or RL) (SH or RH) Group display: E1 Two input ranges PV input (RL or SL) (RH or SH) 800ºC Setting Details...

  • Page 125: Setting Pv Switching Methods Of Loop Control With Pv Switching

    7.7 Setting PV Switching Methods of Loop Control with PV Switching Description PV switching method of Loop control with PV switching can be set when the control mode is Loop control with PV switching. ► Block diagram of Loop control with PV switching: 8.1.6 Loop Control with PV Switching, Heating/cooling Loop Control with PV Switching, and Position Proportional Loop Control with PV Switching Input 1: PV terminal input Input 2: RSP terminal input Switching within the Temperature Range (Low-temperature side) (Parameter PV.2C=0) This method automatically switches PV within the range of input switching PV high limit and low limit. It should be selected in case where a sudden change in PV must be avoided. PV rising process Input 2 (High-temperature side) PV.HL PV.LL Input 1 (Low-temperature side) Time PV = Input 1 During switching PV = Input 2 PV falling process Input 2...
  • Page 126 7.7 Setting PV Switching Methods of Loop Control with PV Switching Switching within the Temperature Range (High-temperature side) (Parameter PV.2C=3) This method automatically switches PV within the range of input switching PV high limit and low limit. It should be selected in case where a sudden change in PV must be avoided. PV rising process Input 2 (High-temperature side) PV.HL PV.LL Input 1 (Low-temperature side) Time PV = Input 1 During switching PV = Input 2 PV falling process Input 2 (High-temperature side) PV.HL PV.LL Input 1 (Low-temperature side) Time PV = Input 2 During switching...
  • Page 127 7.7 Setting PV Switching Methods of Loop Control with PV Switching Switching at the Input Switching PV High Limit (Parameter PV.2C=1) This method automatically switches two inputs at switching point (input switching PV high limit) It should be selected in case where a sudden change in PV is allowed. Control output will change smoothly (i.e., without any bumps) when PV switches. Hysteresis (0.5% of PV range span) is provided around the switching point. PV rising process Input 2 (High-temperature side) PV.HL Input 1 Hysteresis (Low-temperature side) Time PV = Input 1 PV = Input 2 PV falling process Input 2 (High-temperature side) PV.HL Input 1 Hysteresis (Low-temperature side) Time PV = Input 1 PV = Input 2 When input 1 < PV.HL – 0.5% of PV input range span, PV=Input 1.
  • Page 128 7.7 Setting PV Switching Methods of Loop Control with PV Switching Switching by Contact Input (Parameter PV.2C=2) This method switches two inputs by contact input ON/OFF. When the contact input is OFF, PV = Input 1 (low-temperature side). When the contact input is ON, PV = Input 2 (high-temperature side). Input 2 (High-temperature side) Input 1 (Low-temperature side) Time Input 1 Input 2 Input 1 Input 2 Contact input The function is assigned to DI16 for the factory default when switched by DI. Control output will change smoothly (i.e., without any bumps) when PV switches.
  • Page 129 Blank Page...

  • Page 130: Chapter 8 Control Functions

    Chapter 8 Control Functions 8.1 Setting Control Mode (CTLM) 8.1.1 Single-loop Control, Single-loop Heating/cooling Control, Single-loop Position Proportional Control, and Single-loop Two-position Two-level Control Setting Details Parameter Name Display level Setting range Menu symbol symbol SGL: Single-loop control CAS1: Cascade primary-loop control CAS2: Cascade secondary-loop control CAS: Cascade control CTLM Control mode BUM: Loop control for backup PVSW: Loop control with PV switching PVSEL: Loop control with PV auto-...

  • Page 131: Single-Loop Control Function Block Diagram

    DI16 is equipped when code: Type 2 = 1, 2, 4, 5, or 7; UT52A suffix Feedforward input can be used when UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7; code: Type 2 = 1 or 2. Communication Equipped as standard UT55A suffix code: Type 2 = 7.
  • Page 132 Output limiter OH, OL Input error preset output Normal When sensor burnout occurs Manual preset output MPON Manual operation Output limiter OH, OL OLMT AUTO AUTO (ON)/MAN (OFF) switch Preset output STOP STOP (ON)/RUN (OFF) switch * After the control output terminal is specified by the parameter OT, Output terminal assignment other current output terminals can be used as retransmission output.

  • Page 133: Single-Loop Heating/Cooling Control Function Block Diagram

    (For Standard model) Remote input can be used when UT55A suffix DI16 is equipped when UT55A suffix code: Type 2 = code: Type 2 = 1, 2, 4, 5, or 7; UT52A suffix code: 1, 2, 4, 5, or 7; UT52A suffix code: Type 2 = 1 or 2.
  • Page 134 Manual preset output MPON Manual operation AUTO AUTO (ON)/MAN (OFF) switch Heating/cooling computation Manual output is prioritized even if sensor burnout occurs in MAN. Heating-side output limiter Cooling-side output limiter Input error preset output Input error preset output OH, OL OHc, OLc Normal Normal...

  • Page 135: Single-Loop Position Proportional Control Function Block Diagram

    (For Standard model) (For Standard model) DI16 is equipped when UT55A suffix Remote input can be used when UT55A suffix code: Feedforward input can be used when code: Type 2 = 1, 2, 4, 5, or 7; UT52A Type 2 = 1, 2, 4, 5, or 7; UT52A suffix code: Type 2 = UT55A suffix code: Type 2 = 7.
  • Page 136 Output limiter OH, OL In Estimating-type position proportional control, the limiter function does not work on output operation. Input error preset output The reverse-signal relay turns on when being limited by low limit. The direct-signal relay turns on when being limited by high limit. Normal When sensor burnout occurs In Manual operation, the relay turns on while the...

  • Page 137: Single-Loop Two-Position Two-Level Control Function Block Diagram

    DI1 to DI3 are equipped as standard. Remote input can be used when DI16 is equipped when UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7; UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7; Equipped as standard UT52A suffix code: Type 2 = 1 or 2.
  • Page 138 Manual output is prioritized even if sensor burnout occurs in MAN. Input error preset output Input error preset output Normal Normal When sensor burnout occurs When sensor burnout occurs Manual operation Manual operation AUTO AUTO AUTO (ON)/MAN (OFF) switch Preset output Sub-preset output SU.PO STOP...
  • Page 139 8.1 Setting Control Mode (CTLM) Intentionally blank 8-10 IM 05P01C31-01EN...

  • Page 140: Cascade Primary-Loop Control

    8.1 Setting Control Mode (CTLM) 8.1.2 Cascade Primary-loop Control Setting Details Parameter Display Name Setting range Menu symbol symbol level SGL: Single-loop control CAS1: Cascade primary-loop control CAS2: Cascade secondary-loop control CAS: Cascade control CTLM Control mode BUM: Loop control for backup PVSW: Loop control with PV switching PVSEL: Loop control with PV auto-selector PVHD: Loop control with PV-hold function CAUTION • Some parameters will be initialized if the control mode (CTLM) is changed.

  • Page 141: Cascade Primary-Loop Control Function Block Diagram

    /R1 or /RCH1. Remote input can be used when UT55A optional suffix code /A2. UT55A suffix code: Type 2 = 1, 2, 4, 5, or (For Standard model) 7; UT52A suffix code: Type 2 = 1 or 2 is...
  • Page 142 Output limiter OH, OL Input error preset output Normal AUTO (ON)/MAN (OFF) switch When sensor burnout occurs Manual preset output MPON Manual operation Output tracking input Output limiter OH, OL OLMT AUTO Output limiter OH, OL Preset output Output tracking switch (Tracking at ON) STOP STOP (ON)/RUN (OFF) switch Equipped as standard...
  • Page 143 8.1 Setting Control Mode (CTLM) Intentionally blank 8-14 IM 05P01C31-01EN...

  • Page 144: Cascade Secondary-Loop Control, Cascade Secondary-Loop Heating/Cooling Control, And Cascade Secondary-Loop Position Proportional Control

    8.1 Setting Control Mode (CTLM) 8.1.3 Cascade Secondary-loop Control, Cascade Secondary-loop Heating/ cooling Control, and Cascade Secondary-loop Position Proportional Control Setting Details Parameter Display Name Setting range Menu symbol symbol level SGL: Single-loop control CAS1: Cascade primary-loop control CAS2: Cascade secondary-loop control CAS: Cascade control CTLM Control mode BUM: Loop control for backup...

  • Page 145: Cascade Secondary-Loop Control Function Block Diagram

    (For Standard model) Cascade input can be used when UT55A suffix code: Type 2 DI16 is equipped when UT55A suffix code: Type 2 = 1, 2, 4, Equipped as standard = 1, 2, 4, 5, or 7; UT52A suffix code: Type 2 = 1 or 2.
  • Page 146 Output limiter OH, OL Input error preset output Normal When sensor burnout occurs Manual preset output MPON Manual operation Output limiter OH, OL OLMT AUTO Preset output STOP * After the control output terminal is specified by the parameter OT, other current output terminals can be used as retransmission output.

  • Page 147: Cascade Secondary-Loop Heating/Cooling Control Function Block Diagram

    Cascade input can be used when UT55A suffix (For Standard model) code: Type 2 = 1, 2, 4, 5, or 7; UT52A suffix code: DI16 is equipped when UT55A suffix code: Type 2 = Equipped as standard Type 2 = 1 or 2.
  • Page 148 Manual preset output MPON Manual operation AUTO Heating/cooling computation Manual output is prioritized even if sensor burnout occurs in MAN. Heating-side output limiter Cooling-side output limiter Input error preset output Input error preset output OH, OL OHc, OLc Normal Normal When sensor When sensor Heating-side preset output...

  • Page 149: Cascade Secondary-Loop Position Proportional Control Function Block Diagram

    (For Standard model) Cascade input can be used when UT55A suffix code: Type DI16 is equipped when UT55A suffix code: Type 2 = 1, 2, Equipped as standard 2 = 1, 2, 4, 5, or 7; UT52A suffix code: Type 2 = 1 or 2.
  • Page 150 Output limiter OH, OL In Estimating-type position proportional control, the limiter function does not work on output operation. Input error preset output The reverse-signal relay turns on when being limited by low limit. Normal The direct-signal relay turns on when being limited by high limit. When sensor burnout occurs In Manual operation, the relay turns on while the...
  • Page 151 8.1 Setting Control Mode (CTLM) Intentionally blank 8-22 IM 05P01C31-01EN...

  • Page 152: Cascade Control, Cascade Heating/Cooling Control, And Cascade Position Proportional Control

    8.1 Setting Control Mode (CTLM) 8.1.4 Cascade Control, Cascade Heating/cooling Control, and Cascade Position Proportional Control Setting Details Parameter Display Name Setting range Menu symbol symbol level SGL: Single-loop control CAS1: Cascade primary-loop control CAS2: Cascade secondary-loop control CAS: Cascade control CTLM Control mode BUM: Loop control for backup PVSW: Loop control with PV switching PVSEL: Loop control with PV auto- selector...

  • Page 153: Cascade Control Function Block Diagram

    Equipped as standard However, DI16 does not exist. Remote input can be used when UT55A suffix code: Type 2 = 7. suffix code: Type 2 = 1 or 2 is necessary. or 7; UT52A suffix code: Type 2 = 1 or 2.
  • Page 154 Output limiter OH, OL Input error preset output Normal When Loop-2 sensor burnout occurs Loop-2 parameters Manual preset output MPON Manual operation Output limiter OH, OL OLMT CAS, AUTO C/A/M Preset output STOP STOP (ON)/RUN (OFF) switch * After the control output terminal is specified by the parameter OT, Output terminal assignment other current output terminals can be used as retransmission output.

  • Page 155: Cascade Heating/Cooling Control Function Block Diagram

    For the model with optional suffix code /DR: Remote input with direct input (E1-terminal area) AIN2 DI16 can be used when UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7 and with optional suffix code /DR; Input type Input type Input type UT52A suffix code: Type 2 = 1 or 2 and with optional suffix code /DR.
  • Page 156 Manual preset output MPON Manual operation CAS, AUTO C/A/M Heating/cooling computation Manual output is prioritized even if Loop-2 parameters sensor burnout occurs in MAN. Heating-side output limiter Cooling-side output limiter Input error preset output Input error preset output OH, OL OHc, OLc Normal Normal...

  • Page 157: Cascade Position Proportional Control Function Block Diagram

    For the model with optional suffix code /DR: Remote input with direct input (E1-terminal area) AIN2 DI16 can be used when UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7 and with optional suffix code /DR; Input type Input type Input type UT52A suffix code: Type 2 = 1 or 2 and with optional suffix code /DR.
  • Page 158 In Estimating-type position proportional control, the limiter function Output limiter OH, OL Input error preset output does not work on output operation. Normal The reverse-signal relay turns on when being limited by low limit. When Loop-2 sensor burnout occurs The direct-signal relay turns on when being limited by high limit. In Manual operation, the relay turns on while the key is pressed.
  • Page 159 8.1 Setting Control Mode (CTLM) Intentionally blank 8-30 IM 05P01C31-01EN...

  • Page 160: Loop Control For Backup, Heating/Cooling Loop Control For Backup, And Position Proportional Loop Control For Backup

    8.1 Setting Control Mode (CTLM) 8.1.5 Loop Control for Backup, Heating/cooling Loop Control for Backup, and Position Proportional Loop Control for Backup Setting Details Parameter Display Name Setting range Menu symbol symbol level SGL: Single-loop control CAS1: Cascade primary-loop control CAS2: Cascade secondary-loop control CAS: Cascade control CTLM Control mode BUM: Loop control for backup PVSW: Loop control with PV switching PVSEL: Loop control with PV auto- selector PVHD: Loop control with PV-hold function CAUTION • Some parameters will be initialized if the control mode (CTLM) is changed.

  • Page 161: Loop Control For Backup Function Block Diagram

    /R1 or /RCH1. Remote input can be used when (For Standard model) UT55A optional suffix code /A2. UT55A suffix code: Type 2 = 1, 2, (For Standard model) DI16 is equipped when UT55A suffix (For Standard model) 4, 5, or 7;...
  • Page 162 Output limiter OH, OL Input error preset output Normal AUTO (ON)/MAN (OFF) switch When sensor burnout occurs Manual preset output MPON Manual operation Output tracking input Output limiter OH, OL OLMT AUTO Output limiter OH, OL Preset output Output tracking switch (Tracking at ON) STOP STOP (ON)/RUN (OFF) switch * After the control output terminal is specified by the parameter OT,...

  • Page 163: Heating/Cooling Loop Control For Backup Function Block Diagram

    (For Standard model) (For Standard model) optional suffix code /A2. UT55A suffix code: Type 2 = 1, 2, 4, 5, or DI16 is equipped when UT55A suffix (For Standard model) 7; UT52A suffix code: Type 2 = 1 or 2 code: Type 2 = 1, 2, 4, 5, or 7;...
  • Page 164 AUTO (ON)/MAN (OFF) switch Manual preset output MPON AUTO Output tracking input Manual operation Output limiter OH, OL Output tracking is prioritized even if sensor burnout Output tracking switch (Tracking at ON) occurs in the output tracking operation. Manual output is prioritized even if Heating/cooling computation sensor burnout...

  • Page 165: Position Proportional Loop Control For Backup Function Block Diagram

    (For Standard model) optional suffix code /A2. (For Standard model) UT55A suffix code: Type 2 = 1, 2, 4, 5, DI16 is equipped when UT55A suffix (For Standard model) or 7; UT52A suffix code: Type 2 = 1 or 2 code: Type 2 = 1, 2, 4, 5, or 7;...
  • Page 166 In Estimating-type position proportional control, the limiter function Output limiter OH, OL does not work on output operation. Input error preset output The reverse-signal relay turns on when being limited by low limit. Normal The direct-signal relay turns on when being limited by high limit. When sensor burnout occurs In Manual operation, the relay turns on while the...
  • Page 167 8.1 Setting Control Mode (CTLM) Intentionally blank 8-38 IM 05P01C31-01EN...

  • Page 168: Loop Control With Pv Switching, Heating/Cooling Loop Control With Pv Switching, And Position Proportional Loop Control With Pv Switching

    8.1 Setting Control Mode (CTLM) 8.1.6 Loop Control with PV Switching, Heating/cooling Loop Control with PV Switching, and Position Proportional Loop Control with PV Switching Setting Details Parameter Display Name Setting range Menu symbol symbol level SGL: Single-loop control CAS1: Cascade primary-loop control CAS2: Cascade secondary-loop control CAS: Cascade control CTLM Control mode BUM: Loop control for backup PVSW: Loop control with PV switching PVSEL: Loop control with PV auto-selector PVHD: Loop control with PV-hold function CAUTION...

  • Page 169: Loop Control With Pv Switching Function Block Diagram

    For the model with optional suffix code /DR: Remote input with direct input (E1-terminal area) AIN2 DI16 can be used when UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7 and with optional suffix code /DR; Input type Input type Input type...
  • Page 170 Output limiter OH, OL Input error preset output Normal When sensor burnout occurs Sensor burnout occurs when PV or RSP input burnout occurs. However, burnout is not detected if input is not connected. Manual preset output MPON Manual operation Output limiter OH, OL OLMT AUTO...

  • Page 171: Heating/Cooling Loop Control With Pv Switching Function Block Diagram

    PV input 2 Contact inputs Remote input with direct input (E1-terminal area) can be used when UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7 and AIN2 DI16 with optional suffix code /DR; UT52A suffix code: Type 2 = 1 or 2 and with optional suffix code /DR.
  • Page 172 Manual preset output MPON Manual operation AUTO AUTO (ON)/MAN (OFF) switch Heating/cooling computation Manual output is prioritized even if sensor burnout occurs in MAN. Heating-side output limiter Cooling-side output limiter Input error preset output Input error preset output OH, OL OHc, OLc Normal Normal...

