IEEE 1394 Port

The mainboard provides one standard 1394 port. You can
connect any 1394 (Firewire) device to this port.

Serial Port: COM1

The mainboard offers one 9-pin male Serial Port connector COM1. You can
attach a serial mouse or other serial devices directly to these port.
Pin Signal
1 DCD
2 SIN
3 SOUT
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI
Card Slots: PCMCIA, CF
The mainboard comes with an add-on card that provides support for
PCMCIA and CF cards. The CF slot supports both type I and type II. These
slots are accessed on the same side as the ports.
Description
Data Carry Detect
Serial In or Receive Data
Serial Out or Transmit Data
Data Terminal Ready
Ground
Data Set Ready
Request To Send
Clear To Send
Ring Indicate
2-9
Installation
1 5
6 9
9-Pin Serial Port
