(C) Auto_Run Mode for Single Cycle
The speed of final step will be held to run.
For example :
Sn-44 ＝ 3
Sn-45~48 = 1 (FWD) Sn-49~60 ＝ 0
An-01∼16, Bn-21∼36 ： same setting as the example (A)
•Sn-44 = 1~3 : If the inverter stops and re-starts again, it will continue running from
= 4~6 : If the inverter stops and re-starts again, it will begin a new cycle and
Sn-44
Run
Command
Output
Frequency
•ACC/DEC time follow the setting of Bn-01，Bn-02 in Auto_Run Mode.
•If the setting values of Bn-21∼Bn-36 are all zero, the Auto_Run Mode is disabled.

(46) Applied Torque Load (Sn-61)

•Select either the constant torque load (Sn-61=0) or varied torque load (Sn-61=1).
The inverter will automatically choose the proper V/F pattern and change the
inverter overload protection curve. (See page 69 for 'INVERTER CAPACITY
SELECTION').
Freq.
50 Hz
30 Hz
An-01
15 Hz
20s
(Bn-21) (Bn-22) (Bn-23) (Bn-24)
the unfinished step, according to the setting of Sn-44.
continue running according to the setting of Sn-44.
1~3
run stop run
Continue running from
unfinished step
An-03
An-02
25s 30s
Run
Command
Output
Frequency
time
97
An-04 (20Hz)
40s
4~6
run stop
begin a new cycle
run
time