  • Page 173: Position Proportional Loop Control With Pv Switching Function Block Diagram

    For the model with optional suffix code /DR: Remote input with direct input (E1-terminal area) AIN2 DI16 can be used when UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7 and with optional suffix code /DR; Input type Input type Input type...
  • Page 174 In Estimating-type position proportional control, the limiter function Output limiter OH, OL does not work on output operation. The reverse-signal relay turns on when being limited by low limit. Input error preset output The direct-signal relay turns on when being limited by high limit. Normal When sensor burnout occurs In Manual operation, the relay turns on while the...
  • Page 175 8.1 Setting Control Mode (CTLM) Intentionally blank 8-46 IM 05P01C31-01EN...

  • Page 176: Loop Control With Pv Auto-Selector, Heating/Cooling Loop Control With Pv Auto-Selector, And Position Proportional Loop Control With Pv Auto-Selector

    8.1 Setting Control Mode (CTLM) 8.1.7 Loop Control with PV Auto-selector, Heating/cooling Loop Control with PV Auto-selector, and Position Proportional Loop Control with PV Auto- selector Setting Details Parameter Display Name Setting range Menu symbol symbol level SGL: Single-loop control CAS1: Cascade primary-loop control CAS2: Cascade secondary-loop control CAS: Cascade control CTLM Control mode BUM: Loop control for backup PVSW: Loop control with PV switching PVSEL: Loop control with PV auto-selector PVHD: Loop control with PV-hold function...

  • Page 177: Loop Control With Pv Auto-Selector (2 Inputs) Function Block Diagram

    Remote input with direct input (E1-terminal area) can be used when DI16 UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7 and with optional suffix code /DR; UT52A suffix code:Type 2 = 1 or 2 and No function...
  • Page 178 Output limiter OH, OL Input error preset output Normal When sensor Sensor burnout occurs when PV or RSP input burnout occurs. burnout occurs However, burnout is not detected if input is not conncted. MPON Manual preset output Manual operation Output limiter OH, OL OLMT AUTO...

  • Page 179: Heating/Cooling Loop Control With Pv Auto-Selector (2 Inputs) Function Block Diagram

    Remote input with direct input (E1-terminal area) can be used when DI16 UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7 and with optional suffix code /DR; UT52A suffix code:Type 2 = 1 or 2 and No function...
  • Page 180 Manual preset output MPON Manual operation AUTO AUTO (ON)/MAN (OFF) switch Heating/cooling computation Manual output is prioritized even if sensor burnout occurs in MAN. Sensor burnout occurs when PV or RSP Heating-side output limiter Cooling-side output limiter Input error preset output Error preset output input burnout occurs.

  • Page 181: Position Proportional Loop Control With Pv Auto-Selector (2 Inputs) Function Block Diagram

    For the model with optional suffix code /DR: Remote input with direct input (E1-terminal area) DI16 can be used when UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7 and with optional suffix code /DR; No function Input type...
  • Page 182 In Estimating-type position proportional control, the limiter function Output limiter OH, OL does not work on output operation. Input error preset output The reverse-signal relay turns on when being limited by low limit. The direct-signal relay turns on when being limited by high limit. Normal When sensor burnout occurs...

  • Page 183: Loop Control With Pv Auto-Selector (4 Inputs) Function Block Diagram (Only For Ut55A)

    (For Detailed model) When UT55A DI46 is equipped when UT55A optional suffix code /A4 or (For Standard model) UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7 is necessary. optional suffix code /A4 or /AC4. optional suffix code /A2.
  • Page 184 Output limiter OH, OL Error preset output Normal When sensor Sensor burnout occurs when PV, RSP, AIN2, or AIN4 input burnout occurs. burnout occurs However, burnout is not detected if input is not conncted. Manual preset output MPON Manual operation Output limiter OH, OL OLMT...

  • Page 185: Heating/Cooling Loop Control With Pv Auto-Selector (4 Inputs) Function Block Diagram (Only For Ut55A)

    (For Detailed model) When UT55A DI46 is equipped when UT55A optional suffix code /A4 (For Standard model) UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7 is necessary. optional suffix code /A4 or /AC4. optional suffix code /A2.
  • Page 186 Manual preset output MPON Manual operation AUTO AUTO (ON)/MAN (OFF) switch Heating/cooling computation Manual output is prioritized even if Sensor burnout occurs when PV, RSP, AIN2, or AIN4 input burnout occurs. sensor burnout occurs in MAN. However, burnout is not detected if input is not conncted. Heating-side output limiter Cooling-side output limiter Input error preset output...

  • Page 187: Position Proportional Loop Control With Pv Auto-Selector (4 Inputs) Function Block Diagram (Only For Ut55A)

    (For Detailed model) When UT55A DI46 is equipped when UT55A optional suffix code /A4 (For Standard model) UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7 is necessary. optional suffix code /A4 or /AC4. optional suffix code /A2.
  • Page 188 In Estimating-type position proportional control, the limiter function does not Output limiter OH, OL work on output operation. Input error preset output The reverse-signal relay turns on when being limited by low limit. The direct-signal relay turns on when being limited by high limit. Normal When sensor burnout occurs...
  • Page 189 8.1 Setting Control Mode (CTLM) Intentionally blank 8-60 IM 05P01C31-01EN...

  • Page 190: Loop Control With Pv-Hold Function, Heating/Cooling Loop Control With Pv-Hold Function, And Position Proportional Loop Control With Pv-Hold Function

    8.1 Setting Control Mode (CTLM) 8.1.8 Loop Control with PV-hold Function, Heating/cooling Loop Control with PV-hold Function, and Position Proportional Loop Control with PV-hold Function Setting Details Parameter Display Name Setting range Menu symbol symbol level SGL: Single-loop control CAS1: Cascade primary-loop control CAS2: Cascade secondary-loop control CAS: Cascade control CTLM Control mode BUM: Loop control for backup PVSW: Loop control with PV switching PVSEL: Loop control with PV auto- selector PVHD: Loop control with PV-hold function CAUTION...

  • Page 191: Loop Control With Pv-Hold Function Function Block Diagram

    (For Standard model) (For Standard model) (For Standard model) Remote input can be used when UT55A suffix code: DI16 is equipped when UT55A suffix Feedforward input can be used when code: Type 2 = 1, 2, 4, 5, or 7; UT52A Type 2 = 1, 2, 4, 5, or 7;...
  • Page 192 Output limiter OH, OL Input error preset output Normal When sensor burnout occurs Manual preset output MPON Manual operation Output limiter OH, OL OLMT AUTO AUTO (ON)/PV hold, MAN (OFF) switch Preset output STOP STOP (ON)/RUN (OFF) switch * After the control output terminal is specified by the parameter OT, Output terminal assignment other current output terminals can be used as retransmission output.

  • Page 193: Heating/Cooling Loop Control With Pv-Hold Function Function Block Diagram

    /R1 or /RCH1. (For Standard model) (For Standard model) DI16 is equipped when UT55A suffix code: Type Remote input can be used when UT55A suffix 2 = 1, 2, 4, 5, or 7; UT52A suffix code: Type 2 = code: Type 2 = 1, 2, 4, 5, or 7;...
  • Page 194 Manual preset output MPON Manual operation AUTO AUTO (ON)/PV hold, MAN (OFF) switch Heating/cooling computation Manual output is prioritized even if sensor burnout occurs in MAN. Heating-side output limiter Cooling-side output limiter Input error preset output Error preset output OH, OL OHc, OLc Normal Normal...

  • Page 195: Position Proportional Loop Control With Pv-Hold Function Function Block Diagram

    (For Standard model) DI16 is equipped when UT55A suffix Feedforward input can be used when Remote input can be used when UT55A suffix code: Type 2 = 1, 2, 4, 5, or 7; UT52A UT55A suffix code: Type 2 = 7.
  • Page 196 In Estimating-type position proportional control, the limiter function Output limiter OH, OL does not work on output operation. Input error preset output The reverse-signal relay turns on when being limited by low limit. The direct-signal relay turns on when being limited by high limit. Normal When sensor burnout occurs In Manual operation, the relay turns on while the...

  • Page 197: Setting Control Type (Cnt)

    8.2 Setting Control Type (CNT) The following table shows combination of Standard type, Heating/cooling type, Position proportional type and control type (CNT). Suffix code: Type 1 Control type Heating/cooling Position Standard type type proportional type PID control √ √ √ ON/OFF control √ √ (1 point of hysteresis) ON/OFF control √...

  • Page 198: Pid Control

    8.2 Setting Control Type (CNT) 8.2.1 PID Control Description PID control is a general control using control-related parameters PID. When PID control is selected, PID should be obtained by auto-tuning after setting SP or PID should be set manually. Setting Details Parameter Display Name Setting range Menu symbol symbol...

  • Page 199: On/Off Control (1 Point Of Hysteresis / 2 Points Of Hysteresis)

    8.2 Setting Control Type (CNT) 8.2.2 ON/OFF Control (1 point of hysteresis / 2 points of hysteresis) Description ON/OFF control compares the SP and PV and outputs an on or off signal according to the positive or negative deviation (PV – SP). Hysteresis can be set in the vicinity of the on/off output operating point. If the SP and PV become close and the polarity of the deviation reverses frequently, the on/off output will cycle repeatedly. The life of the output relay will therefore be dramatically shortened. In such a case, set a wider hysteresis so that the relay’s frequent on/off output (chattering) will not occur.
  • Page 200 8.2 Setting Control Type (CNT) Setting Details Parameter Display Name Setting range Menu symbol symbol level PID: PID control ONOF: ON/OFF control (1 point of hysteresis) ONOF2: ON/OFF control (2 points of hysteresis) Control type EASY 2P2L: Two-position two-level control H/C: Heating/cooling control S-PI: Sample PI control BATCH: Batch PID control FFPID: Feedforward control Hysteresis...

  • Page 201: Heating/Cooling Control

    8.2 Setting Control Type (CNT) 8.2.3 Heating/cooling Control Description Heating/cooling control can be used only for Heating/cooling type. In Heating/cooling control, the controller outputs the result of computation after splitting it into heating-purpose and cooling-purpose signals. PID control or ON/OFF control can be selected for each of the heating side and the cooling side. Set the heating-side proportional band to “0”...
  • Page 202 8.2 Setting Control Type (CNT) Positive Dead Band Cooling-side control output (%) Heating-side control output (%) 100% 100% Heating-side control output Cooling-side high limit control output (OH) high limit (OHc) Dead Dead band band (DB) (DB) 100% 100% Control computation output (OUT) Negative Dead Band Cooling-side control output (%) Heating-side control output (%) 100% 100%...
  • Page 203 8.2 Setting Control Type (CNT) When the Heating Side is in ON/OFF Control and the Cooling Side is in PID Control: The following shows the formula and operation example. Output turns on when HOUT = OUT > ( 50% + Other than this case, maintain current state. COUT = ( 50% – – ) × 2 *: OUT: control output, HOUT: heating-side control output, COUT: cooling-side control output, DB: dead band, and HYS: heating-side hysteresis Positive Dead Band...
  • Page 204 8.2 Setting Control Type (CNT) When the Heating Side is in PID Control and the Cooling Side is in ON/OFF Control: The following shows the formula and operation example. HOUT = ( OUT – – 50% ) × 2 Output turns on when HYSc COUT = OUT < ( 50% – – Output turns off when HYSc OUT > ( 50% + Other than these cases, maintain current state.
  • Page 205 8.2 Setting Control Type (CNT) When both the Heating Side and Cooling Side are in ON/OFF Control: The following shows the operation example. Cooling-side hysteresis (HYSc) Neutral (OFF) Heating-side hysteresis (HYS) Positive dead band (DB) Dead Band (DB) In Heating/cooling control, the positive dead band denotes the zone where none of the heating-side and cooling-side outputs are presented. The negative dead band denotes the zone where both of the heating-side and cooling-side outputs are presented. Output (%) Output (%) Cooling-side Heating-side Cooling-side Heating-side output...
  • Page 206 8.2 Setting Control Type (CNT) Setting Details Parameter Display Name Setting range Menu symbol symbol level PID: PID control ONOF: ON/OFF control (1 point of hysteresis) ONOF2: ON/OFF control (2 points of hysteresis) Control type EASY 2P2L: Two-position two-level control H/C: Heating/cooling control S-PI: Sample PI control BATCH: Batch PID control FFPID: Feedforward control Hysteresis...

  • Page 207: Two-Position Two-Level Control

    8.2 Setting Control Type (CNT) 8.2.4 Two-position Two-level Control Description Two-position two-level control outputs the ON signal and OFF signal for the target setpoint (SP) of the main setting and the sub-target setpoint (SP + SUB) of the sub- setting. The sub-setting is set as a deviation from the main setting. Hysteresis can be set in the vicinity of the on/off output operating point ► Two-position two-level control: 8.1.1 Single-loop Control, Single-loop Heating/cooling Control, Single-loop Position Proportional Control, and Single-loop Two-position Two-level Control...
  • Page 208 8.2 Setting Control Type (CNT) Setting Details Parameter Display Name Setting range Menu symbol symbol level PID: PID control ONOF: ON/OFF control (1 point of hysteresis) ONOF2: ON/OFF control (2 points of hysteresis) Control type EASY 2P2L: Two-position two-level control H/C: Heating/cooling control S-PI: Sample PI control BATCH: Batch PID control FFPID: Feedforward control 0.0 to 100.0% of PV input range...

  • Page 209: Pd Control (Stable Control In Which A Setpoint Is Not Exceeded)

    8.2 Setting Control Type (CNT) 8.2.5 PD Control (Stable Control in Which a Setpoint is not Exceeded) Description This control type performs control in which integral action (I action) is excluded from PID action. Set the integral time (I or Ic) to OFF. It is useful when stable control in which a setpoint is not exceeded is desired for integral processes in which constant flows are delivered.

  • Page 210: Sample Pi Control (Controlling A Process With Long Dead Time)

    8.2 Setting Control Type (CNT) 8.2.6 Sample PI Control (Controlling a Process with Long Dead Time) Description Sample PI control performs PI control for a sample PI sampled time (STM) only during the first sample PI control time span (SWD). It subsequently holds a control output when that time elapses. This control is useful for processes with long dead times where the results of the control output are not quickly reflected on PV.
  • Page 211 8.2 Setting Control Type (CNT) Setting Details Parameter Display Name Setting range Menu symbol symbol level PID: PID control ONOF: ON/OFF control (1 point of hysteresis) ONOF2: ON/OFF control (2 points of hysteresis) Control type EASY 2P2L: Two-position two-level control H/C: Heating/cooling control S-PI: Sample PI control BATCH: Batch PID control FFPID: Feedforward control 0.0 to 999.9%...

  • Page 212: Batch Pid Control (Performing Control With Rapidly Settling Setpoints)

    8.2 Setting Control Type (CNT) 8.2.7 Batch PID Control (Performing Control with Rapidly Settling Setpoints) Description Batch PID control is useful for cases where control is performed causing the PV to settle to a target setpoint (SP) as quickly as possible without overshooting. If a deviation (E) exceeding a batch PID deviation setpoint (BD) occurs, the controller outputs the control output high limit (OH) to quickly bring the PV to the SP (in the case of reverse action). If a deviation (E) falls within the batch PID deviation setpoint (BD), the controller determines that the process is in a steady state and changes to PID control.
  • Page 213 8.2 Setting Control Type (CNT) Setting Details Parameter Display Name Setting range Menu symbol symbol level PID: PID control ONOF: ON/OFF control (1 point of hysteresis) ONOF2: ON/OFF control (2 points of hysteresis) Control type EASY 2P2L: Two-position two-level control H/C: Heating/cooling control S-PI: Sample PI control BATCH: Batch PID control FFPID: Feedforward controll 0.0 to 999.9%...

  • Page 214: Feedforward Control

    Product Inflow rate (feedforward signal) Note For Feedforward control, it is necessary to use the controller (UT55A-x7) equipped with AIN2 aux. analog input or to build the function by LL50A Parameter Setting Software with unused aux. analog input. ► Controller with AIN2 aux. analog input: 8.1 Setting Control Mode (CTLM), Function Block Diagram...
  • Page 215 8.2 Setting Control Type (CNT) Operation Description The parameters that perform gain operation (feedforward gain (FGN)) and bias operation (feedforward input bias (FBI) and feedforward output bias (FBO)) for a disturbance measurement input signal (feedforward input (FF_CTL)) are provided. FIN is within the range of -100.0 to 100.0%. FF_CTL is within the range of -5.0 to 105.0% Analog input scale (AIN2 or AIN4) for the feedforward input is necessary to be set to “0 to 100.”...

  • Page 216: Setting Pid Control Mode (Alg)

    8.3 Setting PID Control Mode (ALG) Description There are two PID control modes: standard PID control mode and fixed-point control mode. Select a PID control computation formula shown in the following table according to the control mode or operation mode. Single-loop Control, Loop Control for Backup, Loop Control with PV Switching, Loop Control with PV Auto-selector, and Loop Control with PV-hold Function. Operation mode AUTO+Local AUTO+Remote Standard PID control PV derivative type...
  • Page 217 8.3 Setting PID Control Mode (ALG) PV Derivative Type PID (output bumpless at SP change) Deviation Derivative Type PID The PID control method in which derivative action works for the deviation value = PV – The derivative action works for a SP change, so this method is useful for cases like Cascade secondary-loop control where the SP-following capability is important. The following shows the deviation derivative type PID control computation formula. ...

  • Page 218: Switching Pid

    8.4 Switching PID 8.4.1 Switching PID According to Target Setpoint Number (SPNO) Description The SP group number selection selects a group of target setpoint (SP) and PID parameters by switching the SP number (SPNO). The PID number selection (PIDN) can be set for each SP group. SP number (SPNO) PID parameter group SP of group 1 Specify using the parameter PIDN of group 1 SP of group 2...

