15 minutes keeping eyelids open. Seek medical attention. Spillages should be treated with cold water and soap to help reduce risk of staining skin or clothing. Importer to the EU/authorised representative Oki Europe Limited (trading as Oki Printing Solutions) Blays House Wick Road Egham...
Contents Preface......................x-2 Emergency first aid ..................x-3 Importer to the EU/authorised representative ..........x-3 Environmental information ................x-3 1 Introduction ....................1-1 Getting Acquainted with Your Machine ............1-2 Space Requirements................... 1-2 Part Names ....................1-5 Front View..................... 1-5 Rear View .....................
Page 6
2 Control Panel and Configuration Menu ............2-1 About the Control Panel ................2-2 Control Panel Indicators and Keys.............. 2-2 Display Indications ..................2-5 Main Screen (Copy Mode) ..............2-5 Main Screen (Scan Mode) ..............2-7 Main Screen (Fax Mode) ..............2-10 Print Screen ..................
Page 7
Tray 2 ......................3-14 Loading Plain Paper................3-14 About Duplex Printing ................. 3-17 How do I autoduplex? ................3-17 Output Tray ....................3-19 Media Storage ....................3-20 Original Media ....................3-21 Specifications .................... 3-21 Documents that can be placed on the original glass ......3-21 Documents that can be loaded into the ADF ........
Page 8
Poster Copying ................... 5-10 Setting Duplex (Double-Sided) Copying ........... 5-11 Duplex (Double-Sided) Copying From the ADF........5-11 Duplex (Double-Sided) Copying From the Original Glass ....5-12 Setting Collated (Sort) Copying..............5-13 Collated (Sort) Copying From the ADF ..........5-13 Collated (Sort) Copying From the Original Glass........ 5-13 6 Using the Scanner ..................
Page 9
Deleting a Queued Transmission Job ............6-29 7 Replacing Consumables ................7-1 Replacing Consumables ................7-2 About Toner Cartridges................7-2 Replacing a Toner Cartridge ............... 7-4 Replacing All Toner Cartridges at the Same Time........7-10 Replacing the Imaging Cartridge............... 7-11 Replacing the Fuser Unit................
Page 10
Entering Names ..................A-7 Entering E-mail Addresses ..............A-7 Changing Input Mode..................A-8 Inputting Example ..................A-8 Correcting Text and Input Precautions............A-9 Our Concern for Environmental Protection ..........A-10 What is an ENERGY STAR product? ..........A-10 Index ......................... I-1 Oki contact details ..................I-5 x-10 Contents...
Getting Acquainted with Your Machine Space Requirements To ensure easy operation, consumable replacement and maintenance, adhere to the recommended space requirements detailed below. 505 mm (19.9") 405 mm (15.9") 100 mm (3.9") Front View 160 mm 405 mm (15.9") (6.3") 100 mm 100 mm (3.9")
Page 13
160 mm 157 mm 430 mm (16.9") (6.3") (6.2") 100 mm 100 mm 947 mm (37.3") (3.9") (3.9") Side View with Options (when Tray 2 and the duplex option are installed) The option appears shaded in the above illustrations. Getting Acquainted with Your Machine...
Page 14
160 mm 157 mm (6.3") (6.2") 430 mm (16.9") 100 mm 100 mm (3.9") (3.9") 947 mm (37.3") Side View with Options (when the attachment and duplex option are installed) The option appears shaded in the above illustrations. Getting Acquainted with Your Machine...
Part Names The following drawings illustrate the parts of your machine referred to throughout this guide, so please take some time to become familiar with them. Front View 1–Control Panel 2–Automatic document Feeder (ADF) 2–a:ADF feed cover 2–b:Document guide 2–c:Document feed tray 2–d:Document output tray 2–e:Document stopper The ADF may appear as...
11—Fuser unit 12—Fuser separator levers 13—Fuser cover lever 14—Imaging cartridge 15—Toner cartridge 16—Front cover Rear View 1–Power switch 2–Power connection 3–TEL (telephone) jack 4–LINE (telephone line) jack 5–USB port 6–10Base-T/100Base-TX (IEEE 802.3) Ethernet Interface port Getting Acquainted with Your Machine...
Front View with Options (when Tray 2 is installed) 1—Lower feeder unit (Tray 2) (when Tray 2 and duplex option are installed) 1—Duplex option 2—Lower feeder unit (Tray 2) (when the attachment and duplex option are installed) 1—Duplex option 2—Attachment Getting Acquainted with Your Machine...
Rear View with Options (When Tray 2 is installed) 1—Lower feeder unit (Tray 2) 2—Locking pin (when Tray 2 and duplex option are installed) 1—Duplex option 2—Lower feeder unit (Tray 2) Getting Acquainted with Your Machine...
Page 19
(when the attachment and duplex option are installed) 1—Duplex option 2—Attachment Getting Acquainted with Your Machine...
CD Contents Printer Drivers Drivers Use/Benefit Installers This software provides easy installa- tion of drivers and other software for your MC160n and also for changing the display and reporting language used. (Default is English.) Windows Vista/XP/Server 2003/ These drivers give you access to all of Server 2008/2000 the printer features.
Page 21
For details on the installation of the drivers for Windows and Macin- tosh, refer to the Installation CD. Windows TWAIN driver does not correspond to 64-bit applications though it corresponds to 32-bit applications on 64-bit OS. For exam- ple, it will work in a 32-bit application running on a Windows 64-bit operating system but it will not work in a 64-bit application.
Template Manager Lite 3.0 This software helps you to quickly generate labels for mailing, CDs/ DVDs, etc. Lite version can be upgraded to Stan- dard via registration on the Oki web- site. OkiLPR Network software for printing via TCP/ IP LAN.
System Requirements Personal computer For Windows – Pentium II: 400MHz or higher (Pentium 3: 500MHz or higher is recom- mended) For Macintosh – PowerPC G3 or later (G4 or later is recommended) – Intel processor Operating System – Microsoft Windows Vista Home Basic/Home Premium/Ultimate/Busi- ness/Enterprise, Windows Vista Home Basic/Home Premium/ Ulti- mate/Business/Enterprise x64 Edition, Windows XP Home Edition/ Professional (Service Pack 2 or later), Windows XP Professional x64...
Page 24
1-14 Getting Acquainted with Your Machine...
About the Control Panel 7 6 8 7 Control Panel Indicators and Keys No. Name Function Displays the information registered in the favorite DDRESS BOOK list, speed dial destinations and group dial destina- tions. For details, refer to the Facsimile User’s Guide on the CD.
Page 27
No. Name Function / keys Moves up and down through menus, options, or choices. / keys Moves left and right through menus, options, or choices. Press to select the setting that is currently displayed. NTER indicator Indicates an error condition. RROR Clears the specified number of copies and entered text.
Page 28
No. Name Function indicator Lights up in blue when copying and fax transmis- TART sions are possible. Lights up in orange when copying and fax transmis- sions are not possible, for example, during warm-up or if an error has occurred. Starts color copying, scanning or faxing.
Display Indications Main Screen (Copy Mode) No. Indication Description Copy settings Allows the current settings to be checked and the various settings to be changed. For details, refer to “Copy settings” on page 2-6. Status Depending on the situation, the machine status or an error message may appear.
Page 30
Copy settings Press / Press / No. Indication Description Media tray Indicates the media tray that is selected. For details on selecting the media tray, refer to “Selecting the Media Tray” on page 5-5. Zoom ratio Indicates the zoom ratio that is specified. For details on specifying the zoom ratio, refer to “Specifying the Zoom Ratio”...
No. Indication Description Double-sided This appears only when the duplex option has been copying installed. Indicates whether or not double-sided copying is selected. If double-sided copying is selected, the specified binding position is indicated. For details on selecting double-sided copying, refer to “Setting Duplex (Double-Sided) Copying”...
Page 32
Scan settings Press / Press / No. Indication Description Data format Indicates the data format that is selected. For details on selecting the data format, refer to “Selecting the Data Format” on page 6-26. Scan quality Indicates the scan quality that is selected. For details on selecting the scan quality, refer to “Selecting the Scan Quality Setting”...
