User Manual
ITA-1711 Series
Fanless Embedded Celeron
Dual Core Compact Industrial
Computer
嵌入式無風扇電腦

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ITA-1711 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Advantech ITA-1711 Series

  • Page 1 User Manual ITA-1711 Series Fanless Embedded Celeron Dual Core Compact Industrial Computer 嵌入式無風扇電腦...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
  • Page 3 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
  • Page 4: Initial Inspection

    Advantech has come to be known. Your satisfaction is our primary concern. Here is a guide to Advantech's customer services.
  • Page 5 Warnings, Cautions, and Notes Warning! Warnings indicate conditions, which if not observed, can cause personal injury! Caution! Cautions are included to help you avoid damaging hardware or losing data. e.g. There is a danger of a new battery exploding if it is incorrectly installed. Replace the battery only with the same or equivalent type recom- mended by the manufacturer.
  • Page 6: Safety Instructions

    The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 7 Safety Precaution - Static Electricity Follow these simple precautions to protect yourself from harm and the products from damage. To avoid electrical shock, always disconnect the power from your PC chassis before you work on it. Don’t touch any components on the CPU card or other cards while the PC is on.
  • Page 8 ITA-1711 User Manual viii...
  • Page 9: Table Of Contents

    Contents Chapter Overview..........1 Introduction ....................2 Specifications .................... 2 Power Information ..................2 Table 1.1: Power ................. 2 Environmental Specifications ..............3 Table 1.2: Environmental Specifications ........3 Dimension Diagram................... 3 Figure 1.1 Dimension Diagram of ITA-1711 ........ 3 Exploded Diagram..................4 Figure 1.2 Exploded Diagram of ITA-1711 ........
  • Page 10 3.1.1 Installing the Motherboard M-sata Card ........20 Figure 3.1 Installing the Motherboard CF Card ......20 3.1.2 Installing the Mini PCIe Card ............21 Figure 3.2 Installing the Mini PCIe Card........21 3.1.3 Installing the HDD Module ............22 Figure 3.3 Installing the HDD Module........
  • Page 11: Chapter 1 Overview

    Chapter Overview This chapter provider general Information about the ITA-1711.
  • Page 12: Introduction

    Introduction The ITA-1711 is a fan-less compact industrial computer chassis with Celeron dual core processor and wide voltage input range, which is specially designed for intelli- gent transportation - E-police applications. This powerful computing platform can stand operation under harsh conditions 24 hours a day, 7 days a week. Specifications ...
  • Page 13: Environmental Specifications

    Environmental Specifications Table 1.2: Environmental Specifications With industrial HDD: 0 ~ 40°C Operating Temperature With CF/M-SATA card: -25 ~ 60 °C Storage Temperature 85°C º C, Humidity 95% @ 40 non-condensing With CF card: 2 Grms @ 5 ~ 500 Hz, random, 1 hr/axis Vibration With 2.5”...
  • Page 14: Exploded Diagram

    Exploded Diagram Figure 1.2 Exploded Diagram of ITA-1711 Table 1.3: Part List Heat sink Expansion display card Slide rail Expansion I/O card CF adapter board HDD bracket CF extraction rack HDD (not included) CF fixing rack HDD fixed bracket Wall mounting bracket Top cover Main board Replaceable plate...
  • Page 15: Chapter 2 H/W Installation

    Chapter H/W Installation This chapter provides H/W Instal- lation about the ITA-1711.
  • Page 16: Introduction

    Introduction The following sections show the internal jumpers setting and the external connectors pin assignment for application integration. System Status Indicators 2.2.1 System Status LED Indicators The top right LED of the front panel indicates system healthy and active status. Figure 2.1 Front panel indicators Figure 2.2 Rear panel indicators Refer to below table for a LED definition summary.
  • Page 17: Jumpers And Connector

    Jumpers and Connector 2.3.1 Jumper Description You may configure the ITA-1711 to match the needs of your application by setting jumpers. A jumper is a metal bridge used to close an electric circuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.
  • Page 18: Jumper And Connector Location