  • Page 219: Switching Pid According To Pv

    8.4 Switching PID 8.4.2 Switching PID According to PV Description The PID switching according to PV is a function that switches between the groups of PID parameters according to the PV. The maximum number of PID groups to be switched is 8. (Set RP1 to RP7.) This function is useful for reactors in which the chemical reaction gain changes depending on the temperature. The figure below shows an example of dividing the PV input range from the maximum value to the minimum value into seven zones by reference points 1 to 6. (Set RP1 to RP6.) If the PV is currently positioned at this point, control is based on the PID of group 6.
  • Page 220 8.4 Switching PID Setting Details Parameter Display Name Setting range Menu symbol symbol level 0: SP group number selection 1 1: Zone PID selection (selection by PV) Zone PID 2: Zone PID selection (selection selection by target SP) 3: SP group number selection 2 4: Zone PID selection (selection by SP) 0.0 to 100.0% of PV input range Reference point (EU) RP1 to RP7 ZONE 1 to 7 (RP1 ≤ RP2 ≤ RP3 ≤ RP4 ≤ RP5...

  • Page 221: Switching Pid According To Sp

    8.4 Switching PID 8.4.3 Switching PID According to SP Description The zone PID selection by SP switches between the groups of PID parameters according to the SP. The maximum number of PID groups to be switched is 8. (Set RP1 to RP7) The figure below shows the example of switching the group of PID parameters according to the SP. It shows an example of dividing the PV input range from the maximum value to the minimum value into five zones by reference points 1 to 4. (Set RP1 to RP4.) Maximum value of PV input range...
  • Page 222 8.4 Switching PID Setting Details Parameter Display Name Setting range Menu symbol symbol level 0: SP group number selection 1 1: Zone PID selection (selection by PV) Zone PID 2: Zone PID selection (selection selection by target SP) 3: SP group number selection 2 4: Zone PID selection (selection by SP) 0.0 to 100.0% of PV input range Reference point 1 (EU) RP1 to RP7 ZONE to 7 (RP1 ≤ RP2 ≤ RP3 ≤ RP4 ≤ RP5...

  • Page 223: Switching Pid According To Target Sp

    8.4 Switching PID 8.4.4 Switching PID According to Target SP Description The zone PID selection by target SP switches between the groups of PID parameters according to the target SP. The figure below shows the example of switching the group of PID parameters according to the target SP. It shows an example of dividing the PV input range from the maximum value to the minimum value into five zones by reference points 1 to 4. (Set RP1 to RP4.) Maximum value of PV input range (PID of group 5) 800ºC Reference point 4 (PID of group 4)
  • Page 224 8.4 Switching PID Setting Details Parameter Display Name Setting range Menu symbol symbol level 0: SP group number selection 1 1: Zone PID selection (selection by PV) Zone PID 2: Zone PID selection (selection selection by target SP) 3: SP group number selection 2 4: Zone PID selection (selection by SP) 0.0 to 100.0% of PV input range Reference point 1 (EU) RP1 to RP7 ZONE to 7 (RP1 ≤ RP2 ≤ RP3 ≤ RP4 ≤ RP5...

  • Page 225: Switching Pid According To Deviation (Reference Deviation)

    8.4 Switching PID 8.4.5 Switching PID According to Deviation (Reference Deviation) Description The zone PID selection by deviation switches between the groups of PID parameters according to the amount of deviation. This function is called “reference deviation.” In the fixed point control, if the actual amount of deviation exceeds the setpoint of the reference deviation, the controller automatically changes to the PID parameter group (PID of group R) set for the zone. If the actual amount of deviation becomes smaller than the setpoint of reference deviation, the controller changes to the PID parameter group appropriate for the zone.

  • Page 226: Setting Hysteresis At Time Of Pid Switch

    8.4 Switching PID 8.4.6 Setting Hysteresis at Time of PID Switch Description When the zone PID selection is selected, hysteresis at time of each zone switch can be set. The following shows the operation example of hysteresis at time of zone switch. Reference point 1 Hysteresis 0.5% of PV input range span PID of group 1 PID of group 2 PID of group 1 PID of group 2 Setting Details Parameter Display Name Setting range Menu symbol symbol level...

  • Page 227: Suppressing Overshoot (Super Function)

    8.5 Suppressing Overshoot (Super Function) Description The Super function monitors the deviation for evidence that there is a danger of overshoot, and on sensing such danger automatically changes the setpoint temporarily to a somewhat lower value (sub-SP). Once the danger of overshoot appears diminished, the function returns the effective SP gradually to the true SP. “Fuzzy ratiocination” techniques are employed in the algorithms used to change the SP to the lower temporary value, and to return it gradually to the true Operation Diagram...
  • Page 228 8.5 Suppressing Overshoot (Super Function) Example of Overshoot Suppression Control for Setpoint Changes Time Time SUPER is not used SUPER is used Example of Overshoot Suppression Control for Ramp-to-soak Transition Sub-SP Time Time SUPER is not used SUPER is used Setting Details Parameter Display Name Setting range Menu symbol symbol level OFF: Disable 1: Overshoot suppressing function (normal mode) 2: Hunting suppressing function Super function EASY...

  • Page 229: Suppressing Hunting (Super2 Function)

    8.6 Suppressing Hunting (Super2 Function) Description The Super2 function suppresses the hunting effect of the controller without re-tuning the PID parameters. Hunting means the PV becomes unstable and oscillates around SP. SUPER2 = ON Hunting ● In hunting condition, the Super2 function selects the output from process model as PV signal. ● The process model removes a factor of dead time from the actual process. ● The real process is under the open-loop condition. ● After hunting is suppressed, the Super2 function selects real PV signal, and carry out the standard feedback control. PID control Process – Process model 8-100...
  • Page 230 8.6 Suppressing Hunting (Super2 Function) Effects of Super2 Load change SUPER2 = ON Hunting Temperature change PID parameters are set at this condition. SUPER2 = ON Hunting Setting Details Parameter Display Name Setting range Menu symbol symbol level OFF: Disable 1: Overshoot suppressing function (normal mode) 2: Hunting suppressing function Super function EASY...

  • Page 231: Suppressing Integral Action (Anti-Reset Wind-Up)

    Suppressing Integral Action (Anti-reset Wind-up) Description Where there is a large deviation at the start of the control operation, for example, integral outputs are accumulated and the PV exceeds the SP, thereby causing the output to overshoot. To avoid this, the controller provides an anti-reset wind-up function for suppressing an extreme integral output by stopping PID computations. Same applies to the case of undershoot.

  • Page 232: Performing Non-Linear Pid Control

    8.8 Performing Non-linear PID Control Description If a deviation (E) is smaller than the non-linear control gap width (GW), it is computed as a proportional added the non-lenear control gain (GG). Proportional Band (CPB) = Proportional Band (P) / GG * | E | ≤ GW / 2 However, CPB is limited by 0.1 to 999.9%. 100% EU(100%) SP=EU(50%) EU(0%) Control output will change smoothly (i.e., without any bumps) when CPB switches. Setting Details Parameter Display...

  • Page 233: Adjusting Auto-Tuning Operation

    8.9 Adjusting Auto-tuning Operation Description Auto-tuning Type “Normal” of auto-tuning type requires a rapidly rising PID constant. This type is useful for processes that allow some overshooting. On the other hand, “stable” of auto-tuning type requires a slowly rising PID constant. Auto-tuning Output Limiter When executing auto-tuning, the control output high and low limits can be set.

  • Page 234: Chapter 9 Auxiliary Control Functions

    Chapter 9 Auxiliary Control Functions 9.1 Setting SP Limiter Description The SP high and low limits can be set to restrict the SP to the range between those limits whether in REM (remote) or LCL (local) mode. They works to the SP of all SP groups. In Cascade control, the SP high and low limits can be set for both Loop1 and Loop 2.

  • Page 235: Changing Sp At A Fixed Rate (Sp Ramp-Rate Setting Function)

    9.2 Changing SP at a Fixed Rate (SP Ramp-Rate Setting Function) Description SP ramp-rate setting function forces SP to change at a fixed rate when SP is changed in order to prevent abrupt changes in SP. Velocity (rate-of-change) can be set for both the SP ramp-up rate (UPR) and SP ramp- down rate (DNR). Set the ramp–rate time unit (TMU) per hour or minute. The SP ramp-rate setting function works when: (1) SP is changed.
  • Page 236 9.2 Changing SP at a Fixed Rate (SP Ramp-Rate Setting Function) SP switch SP of group 1 SP of group 2 SP of group 2= 640ºC Temperature difference of 140ºC 70ºC/min UPR = 140/2 = 70 (ºC/min) SP of group 1 = 500ºC Temperature rise time of 2 min. Temperature difference (ºC) 140ºC UPR = = 70 (ºC/min)

  • Page 237: Forcing Sp To Track Pv (Pv Tracking)

    9.3 Forcing SP to Track PV (PV Tracking) Description PV tracking function is used to prevent abrupt PV changes. With PV tracking, SP is first aligned with PV and then changed to its original SP at the SP ramp rate. ► SP ramp-rate setting function: 9.2 Changing SP at a Fixed Rate (SP Ramp-Rate Setting Function) PV tracking function works when: (1) Power is turned on or has recovered from a failure, (2) SP number (SPNO) is changed, (3) Operation mode is switched from STOP to RUN, (4) Operation mode is switched from MAN to AUTO, (5) Operation mode is switched from MAN to CAS (in Cascade control);...

  • Page 238: Forcing Sp To Track Remote Input (Sp Tracking)

    9.4 Forcing SP to Track Remote Input (SP Tracking) Description SP tracking function is the function to force the local setpoint (SP) to track the remote setpoint (RSP) when the operation mode is switched from REM (remote) to LCL (local) mode. The function is effective to prevent abrupt PV changes. SP tracking enabled SP tracking disabled Time Time REM →...

  • Page 239: Setting Controller Action At Power On (Restart Mode)

    9.5 Setting Controller Action at Power ON (Restart Mode) Description For details, see Chapter 15, “Power Failure Recovery Processing.” Setting Details Parameter Display Name Setting range Menu symbol symbol level Set how the controller should recover from a power failure of 5 seconds or more. R.MD Restart Mode CONT: Continue action set before power failure.

  • Page 240: Setting Time Between Powering On Controller And Starting Control (Restart Timer)

    9.6 Setting Time between Powering on Controller and Starting Control (Restart Timer) Description The time between power on and the instant where controller starts control computation can be set. Operation start time = Operating time of controller initialization after power on. Setting Details Parameter Display Name Setting range Menu symbol symbol level R.TM Restart Timer 0 to 10 s IM 05P01C31-01EN...
  • Page 241 Blank Page...

  • Page 242: Chapter 10 Output (Control And Retransmission) Functions

    The pulse width is calculated as follows with the cycle time (control output cycle) at 100%. Control output pulse width = Control output (%) x Cycle time The output type is selected as either the relay/triac output or the voltage pulse output. UT55A/UT52A Ristricted to the range ON/OFF signal between output high...
  • Page 243 Position proportional output is equipped only with Position proportional type. In position proportional output, valve opening is made proportional to the control computation results. The controller outputs direct and reverse signals (relay) to control motor movement and valve opening. UT55A/UT52A H (direct) or L (reverse) contact signal Control motor...
  • Page 244 10.1 Setting Control Output Type Two-position Two-level Control Output Two-position Two-level Control is equipped only with Heating/cooling type (Suffix code: Type 1 = -2). ► Two-position two-level control output: 8.1.1 Single-loop Control, Single-loop Heating/cooling Control, Single-loop Position Proportional Control, and Single-loop Two-position Two-level Control ► Two-position two-level control: 8.2.4 Two-position Two-level Control Setting Details Parameter Display...
  • Page 245 10.1 Setting Control Output Type Heating/cooling Control Output of Heating/cooling Type The figure below shows an example of setting the current output of the OUT terminal to the heating-side control output terminal and type, and setting the relay output of the OUT2 terminal to the cooling-side control output terminal and type. Heating side: Set “02”...

  • Page 246: Setting Control Output Cycle Time

    10.2 Setting Control Output Cycle Time Description Cycle time is the basic cycle period for a signal full cycle of ON/OFF operation for a relay or voltage pulse output. Reducing cycle time results in faster cycling and finer control. In contrast, reducing the ON/OFF period also reduces relay life. For relay output, set the control output cycle time to 30 to 200 seconds according to the process speed.

  • Page 247: Setting Limiter To Control Output

    10.3 Setting Limiter to Control Output Description Control output high and low limits can be set to restrict the control output to the operation range between those limits. The output limiter is prepared for each PID group, and works according to the selected PID group. This, however, excludes preset output in STOP mode.

  • Page 248: Disabling Output Limiter In Man Mode

    10.4 Disabling Output Limiter in MAN mode Description Output limiter can be released when in MAN mode. However, cannot be released when in Heating/cooling control. Note that the output bump is caused if the operation mode is changed from MAN to AUTO while the control output is out of the range between the control output high limit (OH) and control output low limit (OL).

  • Page 249: Setting Velocity Limiter To Control Output

    10.5 Setting Velocity Limiter to Control Output Description Output velocity limiter prevents the control output signal from changing suddenly in order to protect the control valves (or other actuators) and controlled process. The output velocity limiter does not work in MAN or STOP mode or when input burnout or A/D error occurs.

  • Page 250: Reducing 4-20 Ma Current Output To 0 Ma (Tight Shut Function)

    10.6 Reducing 4-20 mA Current Output to 0 mA (Tight Shut Function) Description Tight shut function fully closes the control valve (or other actuators) (i.e., so that output is zero) beyond its positioner dead band. When the output low limit is set to “SD,” the output is as follows in MAN or AUTO mode. • In MAN mode When the output is reduced with the Down arrow key and “SD”...

  • Page 251: Setting On/Off Control Hysteresis

    10.7 Setting ON/OFF Control Hysteresis Description In ON/OFF control, since the only two possible output states are ON and OFF, the control output cycles are as shown in the figure below. ON/OFF becomes quite narrow, so that if relay output is used, chattering occurs. In this case, the hysteresis should be set wider to prevent relay chattering and for the service life of the relay.
  • Page 252 10.7 Setting ON/OFF Control Hysteresis Setting Details Parameter Display Name Setting range Menu symbol symbol level Hysteresis (in ON/OFF control, Position In ON/OFF control or Two- proportional control, or position two-level control: Two-position two-level 0.0 to 100.0% of PV input control) EASY range span (EUS) Heating-side ON/OFF In Heating/cooling control control hysteresis or Position proportional (in Heating/cooling...

  • Page 253: Canceling Offset Of Pv And Sp (Manual Reset)

    10.8 Canceling Offset of PV and SP (Manual Reset) Description Manual reset can be used when the integral action is disabled. When the integral action is disabled, there will be an offset of PV and SP. Manual reset cancels this offset. The manual reset value equals the output value when PV = SP is true. Setting Details Parameter Display Name Setting range Menu symbol symbol level Manual reset EASY -5.0 to 105.0% PIDN PID number selection EASY 1 to 8 PIDG.

  • Page 254: Setting Hysteresis And Dead Band For Heating/Cooling Control Output

    10.9 Setting Hysteresis and Dead Band for Heating/ cooling Control Output Description In Heating/cooling control, the positive dead band denotes the zone where none of the heating-side and cooling-side outputs are presented. The negative dead band denotes the zone where both of the heating-side and cooling-side outputs are presented. The following shows the case when both the heating side and cooling side are ON/OFF control. Cooling-side hysteresis (HYSc) Neutral (OFF) Heating-side hysteresis (HYS) Positive dead band The following shows the case when both the heating side and cooling side are PID control.
  • Page 255 10.9 Setting Hysteresis and Dead Band for Heating/cooling Control Output Setting Details Parameter Display Name Setting range Menu symbol symbol level Hysteresis (in ON/OFF control, Position In ON/OFF control or Two- proportional control, or position two-level control: Two-position two-level 0.0 to 100.0% of PV input control) EASY range span (EUS) Heating-side ON/OFF In Heating/cooling control control hysteresis or Position proportional (in Heating/cooling...

  • Page 256: Setting Hysteresis And Dead Band For Position Proportional Control Output

    10.10 Setting Hysteresis and Dead Band for Position Proportional Control Output Description To prevent excessively frequent operation of the motor and relays, a dead band is provided between two relay output operating points, and hysteresis is provided for each relay output. If position signal differs from the control computation output by less than the dead band value, neither the “direct”...

  • Page 257: Setting Retransmission Output Terminal, Type, And Scales

    10.11 Setting Retransmission Output Terminal, Type, and Scales Description The retransmission output can be used when the control output is not assigned to the analog output terminal. Confirm the output type selection (OT) before setting the retransmission output. The range can be changed. ► Control output terminal: 10.1 Setting Control Output Type ► Current output range: 10.14 Changing Current Output Range Minimum value of Maximum value of...
  • Page 258 10.11 Setting Retransmission Output Terminal, Type, and Scales (Continued) Parameter Display Name Setting range Menu symbol symbol level Maximum When RTS = PV1, SP1, PV2, SP2, value of TSP1, TSP2, PV, RSP, AIN2, or AIN4, retransmission RTL + 1 digit to 30000 output scale of -19999 to RTH - 1 digit Decimal point position: When RTS=PV1, SP1, or TSP1, decimal point position is same as that of PV input.
  • Page 259 Setpoints HOUT2 and COUT2: Can be used in Cascade control of Heating/cooling type. Setpoint MV2: Can be used in Cascade control of Position proportional type. (When opening or closing a valve by key operation in manual mode opration, the transmission output becomes -5.0 %.) Setpoint RSP: Can be used when equipped with remote input. Setpoints AIN2 and AIN4: Can be used when the UT55A suffix code: Type 2 = 7. Parameters and Corresponding Terminals RTS, RTH, RTL RET terminal O1RS, O1RH, O1RL...