Page 33
No. Indication Description Scan color Indicates the scan color that is selected. For details on selecting the scan color, refer to “Setting the Scan Color” on page 6-28. Select this menu item to specify the subject. For SUBJECT details on specifying the subject, refer to “Specifying the Subject”...
Main Screen (Fax Mode) No. Indication Description Time Indicates the current time configured in ADMIN. MANAGEMENT/USER SETTING/DATE&TIME the UTILITY menu. Available mem- Indicates the percentage of memory available for fax operations. Fax settings Allows the current settings to be checked and the various settings to be changed.
Page 35
Fax settings Press / Press / , Press / , No. Indication Description Fax quality Indicates the fax quality that is selected. For details on selecting the fax quality, refer to the Facsimile User’s Guide on the CD. Fax destination Indicates the specified fax destination.
Page 36
No. Indication Description Select this menu item to specify the time when the TIMER TX fax is to be sent. For details, refer to the Facsimile User’s Guide on the CD. Transmission Indicates the fax transmission mode that is selected. mode For details on selecting the transmission mode, refer to the Facsimile User’s Guide on the CD.
Print Screen When a print job is received, appears in the status PRINTER: Printing section of the main screen. To display the print screen (as shown below), press the key while is displayed. PRINTER: Printing To cancel printing, press the S key when the print screen appears.
Checking the Machine Status and Settings PRINTER MODE Menu With the main screen displayed, press the key to display the PRINTER MODE screen. From this menu, a general estimate of the amount of toner remaining in the toner cartridges can be viewed, and the printer operation mode can be switched.
TONER REMAINING A general estimate of the amount of toner remaining in the toner cartridges can be viewed. If the E key is held down for at least 2 seconds while the screen NTER described above is displayed, the configuration page will be printed. T/C CHANGE Switches the machine to the REPLACE MODE.
Page 40
Switches the machine to the P/H CLEAN P/H CLEAN MODE MODE. P/H CLEAN MODE is a mode that allows the user to clean the print head window more eas- ily. The print head window is not cleaned auto- matically. For details on cleaning the print head window, refer to “Clearing the Print Head Window”...
REPORT/STATUS Menu To display the REPORT/STATUS screen, select in the REPORT/STATUS main screen, and then press the E key. From this menu, the total num- NTER ber of pages printed by this machine and the results of fax transmissions/ receptions can be viewed. In addition, the reports can be printed. The REPORT/STATUS menu is structured as shown below.
SUPPLIES STATUS The remaining amount of toner in the toner cartridges and the remaining ser- vice life of the imaging cartridges can be displayed as a percentage. Displays the remaining amount of toner in the C TONER cyan (C) toner cartridge as a percentage. Displays the remaining amount of toner in the M TONER magenta (M) toner cartridge as a percentage.
Page 43
Prints a list of the destinations programmed for SPEED DIAL LIST speed dialing. For details, refer to the Facsimile User’s Guide on the CD. Prints a list of the one-touch dialing groups. For GROUP DIAL LIST details, refer to the Facsimile User’s Guide on the CD.
Configuration Menu Overview To display the settings menu for this machine, select in the main UTILITY screen, and then press the E key. From the UTILITY menu, settings for NTER the various machine functions can be changed. Machine configuration settings can also be viewed over your network using a web browser.
MACHINE SETTING Menu MACHINE SETTING AUTO PANEL RESET ENERGY SAVE MODE LCD CONTRAST KEY SPEED TIME TO START INTERVAL LANGUAGE BUZZER VOLUME INITIAL MODE TONER OUT STOP TONER LOW AUTO CONTINUE IMAGE REFRESH 2-22 Configuration Menu Overview...
Page 47
DUPLEX SPEED CALIBRATION This appears only when the duplex option has been installed. Manufacturer’s default settings appear in bold. Setting AUTO PANEL RESET 30sec 2min 1min 3min 4min 5min Specify the length of time until all settings that have not been programmed, such as the num- ber of copies, are cleared and return to their default settings when no operation is performed.
Page 48
Setting LANGUAGE ENGLISH FRENCH GERMAN ITALIAN SPANISH PORTU- GUESE RUSSIAN CZECH HUNGARIAN POLISH Select the language of the menus and mes- sages that appear in the message window. Setting BUZZER VOLUME HIGH Select the volume of the sound produced when a key is pressed and of the alarm that is sounded when an error occurs.
Page 49
Setting DUPLEX SPEED AUTOMATIC SPEED QUALITY Select the print speed for double-sided printing. is selected, the print speed is AUTOMATIC automatically selected. is selected, the print speed has prior- SPEED ity; however, the print quality may decrease. is selected, the print quality has QUALITY priority;...
TRAY1 PAPER SETUP Menu TRAY1 PAPER SETUP Manufacturer’s default settings appear in bold. Media type LETTERHEAD THICK1 THICK2 PLAIN PAPER LABELS Paper size The available paper sizes differ depending on the setting selected as the media type. Setting selected as the Available paper sizes media type PLAIN PAPER...
Page 51
Select the type and size of the media loaded into Tray 1. If CUS- is selected as the paper size, specify TOM(PLAIN) CUSTOM(THICK) settings for separately. LENGTH WIDTH The setting range for mm for , and LENGTH PLAIN PAPER mm for THICK1 THICK2 The default setting is...
ADMIN. MANAGEMENT Menu The ADMIN. MANAGEMENT menu is accessible only by the adminis- trator. To display the settings for this menu, select ADMIN MANAGE- , use the keypad to type in the 6-digit administrator access code MENT (default: 000000), and then press the E key.
Page 53
SNMP SPEED/ DUPLEX E-MAIL SETTING SMTP SENDER NAME E-MAIL ADDRESS DEFAULT SUBJECT SMTP SERVER ADDR. SMTP PORT NO. SMTP TIMEOUT TEXT INSERT POP BEFORE SMTP DISABLE/ENABLE Configuration Menu Overview 2-29...
Page 54
POP3 SERVER ADDR. POP3 PORT NO. POP3 TIMEOUT POP3 ACCOUNT POP3 PASSWORD SMTP AUTH. DISABLE/ENABLE SMTP USER NAME SMTP PASSWORD LDAP SETTING DISABLE/ENABLE LDAP SERVER ADDR. LDAP PORT NO. SSL SETTING SEARCH BASE 2-30 Configuration Menu Overview...
Page 55
ATTRIBUTE SEARCH METHOD LDAP TIMEOUT MAX.SEARCH RESULTS AUTHENTICATION LDAP ACCOUNT LDAP PASSWORD DOMAIN NAME USB SETTING COMM. SETTING TONE/PULSE LINE MONITOR PSTN/PBX TEL/FAX MODE Configuration Menu Overview 2-31...
Page 56
RBT SIGNAL TIME USER SETTING PTT SETTING DATE&TIME DATE FORMAT PRESET ZOOM USER FAX NUMBER USER NAME AUTO REDIAL NUMBER OF REDIAL INTERVAL This menu item appears when ADMIN. MANAGEMENT/NET- is set to WORK SETTING/TCP/IP ENABLE This menu item appears when ADMIN.
Page 57
Manufacturer’s default settings appear in bold. Specify the new administrator access ADMINISTRATOR NO. code. Setting NETWORK TCP/IP DISABLE ENABLE SETTING Select the setting for connecting to this machine through a network. Setting IP ADDR. SET- AUTO SPECIFY TING Set the address of this machine on the network.
Page 58
Setting DNS CONFIG. DISABLE ENABLE Set whether or not the DNS server set- ting is to be specified. is selected, specify DNS ENABLE server addresses (up to three addresses). Setting DHCP DISABLE ENABLE If there is a DHCP server on the net- work, specify whether the IP address and other network information is auto- matically assigned by the DHCP server.
Page 59
Specify the name of the E-mail sender SENDER NAME (up to 20 characters) used for network scanning. The default setting is “OKI-MC160n”. Specify the E-mail address (up to 64 E-MAIL ADDRESS characters) of the E-mail sender used for network scanning.
Page 60
Setting (Default: SMTP TIMEOUT 300 sec 60 sec Select the amount of time (in seconds) until the connection with the SMTP server times out. Setting TEXT INSERT Select whether or not the specified text is inserted into the E-mail message. Setting DIS- DISABLE...