    2.3.2 Jumper and Connector Location The board has a number of connectors and jumpers that allow you to configure your system to suit your application. The table below lists the function of each of the con- nectors and jumpers.The locations of jumpers and connector on the board are shown in Fig 2.3 and Fig 2.4.
  • Page 19: Figure 2.3 Motherboard Connectors And Jumpers Location

    LPT1 LVDS1 Conn. SATA_PWR1 LPC1 Conn. SATA2 SATA1 SATA_PWR2 GPIO VCCGPIO1 MSATA1 PSON1 SPI1 BIOS Slot COM3 SODIMM1 JCMOS1 JCMOS2 AMPL1 AMPR1 MINIPCIE1 BAT1 LPC2 LVDS2 Figure 2.3 Motherboard Connectors and Jumpers Location JSETCOM7 GPIO02 JSETCOM6 JSETCOM10 COM6_7 JSETCOM4 JSETCOM5 JSETCOM8 JSETCOM9 JSETCOM3...
  • Page 20: Table 2.2: Jlvds1: Lvds Voltage Selection

    Table 2.2: JLVDS1: LVDS Voltage Selection Closed Pins Setting +12V 4/-6 +3.3V (Default) +12V +3.3V Table 2.3: JCOMS1: Clear COMS Selection Closed Pins Setting Normal (+V3.3_SB)* Clear CMOS settings *Default setting Default setting Clear CMOS selection Table 2.4: VCCGPIO1: GPIO Voltage Selection Closed Pins Setting +V3.3_SB...
  • Page 21: Table 2.6: Ampl1: L Sound Channel Amplifier Switch

    Table 2.6: AMPL1: L Sound Channel Amplifier Switch Closed Pins Setting 1-2,4-5 L Sound Channel Amplifier Switch ON (Default) 2-3,5-6 L Sound Channel Amplifier Switch OFF (Default) Table 2.7: AMPR1: R Sound Channel Amplifier Switch Closed Pins Setting 1-2,4-5 R Sound Channel Amplifier Switch ON (Default) 2-3,5-6 R Sound Channel Amplifier Switch OFF (Default) ITA-1711 User Manual...
  • Page 22: I/O Connector

    I/O Connector Figure 2.5 ITA-1711-00A1E, ITA-1711-10A1E, ITA-1711-20A1E Front I/O Interfaces Figure 2.6 ITA-1711-S0A1E Front I/O Interfaces Figure 2.7 ITA-1711-00A1E Rear I/O Interfaces ITA-1711 User Manual...
  • Page 23: Com Connectors

    Figure 2.8 ITA-1711-10A1E Rear I/O Interfaces Figure 2.9 ITA-1711-20A1E Rear I/O Interfaces 2.4.1 COM Connectors ITA-1711 series provides up to ten D-sub 9-pin connectors for RS-232/422/485. RS-232 RS-422 RS-485 Signal Name Signal Name Signal Name DATA- DATA+ ITA-1711 User Manual...
  • Page 24: Usb Connector

    2.4.2 USB Connector ITA-1711 provides five USB2.0 connectors and a USB3.0 connector. They can be disabled in system BIOS setup. Signal Name +V5(VCC) USB_data- USB_data+ 2.4.3 VGA Connector ITA-1711 offers two D-sub 15-pin female connectors. Signal Name Green Blue DDC-DATA H-SYNC V-SYNC DDC-CLK...
  • Page 25: Dio Connector

    2.4.5 Audio in Connector ITA-1711 provides an integrated Mic-in/speaker out audio connector. 2.4.6 LAN Connector ITA-1711 series provide two Intel I211-AT Ethernet controllers, which are fully compli- ant with IEEE 802.3u 10/100/1000 Mbps standard. Signal Name Signal Name A1/B1 MDIO0+...
  • Page 26: Phoenix Terminal Connector

