S h a p i n g t h e b e a m
The beam can be shaped using the shutters (see
P a t t e r n P r o j e c t i o n
The pattern holder slot is on the top side of the barrel and in front of the shutters. It accommodates
an M-size pattern holder (see
shutter handle to keep it from interfering with the action of the shutter handle.
Use an optional donut in the accessory holder to enhance pattern projection. Donut diameter range
should be 2.5" to 2.75".
D r o p - I n I r i s S l o t
The drop-in iris slot is located on the top of the barrel and in front of the pattern holder slot. It
accommodates either a drop-in iris or a motorized pattern device. When the slot is not in use, a
small sheet metal cover secured with two Phillips screws prevents light leakage (see
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
6
Downloaded from www.Manualslib.com
Figure
Pattern holder slot
Drop-in iris slot
Use a Phillips screwdriver to loosen the screws on the drop-in iris slot cover. Do not
remove screws.
Slide the cover completely forward to expose the slot.
Insert the iris with the flat side toward the shutters and make sure the iris handle extends
from the slot.
Slide the slot cover back toward the shutters until it meets the iris handle. Leave enough
space to move the iris handle.
Secure the drop-in iris slot cover by tightening the screws.
manuals search engine
Figure 1, a pattern or an optional drop-in iris.
7). The pattern holder handle can be bent away from the
M-Size Pattern holder
Figure 7
Iris
Figure 8
Figure 8).