  • Page 260: Setting Preset Output Value

    10.12 Setting Preset Output Value 10.12.1 Setting Output Value in STOP Mode (Preset Output) Description Preset output becomes the output when the operation mode is switched from RUN to STOP. The preset output is not limited by the output high and low limits. The preset output is prepared for each PID parameter group, and works according to the selected PID parameter group.
  • Page 261 10.12 Setting Preset Output Value Setting Details Parameter Display Name Setting range Menu symbol symbol level Preset output In STOP mode, fixed control Heating-side preset output can be generated. EASY output (in Heating/ In Position proportional cooling control) control, Valve opening can be set; Cooling-side preset EASY -5.0 to 105.0% output In STOP mode, fixed sub- Sub-preset output (in control output can be SU.PO Two-position two-level...

  • Page 262: Setting Output Value When Switched To Man Mode (Manual Preset Output)

    10.12 Setting Preset Output Value 10.12.2 Setting Output Value When Switched to MAN Mode (Manual Preset Output) Description When the operation mode is switched from AUTO to MAN, each of the following can be selected. • The control output takes over the control output as is. • The control output bumps to the manual preset output. When the manual preset output is output, the manual operation is possible after the bump.
  • Page 263 10.12 Setting Preset Output Value Setting Details Parameter Display Name Setting range Menu symbol symbol level OFF: Hold the control output in AUTO mode (bumpless) 1: Use manual preset output 1 (output bump) 2: Use manual preset output 2 Manual preset output (output bump) MPON number selection 3: Use manual preset output 3 TUNE...

  • Page 264: Setting Output Value When Error Occurs (Input Error Preset Output)

    10.12 Setting Preset Output Value 10.12.3 Setting Output Value When Error Occurs (Input Error Preset Output) Description The 0% control output, 100% control output, or input preset output can be selected and output as input error preset output in the following conditions. • The input burnout occurs during operation in AUTO or CAS mode and RUN mode. • The ADC error occurs during operation in AUTO or CAS mode and RUN mode. However, the manual output becomes the output when the input burnout occurs in MAN mode and RUN mode.

  • Page 265: Setting 10-Segment Linearizer For Output

    10.13 Setting 10-segment Linearizer for Output Description A total of up to four 10-segment linearizers can be used for the input unit and output unit. For the position used by a 10-segment linearizer, see the function block diagram. ► Function block diagram: 8.1 Setting Control Mode (CTLM) ► 10-segment linearizer input: 7.1.4 (3) Setting 10-segment Linearizer 10-segment Linearizer Biasing This function is used to correct the control output by adding the corresponding bias values to each of the 11 points of optionally set input values. When the 10-segment linearizer input is A1 or less, B1 is added. Moreover, the input is A11 or more, B11 is added.
  • Page 266 10.13 Setting 10-segment Linearizer for Output Setting Details Parameter Name Display level Setting range Menu symbol symbol OFF: Disable PV: PV analog input RSP: RSP analog input AIN2: AIN2 analog input 10-segment Group 1, 2: STD AIN4: AIN4 analog input linearizer Group 3, 4: PRO PVIN: PV input selection OUT: OUT analog output OUT2: OUT2 analog output RET: RET analog output...

  • Page 267: Changing Current Output Range

    10.14 Changing Current Output Range Description The analog output type can be selected from among 4 to 20, 0 to 20, 20 to 4, or 20 to 0 Setting Details Parameter Display Name Setting range Menu symbol symbol level OUT current output OU.A range 4-20: 4 to 20 mA, OUT2 current output 0-20: 0 to 20 mA, OU2.A...

  • Page 268: Setting Split Computation Output Function

    10.15 Setting Split Computation Output Function Description Split computation output is useful for the case where multiple (up to 3) operating units for switching, for example, hot and cool water are linked for control. There are two characteristics of split computations: V-mode characteristics and Parallel-mode characteristics. The current output range can be changed. ► Current output range: 10.14 Changing Current Output Range V-mode Characteristics The following explains an example of letting OUT terminal and RET terminal present the...
  • Page 269 10.15 Settisng Split Computation Output Function Parallel-mode Characteristics The following explains an example of letting OUT terminal and RET terminal present the Parallel-mode characteristics of split computations. Setting Example OUT terminal RET terminal Control output type/Retransmission output type OT = 00.02 (current) RTS=OUT1 Current output 100% segmental point OU.H=100.0% RET.H=75.0% Current output 0% segmental point OU.L=25.0% RET.L=0.0% Current output range OU.A=4-20 RET.A=4-20 RET terminal...

  • Page 270: Adjusting Motor-Operated Valve Position (Position Proportional Output)

    10.16 Adjusting Motor-operated Valve Position (Position Proportional Output) When performing control using the motor-operated valve position, adjustment of the valve position is necessary. Start of valve position adjustment. Use the feedback input. Move to the estimating type if a feedback input burnout occurs. V.MOD = 1 V.MOD = 0 V.MOD = 2 Control by estimating type Control with Control by estimating type at feedback input error.

  • Page 271: Setting Valve Operation Mode

    10.16 Adjusting Motor-operated Valve Position (Position Proportional Output) 10.16.1 Setting Valve Operation Mode Description Position proportional control monitors the control output signals and the feedback signals from the control valve and regulates to keep the valve opening and the control output signal in agreement. Position proportional control (output) operation mode has feedback type and estimating type.

  • Page 272: Adjusting Valve Position Manually

    10.16 Adjusting Motor-operated Valve Position (Position Proportional Output) 10.16.3 Adjusting Valve Position Manually Description The following procedure describes how to adjust valve position manually. (1) Verify that the wirings are correct. (2) Set the operation mode to MAN. (3) Reset the valve position (Set V.RS=ON). (4) Display the fully-closed valve position setting (V.L), determine the fully-closed position while holding down the Down arrow ( ) key, and press the SET/ENTER key. (5) Display the fully-opened valve position setting (V.H), determine the fully-opened position while holding down the Up arrow ( ) key, and press the SET/ENTER key.

  • Page 273: Setting Valve Traveling Time (Estimating Type)

    10.16 Adjusting Motor-operated Valve Position (Position Proportional Output) 10.16.4 Setting Valve Traveling Time (Estimating Type) Description In the estimating type, a traveling time required to fully open the valve from its fully- closed position is set and valve positions are estimated according to the time consumed for valve operation. The valve position estimating type is used when the feedback input of valve positions cannot be obtained.

  • Page 274: Using 15 V Dc Loop Power Supply

    10.17 Using 15 V DC Loop Power Supply Description The 15 V DC loop power supply is a function to supply DC power (14.5 to 18.0 V DC (21 mA DC)) to a 2-wire transmitter. The loop power supply block is isolated from the controller’s internal circuitry. In addition, the block is equipped with a current limiting circuit. Therefore, accidental short-circuits that may occur in the field do not adversely affect the rest of the controller’s internal circuitry.
  • Page 275 10.17 Using 15 V DC Loop Power Supply Setting Details Parameter Display Name Setting range Menu symbol symbol level Retransmission OFF: Disable EASY output type of RET PV1: PV SP1: SP Retransmission OUT1: OUT (Valve opening: 0 to O1RS output type of OUT EASY 100 % in Position proportional current output control) LPS: 15 V DC loop power supply PV2: Loop-2 PV SP2: Loop-2 SP OUT2: Loop-2 OUT TSP1: Target SP HOUT1: Heating-side OUT COUT1: Cooling-side OUT...

  • Page 276: Chapter 11 Alarm Functions

    Chapter 11 Alarm Functions 11.1 Setting Alarm Type Description The alarm-related parameters consist of the alarm type (type, stand-by action, energized/ de-energized, and latch function), PV velocity alarm time setpoint, alarm hysteresis, alarm (On-/Off-) delay timer, and alarm setpoint. In Cascade control, both of Loop 1 and Loop 2 have these parameters. Alarm-related parameter Number of settings Alarm type 8 (number of settings) x 2 (number of loops) PV velocity alarm time setpoint 8 (number of settings) x 2 (number of loops) Alarm hysteresis 8 (number of settings) x 2 (number of loops) Alarm (on-/off-) delay timer...
  • Page 277 11.1 Setting Alarm Type PV High Limit Alarm and PV Low Limit Alarm PV high limit alarm output PV high limit Alarm hysteresis alarm setpoint Alarm hysteresis PV low limit alarm setpoint PV low limit alarm output Time Contact type in the figure above: Energized when an event occurs (factory default). SP High Limit Alarm and SP Low Limit Alarm SP high limit alarm output...
  • Page 278 11.1 Setting Alarm Type Deviation High Limit Alarm and Deviation Low Limit Alarm Deviation high limit alarm output Alarm hysteresis Deviation high limit alarm setpoint (positive setpoint) Target setpoint (SP) Deviation low limit alarm setpoint (negative setpoint) Alarm hysteresis Deviation low limit alarm output Time Contact type in the figure above: Energized when an event occurs (factory default). When a negative setpoint is set for the deviation high limit alarm setpoint, the deviation setpoint will be lower than the SP.
  • Page 279 11.1 Setting Alarm Type Target SP High Limit Alarm and Target SP Low Limit Alarm Target SP high limit alarm output Alarm hysteresis Target SP high limit alarm setpoint SP in ramp rate setting Taraget SP Target SP low limit alarm setpoint Alarm hysteresis Target SP low limit alarm output Time SP changing SP changing SP changing SP changing...
  • Page 280 11.1 Setting Alarm Type Target SP Deviation High and Low Limits Alarm Deviation high and low limits alarm output Alarm hysteresis Deviation high and low limits alarm setpoint Target SP (SP) Alarm hysteresis Time Contact type in the figure above: Energized when an event occurs (factory default). Target SP Deviation within High and Low Limits Alarm Deviation within high and low limits alarm output Alarm hysteresis...
  • Page 281 11.1 Setting Alarm Type Control Output High Limit Alarm and Control Output Low Limit Alarm In Heating/cooling control, alarms are heating-side control output high limit alarm and heating-side control output low limit alarm. Control output high limit alarm output Control output high limit Alarm hysteresis alarm setpoint Control output (OUT) Alarm hysteresis Control output low limit alarm setpoint Control output low limit alarm output...
  • Page 282 11.1 Setting Alarm Type Analog Input PV High Limit Alarm and Analog Input PV Low Limit Alarm These alarms monitor the input value after the analog input computation process (entrance to the input ladder calculation) is completed. Analog input PV high limit alarm output Analog input PV high limit Alarm hysteresis alarm setpoint Analog input Analog input Alarm hysteresis PV low limit...
  • Page 283 11.1 Setting Alarm Type Analog Input AIN2 High Limit Alarm and Analog Input AIN2 Low Limit Alarm These alarms monitor the input value after the analog input computation process (entrance to the input ladder calculation) is completed. Analog input AIN2 high limit alarm output Analog input AIN2 high limit Alarm hysteresis alarm setpoint Aux. analog (AIN2) input Analog input Alarm hysteresis AIN2 low limit...
  • Page 284 11.1 Setting Alarm Type Feedback Input High Limit Alarm and Feedback Input Low Limit Alarm These alarms can be used only for Position proportional type.. These alarms monitor the feedback input (resistance or current) value. The setting range for these alarms is 0.0 to 100.0%. However, the setting range varies depending on whether the feedback input is a current value (4 to 20 mA) or resistance value (100 Ω to 2.5 kΩ). Current value: 4 mA corresponds to 0.0%, and 20 mA to 100.0%. Resistance value (e.g., 1 kΩ): The resistance value when the valve is fully closed after the valve position adjustment corresponds to 0.0%, and the resistance value when the valve is fully opened corresponds to 100.0%. 0 Ω does not correspond to 0.0%, and 1 kΩ does not correspond to 100.0%.
  • Page 285 11.1 Setting Alarm Type Fault diagnosis Alarm The function outputs an alarm signal in the following cases. The corresponding event (EV) lamp is lit and the contact output turns on (when the contact type is energized). • Burnout of PV input, RSP remote input, or auxiliary analog input • ADC failure of PV input, RSP remote input, or auxiliary analog input • Reference junction compensation (RJC) error of PV input, RSP remote input The fault diagnosis alarm does not work the stand-by action functions. FAIL output When the FAIL condition is caused (faulty MCU or system data error), DO (alarm output) turned off regardless of contact type.
  • Page 286 11.1 Setting Alarm Type Alarm Latch Function The alarm latch function is a function for keeping the alarm output (keeping the alarm output on) after entering the alarm condition (alarm output is turned on) until an order to release the alarm latch is received. The alarm latch function has the following four types of action. Latch 1 Cancels the alarm output when an order to release the alarm latch is received.
  • Page 287 11.1 Setting Alarm Type Release of Alarm Latch The alarm latch function can be cancelled by the user function key, via communication/ ladder program, or by contact input. Cancelling the alarm latch function cancels all latched alarm outputs. ► Release by user function key: 13.2 Assigning Function to User Function Key and A/M key ► Release by contact input: 12.1.1 Setting Contact Input Function ► Release via communication: UTAdvanced Series Communication Interface User’s Manual PV high limit alarm setpoint Alarm hysteresis Alarm hysteresis...
  • Page 288 11.1 Setting Alarm Type Setting Details Parameter Display Name Setting range Menu symbol symbol level AL1 to AL8 Alarm-1 to -8 type EASY See the table below. ALRM PV velocity alarm time 00.01 to 99.59 VT1 to VT8 EASY setpoint 1 to 8 (minute.second) Note1: The initial values of the parmeters AL1 to AL8 and VT1 to VT8 are "4". Only AL1 to AL4 and VT1 to VT4 are displayed. The number of alarms can be changed using the parameter ALNO. Note2: In Cascade control, the LP2 lamp is lit while the Loop-2 parameter is displayed.
  • Page 289 11.1 Setting Alarm Type The following shows the example of setting PV high limit (01), With stand-by action (1), De-energized (1), and Latch 1 action (1). Symbol Alarm type Stand-by action Energized/de-energized Latch Latch action Energized (0) / Stand-by action Alarm Name (Note 1) de-energized (1) Without (0) / with (1) type Disable - (Note 2) - (Note 2) - (Note 2) PV high limit 0 / 1 / 2 / 3 / 4 0 / 1 0 / 1 PV low limit 0 / 1 / 2 / 3 / 4...

  • Page 290: Setting Number Of Alarm Groups To Use

    11.2 Setting Number of Alarm Groups to Use Description Up to eight alarm groups of alarm type, alarm hysteresis, alarm (On-/Off-) delay timer, and alarm setpoint are available. Unused alarm parameters can be hidden and their functions can be turned off. The initial value of parameter ALNO. is “4.” When ALNO. = 4, for example, only the four groups of alarm type, PV velocity alarm time setpoint, alarm hysteresis, alarm delay timer, and alarm setpoint are displayed.

  • Page 291: Setting Hysteresis To Alarm Operation

    11.3 Setting Hysteresis to Alarm Operation Description If the On/Off switch of the alarm output is too busy, you can alleviate the busyness by increasing the alarm hysteresis. Hysteresis for PV High Limit Alarm Point of ON/OFF action Output (alarm setpoint) Hysteresis When Setting Hysteresis of 5ºC and 15ºC for PV High Limit Alarm HYS: 5ºC (example) HYS: 15ºC (example) Closed (ON) Closed (ON) Open...

  • Page 292: Delaying Alarm Output (Alarm Delay Timer)

    11.4 Delaying Alarm Output (Alarm Delay Timer) Description The alarm on-delay timer is a function for turning on the alarm when the alarm condition occurs, and the timer starts and the set time elapses. The timer is reset if the alarm condition is removed while the timer is running. No alarm is generated.

  • Page 293: Setting Alarm Output To Control Relay Terminal

    11.5 Setting Alarm Output to Control Relay Terminal Description The control relay terminal can be used for alarm output when it is not used for control output. Setting Details Parameter Display Name Setting range Menu symbol symbol level Same as the setpoint for the OUT relay function contact output function.

  • Page 294: Setting Alarm Action According To Operation Mode

    11.6 Setting Alarm Action According to Operation Mode Description The alarm action usually functions regardless of operation modes. Setting the alarm mode allows the alarm action to be disabled in STOP or in STOP or MAN mode. Setting Details Parameter Display Name Setting range Menu symbol symbol level 0: Always active...

  • Page 295: Setting Heater Break Alarm

    11.7 Setting Heater Break Alarm Description Either of heater break alarm function or heater current measurement function can be selected. Heater Break Alarm Function The heater break alarm function measures the heater current, and outputs the heater break alarm if the current is less than the heater break detecting point. The heater break alarm function can be used only for ON/OFF output (relay output) or for time proportional output (relay output, voltage pulse output).
  • Page 296 11.7 Setting Heater Break Alarm Heater Current Measured Value A measured heater current value can be confirmed by a displayed value on operation display. ► Heater current measured value: 6.1 Monitoring and Control of Operaiotn Displays Heater Break Alarm Delay Timer The delay timer (On-delay timer, Off-delay timer) can be set for the heater break alarm function.
  • Page 297 11.7 Setting Heater Break Alarm Heater Current Measurement Function The heater current value can be confirmed by a displayed value on operation display. ► Heater current measured value: 6.1 Monitoring and Control of Operaiotn Displays The heater break alarm function can be used only for ON/OFF output (relay output), for time proportional output (relay output, voltage pulse output) or for current output.