Page 61
Setting SMTP DIS- DISABLE ENABLE AUTH. ABLE/ Select whether or not to enable SMTP ENABLE authentication. Specify the user name (up to 63 charac- SMTP ters) used for SMTP authentication. USER- NAME The default setting is blank. Specify the password (up to 15 charac- SMTP ters) used for SMTP authentication.
Page 62
Setting (Default: MAX.SEARCH RESULTS Specify the maximum number of desti- nations displayed after a search. Setting AUTHENTICATION ANONYMOUS SIMPLE DIGEST-MD5 GSS-SPNEGO Select the authentication method used for logging on to the LDAP server. Specify the account (up to 64 charac- LDAP ACCOUNT ters) used to connect to the LDAP server.
Page 63
Setting LINE MONITOR HIGH Select the volume of the monitoring sound of the transmission signal. Setting PSTN/PBX PSTN Select whether the connected tele- phone wiring is a public switched tele- phone network (PSTN) or a private branch exchange (PBX). For a PBX system, the prefix number (outside line access number or exten- sion number) can be specified.
Page 64
Setting USER PTT SETTING ARGENTINA AUSTRA- SETTING AUSTRIA BEL- GIUM BRAZIL CANADA CHINA CZECH DENMARK EUROPE FINLAND FRANCE GERMANY GREECE HONG KONG HUNGARY IRELAND ITALY JAPAN KOREA MALAYSIA MEXICO THE NETHERLANDS NEW ZEALAND NORWAY PHILIPPINES POLAND PORTUGAL RUSSIA SAUDI ARA- SINGAPORE SLOVAKIA SOUTH...
Page 65
Setting : 00:00-23:59 DATE&TIME TIME (Default: 00:00 : ’00/01/01-’99/12/31 DATE ZONE GMT+12:00-GMT-12:00 (in 30-minute intervals) (Default: GMT+00:00 Use the keypad to specify the current date, time and time zone. Setting DATE FORMAT MM/DD/YY DD/MM/YY YY/MM/DD Select the display format for reports and lists.
Page 66
Setting (Default: INTERVAL 99 min depends on PTT SET- TING Specify the interval between redial attempts. 2-42 Configuration Menu Overview...
COPY SETTING Menu COPY SETTING PAPER PRIORITY QUALITY PRIORITY DENSITY PRIORITY DENSITY LEVEL AUTO MANUAL OUTPUT PRIORITY DUPLEX COPY This appears only when the duplex option has been installed. Manufacturer’s default settings appear in bold. Setting PAPER PRIOR- TRAY1 TRAY2 Specify the paper tray that is normally used.
Page 68
Setting (LIGHT) (DARK) DEN- AUTO SITY Adjust the density of the background color. LEVEL Setting (LIGHT) (DARK) MANUAL Specify the default copy density. Setting OUTPUT PRIOR- NON-SORT SORT Select whether or not to sort copies by sets. Setting DUPLEX COPY LONG EDGE SHORT EDGE Select the default setting for duplex (double-sided)
DIAL REGISTER Menu DIAL REGISTER FAVORITE SPEED DIAL GROUP DIAL Register frequently used fax numbers and e-mail FAVORITE addresses in the favorite list. Instead of being entered manually, fax numbers and e-mail addresses can simply be recalled to ensure that destination information is registered correctly.
FAX TX OPERATION Menu FAX TX OPERATION DENSITY LEVEL QUALITY PRIORITY DEFAULT TX HEADER Manufacturer’s default settings appear in bold. Setting (LIGHT) (DARK) DENSITY LEVEL Specify the density for scanning a document. Setting QUALITY PRI- STD/TEXT FINE/TEXT S-FINE/ ORITY TEXT STD/PHOTO FINE/PHOTO S-FINE/PHOTO...
Page 71
Setting DEFAULT TX MEMORY TX DIRECT TX Select the desired method for sending documents. : With this method, the fax transmission MEMORY TX starts after the entire document is scanned and stored in the memory. The total number of pages is automati- cally printed with the page number in the header.
FAX RX OPERATION Menu FAX RX OPERATION MEMORY RX MODE NO. of RINGS REDUCTION RX RX PRINT RX MODE FORWARD FOOTER SELECT TRAY Manufacturer’s default settings appear in bold. Setting MEMORY RX MODE Select whether to allow ( ) memory reception or not ).
Page 73
Setting (Default: depends on No. of RINGS SETTING Enter the number of rings (between ) until the machine automatically begins receiving the fax when an external telephone is connected. in the PTT SETTING USER SETTING menu is set to , this setting NEW ZEALAND range changes to Setting...
Page 74
Setting FORWARD ON(PRINT) Select whether or not to forward received fax docu- ments. : Select this setting to not forward the document. : Select this setting to forward the received fax doc- ument to the specified fax number or e-mail address. : Select this setting to forward the ON(PRINT) received fax document to the specified fax number or...
REPORTING Menu REPORTING ACTIVITY REPORT TX RESULT REPORT RX RESULT REPORT Manufacturer’s default settings appear in bold. Setting ACTIVITY REPORT After every 60 transmissions/receptions, a report can be printed to show the results of the transmissions/ receptions. Select whether the report is printed auto- matically when the 60th transmission/reception is reached.
Page 76
Setting RX RESULT ON(ERROR) REPORT Select whether the report showing the result of a reception is printed automatically after the reception is finished. : Prints the report after each reception. : Prints the report after a reception only if ON(ERROR) an error occurred.
SCAN SETTING Menu SCAN SETTING RESOLUTION IMAGE FORMAT CODING METHOD FILE SIZE QUALITY PRIORITY DENSITY LEVEL Manufacturer’s default settings appear in bold. Setting RESOLUTION 150×150dpi 300×300dpi Select the default scanning resolution for scan to E-mail operations. Setting IMAGE FORMAT TIFF JPEG Select the default format for saving files with scan to E-mail operations.
Page 78
Setting CODING METHOD Select the default compression method for scan to E-mail operations. The compression ratio for these methods increases in the following order: > > These settings are available only if BW Only was selected for the color setting during the e-mail transmission.
Print Media Specifications Media Media Size Tray* Duplex Copy Print Inch Millimeter 8.2 x 11.7 210.0 x 297.0 1/2 7.2 x 10.1 182.0 x 257.0 1 5.9 x 8.3 148.0 x 210.0 1 Legal 14 8.5 x 14.0 215.9 x 355.6 1 (ADF) Letter 8.5 x 11.0...
Types Before purchasing a large quantity of special media, do a trial print with the same media and check the print quality. Keep media on a flat, level surface in its original wrapper until it is time to load it. Plain Paper (Recycled Paper) Capacity Tray 1...
Dusty Wet (or damp) Keep media between 15% and 85% relative humidity. Toner does not adhere well to moist or wet media. Layered Adhesive Folded, creased, curled, embossed, warped, or wrinkled Perforated, three-hole punched, or torn Too slick, too coarse, or too textured Different in texture (roughness) on the front and back Too thin or too thick Stuck together with static electricity...
Weight Thick Stock 1: 91 to 163 g/m (25 to 43.5 lb bond) Thick Stock 2: 164 to 209 g/m (43.6 to 55.6 lb bond) Duplexing Not supported DO NOT use thick stock that is Mixed with any other media in the trays (as this will cause media misfeed- ing) Label A sheet of labels consists of a face sheet (the printing surface), adhesive, and...
Are precut or perforated OK to use Do not use Shiny backed paper Full-page labels (uncut) Letterhead You can print continuously with letterhead. However, this could affect the media feed, depending on the media quality and printing environment. If problems occur, stop the continuous printing and print one sheet at a time. Try printing your data on a sheet of plain paper first to check placement.
Printable Area The printable area on all media sizes is up to 4.0 mm (0.157") from the edges of the media. Each media size has a specific print- Printable able area (the maximum area on which Area the machine can print clearly and with- out distortion).
Loading Media How do I load media? Take off the top and bottom sheets of a ream of paper. Holding a stack of approx- imately 200 sheets at a time, fan the stack to prevent static buildup before inserting it in a tray. Note Although this machine was designed for printing on a wide range of media types, it is not intended to print exclusively on a single media...
