Back Panel Ports

The back panel has the following ports:
PS2_MS COM1
PS2_KB VGA Out
Mouse Port: PS2_MS
The mainboard provides a standard PS/2 mouse connector for attaching a
PS/2 mouse. You can plug a PS/2 mouse directly into this connector. The
connector location and pin assignments are as follows.
6
4
2
PS2 Mouse (6-pin female)
Keyboard Port: PS2_KB
The mainboard provides a standard PS/2 keyboard connector for attaching a
PS/2 keyboard. You can plug a PS/2 keyboard directly into this connector.
6
4
2
PS2 Keyboard (6-pin female)
RJ45
USB S-Video
Pin Signal
1 Mouse DATA
5
2 NC
3
3 GND
1
4 VCC
5 Mouse Clock
6 NC
Pin Signal
1 Keyboard DATA Keyboard data
5
2 NC
3
3 GND
1
4 VCC
5 Keyboard Clock Keyboard clock
6 NC
2-7
Cardbus
RCA / SPDIF Line-Out
Description
Mouse data
No connection
Ground
+5V
Mouse clock
No connection
Description
No connection
Ground
+5V
No connection
Installation
CF
Line-In Microphone 1394