  • Page 298: Chapter 12 Contact Input/Output Functions

    Chapter 12 Contact Input/Output Functions 12.1 Setting Contact Input Function 12.1.1 Setting Contact Input Function Description The contact input function works by setting the contact input number (I relay) to functions such as the operation mode. This explanation assumes that the contact type is energized. (The function is executed when the contact is turned on) AUTO/MAN Switch (A/M) AUTO/MAN mode can be switched using contact input.
  • Page 299 12.1 Setting Contact Input Function Switch to MAN (MAN) The mode can be switched to MAN using contact input. (Switch by the rising edge) Contact status Operation Remark OFF→ON Switch to MAN – ON→OFF Maintains the current operation status – Switch to REMOTE (REM) The mode can be switched to REMOTE using contact input. (Switch by the rising edge) Contact status Operation Remark...
  • Page 300 12.1 Setting Contact Input Function PV Hold (PVHD) PV can be held using contact input. (Status switch) Contact status Operation Remark AUTO/MAN switch by keystroke or via Switches to MAN, holds PV communication is disabled. Holds the PV status. AUTO/MAN switch by keystroke or via Switches to AUTO communication is enabled. Can be used in Loop control with PV-hold function. Latch Release (LAT) Latch can be released using contact input. (Switch by the rising edge) Contact status Operation Remark...
  • Page 301 12.1 Setting Contact Input Function Bit-0 to Bit-3 of SP Number (SP.B0 to SP.B3) The SP number can be switched using contact input. There are two methods to specify SP number. • Status switch 1 (Operation by keystroke or via communication is enabled depending on the conditions.) Contact status SP number SP.B3 SP.B2...
  • Page 302 12.1 Setting Contact Input Function Bit-0 to Bit-3 of PID Number (PN.B0 to PN.B3) The PID number can be switched using contact input. There are two methods to specify a PID number. • Status switch 1 (Operation by keystroke or via communication is enabled depending on the conditions.) Contact status PID number PN.B3...
  • Page 303 12.1 Setting Contact Input Function Bit-0 to Bit-2 of Manual Preset Output Number (MP.B0 to MP.B2) The manual preset output number can be switched using contact input. There are two methods to specify a manual preset output number. • Status switch 1 (Operation by keystroke or via communication is enabled depending on the conditions.) Contact status Manual preset...
  • Page 304 12.1 Setting Contact Input Function Contact Action Type Operation Description Receiving a contact input signal changes the status to the specified operation, and Status a release changes the status back to the original action. Rising edge Receiving an OFF-to-ON contact input signal changes the status to the specified operation. The minimum detection time is Rising edge the control period + 50 ms.

  • Page 305: Setting Contact Input Function

    PV switch PVHD PV hold CTOA CAS to AUTO switch Latch release LCD backlight ON/OFF switch See the following section, "UT55A PVRW PV red/white switch DI and Setpoint" Message display interruption 1 or "UT52A DI and Setpoint". Message display interruption 2 Message display interruption 3 Message display interruption 4 SP.B0...
  • Page 306 12.1 Setting Contact Input Function UT55A (Standard model) DI and Setpoint (I relay number) DI equipped as standard DI symbol Setpoint 5025 5026 5027 Additional DI DI symbol Setpoint DI symbol Setpoint DI symbol Setpoint DI symbol Setpoint DI11 5041 – – DI31 5073 DI41 5089 DI12 5042 – – DI32 5074 DI42...

  • Page 307: Changing Contact Type Of Contact Input

    12.1 Setting Contact Input Function 12.1.2 Changing Contact Type of Contact Input Description The contact type can set the action direction of contact input assigned to the function. Setting Details Contact Input Equipped as Standard Parameter Display Name Setting range Menu symbol symbol level 0: The assigned function is DI1.D DI1 contact type enabled when the contact input...

  • Page 308: Setting Contact Output Function

    12.2 Setting Contact Output Function 12.2.1 Setting Function of Contact Output Description The contact output function works by setting a status such as an alarm to the contact output. This explanation assumes that the contact type is energized. (The contact is turned on when an event occurs.) Setting Details Contact Output Equipped as Standard Parameter Display Name Setting range Menu symbol symbol level AL1.S AL1 function selection AL2.S AL2 function selection See the following section.
  • Page 309 12.2 Setting Contact Output Function Alarm Status The alarm status can be output to the contact output. (The setpoints below are I relay numbers.) ► I relay: UTAdvanced Series Communication Interface (RS-485, Ethernet) User's Manual Setpoint Function Alarm output Alarm status status 4321 4353 Alarm 1 4322 4354 Alarm 2 4323 4355 Alarm 3 4325 4357 Alarm 4 4326 4358...
  • Page 310 12.2 Setting Contact Output Function Alarm Latch Status The alarm latch status can be output to another contact output irrespective of the setting of alarm-1 to -8 type (AL1 to AL8). (The setpoints below are I relay numbers.) ► I relay: UTAdvanced Series Communication Interface (RS-485, Ethernet) User's Manual Setpoint Function Alarm output...
  • Page 311 12.2 Setting Contact Output Function Key and Display Status The key and display status can be output to the contact output. (The setpoints below are I relay numbers.) Contact status Setpoint Function 4705 PARAMETER key 4706 DISPLAY key 4707 Right arrow key 4708 Down arrow key 4709 SET/ENTER key 4710...
  • Page 312 12.2 Setting Contact Output Function Error Status Contact status Setpoint Function 4065 PV input ADC error RSP input (E1-terminal area) 4066 ADC error AIN2 input (E2-terminal area) 4067 ADC error AIN4 input (E4-terminal area) 4069 ADC error 4073 PV input burnout error RSP input (E1-terminal area) 4074 burnout error AIN2 input (E2-terminal area) 4075 burnout error AIN4 input (E4-terminal area)
  • Page 313 12.2 Setting Contact Output Function System Error Status Contact status Setpoint Function 4001 System data error 4002 Calibration value error 4003 User (parameter) default value error 4005 Setup parameter error 4006 Operation parameter error 4017 Corrupted ladder program Error occurs Normal 4018 Ladder calculation overflow 4019 Ladder program error 4021 Load factor over 100% 4022...

  • Page 314: Changing Contact Type Of Contact Output

    12.2 Setting Contact Output Function 12.2.2 Changing Contact Type of Contact Output Description The contact type can set the action direction of contact output assigned to the function. Setting Details Contact Output Equipped as Standard Parameter Display Name Setting range Menu symbol symbol level 0: When the event of assigned AL1.D AL1 contact type function occurs, the contact AL2.D AL2 contact type...
  • Page 315 Blank Page...

  • Page 316: Chapter 13 Display, Key, And Security Functions

    Chapter 13 Display, Key, and Security Functions 13.1 Setting Display Functions 13.1.1 Setting Active Color PV Display Function The active color PV display function changes the PV display color when an event occurs. Description Link to Alarm The PV display color changes by linking to the alarm 1 or alarm 2. The following is an example of operation linking to alarm 1. Set the alarm-1 type to “PV high limit alarm” and alarm-1 setpoint to “80°C.” When the active color PV display switch is set to”2,” PV display color changes from white to red if PV exceeds the alarm-1 setpoint. The red-to-white switching action can be set. °C Alarm-1 hysteresis Alarm-1 setpoint A1 = 80°C 75°C Time PV color: white...
  • Page 317 13.1 Setting Display Functions Link to PV The PV display color changes by linking to PV. Set the PV color change high limit to “70°C” and the PV color change low limit to “20°C.” PV display color changes from white to red if PV is out of the range. The red-to-white switching action can be set. There is no hysteresis. °C Parameter “PCH” (PV color change high limit) = 70°C 70°C Parameter “PCL” (PV color change low limit) = 20°C 20°C Time PV color: red PV color: red...
  • Page 318 13.1 Setting Display Functions Setting Details Parameter Display Name Setting range Menu symbol symbol level 0: Fixed in white 1: Fixed in red 2: Link to alarm 1 (Alarm OFF: white, Alarm ON: red) 3: Link to alarm 1 (Alarm OFF: red, Alarm ON: white) 4: Link to alarm 1 or 2 (Alarm OFF: white, Alarm ON: red)

  • Page 319: Masking Arbitrary Display Value In Operation Display

    13.1 Setting Display Functions 13.1.2 Masking Arbitrary Display Value in Operation Display Description Display/non-display of the PV display, Setpoint display, and Status display in the Operation Display can be set. Items that you do not want to display can be set to non-display. For example, when the Setpoint display is set to non-display, SP of the SP Display and OUT of the OUT Display are not displayed.

  • Page 320: Registering Select Display (Up To 5 Displays)

    13.1 Setting Display Functions 13.1.3 Registering SELECT Display (Up to 5 Displays) Description Registering frequently changed-operation parameters (except for the operation mode) in the SELECT Display of the Operation Displays will allow you to change parameter settings easily. A maximum of five Displays can be registered. Set the D register number of the parameter you wish to register for the registration to the SELECT Display.

  • Page 321: Changing Event Display

    13.1 Setting Display Functions 13.1.4 Changing Event Display Description The UT55A has eight event (EV) lamps. The UT52A has four event (EV) lamps. The default values are assigned to EV1 to EV8 lamps on the front of the controller according to each control mode. The alarms 1 to 8 are assigned to EV1 to EV8 in the control modes other than Cascade control. The alarms 1 to 8 are assigned to EV1 to EV 8 of Loop1, and the Loop-2 alarms 1 to 8 are assigned to EV1 to EV8 of Loop 2 (the LP2 lamp is lit) in Cascade control. Loop-2 EV lamps are lit when the control mode is cascade and the operation mode is automatic or manual. Setting Details Parameter Display Menu Name Setting range symbol level symbol Setting range: 4001 to 6304 OFF: Disable...
  • Page 322 13.1 Setting Display Functions Reference in Relay Description Communication Interface Number User's Manual 4001 to 4064 System error 4065 to 4128 Input error 4129 to 4192 Free area 4193 to 4256 Operation mode 4257 to 4320 Free area 4321 to 4384 Alarm 4385 to 4528 Alarm latch...

  • Page 323: Registering Select Parameter Display (Up To 10 Displays)

    13.1 Setting Display Functions 13.1.5 Registering SELECT Parameter Display (Up to 10 Displays) Description Registering frequently changed operation parameters (change frequency is lower than SELECT Display) in the SELECT Parameter Display will allow you to change parameter settings easily. A maximum of ten Displays can be registered. Set the D register number of the parameter you wish to register for the registration to the SELECT Parameter Display.
  • Page 324 13.1 Setting Display Functions Setting Details Parameter Display Name Setting range Menu symbol symbol level OFF: No registration CS10 to SELECT parameter-10 D register number (2301 to CSEL CS19 to -19 registration 5000) For D register numbers, see sections 6.4.3 to 6.4.6 of UTAdvanced Series Communication Interface User’s Manual.

  • Page 325: Setting Bar-Graph Display Function

    13.1 Setting Display Functions 13.1.6 Setting Bar-graph Display Function Description The upper and lower bar-graph displays are provided on the front of the controller. PV or OUT can be displayed. Data which can be displayed on Bar-graph display are as follows. OUT, Output Displayed by 10% increment of output 100% Less than 0% More than 100% For relay, OFF is equivalent to 0% and ON is equivalent to 100%. PV, SP, and Analog Input Displayed by 10% increment of analog input/PV input range 100% Less than 0%...
  • Page 326 13.1 Setting Display Functions Setting Details Parameter Display Name Setting range Menu symbol symbol level Upper bar-graph 0: Disable BAR1 display registration 1:OUT, Heating-side OUT, Internal value in Position proportional control 2: Cooling-side OUT 3: PV 4: SP 5: Deviation 6: Loop-2 OUT, Loop-2 heating-side OUT 7: Loop-2 cooling-side OUT Lower bar-graph 8: Loop-2 PV...

  • Page 327: Masking Least Significant Digit Of Pv Display

    13.1 Setting Display Functions 13.1.7 Masking Least Significant Digit of PV Display Description With and without least significant digit of the PV in the Operation Display can be set. When without least significant digit is set, the value of the least significant digit is truncated and not displayed. The internal value is not changed depending on whether with or without least significant digit (the value is for display only). This parameter does not function for the PV without decimal point.

  • Page 328: Changing Deviation Display Lamp Action

    13.1 Setting Display Functions 13.1.8 Changing Deviation Display Lamp Action Description The deviation display shows the condition of (PV – SP). The deviation display is only for the UT55A. Lit when exceeding SP + (deviation display band). Lit when within (Deviation display band). Lit when exceeding SP – (deviation display band). SP + (deviation display band) Deviation display band SP –...

  • Page 329: Setting Economy Mode

    13.1 Setting Display Functions 13.1.9 Setting Economy Mode Description The LCD backlight ON/OFF can be set in the following methods. Setting the LCD backlight to OFF saves energy. User Function Keys The LCD backlight ON/OFF switch can be assigned to the user function key. ► User function key: 13.2 Assigning Function to User Function Key and A/M Key Backlight OFF timer The backlight OFF timer sets the economy mode parameter to ON.

  • Page 330: Selecting The Initial Operation Display That Appears At Power On

    13.1 Setting Display Functions 13.1.10 Selecting the Initial Operation Display that Appears at Power ON Description The initial Operation Display that appears when the power is turned on can be set. Setting Details Parameter Display Name Setting range Menu symbol symbol level SP1: SP Display SP2: Loop-2 SP Display OUT1: OUT Display OUT2: Loop-2 OUT Display HCO: Heating/cooling OUT Display VP: Valve Position Display...

  • Page 331: Setting Message Function

    13.1 Setting Display Functions 13.1.11 Setting Message Function Description Using the message function and turning the contact input on/off, the message registered beforehand can be displayed on PV display by interrupt. The message is registered using LL50A Parameter Setting Software. The messages are limited to 20 alphanumeric characters. A maximum of four messages can be registered.

  • Page 332: Changing Guide Scroll Speed

    13.1 Setting Display Functions 13.1.13 Changing Guide Scroll Speed Description The scroll speed can be changed when the guide for the parameter or menu is displayed. Setting Details Parameter Display Name Setting range Menu symbol symbol level Scroll speed (Slow) 1 to 8 (Quick) DISP 13.1.14 Turning Guide Display ON/OFF Description The guide display that appears when the parameter or the menu is displayed can be switched.

  • Page 333: Setting Brightness And Contrast Adjustment Of Lcd And Display Update Cycle

    13.1 Setting Display Functions 13.1.16 Setting Brightness and Contrast Adjustment of LCD and Display Update Cycle Description The brightness and contrast for PV, Setpoint, Bar-graph, and Status indicator can be adjusted. Brightness ranges for each display can be set. The LCD has a characteristic that the display action becomes late at the low temperature. This can be solved by adjusting the display update cycle (D.CYC). Setting Details Parameter Display Name Setting range Menu symbol symbol...

  • Page 334: Assigning Function To User Function Key And A/M Key

    13.2 Assigning Function to User Function Key and A/M Key Description The UT55A has three user function keys on the front panel. The UT52A has one user function key. Various functions (operation mode switch etc.) can be assigned to the user function key. Press the user function key to perform the assigned function.
  • Page 335 13.2 Assigning Function to User Function Key and A/M Key Setting Details Parameter Display Name Setting range Menu symbol symbol level F1 to Fn User function key action setting EASY See the table below A/M key action setting Availability (Note 1) Setpoint Function Action Unassigned –...
  • Page 336 13.2 Assigning Function to User Function Key and A/M Key (Continued) Availability (Note 1) Setpoint Function Action Latch 1 to latch 4 are released every time the user Latch release √ √ √ – function key is pressed. Pressing the function key during operation displays the first parameter (proportional band) of the currently selected PID parameter group and enables the setting to be changed.

  • Page 337: Setting Security Functions

    13.3 Setting Security Functions 13.3.1 Setting a Password Description The password function can prevent inadvertent changes to the parameter settings. If a password is set, the checking is required when moving to the Setup Parameter Setting Display. When the password is verified, can be changed to the Setup Parameter Setting Display.

  • Page 338: Locking (Hiding) Parameter Menu Display

    13.3 Setting Security Functions 13.3.3 Locking (Hiding) Parameter Menu Display Description The parameter menu display lock function hides the following Parameter Menu Displays. Setting Details Parameter Display Name Setting range Menu symbol symbol level [CTL] menu lock [PV] menu lock [RSP] menu lock AIN2 [AIN2] menu lock AIN4 [AIN4] menu lock [MPV] menu lock...
  • Page 339 13.3 Setting Security Functions (Continued) Parameter Display Name Setting range Menu symbol symbol level MODE [MODE] menu lock [CS] menu lock [SP] menu lock [SPS] menu lock ALRM [ALRM] menu lock [PVS] menu lock [PID] menu lock OFF: Display MLOC ON: Nondisplay TUNE [TUNE] menu lock ZONE [ZONE] menu lock...

  • Page 340: Key Lock

    13.3 Setting Security Functions 13.3.4 Key Lock Description The key lock function locks the key on the front panel to prohibit key operation. It can prohibit the operation mode switch or parameter setting change. Setting Details Parameter Display Name Setting range Menu symbol symbol level...

  • Page 341: Prohibiting Writing Via Communication

    13.3 Setting Security Functions 13.3.6 Prohibiting Writing via Communication Description Writing data to each register via all communication methods can be permitted or prohibited. However, writing data via light-loader (front) or maintenance port (upper) is possible using LL50A Parameter Setting Software. Setting Details Parameter Display Name...

