ITA-2231 Intel® 6th Generation Core™ i Processor 2U
Fanless System with 3 ITA-EM Slots
Startup Manual
Packing List
Before installing the board, please ensure that the following
items have been shipped:
1. 1 x ITA-2231 IPC
2. 1 x ITA-2231 Accessory Box
3. 1 x ITA-2231 Warranty Card
If any of the above items are missing or damaged, please
contact your distributor or sales representative immediately.
Note: Adobe Acrobat Reader is required to view PDF
files. Adobe Acrobat Reader can be downloaded at www.
adobe.com/Prodindex/acrobat/readstep2.html (Acrobat is a
trademark of Adobe).
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.tw/support
This manual is for the ITA-2231 Series.
Part No. 2001223112
Printed in China
Specifications
Standard Functions
• Chip & Chipset: Intel Core™ i7-6822EQ processor and
QM170 Chipset
• BIOS: AMI SPI 128 Mb
• Memory: Onboard 16GB DDR4-2133
• Display:
Intel HD530, frequency 350 MHz,
Shared system memory up to 512MB SDRAM
• Dual display mode:
Display resolution up to 1920 x 1200 @ 60 Hz,
1 x DVI-I + 1 x DVI-D
• Storage:
- 1 x 3.5"HDD or 2 x 2.5"HDD
- 1 x 2260 size M.2 (only supports SATA interface)
• Expansion slot:
- 3 x ITA-EM slot
- 1 x PCI104
- 1 x Mini PCIe slot
System Specifications
• Ethernet: 2 x 10/100/1000M Ethernet
• USB: 4 USB 3.0, 3 USB 2.0
• DVI: 1 x DVI-D, 1 x DVI-I
• Serial port: 2 DB9 ports, supports RS-232/422/485
• Audio: 1 Speaker Out (supports 4W Amp),1 Mic-in
• ITA-EM module (optional): ITA-EM modules can be
optionally inserted into three ITA-EM slots to make up to
24 additional LAN or COM ports for expansion needs.
Mechanical and Environment
• Dimensions (W x H x D): 427 x 88 x 325 mm
• Voltage input: AC 100-240 or DC 110V
• Working temperature:
- 0 -40 °C (32 ~ 104 °F , with HDD)
- 25 - 60 °C (-13 ~ 140 °F, with SSD)
• Weight:
- Single power: 7.7 kg
- Dual power: 8 kg
3rd Edition
April 2018
ITA-2231 Startup Manual 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ITA-2231 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech ITA-2231

Summary of Contents for Advantech ITA-2231

  • Page 1 ITA-2231 Intel® 6th Generation Core™ i Processor 2U Fanless System with 3 ITA-EM Slots Startup Manual Packing List Specifications Before installing the board, please ensure that the following Standard Functions items have been shipped: • Chip & Chipset: Intel Core™ i7-6822EQ processor and 1.

  • Page 2: Jumpers And Connectors

    Clear CMOS setting RS232 RS422 RS485 *Default setting Pins Signal Name Signal Name Signal Name DATA- Default Clear CMOS DATA+ PSON1: Power On Mode Setting Pins Setting AT mode ATX mode* *Default setting AT Mode ATX Mode 2 ITA-2231 Startup Manual...
  • Page 3 DDC Clock Ground AUD_GND LOUT_R DDC Data DVI Detect MIC_R Analog Vertical T.M.D.S. Clock+ Sync T.M.D.S. Data1- T.M.D.S. Clock- T.M.D.S. Data1+ Analog Red Ground Analog Green Ground Analog Blue Analog Horizontal Ground Sync +5V Power Ground Ground ITA-2231 Startup Manual 3...
  • Page 4 ITA-EM slot on the backplane. c. Check whether the rivet of the module is fully inserted. LED Status: 3. Fix the ITA-EM Module to ITA-2231 system with screws 1000M Green (top left LED) on the front and rear side.

  • Page 5: Safety Instructions

    The sound pressure level at the operator’s position does not exceed 70 dB (A) as per the IEC 704-1:1982 specifications. DISCLAIMER: These instructions are provided according to the IEC 704-1 standard. Advantech assumes no responsibil- ity for the accuracy of this manual. ITA-2231 Startup Manual 5...
  • Page 6 Board Jumper Setting Drawing Mainboard Jumpers and Connectors Location USB7_8 M.2 Slot LPT1 JCMOS1 GPIO1 SATA3.0 SATA PWR PSON1 Mini PCIe Slot Backplane Jumpers and Connectors Location VIO1 PCI104 ITA-EM Slot1 ITA-EM Slot2 ITA-EM Slot3 6 ITA-2231 Startup Manual...

  • Page 7: System Diagram

    USB 2.0 x 3, ITA-EM Module Interface USB 3.0 x 2 Alarm LED PS/2 DVI-D ( i219 port w/iAMT function） Power Button COM LED Reset Button Audio Power Supply Reset Button Alarm/HDD LED DVI-I HDD LED LAN LED ITA-2231 Startup Manual 7...