Page 87
Slide the media guides to pro- vide more space between them. Load the paper face up in the tray. Do not load paper above mark. Up to 200 sheets (80 g/m [21 lb]) of plain paper can be loaded into the tray at one time.
Page 88
Slide the media guides against the edges of the paper. Install the dust cover. Select in the menu, and then select TRAY1 PAPER SETUP UTILITY the settings for the size and type of paper that is loaded. See also “Print Media”...
Other Media When loading media other than plain paper, set the media mode (Label, Let- terhead, Thick Stock 1, or Thick Stock 2) in the driver for optimum print qual- ity. Loading Label Sheets/Letterheads and Thick Stock Remove the dust cover. Remove any media in the tray.
Page 90
Load the media face up in the tray. Up to 50 sheets can be loaded into the tray at one time. Slide the media guides against the edges of the media. Install the dust cover. 3-12 Loading Media...
Page 91
Select in the menu, and then select TRAY1 PAPER SETUP UTILITY the settings for the size and type of media that is loaded. See also “Print Media” on page 3-2. Loading Media 3-13...
Tray 2 Only Letter/A4 plain paper can be loaded in Tray 2. Loading Plain Paper Pull out Tray 2 as far as possi- ble. Lift up Tray 2 to remove it. 3-14 Loading Media...
Page 93
Remove the lid from Tray 2. Press down the media pressure plate to lock it into place. Load the paper face up in the tray. Do not load above the 100% line. Up to 500 sheets (80 g/m [21 lb]) of plain paper can be loaded into the tray at one time.
Page 94
Reattach the lid to Tray 2. Reinsert Tray 2 into the machine. 3-16 Loading Media...
About Duplex Printing Duplex (double-sided) printing can be performed when the duplex option has been installed on this machine. For details on installing the duplex option, refer to “Duplex Option” on page 10-7. If the paper has low opacity (high translucency), then the printed data from one side of the page will show through to the other side.
Page 96
In addition, if “Combination” has been set to “Booklet”, autoduplex printing is performed. The following Order settings are available when “Booklet” is selected. If “Left Binding” is selected, the pages can be folded as a left-bound booklet. If “Right Binding” is selected, the pages can be folded as a right-bound booklet.
Output Tray The printed media is fed out facing down into the output tray below the control panel. This tray has a capacity of approximately 100 sheets (A4/Letter) of 80 paper or equivalent. If the media is stacked too high in the output tray, your machine may experience media misfeeds, excessive media curl, or static buildup.
Media Storage Keep media on a flat, level surface in its original wrapper until it is time to load it. Media that has been stored for a long time out of its packaging may dry up too much and cause misfeeding. If media has been removed from its wrapper, place it in its original pack- aging and store in a cool, dark place on a level surface.
Original Media Specifications Documents that can be placed on the original glass The following types of documents can be placed on the original glass. Document type Sheets or books Maximum document size A4 or Letter Maximum weight 3 kg (6.6 lb) Observe the following precautions when placing a document on the original glass.
Page 100
Documents with pages that have had cutouts removed or are cutouts Label sheets Offset printing masters Documents with binder holes 3-22 Original Media...
Loading a Document to be Copied Placing a document on the original glass Lift to open the ADF cover. Position the document on the original glass. Document Align the document with the arrow on the left side toward the rear of the machine.
Gently close the ADF cover. Take care not to trap your fin- gers when closing the ADF cover. Loading a document into the ADF Put the document into the ADF document feed tray face up. Document Before loading a docu- ment into the ADF, check that no document pages remain on the original...
Page 103
Adjust the document guides to the document size. For details on copying the loaded document, refer to “Using the Copier” on page 5-1. For details on scanning, refer to “Using the Scanner” on page 6-1. Loading a Document to be Copied 3-25...
Port by default.) Displaying Printer Driver Settings Windows Vista From the Start menu, select Control Panel, and then click Hardware and Sound to select Printers. Right-click the OKI-MC160n printer icon then select Printing Prefer- ences. Selecting Printer Driver Options/Defaults (for Windows)
Windows XP/Server 2003 From the start menu, select Printers and Faxes to display the Printers and Faxes directory. OKI-MC160n printer icon and select Printing Preferences. Windows 2000 From the Start menu, select Settings, and then click Printers to display the Printers directory.
Printer Driver Settings Common Buttons The buttons described below appear on each tab. Click to exit the Properties dialog box, saving any changes made. Cancel Click to exit the Properties dialog box without saving any changes made. Apply Click to save all changes without exiting the Properties dialog box. Help Click to view the help.
Watermark View Click the button to display a preview of the watermark. When this button is clicked, it changes to the Printer View button. This button appears only when the Watermark tab is selected. Quality View Click the button to display a sample of the settings selected in the Quality tab. When this button is clicked, it changes to the Printer View button.
Layout Tab The Layout Tab allows you to Print several pages of a document on the same page (N-up printing) Specify booklet printing (when the duplex option is installed) Print a single copy for enlargement and print several pages Rotate the print image 180 degrees Specify Double-Sided printing (when the duplex option is installed) Specify image shift settings Overlay Tab...
Adjust the contrast (Contrast) Control the darkness of an image (Brightness) Adjust the saturation of printed image (Saturation) Adjust the sharpness of the printed image (Sharpness) Version Tab The Version Tab allows you to view information about the printer driver. Printer Driver Settings...
Making Basic Copies This section contains descriptions of the basic copy operation procedure and the functions that are frequently used when making copies, such as specify- ing the zoom ratio and the copy density. Before making copies, check that the C key is lit up in green.
Press the C key. Specify the desired copy settings. For details on specifying the copy mode and the copy density, refer to “Specifying the Copy Quality Setting” on page 5-3. For details on specifying the zoom ratio, refer to “Specifying the Zoom Ratio”...
Specifying the Copy Density In the main screen (Copy mode), press the key to select the current copy quality setting, and then press the E key. NTER Press the key to select , and then press the E key. DENSITY NTER Press the key to select the desired copy density, and then press...
Use the keypad to type in the desired zoom ratio, or press the to specify the zoom ratio, and then press the E key. NTER The main screen (Copy mode) appears again. Each press of the key changes the zoom ratio by 1%. A setting between 50% and 200% can be specified.
Making Advanced Copies This section contains descriptions on setting 2in1 copying, ID card copying, repeat copying, poster copying, duplex (double-sided) copying and collated (Sort) copying. ID card copying, repeat copying or poster copying cannot be set at the same time that 2in1 copying, duplex (double-sided) copying or col- lated (Sort) copying is set.
To print color copies, press the S key. To print monochrome TART OLOR copies, press the S key. TART Scanning of the document begins. In order to perform duplex (double-sided) copying or collated (Sort) copying with 2in1 copying, specify the necessary settings before performing step 4.
ID Card Copying With ID card copying, the back and front of a document, such as a certificate, are copied at full size on a single sheet of paper. front side back side The paper sizes that are available for ID card copying are A4, Let- ter and Legal.
To print only the front sides that were scanned first, press the key or the S key in step 5. TART OLOR TART Repeat Copying With repeat copying, small documents, such as memos, are tiled and printed on a single page. Position the document on the original glass.
Poster Copying With poster copying, the length and width of the scanned document are each enlarged 200%, and printed on four pages. If the scanned image does not fit on the size of paper that is used, there may be margins on the sides of the image or the image may not fit in the paper.
Setting Duplex (Double-Sided) Copying In order to perform double-sided copying, the duplex option must be installed on the machine. For details on installing the duplex option, refer to “Duplex Option” on page 10-7. Duplex (Double-Sided) Copying From the ADF With duplex (double-sided) copying, two single-sided document pages can be scanned with the ADF and printed onto a single sheet of paper.
Duplex (Double-Sided) Copying From the Original Glass Duplex (double-sided) copying can also be performed by placing the docu- ment on the original glass. Position the document on the original glass. For details on positioning the document on the orig- inal glass, refer to “Plac- ing a document on the original glass”...
Setting Collated (Sort) Copying With collated (Sort) copying, multiple copies of multi-page documents can be printed in order and sorted by copy set. Collated (Sort) Copying From the ADF In the main screen (Copy mode), press the key to select the current Sort setting, and then press the E key.