  • Page 342: Confirmation Of Key And I/O Condition And Version

    13.4 Confirmation of Key and I/O Condition and Version 13.4.1 Confirmation of Key and I/O Condition Description Can be confirm the Key and I/O condition. Setting Details Parameter Display Name Setting range Menu symbol symbol level Key status X000 DI1-DI3 status (equipped as standard) X100 DI11-DI16 status (E1-terminal area) X200 DI21-DI26 status (E2-terminal area) X300 DI31-DI35 status (E3-terminal area) X400...
  • Page 343 13.4 Confirmation of Key and I/O Condition and Version Parameter KEY Displayed digit Description PARAMETER (or PARA) key (0: OFF, 1: ON) DISPLAY (or DISP) key (0: OFF, 1: ON) 1st digit RIGHT arrow key (0: OFF, 1: ON) DOWN arrow key (0: OFF 1: ON) SET/ENTER key (0: OFF, 1: ON) UP arrow key (0: OFF, 1: ON) 2nd digit LEFT arrow key (0: OFF, 1: ON)
  • Page 344 13.4 Confirmation of Key and I/O Condition and Version Parameter X200 Displayed digit Description DI21 status (0: OFF, 1: ON) DI22 status (0: OFF, 1: ON) 1st digit DI23 status (0: OFF, 1: ON) DI24 status (0: OFF, 1: ON) DI25 status (0: OFF, 1: ON) DI26 status (0: OFF, 1: ON) 2nd digit –...
  • Page 345 13.4 Confirmation of Key and I/O Condition and Version Parameter Y000 Displayed digit Description AL1 status (0: OFF, 1: ON) AL2 status (0: OFF, 1: ON) 1st digit AL3 status (0: OFF, 1: ON) – – – 2nd digit – – – – 3rd digit – – – – 4th digit –...
  • Page 346 13.4 Confirmation of Key and I/O Condition and Version Parameter Y300 Displayed digit Description DO31 status (0: OFF, 1: ON) DO32 status (0: OFF, 1: ON) 1st digit DO33 status (0: OFF, 1: ON) DO34 status (0: OFF, 1: ON) DO35 status (0: OFF, 1: ON) – 2nd digit –...

  • Page 347: Confirmation Of Version

    13.4 Confirmation of Key and I/O Condition and Version 13.4.2 Confirmation of Version Description Can be confirm the version of the controller. Setting Details Parameter Display Name Setting range Menu symbol symbol level MCU version EASY DCU version EASY ECU1 ECU-1 version EASY ECU2 ECU-2 version EASY ECU3 ECU-3 version EASY ECU4 ECU-4 version EASY...

  • Page 348: Chapter 14 Parameter Initialization

    Chapter 14 Parameter Initialization 14.1 Initializing Parameter Settings to Factory Default Values Description Parameter settings can be initialized to the factory default values. The ladder program is also initialized to the factory default. Use the key or LL50A Parameter Setting Software to execute it. Note The user setting values (defaults) are not initialized even if the parameter setting values are initialized to the factory default values. Setting Details Parameter Display Name Setting range Menu symbol symbol level -12345: Initialization, Initialization to factory F.DEF automatically returned to "0" INIT default value after initialization.

  • Page 349: Registering And Initializing User Default Values

    14.2 Registering and Initializing User Default Values 14.2.1 Registering as User Setting (Default) Values Description The user default values can be registered as parameter default values. The ladder program can not be registered as user default values. Use the LL50A Parameter Setting Software to register user setting (default) values. CAUTION Before registering the user default value, make sure that the user setting value is set to the parameter.

  • Page 350: Remedies If Power Failure Occurs During Operations

    Chapter 15 Power Failure Recovery Processing / Power Frequency Setting / Other Settings 15.1 Remedies if Power Failure Occurs during Operations Description The operation status and remedies after a power failure differ with the length of power failure time: Regardless of the length of power failure time, all functions of the controller cannot be operated for about 10 seconds after recovery. However, the case of instantaneous power failure is excepted.

  • Page 351: Power Frequency Setting

    15.2 Power Frequency Setting Description The power frequency can be set by automatic detection or manually. However, when the /DC option is specified, only manual setting is available. Set the range to the commercial frequency of the installation location. Setting Details Parameter Display Name...

  • Page 352: Chapter 16 Troubleshooting, Maintenance, And Inspections

    Chapter 16 Troubleshooting, Maintenance, and Inspections 16.1 Troubleshooting 16.1.1 Troubleshooting Flowchart If the Operation Display does not appear after turning on the controller’s power, follow the measures in the procedure below. If a problem appears complicated, contact our sales representative. Is the controller defective? Completely Display I/O signal Communication operation...

  • Page 354: Errors At Power On

    Errors at Power On (Input/output Action) Analog out- Relay output Feedback PV input, Control Retrans- put (control Voltage pulse (control out- input (for Contact Error RSP input, Ladder Control Alarm Contact Communi- computa- mission output, re- output (con- put, position Position (alarm) description and aux. calculation output action input...

  • Page 361: Errors During Operation

    Errors during Operation (4) The errors shown below may occur during operation. Parameter Data display Status indicator PV display (Op- that (Operation (Operation Error description Cause and diagnosis Remedy eration Display) displays er- Display) Display) ror details Faulty Undefined Undefined – – Faulty MCU MCU is corrupted. Contact us for repair.
  • Page 362 16.1 Troubleshooting Hexadecimal Display on Setpoint Display (Operation Display) Some error codes are displayed in hexadecimal. When the error occurs, "1" is set on the bit of corresponding error , and the bit data is displayed in hexadecimal. If the setup parameter error or the operation parameter errors occur, it is displayed as follows: Data display Symbol display...
  • Page 363 16.1 Troubleshooting Hexadecimal Display of the Parameter which Shows the Error Details Error confirmation parameters are displayed in hexadecimal. When the error occurs, "1" is set on the bit of corresponding error. Data display 1st digit (hexadecimal) Symbol display 2nd digit (hexadecimal) 3rd digit (hexadecimal) 4th digit (hexadecimal) Parameter PA.ER Displayed digit Description 1st digit System data error...
  • Page 364 16.1 Troubleshooting Parameter OP.ER Displayed digit Description 1st digit Non responding hardware in E1-terminal area Non responding hardware in E2-terminal area Non responding hardware in E3-terminal area – 2nd digit Non responding hardware in E4-terminal area – – – 3rd digit Communication error in E1-terminal area –...
  • Page 365 16.1 Troubleshooting Parameter PV1.E Displayed digit Description 1st digit Loop-1 PV input burnout error Loop-1 RSP input burnout error Burnout error when Loop-1 RSP input is used for control – 2nd digit Loop-1 PV input over-scale Loop-1 PV input under-scale – – 3rd digit – – – – 4th digit – – Loop-1 auto-tuning time-out –...

  • Page 366: Maintenance

    16.2 Maintenance 16.2.1 Cleaning The front panel and operation keys should be gently wiped with a cloth soaked with water and squeezed firmly. CAUTION In order to prevent LCD from static electricity damage, do not wipe with dry cloth. (When LCD is electrified, it returns to normal in several minutes.) Do not use alcohol, benzene, or any other solvents.

  • Page 367: Periodic Maintenance

    16.3 Periodic Maintenance Check the operating condition periodically to use this instrument with good condition. 16-16 IM 05P01C31-01EN...

  • Page 368: Disposal

    16.4 Disposal When disposing of this instrument, arrange for appropriate disposal as industrial waste according to the rules of a country, the area, or a local government. 16-17 IM 05P01C31-01EN...
  • Page 369 Blank Page...

  • Page 370: Installation Location

    Chapter 17 Installation and Wiring 17.1 Installation Location The instrument should be installed in indoor locations meeting the following conditions: • Instrumented panel This instrument is designed to be mounted in an instrumented panel. Mount the instrument in a location where its terminals will not inadvertently be touched. •...
  • Page 371 17.1 Installation Location Do not mount the instrument in the following locations: • Outdoors • Locations subject to direct sunlight, ultrared rays, ultraviolet rays, or close to a heater Install the instrument in a location with stable temperatures that remain close to an average temperature of 23°C. Do not mount it in locations subject to direct sunlight or close to a heater. Doing so adversely affects the instrument and LCD. •...

  • Page 372: Mounting Method

    17.2 Mounting Method WARNING Be sure to turn OFF the power supply to the controller before installing it on the panel to avoid an electric shock. Mounting the Instrument Main Unit Provide an instrumented panel steel sheet of 1 to 10 mm thickness. After opening the mounting hole on the panel, follow the procedures below to install the controller: Insert the controller into the opening from the front of the panel so that the terminal board on the rear is at the far side.

  • Page 373: External Dimensions And Panel Cutout Dimensions

    17.3 External Dimensions and Panel Cutout Dimensions Unit: mm UT55A (approx. inch) (0.43) 65 (2.56) 96 (3.78) Bracket Terminal cover 20 (0.79) Bracket 1 to 10 mm (0.04 to 0.39 inch) (panel thickness) General mounting Side-by-ide close mounting +0.8 – × 117 (4.61) min. +0.03 ([(N-1) 3.78+3.62]...

  • Page 374: Wiring

    Use a tester or similar device to ensure that no power is being supplied to a cable to be connected. 2) Wiring work must be carried out by a person with basic electrical knowledge and practical experience. UT55A Terminal Block Diagram UT52A Terminal Block Diagram E4-terminal area E1-terminal area...
  • Page 375 17.4 Wiring CAUTION Do not use an unassigned terminal as the relay terminal. Recommended Crimp-on Terminal Lugs (ød ) Recommended tightening torque: 0.6 N·m Applicable wire size: Power supply wiring 1.25 mm or more Applicable terminal lug Applicable wire size mm (AWG#) (ød) (A) 0.25 to 1.65 (22 to 16) 5.5 3.3 Cable Specifications Purpose Name and Manufacturer Power supply, relay contact 600 V Grade heat-resistant PVC insulated wires, JIS C 3317(HIV), 0.9 output...

  • Page 376: Pv Input Wiring

    4) If there is a risk of external lightning surges, use a lightning arrester etc. UT55A/UT52A TC Input RTD Input (3-wire system) Compensating lead wire Shield –...

  • Page 377: Remote (Auxiliary Analog) Input Wiring

    For RTD input, use shielded wires that have low conductor resistance and cause no significant differences in resistance between the three wires. 4) If there is a risk of external lightning surges, use a lightning arrester etc. UT55A/UT52A Remote input (E1-terminal area) DC voltage –...
  • Page 378 17.4 Wiring AIN4 Auxiliary Analog Input (E4-terminal area) In Loop control with PV auto-selector for 4 inputs, auxiliary analog input (E4-terminal area) is used for PV input 4. In Single-loop control or Single-loop position proportional control, auxiliary analog input (E4-terminal area) is used for feedforward input. UT55A/UT52A Remote Input with Direct Input (Optional suffix code /DR or /U1) (E1-terminal area) TC input Compensating lead wire RSP/DR – Shield Class D grounding (grounding resistance of 100 Ω...

  • Page 379: Control Output (Relay, Triac, Current, And Voltage Pulse) Wiring

    Functional Reinforced insulation insulation A hazardous A hazardous voltage circuit voltage circuit Reinforced insulation DC Relay Wiring UT55A/UT52A External DC power supply Relay Diode (Mount it directly to the relay coil UT’s contact Relay terminal (socket).) (Use one with a relay coil rating less than the UT’s contact rating.)
  • Page 380 17.4 Wiring UT55A/UT52A Relay Output (For Standard model) Standard type output (UT55A, UT52A) or Heating/cooling type heating-side output (UT55A) (For Detailed model) Suffix code of Output 1 = “-R” or “-U” (UT55A/UT52A) Contact rating: 250 V AC, 3 A 30 V DC, 3 A (resistance load) (For Standard model) Heating/cooling type (For Standard model) Heating/cooling type heating/cooling output (UT52A) cooling-side output (UT55A) (For Detailed model) Suffix code of Output 1 = (For Detailed model) Suffix code of Output 2 = “-R” or “-U” and Suffix code of Output 2 = “R” “R” or “U” (UT55A) or “-U” (UT52A) Cooling-side OUT2 OUT/OUT2 Heating-side Contact rating: 250 V AC, 3 A...
  • Page 381 17.4 Wiring UT55A/UT52A Current and Voltage Pulse Output (For Standard model) Standard type or (For Standard model) Heating/cooling type Heating/cooling type heating-side output cooling-side output (UT55A) (UT55A/UT52A) (For Detailed model) Suffix code of Output 2 (For Detailed model) Suffix code of Output 1 = “A” or “U” (UT55A) = “-A” or “-U” (UT55A/UT52A) Shield Shield OUT2 – – Class D grounding Control valves Control valves Class D grounding (or other (or other (grounding resistance of (grounding resistance of actuators) actuators) Ω...

  • Page 382: Valve Position Output And Feedback Input Wiring

    (for DC) to the load. 4) If there is a risk of external lightning surges, use a lightning arrester etc. 5) Relays cannot be used for a small load of 10 mA or less. ► When using auxiliary relay: 17.4.4 Control Output (Relay, Current, and Voltage Pulse) Wiring Relay contact output (UT55A) Relay contact output (UT52A) HIGH HIGH...

  • Page 383: Contact Input Wiring

    ON and the leakage current must be 100 µA or less when it is OFF. 4) If there is a risk of external lightning surges, use a lightning arrester etc. UT55A/UT52A Contact Input Equipped as Standard No-voltage contact...
  • Page 384 17.4 Wiring Additional Contact Input According to the UT55A Suffix Codes (For Standard model) UT55A suffix codes: Type 2=1, 2, 4, 5 or 7; however, without optional suffix code /DR (For Detailed model) UT55A optional suffix codes: /R1 Non-voltage contact Transistor contact – +5 V DI16 DI16 Contact rating: 12 V DC, 10 mA or more Contact rating: 12 V DC, 10 mA or more (For Standard model) UT55A suffix code: Type 2=3 (For Detailed model) UT55A optional suffix code: /X1 Non-voltage contact Transistor contact – +5 V...
  • Page 385 17.4 Wiring (For Detailed model) UT55A optional suffix code: /X2 Non-voltage contact Transistor contact – +5 V DI21 DI21 +5 V DI22 DI22 +5 V DI23 DI23 +5 V DI24 DI24 +5 V DI25 DI25 Contact rating: 12 V DC, 10 mA or more Contact rating: 12 V DC, 10 mA or more...
  • Page 386 17.4 Wiring (For Standard model) UT55A suffix code: Type 2=5 or 6 (For Detailed model) UT55A optional suffix code: /X4 No-voltage contact Transistor contact – +5 V DI41 DI41 +5 V DI42 DI42 +5 V DI43 DI43 +5 V DI44 DI44 +5 V DI45 DI45 Contact rating: 12 V DC, 10 mA or more Contact rating: 12 V DC, 10 mA or more...
  • Page 387 17.4 Wiring (For Detailed model) UT55A optional suffix code: /W4 No-voltage contact Transistor contact – +5 V DI41 DI41 +5 V DI42 DI42 Contact rating: 12 V DC, 10 mA or more Contact rating: 12 V DC, 10 mA or more Additional Contact Input According to the UT52A Suffix Codes (For Standard model) UT52A suffix code: Type 2=1 or 2 (However, when Type2=2, applicable when without optional suffix code /DR) (For Detailed model) UT52A optional suffix code: /R1 or /RCH1 No-voltage contact Transistor contact –...
  • Page 388 17.4 Wiring The following table shows the initial status for each control mode and control type. No function is assigned to contact inputs other than those listed below. ► Contact input function registration: 12.1 Setting Contact Input Function Control mode and control type DI16 Single-loop Control Single-loop Heating/cooling Control Single-loop Position Proportional Control Single-loop Two-position Two-level Control Loop Control with PV Auto-selector (4 inputs) Heating/cooling Loop Control with PV...

  • Page 389: Contact Output Wiring

    Functional Reinforced insulation insulation A hazardous A hazardous voltage circuit voltage circuit Reinforced insulation ► When using auxiliary relay: 17.4.4 Control Output (Relay, Current, and Voltage Pulse) Wiring UT55A/UT52A Contact Output Equipped as Standard Relay contact Contact rating: 240 V AC, 1 A 30 V DC, 1 A (resistance load) 17-20 IM 05P01C31-01EN...
  • Page 390 17.4 Wiring Additional Contact Output According to the UT55A Suffix Codes (For Standard model) UT55A suffix code: (For Standard model) UT55A suffix codes: Type 2=6 Type 2=1, 3, 5 or 6 (For Detailed model) UT55A optional suffix (For Detailed model) UT55A optional suffix code: /Y1 codes: /Y2 DO15 DO25 DO14 DO24 DO13 DO23 DO12 DO22 DO11 DO21 Transistor contact rating: 24 V DC, 50 mA Transistor contact rating: 24 V DC, 50 mA Factory default: Function is not assigned to the additional contact outputs (DO11 to DO15).
  • Page 391 17.4 Wiring (For Detailed model) UT55A optional suffix (For Detailed model) UT55A optional suffix code: /W1 code: /W2 DO12 DO22 DO11 DO21 Transistor contact rating: 24 V DC, 50 mA Transistor contact rating: 24 V DC, 50 mA (For Detailed model) UT55A optional suffix (For Detailed model) UT55A optional suffix code: /W3 code: /W4 DO32 DO42 DO31 DO41 Transistor contact rating: 24 V DC, 50 mA...

  • Page 392: Retransmission Output Wiring

    17.4 Wiring The following table shows the initial status for each control mode and control type. Control mode and control type AL1 terminal AL2 terminal AL3 terminal Single-loop Control Single-loop Heating/cooling Control Single-loop Position Proportional Control Single-loop Two-position Two-level Control Loop Control with PV Switching Heating/cooling Loop Control with PV Switching Position Proportional Loop Control with PV Switching Alarm 1 Alarm 2...

  • Page 393: Dc Loop Power Supply Wiring

    17.4 Wiring 17.4.9 15 V DC Loop Power Supply Wiring This can be used when it is not used for retransmission output. The controller is equipped with a non-isolated loop power supply (14.5 to 18.0 V DC) for connecting a 2-wire transmitter. PV input Ω 0.4-2 V DC – Shield 2-wire transmitter RET terminals 4-20 mA DC 14.5-18.0 V DC Class D grounding (grounding resistance of 100 Ω...