    A12/B12 100m/10M LED 100m/10M LED 2.4.7 Phoenix Terminal Connector ITA-1711 provides a 2-pin phoenix terminal connectors for power input. Signal Name Positive 2.4.8 LVDS Connector ITA-1711-20A1E provides a PS/2 interface for mouse or keyboard connection. Signal Name Signal Name TXL0+ TXL1+ TXL2+ TXL3+...
  • Page 27: Lpt Connector

    2.4.9 LPT Connector ITA-1711-S0A1E provides a LVDS connector(in accessory box for users to change by themselves), which could connect a monitor through cables. Signal Name Signal Name LPT_z_STB# LPT_AFD# LPT_z_PD0 LPT_ERR# LPT_PD1 LPT_INIT# LPT_PD2 LPT_SLIN# LPT_PD3 LPT_PD4 LPT_PD5 LPT_PD6 LPT_PD7 LPT_ACK# LPT_BUSY LPT_PE...
  • Page 28 ITA-1711 User Manual...
  • Page 29: Chapter 3 System Setup

    Chapter System Setup This chapter introduces the instal- lationprocess of ITA-1711.
  • Page 30: Introduction

    Introduction The following procedures will instruct you to install all modules into the ITA-1711 sys- tem. 3.1.1 Installing the Motherboard M-sata Card ITA-1711 motherboard front panel includes a M-sata card slot for the user to insert a M-sata card directly. Figure 3.1 Installing the Motherboard CF Card ITA-1711 User Manual...
  • Page 31: Installing The Mini Pcie Card

    3.1.2 Installing the Mini PCIe Card The ITA-1711 motherboard supports a Mini PCIe expansion card. Please refer to theinstallation procedure below. Insert a Mini PCIe card into motherboard PCIe slot. Lock and fix the Mini PCIe card by a copper pillar. Figure 3.2 Installing the Mini PCIe Card ITA-1711 User Manual...
  • Page 32: Installing The Hdd Module

    3.1.3 Installing the HDD Module ITA-1711 reserves the space for installing a 2.5" HDD module. Please refer to the fol- lowing instructions to install the HDD. Place the HDD into 2.5” HDD holder, and lock it with 4 screws. The HDD holder has four semi-circles (two bigger and two smaller) on both sides, which are used to place rubber cushions, with the black ones for bigger semi-circles and transparent ones for smaller semi-circles.
  • Page 33: Figure 3.3 Installing The Hdd Module

    Figure 3.3 Installing the HDD Module ITA-1711 User Manual...
  • Page 34: Installing The Top Cover

    3.1.4 Installing the Top Cover Please follow the below procedures to install chassis top cover. Insert the top cover on the chassis front panel from the opening point and place it well as shown. (See Figure 3.4) Fix the chassis top cover with two screws. Figure 3.4 Installing the Top Cover ITA-1711 User Manual...
  • Page 35: Installing The Mounting Bracket

    3.1.5 Installing the Mounting Bracket Align the 2 mounting brackets with the screw holes on the chassis side panel, and secure them with screws. Top and bottom installation are both supported. (See Fig 3.5) Figure 3.5 Installing the Mounting Bracket 3.1.6 Installing the CF Card Module Please follow the below steps to install CF card module.
  • Page 36 ITA-1711 User Manual...
  • Page 37: Ami Bios

    Chapter AMI BIOS This chapter introduces how to configure AMI BIOS.
  • Page 38: Introduction

    Introduction AMIBIOS has been integrated into many motherboards for over a decade. This chap- ter introduces how to configure BIOS for ITA-1711 series.With the AMIBIOS Setup program, you can modify BIOS settings and control the special features of your com- puter.
  • Page 39: Entering Setup

    Entering Setup Turn on the computer to enter POST screen, and BIOS and CPU information will be shown.press <DEL> and you will immediately be allowed to enter Setup. Figure 4.2 Press <DEL> to Enter Setup ITA-1711 User Manual...
  • Page 40: Main Setup