Scanning From a Computer Application Documents can be scanned from a computer connected to this machine with a USB cable or via a network. Scanning settings can be specified and the scanning operation can be performed from TWAIN- or WIA-compatible appli- cations.
Windows TWAIN Driver Settings Load Load a saved settings file (dat file) for scanning. Save Save the current settings as a settings file (dat file). Default Return all settings to their defaults. Help icon Click to display the Help. About icon Click to display the software version information.
Page 130
Image size Shows the data size of the scan image. Rotation Select the orientation of the image to be scanned. Close Click to close the TWAIN driver window. Prescan Click to begin scanning a preview image. Scan Click to begin scanning. AutoCrop icon Click to automatically detect the scanning position based on the preview image.
Windows WIA Driver Settings Paper source Select whether documents are placed on the original glass or loaded into the ADF. Color picture Select this setting when scanning in color. Grayscale picture Select this setting when scanning in grayscale. Black and white picture or text Select this setting when scanning in black and white.
Macintosh TWAIN Driver Settings Load Load a saved settings file (dat file) for scanning. Save Save the current settings as a settings file (dat file). Default Return all settings to their defaults. Help icon Click to display the Help. About icon Click to display the software version information.
Page 133
Image size Shows the data size of the scan image. Rotation Select the orientation of the image to be scanned. Close Click to close the TWAIN driver window. Prescan Click to begin scanning a preview image. Scan Click to begin scanning. AutoCrop icon Click to automatically detect the scanning position based on the preview image.
Scanning With the Machine The machine keys can be used to make scans. This operation differs from scanning from a computer application since the destination of the scan data can also be specified. Before scanning, check that the S key is lit up in green. If the key is not lit up in green, press the S key to enter Scan mode.
Page 135
Specify the desired scan settings. For details on specifying the destination of the data, refer to “Spec- ifying the Data Location” on page 6-10 and “Specifying the Desti- nation Address (Scan to E-mail/FTP/SMB)” on page 6-12. For details on selecting the data format, refer to “Selecting the Data Format”...
Specifying the Data Location Select whether the computer or USB memory device is the location where scan data is to be saved. When transmitting via a network, refer to “Specify- ing the Destination Address (Scan to E-mail/FTP/SMB)” on page 6-12. If an address has been specified as the destination for the data, SCAN cannot be selected.
Saving Data on a USB Memory Device (Scan to USB Memory) Follow the procedure described below to save scan data to a USB memory device plugged into the USB memory port of this machine. This machine is compatible with a USB Host device of 4 GB or less. Plug the USB memory device into the USB Host port of this machine.
Specifying the Destination Address (Scan to E-mail/FTP/ SMB) Scan data can be sent via the network to a specified address (e-mail address, FTP address or SMB address). The address can be typed in directly, or an address registered on the machine can be selected. To send scan data via the network, settings for NETWORK SETTING (when sending to an e-mail address) must...
Selecting From the Favorite List From the speed dial destinations and group dial destinations registered on this machine, register a maximum of 20 destinations in the favorite list for convenient access to frequently specified destinations. Follow the procedure described below to specify an address (e-mail address, FTP address or SMB address) from the favorite list as the recipient of the scan data.
The information registered for the speed dial destination appears for two seconds. Press the E key again. NTER If an FTP address or an SMB address was selected, the destination address is specified. If an e-mail address was selected, press the key to select FIN- , and then press the E...
Selecting From the Address Book The speed dial destinations and group dial destinations registered on this machine are saved in the address book. Follow the procedure described below to specify an address (e-mail address, FTP address or SMB address) from the address book as the recipient of the scan data. This feature is available only if data has been registered in the address book.
The search begins, and the search results appear after a while. If no data matches the search keyword, appears for about two sec- NOT FOUND onds. For details on entering/editing text, refer to “Entering Text” on page A-6. Text starting with the first character of the maximum 10 characters is searched for.
Page 143
Press the key to select , and then press the E NTER LDAP SEARCH key. Press the key to select , and then press the NAME E-MAIL key. NTER To search registered names, select . To search e-mail NAME addresses, select E-MAIL Use the keypad to type in the search keyword (maximum of 10 charac- ters), and then press the E...
Specifying Multiple Destination Addresses A destination address can be added if a destination e-mail address is speci- fied. If an FTP address or an SMB address was selected, multiple destina- tion addresses cannot be specified. In the main screen (Scan mode), press the key to select the current data destination setting, and then press the E key.
Press the key to select , and then press the E key. NTER FINISH Deleting a Specified Destination Address A specified destination address (e-mail address, FTP address or SMB address) can be deleted. Changes made with this procedure will not be applied to the original data (speed dial destination, group dial destination, etc.).
Registering in the Favorite List From the speed dial destinations and group dial destinations registered on this machine, register a maximum of 20 destinations in the favorite list for convenient access to frequently specified destinations. Follow the procedure described below to register an address (e-mail address, FTP address or SMB address) on the favorite list.
Press the key to select the address to be deleted from the favorite list, and then press the S key. ESET Press the key to select , and then press E key. NTER The selected address is deleted. To delete another address, repeat the procedure from step 5. To finish deleting addresses, press the B key.
A maximum of 64 characters can be entered. Registering Speed Dial Destinations (LDAP Search) E-mail addresses can be registered as speed dial destinations by using infor- mation on the LDAP server. A maximum of 250 speed dial destinations can be registered. To connect to an LDAP server, settings for must be LDAP SETTING...
Text starting with the first character of the maximum 10 characters is searched for. Text will not be found if the search keyword is in the middle of a word. Press the key to select the desired data, and then press the E NTER key.
For details on entering/editing text, refer to “Entering Text” on page A-6. Use the keypad to edit the e-mail address, and then press the E key. NTER The edited settings are saved, and the menu appears DIAL REGISTER again. If the edited speed dial destination is registered in the favorite list or with a group dial destination, a confirmation message asking whether or not to keep the destination registered as it is appears after the operation in step 7 is performed.
Editing/Deleting Group Dial Destinations Information registered with a group dial destination can be edited or deleted. In the main screen (Scan mode), press the key to select UTIL- , and then press the E key. NTER Press the key to select , and then press the DIAL REGISTER key.
If the edited group dial destination is registered in the favorite list, a confirmation message asking whether or not to keep the destination registered as it is appears after the operation in step 12 is performed. To keep the destination registered as it is, select .
Selecting the Scan Quality Setting The resolution, scan mode and density appropriate for the scanned image can be selected. Selecting the Resolution In the main screen (Scan mode), press the key to select the current scan quality setting, and then press the E key.
Setting the Scan Size The size of the scan data can be specified. The default setting is for USA and Canada, and for other LETTER countries. In the main screen (Scan mode), press the key to select the current scan size setting, and then press the E key.
Deleting a Queued Transmission Job The list of jobs queued for transmission can be displayed, and a job can be deleted. In the main screen (Scan mode), press the key to select CANCEL ., and then press the E key. NTER RESERV Press the or...
If you get toner in your eyes, wash it out immediately with cool water and consult a doctor. Note Use of non-OKI consumables may void your warranty if any damage is found to be caused by such consumables. Keep toner cartridges: In their packaging until you’re ready to install them.
Page 159
a cold place to a warm, humid place, condensation may occur, degrading print quality. Allow the toner to adapt to the environment for about one hour before use. Level during handling and storage. Do not hold, stand or store cartridges on their ends or turn them upside down;...
Replacing a Toner Cartridge Note Be careful not to spill toner while replacing a toner cartridge. If toner spills, immediately wipe it off with a soft, dry cloth. in the UTILITY menu is set to MACHINE SETTING/TONER OUT STOP , the message (where ON(FAX) TONER OUT/CHANGE X TONER...
Page 161
Open the front cover. Before opening the front cover, open Tray 1 if it is not already open. Replacing Consumables...
Page 162
Check that the toner cartridge to be replaced has been moved to the front. You can identify the toner cartridge by the color of the handle. Pull down the handle on the toner cartridge until the toner cartridge is unlocked and moves out slightly toward you.
