Basic Assembly
Gel frame
W A R N I N G :
Downloaded from
www.Manualslib.com
Pattern holder slot
Drop-in iris
slot cover
Color frame
Barrel
retaining gel clip
Please note the following safety warnings before use:
Do not mount the fixture on or near combustible surfaces.
Do not operate the fixture without a lens installed.
Always hang the fixture with the colour frame retaining clip in the locked
position.
manuals search engine
C-clamp mounting
Yoke
Yoke locking knob
Zoom rear focus knob
Beam focus knob
(Zoom front focus)
Lamp housing
Figure 1
1