    4.2.1 Main Setup When you first enter the BIOS Setup Utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. There are two Main Setup options. They are described in this section. The Main BIOS Setup screen is shown below.
  • Page 41: Advanced Bios Features Setup

    4.2.2 Advanced BIOS Features Setup Select the Advanced tab from the ITA-1711 setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as CPU Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>...
  • Page 42: Figure 4.5 Acpi Settings

    4.2.2.1 APM Configuration Figure 4.5 ACPI Settings  Board Power Mode Show the current startup-up mode. ITA-1711 User Manual...
  • Page 43 4.2.2.2 F818264TH Super I/O; F81826SEC Super I/O; F81826THD Super I/O Configuration  Serial Port Enable or disable the serial port. Default is “Enabled”.  Change Settings Set the mode of serial port devices. Default is the standard serial port mode. ...
  • Page 44: Figure 4.6 Super I/O Configuration

    4.2.2.3 SH3114 Super IO Configuration Figure 4.6 Super I/O configuration  Serial Port1/2/60 This option configures serial port 1/2 base addresses and IRQ, as well as RS- 232/422/485 mode. Serial Port 3 ~ 10 RS-232/422/485 mode configurations are decided by jumper setting. ...
  • Page 45  Serial Port Enable or disable the serial port. Default is “Enabled”.  Serial Port Mode Configure serial port mode. Default is “RS232”. If it’s “RS485”, the auto flow control option will be enabled and the default is “Disabled”.  Change settings Change IO address and IRQ settings.
  • Page 46: Figure 4.7 Current System Temperature And Voltage

    4.2.2.4 Hardware Monitor Figure 4.7 Current System Temperature and Voltage ITA-1711 User Manual...
  • Page 47: Figure 4.8 Cpu Configuration

    4.2.2.5 CPU Configuration Figure 4.8 CPU Configuration  Socket 0 CPU Information This item allows users to check CPU specifications.  Limit CPUID Maximum This item allows users to configure the maximum of CPUID limit value.  Execute-Disable Bit This item allows users to enable or disable Execute Disable Bit Feature. The default setting is “Enabled”.
  • Page 48: Figure 4.9 Ide Configuration

    4.2.2.6 IDE Configuration Figure 4.9 IDE configuration  Serial-ATA Default setting is “Enabled”, which enables all SATA resources.  SATA Test Mode Default setting is “Enabled”, which enables SATA signal testing mode.  SATA Speed Support Default setting is “Gen2”. Select “Gen1” or “Gen2” to change SATA transferring rate.
  • Page 49: Figure 4.10Usb Configuration

    4.2.2.7 USB Configuration Figure 4.10 USB configuration  Legacy USB Support Enable legacy USB support. Default setting is “Enabled”.  EHCI Hand-Off Enable the operation system without EHCI Hand-off.  XHCI Hand-0ff Enable the operation system without XHCI Hand-off.  USB MAass Storage Driver Support Default setting is “Enabled”.
  • Page 50: Advanced Chipset Settings

    4.2.3 Advanced Chipset Settings 4.2.3.1 North Bridge Chipset Configuration  Intel IGD configuration – Intergrated Graphics Device Enable internal display device. Default setting is “Enabled”. – IGD Turbo Enable Enable IGD turbo function. Default setting is “Enabled”. – GFX Boost Enable GFX boost function.
  • Page 51 – DP 1 LVDS Panel Type Configure LVDS display resolution of DP1 interface. – DP 2 LVDS Panel Type Configure LVDS display resolution of DP2 interface. 4.2.3.2 South Bridge Chipset Configuration  Azalia HD Audio – LPE Audio Support Configure LPE audio mode. Default setting is “Disabled”. –...
  • Page 52 Set the speed of PCIe interface. Default setting is “Auto”. – Extra Bus Reserved Set the amount of reserved extra bus. Default value is “1”. – Reserved Memory Set the range of reserved memory. Default value is “10”. – Reserved Memory Alignment Set the digit of reserved memory alignment.
  • Page 53: Security Setup