Page 163
Note Dispose of the empty toner cartridge according to your local regulations. Do not burn the toner cartridge. For details, refer to “About Toner Cartridges” on page 7-2. Check the color of the new toner cartridge to be installed. Remove the toner cartridge from the bag. Shake the cartridge a few times to distribute the toner.
Page 164
Align the shaft on each end of the toner cartridge with its hold- ers, and then insert the car- tridge. Before inserting the toner cartridge, make sure that the color of the toner car- tridge to be installed is the same as the label on the toner cartridge carou- sel.
Page 165
Press in the toner cartridge until it locks into place. Close the front cover. Press the S key to reset the machine and clear the indicator ESET message. The machine must complete a calibration cycle (less than 2 min- utes) after a toner cartridge has been replaced. If you open the scanner unit or front cover before the machine is reset, the calibra- tion stops, then starts over again after the cover is closed.
Replacing All Toner Cartridges at the Same Time Note Be careful not to spill toner while replacing a toner cartridge. If toner spills, immediately wipe it off with a soft, dry cloth. By selecting the in the PRINTER MODE menu, all toner car- EJECT MODE tridges can be replaced at the same time.
Replacing the Imaging Cartridge For optimum print quality and performance, use only approved Oki imaging cartridge for your specific machine type. You are advised to replace the imaging cartridge when the message appears. I/C LIFE END/REPLACE I/C Open the scanner unit.
Page 168
Grab the handle and lift it up slightly to the back, and then slowly pull the imaging cartridge out vertically. Note Dispose of the used imaging cartridge according to your local regulations. Do not burn the imaging cartridge. Prepare the new imaging cartridge. Note Do not touch the PC drum and the transfer belt on the imaging cartridge.
Page 169
Slowly insert the new imaging cartridge vertically, and then push it slightly down toward you to finish installing the imaging cartridge. Carefully close the scanner unit. Take care not to trap your fin- gers when closing the scan- ner unit. Replacing Consumables 7-13...
Page 170
Note Do not touch the wires and flat cable shown in the illustration. The machine must complete a calibration cycle (less than 2 min- utes) after the imaging cartridge has been replaced. If you open the scanner unit or front cover before the machine is reset, the cal- ibration stops, then starts over again after the cover is closed.
Replacing the Fuser Unit For optimum print quality and performance, use only approved Oki fuser unit for your specific machine type. Turn off the machine and discon- nect the power cord. Note There are extremely hot parts within the machine. Before replacing...
Page 172
Note Do not touch the wires and flat cable shown in the illustration. Push the blue handles back as far as possible. 7-16 Replacing Consumables...
Page 173
Grab the blue handles and lift the fuser unit to remove it. Note Do not touch the matching connectors of the fuser unit and the machine. Replacing Consumables 7-17...
Page 174
Prepare a new fuser unit. Pull the fuser separator levers forward as far as possible. Remove the fuser separator material, and then return the fuser separator levers to their original positions. 7-18 Replacing Consumables...
Page 175
Note Be careful not to touch the paper exit sensor and the surface of the fuser roller in the fuser unit. While lifting the fuser unit with the blue handles (one on each side), vertically insert the fuser unit. Replacing Consumables 7-19...
Page 176
Note Do not touch the paper exit sensor on the fuser unit. Note Do not touch the matching connectors of the fuser unit and the machine. 7-20 Replacing Consumables...
Page 177
After the fuser unit is firmly installed, flip the blue handles down toward you. Carefully close the scanner unit. Take care not to trap your fin- gers when closing the scan- ner unit. Replacing Consumables 7-21...
Page 178
Note Do not touch the wires and flat cable shown in the illustration. Reconnect the power cord, and turn on the machine. 7-22 Replacing Consumables...
Maintaining the Machine CAUTION Read all caution and warning labels carefully, making sure to follow any instructions contained in them. These labels are located on the inside of the machine’s covers and the interior of the machine body. Handle the machine with care to preserve its life. Abuse handling may cause damage and void your warranty.
Page 181
Do not cover the machine immediately after using it. Turn it off and wait until it cools down. Do not leave the machine’s covers open for any length of time, especially in well-lit places; light may damage the toner cartridges. Do not open the machine during printing.
Cleaning the Machine CAUTION Be sure to turn off the machine and unplug the power cord before cleaning. However, be sure to turn on the machine when cleaning the print head window. Exterior Control Panel Ventilation Grill Machine Exterior Original Glass Original Cover Pad Cleaning the Machine...
Media Rollers The accumulation of paper dust and other debris on the media rollers can cause media-feeding problems. Cleaning the Media Feed Roller Open the scanner unit. If there is paper in the output tray, remove it, and then fold up the out- put tray before opening the scanner unit.
Page 184
Grab the handle and lift it up slightly to the back, and then slowly pull the imaging cartridge out vertically. Note Do not touch the PC drum and the transfer belt on the imaging cartridge. Position the removed imaging cartridge horizontally as shown in the illustration at the right.
Page 185
Clean the media feed rollers by wiping them with a soft, dry cloth. BOTTOM VIEW CAUTION The area around the fuser unit is extremely hot. Touching anything other than the indicated levers may result in burns. If you get burned, immediately cool the skin under cold water, and then seek professional medical attention.
Page 186
Note Decreased print quality may result if the surface of the transfer roller is touched. Be careful not to touch the surface of the transfer roller. Slowly insert the imaging car- tridge vertically, and then push it slightly down toward you to fin- ish reinstalling the imaging car- tridge.
Page 187
Carefully close the scanner unit. Take care not to trap your fin- gers when closing the scan- ner unit. Note Do not touch the wires and flat cable shown in the illustration. Cleaning the Machine...
Cleaning the Media Feed Rollers for the ADF Open the ADF feed cover. Clean the media feed rollers by wiping them with a soft, dry cloth. Close the ADF feed cover. 8-10 Cleaning the Machine...
Cleaning the Media Feed Rollers for Tray 2 Be sure to remove the duplex option before cleaning the media feed rollers for Tray 2. If the duplex option is installed, remove it. If the duplex option is not installed and the locking pins are installed at the back of Tray 2, remove the locking pins (one in each opening on the left and right sides at the back of Tray 2).
Page 190
Lift the machine and reinstall it on top of Tray 2. Open Tray 1 and reattach the dust cover. If you removed the duplex option in step 1, reinstall it. If the duplex option is not to be installed, install the locking pins. While holding the grip of the locking pin vertical, insert the locking pin into the opening on either the left or right side of the lower feeder unit and, while pushing it in, turn it to either the left or the...
Cleaning the Media Feed Rollers for the attachment Be sure to remove the duplex option before cleaning the media feed rollers for the attachment. If the duplex option is installed, remove it. Remove the dust cover from Tray 1 and close the tray. Lift the machine off of the attach- ment and temporarily place it on a sturdy flat surface.
Page 192
Lift the machine and reinstall it on top of the attachment. Open Tray 1 and reattach the dust cover. If you removed the duplex option in step 1, reinstall it. 8-14 Cleaning the Machine...
Cleaning the Media Feed Rollers for the Duplex Open the duplex door. Clean the feed rollers by wiping them with a soft, dry cloth. Close the duplex door. Cleaning the Machine 8-15...
Print Head Window Continuing to use this machine with a dirty print head window can cause print quality problems. Clearing the Print Head Window With the main screen displayed, press the key to display the PRINTER MODE screen. Press the key to select and then press the E key.
Page 195
The magenta toner cartridge has been moved to the position from where it can be replaced. Pull down the handle on the toner cartridge until the toner cartridge is unlocked and moves out slightly toward you. Remove the toner cartridge. When the magenta toner cartridge is removed, a gap is created within the...
Page 196
Close the front cover. The toner cartridge rotate within the machine. After the toner cartridges have finished rotating, open the scan- ner unit. Note Do not touch the wires and flat cable shown in the illustration. 8-18 Cleaning the Machine...
Page 197
Grab the handle and lift it up slightly to the back, and then slowly pull the imaging cartridge out vertically. Note Do not touch the PC drum and the transfer belt on the imaging cartridge. Position the removed imaging cartridge horizontally as shown in the illustration at the right.
Page 198
Clean the print head window by wiping it with a soft, dry cloth. CAUTION The area around the fuser unit is extremely hot. Touching anything other than the indicated levers may result in burns. If you get burned, immediately cool the skin under cold water, and then seek professional medical attention.