  • Page 394: Heater Break Alarm Wiring

    17.4 Wiring 17.4.11 Heater Break Alarm Wiring Heater break alarm can be used for the UT55A with the optional suffix code /HA. Heater break alarm Heater break detection Shield HAL1 Class D grounding HAL2 Shield Class D grounding Contact raging: 24 V DC, 50 mA (grounding resistance of 100 Ω...

  • Page 395: Communication Interface Wiring

    100 Ω or less) UT55A/UT52A (For Standard model) (For Standard model) UT55A Suffix code: Type UT55A Suffix code: Type 2 Terminal 3 = 1; however, Type 2 = 1 (For Detailed model) = 1 or 2; however, without symbol or 6 excluded UT52A Optional suffix optional suffix code /LP...
  • Page 396 100 Ω or less) of 100 Ω or less) UT55A/UT52A (For Standard model) UT55A Suffix (For Standard model) UT52A Suffix Terminal code: Type 2=1 or 2, and with optional code: Type 2=1 symbol suffix code /LP (For Detailed model) UT52A Optional...

  • Page 397: Coordinated Operation Wiring

    17.4 Wiring 17.4.13 Coordinated Operation Wiring 4-wire Wiring (for UT55A only) UT (Master) UT (Slave) UT (Slave) SDB (+) RDB (+) RDB (+) (External) (External) Terminating resistor Terminating resistor SDA (–) RDA (–) RDA (–) 220 Ω 1/4 W 220 Ω 1/4 W RDB (+)
  • Page 398 17.4 Wiring UT55A/UT52A (For Standard model) (For Standard model) UT55A UT55A Suffix code: Type 3 Suffix code: Type 2 = 1 or 2; Terminal (For Detailed model) = 1; however, Type 2 = 1 or however, without optional symbol UT52A Optional 6 excluded suffix code /LP above suffix code: /CH1...

  • Page 399: Peer-To Peer Communication Wiring

    100 Ω or less) UT55A/UT52A (For Standard model) (For Standard model) UT55A UT55A Suffix code: Type 3 Suffix code: Type 2 = 1 or 2; Terminal (For Detailed model) = 1; however, Type 2 = 1 or however, without optional symbol UT52A Optional suffix...
  • Page 400 100 Ω or less) of 100 Ω or less) UT55A/UT52A (For Standard model) UT55A Suffix (For Standard model) UT52A Suffix Terminal code: Type 2=1 or 2, and with optional code: Type 2=1 symbol suffix code /LP (For Detailed model) UT52A Optional...

  • Page 401: Ethernet Communication Interface Wiring

    17.4 Wiring 17.4.15 Ethernet Communication Interface Wiring *Devices that can be *Devices that can be connected via Ethernet connected via Ethernet Ethernet Straight cable Crossing cable UT55A UT55A UT55A Upper side LED (baud rate) Lower side LED (link activity) Color Amber Color Green 100M bps...
  • Page 402 Ω or less) of 100 Ω or less) UT55A/UT52A (Slave terminals) (For Standard model) UT55A Suffix code: Type (For Standard model) UT52A Suffix Terminal 2 = 1 or 2, and with optional suffix code /LP code: Type 2=1 symbol (For Detailed model) UT55A Optional suffix...

  • Page 403: Profibus-Dp Communication Interface Wiring

    17.4 Wiring 17.4.16 PROFIBUS-DP Communication Interface Wiring (1) Remove the terminal block Hold both ends of the terminal block and pull straight. (2) Connect the wires Recommended length of stripped wire: 7mm Flat-blade screwdriver (3) Connect the terminal block Hold both ends of the terminal block, align with the connector on the UT side, and push the terminal block into the connector.
  • Page 404 17.4 Wiring Number of Pin Singnal name Description +5V bus power RxD/TxD-P Data signal (positive data receive/transmit) RxD/TxD-N Data signal (negative data recive/transmit) DGND Signal ground SHIELD Shield ground Terminating Resister of Bus 390Ω Data line RxD/TxD-P 220Ω Data line RxD/TxD-N 390Ω DGND PROFIBUS-DP communication connector and LED Unlit CHK (red) User profile error Normal Normal.

  • Page 405: Devicenet Communication Interface Wiring

    17.4 Wiring 17.4.17 DeviceNet Communication Interface Wiring (1) Remove the terminal block Hold both ends of the terminal block and pull straight. (2) Connect the wires Recommended length of stripped wire: 7mm Flat-blade screwdriver (3) Connect the terminal block Hold both ends of the terminal block, align with the connector on the UT side, and push the terminal block into the connector.
  • Page 406 17.4 Wiring Number of Pin Singnal name Description CAN_H RX/TX + signal CAN_L RX/TX - signal Power supply 24V for DeviceNet Power supply COM for DeviceNet DRAIN Shield/drain Terminating Resister of Bus (both ends of the trunk line) CAN_H 121Ω CAN_L DeviceNet communication connector and LED (Red) (White) (Blue) (Black) Lit / flashing Unlit CHK (red) User profile error Normal Normal. Communicating successfully (green, lit). Not connected (green, flashing). Critical link failure (red, lit). MNS (green/red) No electricity, Connection timeout (red, flashing)

  • Page 407: Cc-Link Communication Interface Wiring

    17.4 Wiring 17.4.18 CC-Link Communication Interface Wiring (1) Remove the terminal block Hold both ends of the terminal block and pull straight. (2) Connect the wires Recommended length of stripped wire: 7mm Flat-blade screwdriver (3) Connect the terminal block Hold both ends of the terminal block, align with the connector on the UT side, and push the terminal block into the connector.
  • Page 408 17.4 Wiring Number of Pin Singnal name Description Frame ground Shield TX/RX signal ground RX/TX - signal RS/TX + signal Terminating Resister of Bus (both ends of the trunk line) 110Ω CC-Link communication connector and LED L ERR L RUN Unlit CHK (red) User profile error / address error Normal L ERR (red) Communication failure (CRC error) Normal L RUN (green) Normal. Communicating successfully. No carrier detected. / Connection timeout. Modbus master wiring Modbus master wiring is same as RS-485 communication wiring for Ethernet-serial gateway function.

  • Page 409: Power Supply Wiring

    17.4 Wiring 17.4.19 Power Supply Wiring WARNING 1) Wiring work must be carried out by a person with basic electrical knowledge and practical experience. 2) Be sure to turn OFF the power supply to the controller before wiring to avoid an electric shock. Use a tester or similar device to ensure that no power is being supplied to a cable to be connected.

  • Page 410: Attaching And Detaching Terminal Cover

    17.5 Attaching and Detaching Terminal Cover After completing the wiring, the terminal cover is recommended to use for the instrument. Attaching Method (1) Attach the terminal cover to the rear panel (2) The following figure is a mounting image. of the main unit horizontally. When Ethernet, PROFIBUS-DP, DeviceNet or CC-Link communication is specified, cut and use a terminal cover as follows.
  • Page 411 Blank Page...

  • Page 412: Chapter 18 Parameters

    Chapter 18 Parameters 18.1 Parameter Map Brief Description of Parameter Map Group Display "E1 to E4" and "1 to 8, R" appearing in the parameter map are displayed on Group display (7 segments, 2 digits) while the menu or parameter is displayed. E1: indicates the parameter in E1-terminal area E2: indicates the parameter in E2-terminal area E3: indicates the parameter in E3-terminal area E4: indicates the parameter in E4-terminal area...
  • Page 413 18.1 Parameter Map Function of Each Menu Menu symbol Function Operation mode (STOP/RUN switch, REMOTE/LOCAL switch, Auto-tuning MODE switch, SP number selection, etc.) The parameters in the menu of the following table indicate the parameters to set the functions necessary for operation. The symbol in parentheses are shown on Group display.
  • Page 414 18.1 Parameter Map The parameters in the menu of the following table indicate the parameters to set the basic functions of the controller. The symbol in parentheses are shown on Group display. Menu symbol Functions PASS Password setting (Displayed only when the password has been sent.) Menu symbol Functions Control mode, control type, sampling period, number of SP groups, number of PID groups, etc...
  • Page 415 18.1 Parameter Map Operation Setting parameters for the functions necessary for operations. display Press the key CS menu is displayed when the SELECT parameter has been registered. for 3 seconds. MODE ALRM パターン 2 以降は、オプション 1 ～ 40 によります。 PTNO. C.A.M CS10 STAT CS11 CS12...
  • Page 416 18.1 Parameter Map TUNE ZONE AT.TY AT.OH AT.OL AT.BS SU.HY SU.HY SU.HY HY.UP HY.UP HY.UP HY.LO HY.LO HY.LO … SU.DR SU.DR SU.DR HYSc HYSc HYSc OLMT MPON MPO1 SU.PO SU.PO SU.PO MPO5 TUNE ZONE PPAR PYS1 PYS2 PYS3 PYS4 MODE AT.TY AT.OH AT.OL AT.BS OLMT...
  • Page 417 18.1 Parameter Map Operation Setting parameters for the basic functions of the controller display ＋ Press the keys for 3 seconds. PASS AIN2 AIN4 Displayed when a password has been set. CTLM P.UNI P.UNI UNIT UNIT UNIT UNIT P.DP P.DP P.RH P.RH (LP2) P.RL P.RL...
  • Page 418 18.1 Parameter Map R485 R485 R485 ETHR PROF DNET CC-L HB1.S HB2.S V.AT FILE FILE FILE V.RS CT1.T SCAN SCAN SCAN CT2.T TR.T HDN1 RP.T RP.T RP.T V.MOD HDN2 HDF1 HDF2 HB1.D O1RS 1.IP3 HB2.D O1RH OU2.H 1.IP4 O1RL OU2.L 2.IP1 O2RS RET.H 2.IP2 O2RH...

  • Page 419: List Of Parameters

    18.2 List of Parameters 18.2.1 Operation Parameters Operation Mode Menu (Menu: MODE) Parameter Display Name Setting range Initial value symbol level CAS: Cascade mode AUTO: Automatic mode MAN: Manual mode CAS/AUTO/MAN C.A.M EASY switch Parameter C.A.M is displayed when the control mode is Cascade control or Cascade secondary-loop control.
  • Page 420 18.2 List of Parameters SELECT Parameter Menu (Menu: CS) Parameter Display Name Setting range Initial value symbol level CS10 to SELECT parameter Setting range of a registered EASY CS19 10 to 19 parameter. SP and Alarm Setpoint Setting Menu (Menu: SP) Parameter Display Name Setting range Initial value symbol level 0.0 to 100.0% of PV input range Target setpoint EASY (EU) (Setting range: SPL to SPH) Sub-target setpoint Set the offset from SP.
  • Page 421 18.2 List of Parameters Alarm Function Setting Menu (Menu: ALRM) Parameter Display Name Setting range Initial value symbol level Set a 5-digit value in the following order. [Alarm type: 2 digits (see below)] + [Without (0) or With (1) Stand-by action] + [Energized (0) or De-energized (1)] + [Latch action (0/1/2/3/4)] For latch action, see chapter 11. Alarm type: 2 digits 00: Disable 01: PV high limit...
  • Page 422 18.2 List of Parameters PV-related Setting Menu (Menu: PVS) Parameter Display Name Setting range Initial value symbol level 0.0 % of PV -100.0 to 100.0% of PV input range PV input bias EASY input range span (EUS) span PV input filter EASY OFF, 1 to 120 s In Cascade control, the following parameters are also displayed for secondary loop. (the LP2 lamp is lit) Parameter: BS, FL PID Setting Menu (Menu: PID)
  • Page 423 18.2 List of Parameters PID Setting Menu (Menu: PID) (Continued from previous page) Parameter Display Name Setting range Initial value symbol level Sub-hysteresis (in 0.5 % of PV 0.0 to 100.0% of PV input range SU.HY Two-position two- EASY input range span (EUS) level control) span Upper-side 0.5 % of PV HY.UP hysteresis (in ON/ EASY input range OFF control) span 0.0 to 100.0% of PV input range Lower-side span (EUS) 0.5 % of PV HY.LO hysteresis (in ON/...
  • Page 424 18.2 List of Parameters Tuning Menu (Menu: TUNE) Parameter Display Name Setting range Initial value symbol level OFF: Disable 1: Overshoot suppressing function (normal mode) 2: Hunting suppressing function (stable mode) Enables to answer the wider characteristic changes Super function EASY compared with response mode. 3: Hunting suppressing function (response mode) Enables quick follow-up and short converging time of PV for...
  • Page 425 18.2 List of Parameters Tuning Menu (Menu: TUNE) (Continued from previous page) Parameter Display Name Setting range Initial value symbol level OFF: Hold the control output in AUTO mode (bumpless) 1: Use manual preset output 1 (output bump) 2: Use manual preset output 2 Manual preset (output bump) MPON output number 3: Use manual preset output 3 selection (output bump)
  • Page 426 18.2 List of Parameters 10-segment Linearizer Setting Menu (Menu: PYS1 to PYS4) Parameter Display Name Setting range Initial value symbol level OFF: Disable PV: PV analog input RSP: RSP analog input Group 1, 2: AIN2: AIN2 analog input 10-segment AIN4: AIN4 analog input linearizer selection Group 3, 4: (CTLM: SGL) PVIN: PV input OUT: OUT analog output OUT2: OUT2 analog output RET: RET analog output Group 1, 2:...