    4.2.4 Security Setup Figure 4.11 Password Configuration Select Security Setup from the ITA-1711 Setup main BIOS setup menu. All Security Setup options, such as password protection and virus protection are described in this section. To access the sub menu for the following items, select the item and press <Enter>: ...
  • Page 54: Boot Setup

    4.2.5 Boot Setup Figure 4.12 Boot Configuration  Setup Prompt Timeout Set the timeout time of setup prompt. Default setting is “1s”.  Quiet Boot If it’s set to “Disabled”, the BIOS will display normal POST information. If it’s “Enabled”, the OEM icon rather than POST information will be shown. ...
  • Page 55: Save And Exit

    4.2.6 Save and Exit  Save Changes and Exit Save settings and exit.  Discard Changes and Exit Discard changes and exit.  Save Changes and Reset Save settings and reset.  Discard Changes and Reset Discard changes and reset. ...
  • Page 56 ITA-1711 User Manual...
  • Page 57: Driver Installation

    Chapter Driver Installation This chapter describes how to Install drivers.
  • Page 58: Introduction

    Introduction Advantech offers a complete range of Device Driver and software supports for Win- dows programming developers. You can apply the Windows Device Drivers to the most popular Windows Programming tools, such as Visual C++, Visual Basic, Bor- land C++ Builder and Borland Delphi.
  • Page 59: Chipset Windows Driver Setup

    5.2.2 VGA Windows Driver Setup Insert the driver CD into your system’s CD-ROM drive. You can see the driver folder of ITA-1711 series. Navigate to the “01_VGA” folder and click “Setup.exe” to com- plete driver installation. ITA-1711 User Manual...
  • Page 60: Lan Windows Driver Setup

    5.2.3 LAN Windows Driver Setup Insert the driver CD into your system’s CD-ROM drive. You can see the driver folder of ITA-1711 series. Navigate to the “02_LAN” folder and click “Autorun.exe” to com- plete driver installation. 5.2.4 AUDIO Windows Driver Setup Insert the driver CD into your system’s CD-ROM drive.
  • Page 61: Gpio Programming Guide

    Chapter GPIO Programming Guide This chapter introduces GPIO pro- gramming Guide.
  • Page 62: Ita-1711 Digital Dio Definition

    ITA-1711 Digital DIO Definition See Section 2.4.8. Configuration Sequence ITA-1711’s on-board GPIO with LPC bus operates by Lattice CPLD. The configuration and access to CPLD GPIO IC is completed by IO Space accessing to the system. Mapping between GPIO IO Space and corresponding GPIO pins: Port GPO : IO 0xC10~0xC12 (bit0-bit23) 0xC10:bit0~bit7 GPO(1~8) 0xC11:bit0~bit7 GPO(9~16)
  • Page 63 Note! Please examine the current BIOS version. If it is X006 version or earlier, please open IO decode manually. The opening method is as follows: Use Adu.exe in DOS or RW in XP. The following operation takes DOS as an example. Run Adu, select PCI menu and find ISA Bridge line, then press “Enter”...
  • Page 64 ITA-1711 User Manual...
  • Page 65: Appendix A Programming The Watchdog Timer

    Appendix Programming the Watchdog Timer...
  • Page 66: Watchdog Timer Overview

    The ITA-1711's watchdog timer can be used to monitor system software operation and take corrective action if the software fails to function within the programmed period. This section describes the operation of the watchdog timer and how to pro- gram it. Watchdog Timer Overview The watchdog timer is built into the super I/O controller SMSC SCH3114.
  • Page 67: Program Examples

    Program Examples Enable watchdog timer and set 10 sec. as timeout interval Mov dx,A65h ; Select register 65h, watchdog timer I/O port address A00h+ register shifts 65h Mov al,80h ; Set second as counting unit Out dx,al Mov dx,A66h ; Select register 66h, watchdog timer I/O port address A00h+ register shift 66h Mov al,10 ;...