Page 199
Note Decreased print quality may result if the surface of the transfer roller is touched. Be careful not to touch the surface of the transfer roller. Slowly insert the imaging car- tridge vertically, and then push it slightly down toward you to fin- ish reinstalling the imaging car- tridge.
Page 200
Close the scanner unit. Take care not to trap your fin- gers when closing the scan- ner unit. Note Do not touch the wires and flat cable shown in the illustration. Press the S key. ESET 8-22 Cleaning the Machine...
Page 201
After the toner cartridges have finished rotating, open the front cover. Align the shaft on each end of the toner cartridge with its hold- ers, and then insert the car- tridge. Cleaning the Machine 8-23...
Page 202
Note Do not touch the contact indicated the illustration. Press in the magenta toner car- tridge until it locks into place. Close the front cover. 8-24 Cleaning the Machine...
Introduction This chapter provides information to aid you in resolving machine problems you may encounter, or at least guide you to the proper sources for help. Printing a Configuration Page page 9-3 Preventing Media Misfeeds page 9-4 Understanding the Media Path page 9-5 Clearing Media Misfeeds page 9-5...
Printing a Configuration Page In the main screen, press the key to select REPORT/STATUS and then press the E key. NTER Press the key to select , and then press the E key. REPORT NTER Press the key to select , and then press CONFIGURATION PAGE the E...
Preventing Media Misfeeds Make sure that... Media matches the machine specifications. Media is flat, especially on the leading edge. The machine is on a hard, flat, level surface. You store media in a dry location away from moisture and humidity. You always adjust the media guides in Tray 1 after inserting the media (a guide that is not properly adjusted can cause poor print quality, media mis- feeds, and machine damage).
Understanding the Media Path Understanding the media path will help you locate media misfeeds. 1. ADF media feed rollers 2. Document feed tray 3. Document output tray 4. Output tray 5. Imaging cartridge Document path 6. Toner cartridge carousel 7. Tray 1 (multipurpose tray) 8.
Page 208
CAUTION Unfused toner can mess your hands, clothes, or anything else it gets If you accidentally get toner on your clothes, lightly dust them off as best as you can. If some toner remains on your clothes, use cool, not hot water, to rinse the toner off.
Media Misfeed Messages and Clearing Procedures Media Misfeed Message Page Reference This message appears in the following cases. CHECK TRAY1 PAPER When no media is loaded in Tray 1 LOAD PAPER ( When a misfeed has occurred in Tray 1 (PRESS START KEY) With the first case, load media into the tray, and then press the S...
Clearing a Media Misfeed in the Machine Open the scanner unit. If there is paper in the output tray, remove it, and then fold up the out- put tray before opening the scanner unit. Note Do not touch the wires and flat cable shown in the illustration.
Page 211
Grab the handle and lift it up slightly to the back, and then slowly pull the imaging cartridge out vertically. Note Do not touch the PC drum and the transfer belt on the imaging cartridge. Position the removed imaging cartridge horizontally as shown in the illustration at the right.
Page 212
Push the fuser separator levers back as far as possible. CAUTION The area around the fuser unit is extremely hot. Touching anything other than the indicated levers may result in burns. If you get burned, immediately cool the skin under cold water, and then seek professional medical attention.
Page 213
Remove any misfed media. If a media misfeed occurs near the fuser unit, pull out the media from below the fuser unit, as shown in the illustration at the right. If the media cannot be removed from below the fuser unit, raise the fuser unit cover, and then remove the media from above the fuser unit.
Page 214
Note Do not touch the surface of the fuser roller in the fuser unit. Note Do not touch the paper exit sensor on the fuser unit. 9-12 Clearing Media Misfeeds...
Page 215
Note Decreased print quality may result if the surface of the transfer roller is touched. Be careful not to touch the surface of the transfer roller. Return the fuser separator levers to their original positions. Clearing Media Misfeeds 9-13...
Page 216
Slowly insert the imaging car- tridge vertically, and then push it slightly down toward you to fin- ish reinstalling the imaging car- tridge. Carefully close the scanner unit. Take care not to trap your fin- gers when closing the scan- ner unit.
Page 217
Note Do not touch the wires and flat cable shown in the illustration. Clearing Media Misfeeds 9-15...
Clearing a Media Misfeed From Tray 1 Remove the dust cover from Tray 1. Carefully pull out the misfed media. If the media cannot be removed, instead of pull- ing it with extreme force, clear the media misfeed according to the proce- dure described in “Clear- ing a Media Misfeed in the Machine”...
Clearing a Media Misfeed in Tray 2 Pull out Tray 2 as far as possi- ble. Lift up Tray 2 to remove it. Remove any misfed paper. If necessary, remove the dust cover from Tray 1 and close the tray. Clearing Media Misfeeds 9-17...
Page 220
Remove the lid from Tray 2, and then remove all paper from the tray. Fan the paper, and align its edges. Press down the media pressure plate to lock it into place. Load the media in Tray 2, and attach the lid. 9-18 Clearing Media Misfeeds...
Page 221
Reinsert Tray 2. Open and close the scanner unit to clear the misfeed mes- sage. Clearing Media Misfeeds 9-19...
Clearing a Media Misfeed from the ADF Open the ADF feed cover. Remove the document from the ADF document feed tray. Lift to open the ADF cover. 9-20 Clearing Media Misfeeds...
Page 223
Remove any misfed media. Close the ADF cover. Take care not to trap your fin- gers when closing the ADF cover. Close the ADF feed cover. Clearing Media Misfeeds 9-21...
Clearing a Media Misfeed from the Duplex Option Open the duplex cover. Carefully pull out the misfed media. Always remove the mis- fed media in the feed direction as shown only. If the media misfeed occurs at the bottom feed slot and the media does not stick out enough to be removed, turn the dial at...
Page 225
Close the duplex cover. Clearing Media Misfeeds 9-23...
Duplex mis- Unsupported media Use Oki approved media. feeds. (wrong size, thick- Only Letter/A4 plain paper and recy- ness, type, etc.) is cled paper can be autoduplexed if the being used.
Page 227
Symptom Cause Solution Media is mis- The loaded document Load the correct document. For details fed in the does not meet the on the documents that can be loaded, ADF. specifications. refer to “Documents that can be loaded into the ADF” on page 3-21. The loaded document Load the document so that it does not exceeds the maxi-...
Page 228
C6 and Envelope DL), load the envelopes with the flap edge toward the machine and the flap side facing down. Unsupported media Use Oki approved media. (wrong size, thick- ness, type, etc.) is being used. The media feed roller Clean the media feed roller.
Solving Other Problems Symptom Cause Solution Machine The power cord is not Turn off the machine, confirm that the power is not correctly plugged into power cord is correctly plugged into the outlet. the outlet, and then turn on the machine.
Page 230
The job is very com- Wait. No action needed. plex. A toner cartridge for a Install a correct Oki toner cartridge different region or an approved for your specific machine. unapproved toner cartridge is installed Wrong Toner X is displayed in the message window).
Page 231
Symptom Cause Solution Some parts When printing enve- With 2in1 copying, the zoom ratio is of the image lopes, the zoom ratio automatically adjusted. For 2in1 copy- are lost with was specified, and ing on media with a narrow printing 2in1 copying.
Page 232
Symptom Cause Solution With N-up on Both the printer driver For N-up on multiple copies, choose multiple cop- and the application Collate only in the printer driver’s Basic ies, the out- have been set for col- Tab. Do not set collation in the applica- put is lation.
Page 233
Check them for damage. If necessary, or fuser unit is defec- contact Technical Support with the tive. error information. Unsupported media Use Oki approved media. (wrong size, thick- ness, type, etc.) is being used. Data was An error message is...
Solving Problems with Printing Quality Symptom Cause Solution Nothing is One or more of the Remove the toner cartridges and printed, or toner cartridges may check if any is damaged. there are be defective. blank spots The imaging cartridge Remove the imaging cartridge and on the may be defective.
Page 235
Symptom Cause Solution Image is too The print head win- Clean the print head window. light; there is dow is dirty. low image The copy density is Select a darker copy density. density. set too light. The media is moist Remove the moist media and replace from humidity.