  • Page 427: Setup Parameters

    18.2 List of Parameters 18.2.2 Setup Parameters Control Function Setting Menu (Menu: CTL) Parameter Display Name Setting range Initial value symbol level SGL: Single-loop control CAS1: Cascade primary-loop control CAS2: Cascade secondary-loop control CAS: Cascade control BUM: Loop control for backup PVSW: Loop control with PV CTLM Control mode switching PVSEL: Loop control with PV auto- selector PVHD: Loop control with PV-hold function * When using the ladder program, the control mode cannot be changed.
  • Page 428 18.2 List of Parameters PV Input Setting Menu (Menu: PV) Parameter Display Initial Name Setting range symbol level value OFF: Disable K1: -270.0 to 1370.0 (°C) / -450.0 to 2500.0 (°F) K2: -270.0 to 1000.0 (°C) / -450.0 to 2300.0 (°F) K3: -200.0 to 500.0 (°C) / -200.0 to 1000.0 (°F) J: -200.0 to 1200.0 (°C) / -300.0 to 2300.0 (°F) T1: -270.0 to 400.0 (°C) / -450.0 to 750.0 (°F) T2: 0.0 to 400.0 (°C) / -200.0 to 750.0 (°F)
  • Page 429 18.2 List of Parameters PV Input Setting Menu (Menu: PV) (Continued from previous page) Parameter Display Initial Name Setting range symbol level value 0: No decimal place PV input scale 1: One decimal place Depends decimal point EASY 2: Two decimal places on the position 3: Three decimal places input type 4: Four decimal places Maximum Depends value of PV...
  • Page 430 18.2 List of Parameters RSP Setting Menu (Menu: RSP) (E1 terminal area) Parameter Display Name Setting range Initial value symbol level 0.4-2V: 0.400 to 2.000 V 1-5V: 1.000 to 5.000 V 0-2V: 0.000 to 2.000 V RSP remote input EASY 0-10V: 0.00 to 10.00 V 1-5V type 0-125: 0.000 to 1.250 V For option /DR, RSP remote input type is same as PV input type. -: No unit C: Degree Celsius RSP remote input -: No unit UNIT EASY unit...
  • Page 431 18.2 List of Parameters RSP Input Setting Menu (Menu: RSP) (Continued from previous page) Parameter Display Name Setting range Initial value symbol level 0.0 % of RSP RSP aux. analog -100.0 to 100.0% of RSP input A.BS input range input bias range span (EUS) span RSP aux. analog A.FL OFF, 1 to 120 s input filter OFF: No square root extraction. RSP aux. analog 1: Compute the square root.
  • Page 432 18.2 List of Parameters AIN2 Aux. Analog Input Setting Menu (Menu: AIN2) (E2 terminal area) Parameter Display Name Setting range Initial value symbol level 0.4-2V: 0.400 to 2.000 V 1-5V: 1.000 to 5.000 V AIN2 aux. analog EASY 0-2V: 0.000 to 2.000 V 1-5V input type 0-10V: 0.00 to 10.00 V 0-125: 0.000 to 1.250 V -: No unit C: Degree Celsius AIN2 aux. analog -: No unit UNIT EASY input unit --: No unit ---: No unit F: Degree Fahrenheit Maximum value of...
  • Page 433 18.2 List of Parameters AIN4 Aux. Analog Input Setting Menu (Menu: AIN4) (E4 terminal area) Parameter Display Name Setting range Initial value symbol level 0.4-2V: 0.400 to 2.000 V 1-5V: 1.000 to 5.000 V AIN4 aux. analog EASY 0-2V: 0.000 to 2.000 V 1-5V input type 0-10V: 0.00 to 10.00 V 0-125: 0.000 to 1.250 V -: No unit C: Degree Celsius AIN4 aux. analog -: No unit UNIT EASY input unit --: No unit ---: No unit F: Degree Fahrenheit Maximum value of...
  • Page 434 18.2 List of Parameters Input Range/SP Limiter/Input Switch/Input Auto-selector Setting Menu (Menu: MPV) Parameter Display Name Setting range Initial value symbol level -: No unit C: Degree Celsius Control PV input -: No unit Same as PV P.UNI unit --: No unit input unit ---: No unit F: Degree Fahrenheit 0: No decimal place Control PV input 1: One decimal place P.DP decimal point 2: Two decimal places...
  • Page 435 18.2 List of Parameters Output Setting Menu (Menu: OUT) Parameter Display Name Setting range Initial value symbol level Control output or Heating-side control output (Lower two digits) 00: OFF 01: OUT terminals (voltage pulse) 02: OUT terminals (current) 03: OUT terminals (relay/triac) 04: OUT2 terminals (voltage pulse) Standard type: 05: OUT2 terminals (current) 00.03 06: OUT2 terminals (relay/triac)
  • Page 436 18.2 List of Parameters Output Setting Menu (Menu: OUT) (Continued from previous page) Parameter Display Name Setting range Initial value symbol level OFF: Disable PV1: PV SP1: SP OUT1: OUT (Valve opening: 0 to 100 % in Position proportional control) LPS: 15 V DC loop power supply PV2: Loop-2 PV SP2: Loop-2 SP OUT2: Loop-2 OUT TSP1: Target SP HOUT1: Heating-side OUT COUT1: Cooling-side OUT Retransmission MV1: Position proportional output EASY output type of RET internal computed value) TSP2: Loop-2 target SP HOUT2: Loop-2 heating-side OUT...
  • Page 437 18.2 List of Parameters Output Setting Menu (Menu: OUT) (Continued from previous page) Parameter Display Name Setting range Initial value symbol level Retransmission O1RS output type of OUT Same as RTS current output Maximum value When O1RS = PV1, SP1, PV2, of retransmission SP2, TSP1, TSP2, PV, RSP, AIN2, O1RH output scale of OUT or AIN4, current output O1RL + 1 digit to 30000 -19999 to O1RH - 1 digit Decimal point position: When O1RS=PV1, SP1, or TSP1,...
  • Page 438 18.2 List of Parameters Output Setting Menu (Menu: OUT) (Continued from previous page) Parameter Display Name Setting range Initial value symbol level 100% segmental OU.H point of OUT 100.0% current output 0% segmental point OU.L of OUT current 0.0% output 100% segmental OU2.H point of OUT2 100.0% current output -100.0 to 200.0% 0% segmental point OU2.L of OUT2 current 0.0% output 100% segmental RET.H...
  • Page 439 18.2 List of Parameters RS-485 Communication Setting Menu (Menu: R485) (E1, E3 and E4 terminal area) Parameter Display Name Setting range Initial value symbol level PCL: PC link communication PCLSM: PC link communication (with checksum) LADR: Ladder communication CO-M: Coordinated master station CO-S: Coordinated slave station Protocol selection EASY MBASC: Modbus (ASCII) MBRTU MBRTU: Modbus (RTU) CO-S1: Coordinated slave station (Loop-1 mode) CO-S2: Coordinated slave station...
  • Page 440 18.2 List of Parameters Ethernet Communication Setting Menu (Menu: ETHR) (E3 terminal area) Parameter Display Name Setting range Initial value symbol level High-speed EASY OFF, 1 to 8 response mode 9600: 9600 bps Baud rate EASY 19200: 19.2k bps 38400 38400: 38.4k bps NONE: None Parity EASY EVEN: Even EVEN ODD: Odd 0 to 255 IP1 to IP4 IP address 1 to 4 EASY...
  • Page 441 18.2 List of Parameters DeviceNet Communication Setting Menu (Menu: DNET) (E3 terminal area) Parameter Display Name Setting range Initial value symbol level 125K: 125k bps Baud rate EASY 250K: 250k bps 125K 500K: 500k bps Address EASY 0 to 63 9600: 9600 bps Baud rate EASY 19200: 19.2k bps 38400 38400: 38.4k bps FILE Profile number EASY...
  • Page 442 18.2 List of Parameters Key Action Setting Menu (Menu: KEY) Parameter Display Name Setting range Initial value symbol level User function key-1, OFF: Disable F1 to F2 EASY -2 action setting A/M: AUTO/MAN switch C/A/M: CAS/AUTO/MAN switch R/L1: REM/LCL switch R/L2: Loop-2 REM/LCL switch S/R: STOP/RUN switch CAS: Switch to CAS AUTO: Switch to AUTO MAN: Switch to MAN REM1: Switch to REM...
  • Page 443 18.2 List of Parameters Display Function Setting Menu (Menu: DISP) Parameter Display Name Setting range Initial value symbol level 1.0 % of PV Deviation display 0.0 to 100.0% of PV input range input range band span (EUS) span 0: Fixed in white 1: Fixed in red 2: Link to alarm 1 (Alarm OFF: white, Alarm ON: red) 3: Link to alarm 1 (Alarm OFF: red, Alarm ON: white) 4: Link to alarm 1 or 2 (Alarm OFF: white, Alarm ON: red)
  • Page 444 18.2 List of Parameters Display Function Setting Menu (Menu: DISP) (Continued from previous page) Parameter Display Name Setting range Initial value symbol level Bar-graph 10.0 % of PV 0.0 to 100.0% of PV input range span deviation display input range (EUS) band span Setting range: 4001 to 6304 OFF: Disable 4321: Link to alarm 1 (Lit when the alarm occurs) 4322: Link to alarm 2 (Lit when the alarm occurs) 4323: Link to alarm 3 (Lit when the alarm occurs) 4325: Link to alarm 4 (Lit when the alarm occurs) 4326: Link to alarm 5 (Lit when the alarm occurs)
  • Page 445 18.2 List of Parameters Display Function Setting Menu (Menu: DISP) (Continued from previous page) Parameter Display Name Setting range Initial value symbol level PV display area PV.D ON/OFF Setpoint display SP.D OFF: Nondisplay, ON: Display area ON/OFF Status display area STS.D ON/OFF Scroll speed (Slow) 1 to 8 (Quick) Guide display ON/ OFF: Nondisplay GUID ON: Display SP1: SP Display SP2: Loop-2 SP Display OUT1: OUT Display OUT2: Loop-2 OUT Display...
  • Page 446 18.2 List of Parameters Display Function Setting Menu (Menu: DISP) (Continued from previous page) Parameter Display Name Setting range Initial value symbol level Automatically returned to the Operation Display when there has Autoreturn to OP.JP been no keystroke operation for 5 operation display minutes. OFF, ON Least significant OFF: With least significant digit MLSD digital mask of PV ON: Without least significant digit display SELECT Display Setting Menu (Menu: CSEL) Parameter Display Name...
  • Page 447 18.2 List of Parameters Menu Lock Setting Menu (Menu: MLOC) Parameter Display Name Setting range Initial value symbol level [CTL] menu lock [PV] menu lock [RSP] menu lock AIN2 [AIN2] menu lock AIN4 [AIN4] menu lock [MPV] menu lock [OUT] menu lock [HBA] menu lock R485 [R485] menu lock ETHR [ETHR] menu lock PROF [PROF] menu lock DNET...
  • Page 448 18.2 List of Parameters Menu Lock Setting Menu (Menu: MLOC) Parameter Display Name Setting range Initial value symbol level MODE [MODE] menu lock [CS] menu lock [SP] menu lock [SPS] menu lock ALRM [ALRM] menu lock [PVS] menu lock [PID] menu lock OFF: Display ON: Nondisplay TUNE [TUNE] menu lock ZONE [ZONE] menu lock PPAR [PPAR] menu lock...
  • Page 449 18.2 List of Parameters DI Function Registration Menu (Menu: DI.SL) Parameter Display Name Setting range Initial value symbol level AUTO/MAN switch 5025 REMOTE/LOCAL 5046 switch STOP/RUN switch 5026 Switch to CAS Set an I relay number of contact AUTO Switch to AUTO input. Switch to MAN Set “OFF” to disable the function. Switch to REMOTE Standard terminals Switch to LOCAL...
  • Page 450 18.2 List of Parameters DI Function Numbering Menu (Menu: DI.NU) Parameter Display Name Setting range Initial value symbol level Set an I relay number of contact SP.B0 Bit-0 of SP number EASY input. SP.B1 Bit-1 of SP number EASY Set “OFF” to disable the function. SP.B2 Bit-2 of SP number EASY Standard terminals SP.B3...
  • Page 451 18.2 List of Parameters AL1-AL3 Function Registration Menu (Menu: ALM) Parameter Display Name Setting range Initial value symbol level AL1 function Set an I relay number. AL1.S 4353 selection Setting range: 4001 to 6000 AL2 function AL2.S 4354 No function: OFF selection Alarm 1: 4353 AL3 function AL3.S 4355 Alarm 2: 4354 selection Alarm 3: 4355...
  • Page 452 R.TM Restart timer 0 to 10 s 0: Preset output Input error preset 1: 0% output output 2: 100% output OFF: Works as UT55A/UT52A in communication of device information response or Response as broadcasting. C.GRN GREEN Series ON: Works as GREEN Series in communication of device information response or broadcasting.
  • Page 453 18.2 List of Parameters Initialization Menu (Menu: INIT) Parameter Display Name Setting range Initial value symbol level Initialization to user 12345: Initialization, automatically U.DEF default value returned to "0" after initialization. Initialization to -12345: Initialization, automatically F.DEF factory default value returned to "0" after initialization. Error and Version Confirmation Menu (Menu: VER) Parameter Display Name Read only symbol level PA.ER Parameter error status EASY OP.ER Option error status EASY AD1.E A/D converter error status 1...

  • Page 454: Chapter 19 Specifications

    Chapter 19 Specifications 19.1 Hardware Specifications WARNING This instrument is for Measurement Category I (CAT.I). Do not use it for measurements in locations falling under Measurement Categories II, III, and IV. Internal Wiring Entrance IV Cable Outlet Measurement Category Description Remarks category For measurements performed on circuits not CAT.I directly connected to MAINS. For measurements performed on circuits Appliances, portable CAT.II...

  • Page 455: Input Specifications

    19.1 Hardware Specifications 19.1.1 Input Specifications Universal Input • Number of inputs: 1 • Input type, instrument range, and measurement accuracy: See the table below. Input Type Instrument Range (°C) Instrument Range (°F) Accuracy -270.0 1370.0°C -450.0 2500.0°F ±0.1% of instrument range ±1 digit for 0°C or more -270.0 1000.0°C -450.0 2300.0°F ±0.2% of instrument range ±1 digit for less than 0°C -270.0 500.0°C -200.0 1000.0°F ±2% of instrument range ±1 digit for less than -200.0°C of thermocouple K -200.0...
  • Page 456 19.1 Hardware Specifications • Input sampling (control) period: Select from among 50, 100, and 200 ms • Burnout detection: Functions at TC, RTD, and standard signal Upscale, downscale, and off can be specified. For standard signal, burnout is determined to have occurred if it is 0.1 V or 0.4 mA or less. • Input bias current: 0.05 µA (for TC or RTD) •...

  • Page 457: Analog Output Specifications

    Control output: contact point 1c; 1 point Cooling-side control output of Heating/cooling type: contact point 1c; 1 point (for UT55A only) For UT52A, contact point 1a; 2 points for both heating and cooling sides Alarm output: contact point 1a; 3 points (common is independent) •...

  • Page 458: Triac Output Specifications (For Detailed Model)

    Current input: 4 to 20 mA (with disconnection detection) • Sampling period: 50 ms • Measurement resolution: 0.1% of input span • Position proportional relay output: UT55A: contact point 1a; 2 points, 250 V AC, 3 A or 30 V DC, 3 A (resistance load) UT52A: contact point 1a; 2 points, 240 V AC, 3 A or 30 V DC, 3 A (resistance load) Note: Cannot be used for a small load of 10 mA or less. 19.1.7 Retransmission Output Specifications • Number of outputs: Retransmission output; 1, shared with 15 V DC loop power supply • Current output: 4 to 20 mA DC or 0 to 20 mA DC/ load resistance of 600 Ω or less...

  • Page 459: Transistor Contact Output Specifications

    19.1 Hardware Specifications 19.1.10 Transistor Contact Output Specifications • Number of outputs: See the table of Model and Suffix Codes. • Output type: Open collector (SINK current) • Output contact rating: Max. 24 V DC, 50 mA • Output time resolution: Min. 50 ms 19.1.11 Heater Break Alarm Specifications • Number of inputs: 2 • Number of outputs: 2 (transistor contact output) •...

  • Page 460: Safety And Emc Standards

    • Case color: White (Light gray) or black (Light charcoal gray) • Weight: 0.5 kg or less • External dimensions (mm): UT55A: 96 (W) × 96 (H) × 65 (depth from the panel face) UT52A: 48 (W) × 96 (H) × 65 (depth from the panel face) (Depth except the projection on the rear panel) •...

  • Page 461: Power Supply Specifications And Isolation

    19.1 Hardware Specifications 19.1.15 Power Supply Specifications and Isolation • Power supply: Rated voltage: 100 – 240 V AC (+10%/-15%), 50/60 Hz 24 V AC/DC (+10%/-15%) (for /DC option) • Power consumption: UT55A: 18 VA (DC:9 VA, AC: 14 VA if /DC option is specified) UT52A: 15 VA (DC:7 VA, AC: 11 VA if /DC option is specified) • Data backup: Nonvolatile memory • Power holdup time: 20 ms (for 100 V AC drive) • Withstanding voltage - Between primary terminals and secondary terminals: 2300 V AC for 1 minute - Between primary terminals: 1500 V AC for 1 minute - Between secondary terminals: 500 V AC for 1 minute (Primary terminals: Power (*) and relay output terminals; Secondary terminals: Analog I/O signal terminals, contact input terminals, communication terminals, and functional grounding terminals.)

  • Page 462: Environmental Conditions

    19.1 Hardware Specifications 19.1.16 Environmental Conditions Normal Operating Conditions • Ambient temperature: -10 to 50ºC (-10 to 40ºC for side-by-side close mounting) For the CC-Link option, 0 to 50 ºC (0 to 40 ºC for side-by-side close mounting) • Ambient humidity: 20 to 90% RH (no condensation allowed) • Magnetic field: 400 A/m or less • Continuous vibration at 5 to 9 Hz: Half amplitude of 1.5 mm or less, 1oct/min for 90 minutes each in the three axis directions Continuous vibration at 9 to 150 Hz: 4.9 m/s...
  • Page 463 Blank Page...

  • Page 464: Appendix Input And Output Table

    Appendix Input and Output Table Appendix 1 Input and Output Table (for Standard model) See the next page. App-1 IM 05P01C31-01EN...
  • Page 465 Appendix 1 Input and Output Table (for Standard model) UT55A Model and Suffix Codes Optional INPUT OUTPUT Model Suffix code AIN2 AIN4 OUT2 VALV suffix code ● ● UT55A ● Type 1: Basic ● control ● ● ● ● Type 2: Functions ● ● ● ● ● Type 3: Open networks...
  • Page 466 Appendix 1 Input and Output Table (for Standard model) UT55A (Continued) DI11 DI12 DI13 DI14 DI15 DI16 DI26 DI31 DI32 DI33 DI34 DI35 DI41 DI42 DI43 DI44 DI45 DI46 ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●...

  • Page 467: Appendix

    Appendix 2 Input and Output Table (for Detailed model) UT55A Model and Suffix Codes INPUT OUTPUT Optional OUT OUT2 Model Suffix code OUT OUT OUT2 OUT2 AIN2 AIN4 (mA/ VALV (mA/ suffix code (relay) (triac) (relay) (triac) pulse) pulse) ● UT55A -xxx Fixed code -NNN Display language/ Case color ●...

  • Page 468: Appendix 2 Input And Output Table (For Detailed Model)

    Appendix 2 Input and Output Table (for Detailed model) UT55A (Continued) DI11 DI12 DI13 DI14 DI15 DI16 DI21 DI22 DI23 DI24 DI25 DI26 DI31 DI32 DI33 DI34 DI35 DI41 DI42 DI43 DI44 DI45 DI46 ● ● ● ● ● ● ● ● ● ● ● ● ● ●...
  • Page 469 Appendix 2 Input and Output Table (for Detailed model) UT55A (Continued) Optional Model Suffix code suffix code UT55A -NNN Fixed code -NNN Display language/ Case color Output 1 Output 2 Retransmission output Heater break alarm E1 terminal area E2 terminal area /CH3 /CC3 /PD3 /DN3 E3 terminal area /ET3 /AC4 E4 terminal area /LC4 Power supply Additional treatment App-6 App-6 IM 05P01C31-01EN...
  • Page 470 Appendix 2 Input and Output Table (for Detailed model) UT55A (Continued) AL3 DO11 DO12 DO13 DO14 DO15 DO21 DO22 DO23 DO24 DO25 DO31 DO32 DO33 DO34 DO35 DO41 DO42 DO43 DO44 DO45 HAL1 HAL2 ● ● ● ● ● ● ● ● ● ● ● ● ● ●...
  • Page 471 Appendix 2 Input and Output Table (for Detailed model) UT52A Model and Suffix Codes INPUT OUTPUT Optional OUT OUT2 Model Suffix code OUT OUT OUT2 (mA/ VALV (mA/ suffix code (relay) (triac) (relay) pulse) pulse) ● UT52A -NNN Fixed code -NNN Display language/ Case color ● ● ● ●...
  • Page 472 Appendix 2 Input and Output Table (for Detailed model) UT52A (Continued) DI11 DI12 DI13 DI14 DI15 DI16 DO11 DO12 DO13 DO14 DO15 HAL1 HAL2 ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●: Equipped App-9 IM 05P01C31-01EN...
  • Page 473 Blank Page...

  • Page 474: Revision Information

    Revision Information Title : UT55A/UT52A Digital Indicating Controller User’s Manual  Manual No. : IM 05P01C31-01EN  May 2009/1st Edition Newly published Sep. 2009/2nd Edition Error correction Jan. 2010/3rd Edition Error correction June 2010/4th Edition Style change for the case color option, and addition of DeviceNet and CC-Link communication.
  • Page 475 Blank Page...
  • Page 476 Velizy-Villacoublay (France), Budapest (Hungary), Stockholm (Sweden), Sola (Norway), Warszawa (Poland), Vila Nova de Gaia (Portugal), Bucharest (Romania), Dublin (Ireland) YOKOGAWA AMERICA DO SUL LTDA. Praca Acapulco, 31 - Santo Amaro. Sao Paulo/SP - BRAZIL Phone : 55-11-5681-2400 Fax : 55-11-5681-4434 YOKOGAWA ENGINEERING ASIA PTE.

This manual is also suitable for:

Ut52a
