Advantech ITA-168 Series Startup Manual

ITA-168/178 Series Fanless Compact Embedded
IPC with Intel Celeron J6412 CPU
Startup Manual
Packing List
Before you begin installing your IPC, please make sure that
the following items have been shipped:
1. 1× ITA-168/178 series IPC
2. 1× Accessory box
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1: For more information about ITA-168/178 prod-
ucts, please visit Advantech's official website.
Specifications
Standard Functions
• Chip and chipset: Intel Celeron processor J6412
• BIOS: AMI SPI 64 MB Flash
• Memory: Onboard 8GB DDR4 memory, expandable
through SO-DIMM slot, up to 32GB (ITA-168-L0A1 with-
out onboard memory)
• Display: Intel® UHD Graphics for 10th Gen Intel®
Processors
• Storage: Supports 1 x mSATA slot and 2 × SATA which
support 2.5" SSD
• Expansion slot: Supports up to 2 x Mini PCIe slot
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the ITA-168/178 Series.
Part No. 2041016810
Print in China
1st Edition
November 2015
Specifications
System Specifications
• Ethernet: 4 x 100/1000/2500M Ethernet (ITA-168-L0A1
with 2)
• USB: 2 × USB3.0, 6 × USB2.0
• Display:
- ITA-168 supports single HDMI, up to 3840*2160@30Hz,
- ITA-178 supports triple independent displays by dual
VGA+LVDS, VGA resolution up to 1920*1200@60Hz
• Serial port:
- ITA-168 supports 6 serial ports, two of which support
RS-232/422/485 switching
- ITA-178 supports 14 serial ports, six of which support
RS-232/422/485 switching
• Audio:
- ITA-168-00A1: 1 x Speaker out (with amplifier),
1 × Line in
- ITA-168-L0A1 & ITA-178: 1 x Speaker out (without
amplifier), 1 × Line in
Mechanical and Environment
• Dimensions (W x H x D):
- ITA-168: 200*60*150 mm
- ITA-178: 200*100*150 mm
• Voltage input: DC 9 to 36V wide range input (12V DC
input for ITA-168-L0A1)
• Working temperature: -25~60
• Weight:
- ITA-168: 3.17kg
- ITA-178: 3.86kg
Jumpers
Jumper Setting
The board has a number of jumpers that allow you to con-
figure your system to suit your application.
The table below lists the function of each of the jumpers.
Jumper Setting
Name Function
JLVDS1 LVDS voltage setting
VCCGPIO1 GPIO voltage setting
JSETCOM 1~X COM mode setting
PSON1 Power on mode setting
ITA-168/178 Startup Manual 1
°C