Page 236
Remove the moist media and replace it appears. with new, dry media. Unsupported media Use Oki approved media. (wrong size, thick- ness, type, etc.) is being used. One or more of the Remove the toner cartridges and toner cartridges may check for damage.
Page 237
The media is moist Remove the moist media and replace it insufficient from humidity. with new, dry media. fusing or the Unsupported media Use Oki approved media. image (wrong size, thick- comes off ness, type, etc.) is when being used.
Page 238
Symptom Cause Solution Abnormal The print head win- Clean the print head window. areas (white, dow is dirty. black, or A toner cartridge may Remove the toner cartridges with the color) appear be defective. color causing the abnormal image. in a regular Replace it with a new toner cartridge.
Page 239
If it is damaged, reproduction replace it. or has poor color density. If the problem is not resolved, even after all of the above have been per- formed, contact your Oki dealer with the error information. Solving Problems with Printing Quality 9-37...
Status, Error, and Service Messages Status, error, and service messages are displayed in the message window. They provide information about your machine and help you locate many prob- lems. When the condition associated with a displayed message has changed, the message is cleared from the window. Status Messages This message...
This message... means... Do this... The machine is searching SEARCHING data. The machine is scanning SCANNING the document. The machine is warming up Warming Up or AIDC is being per- formed. Error Messages For details on fax error messages, refer to the Facsimile User’s Guide on the CD.
Page 242
This message... means... Do this... While data was Check the connection COMMUNICATION ERROR being sent in Scan to the USB memory USB Memory mode, the connec- device, and then try tion to the USB sending the data memory device was again.
Page 243
This message... means... Do this... While a document Turn the machine off, JOB CANCELED was being scanned and then, after waiting from the original a few seconds, turn it glass in Scan mode, on again. When send- more than one ing multiple pages, for minute had passed example, from a book,...
Page 244
This message... means... Do this... Duplex (dou- Select Letter- or NO SUITABLE PAPER ble-sided) printing is A4-size plain paper, or CHECK DUPLEX SETTING specified, but paper select simplex (sin- with a type or size gle-sided) printing, and incompatible with then try performing the duplex (dou- print job again.
Page 245
This message... means... Do this... The output tray is Remove all paper from OUTPUT TRAY FULL full of paper. the output tray. REMOVE PAPER Communication with Establish a connection OVER SEARCH TIME the LDAP server with the LDAP server has timed out. again.
Page 246
This message... means... Do this... The LDAP search Change the maximum RESULTS ARE OVER xxx results exceed the setting, or change the maximum specified search conditions (for example, increase the with MAX. length of the key- SEARCH RESULT word), and then try in the LDAP SET- performing the LDAP TING menu.
Page 247
Server indicated server correct one. could not be accessed. An unapproved Install a correct Oki Wrong Toner x toner cartridge is toner cartridge. installed. The indicated cover Close the indicated xxx COVER OPEN is open.
Page 248
This message... means... Do this... The TCP/IP, FTP, Enable the TCP/IP, xxx IS DISABLED SMTP or SMB set- FTP, SMTP or SMB tings are disabled. settings. Repeat copying The maximum possible xxxxx cannot be per- size for repeat copying IS NOT SUPPORTED formed with the is A4.
These messages indicate a more serious fault that can only be corrected by a customer service engineer. If one of these messages appears, turn the machine off, then turn it on again. If the problem persists, contact your Oki dealer or authorized service provider.
Page 250
9-48 Status, Error, and Service Messages...
Introduction Note Use of accessories not manufactured by OKI may void your warranty if any damage is found to be caused by such accessories. This chapter provides information about the following accessories. Tray 2 Lower feeder unit with 500-sheet tray included...
Tray 2 (Lower Feeder Unit) You can install up to one optional lower feeder unit (Tray 2). The lower feeder unit increases your machine’s media feed capacity by 500 sheets. Kit Contents Lower feeder unit with a tray (500-sheet capacity) Tray 2 (Lower Feeder Unit) 10-3...
Installing Tray 2 Note Since consumables are installed in the machine, be sure to keep the machine level when moving it in order to prevent accidental spills. Turn off the machine and discon- nect the power cord and inter- face cables. Remove the dust cover from Tray 1.
Page 255
WARNING! This machine weighs approximately 21 kg (46 lb) when it is fully loaded with consumables. Open Tray 1 and reattach the dust cover. Load paper into Tray 2. For details on loading paper, refer to “Tray 2” in “Loading Media” on pages.
Page 256
When installing Tray 2 without installing the duplex option, also install the locking pins (one in each opening on the left and right sides at the back of Tray 2). While holding the grip of the locking pin vertical, insert the locking pin into the opening on either the left or right side of the lower feeder unit and, while pushing it in, turn it to either the left or the right.
Duplex Option Duplex (Double-Sided) printing can be performed automatically with the duplex option installed. For details, refer to “About Duplex Printing” on page 3-17. In order for the duplex option to be installed, either of the following must be installed on the machine. Tray 2 Attachment Kit Contents...
Installing Attachment If the attachment is installed, the duplex option can be installed. (The attachment cannot be used by itself; it must be used together with the duplex option.) Note Since consumables are installed in the machine, be sure to keep the machine level when moving it in order to prevent accidental spills.
WARNING! This machine weighs approximately 21 kg (46 lb) when it is fully loaded with consumables. Open Tray 1 and reattach the dust cover. Next, install the duplex option. Installing the Duplex option The illustrations in the following installation procedure show the machine with Tray 2 installed;...
Page 260
Remove the tape affixed to the rear cover. If the locking pins are installed on the left and right side at the back of Tray 2, remove them. To remove a locking pin, turn it to either the left or the right so that its grip is vertical, and then pull out the locking pin to remove it.
Page 261
Install the duplex option. Align the duplex option with its installation position, and then push down on the bottom of the duplex option until it locks into place. Note When attaching the duplex option, attach the bottom of the option first. If the duplex option is attached incorrectly, it may be damaged.
Page 262
Reconnect the power cord, and turn on the machine. 10-12 Duplex Option...
Technical Specifications Type Desktop (Full color laser beam printer-based all-in-one) Document holder Stationary Developing system Mono component development system Fusing system Heat roller system 1200 dpi × 600 dpi or Resolution 600 dpi × 600 dpi First print Simplex Monochrome 14 seconds for A4/Letter (plain paper) Full color 23 seconds for A4/Letter (plain paper)
Page 265
Copy speed Simplex Monochrome 20* pages per minute for A4 (plain paper) (Normal 600 x 300 dpi) * When using ADF: 20 pages per minute (Normal 300 × 300 dpi) 10 pages per minute (Fine 600 × 300 dpi) Full Color 5* pages per minute for A4 (plain paper) (Normal 600 x 300 dpi) * When using ADF:...
Page 266
Output capacity Output tray: 100 sheets approx. See note on page 3-19. Operating temperature 10 to 35 °C (50 to 95 °F) Operating humidity 15% to 85% Power supply 120 V, 50 to 60 Hz 220 to 240 V, 50 to 60 Hz Power consumption 120 V: 990 W or less 220 to 240 V: 1060 W or less...
Entering Text When specifying the user name or programming the recipient name, letters, accented characters, numbers and symbols can be entered. Key Operation Use the keypad to enter numbers, letters, and symbols. List of characters available with each key of the keypad Entering Fax Numbers Keypad Available...
Changing Input Mode Each press of the key switches the input mode between numbers and let- ters. [1…]: Numbers can be typed in. [A…]: Letters can be typed in. Inputting Example The procedure for entering text is described below, using “NJ Office” as an example.
Correcting Text and Input Precautions To erase all entered text, hold down the B key. To delete only part of the entered text, use the keys to move the cursor (_) to the character that you want to delete, and then press the key.
Our Concern for Environmental Protection ® As an ENERGY STAR Partner, we have determined that this machine meets the ENERGY STAR Guidelines for energy efficiency. What is an ENERGY STAR product? An ENERGY STAR product has a special feature that allows it to automati- cally switch to a “low-power mode”...
Need help?
Do you have a question about the MC160 and is the answer not in the manual?
Questions and answers
