ESAB Buddy Arc 200 Instruction Manual

Hide thumbs

Advertisement

GB
Buddyä
Arc 180
Arc 200
Instruction manual
0463 266 001 GB 20110902
Valid for serial no. 01107072134, 01108075972

Advertisement

loading

  Summary of Contents for ESAB Buddy Arc 200

  • Page 1 Buddyä Arc 180 Arc 200 Instruction manual 0463 266 001 GB 20110902 Valid for serial no. 01107072134, 01108075972...
  • Page 2 - 2 -...
  • Page 3: Table Of Contents

    1 SAFETY ............2 INTRODUCTION .
  • Page 4: Safety

    SAFETY Users of ESAB equipment have the ultimate responsibility for ensuring that anyone who works on or near the equipment observes all the relevant safety precautions. Safety precautions must meet the requirements that apply to this type of equipment. The following recommendations should be ob­...
  • Page 5 There may be potential difficulties in ensuring electromagnetic compatibility of class A equipment in those locations, due to conducted as well as radiated disturbances. CAUTION This product is solely intended for arc welding. - 5 - © ESAB AB2011 bh40d1e...
  • Page 6: Introduction

    As the person responsible for the equipment, it is your responsibility to obtain information on approved collection stations. For further information contact the nearest ESAB dealer. ESAB can provide you with all necessary welding protection and accessories. INTRODUCTION Arc 180 and Arc 200 are welding power sources intended for use with coated electrodes (MMA welding) and TIG welding (Live Arc).
  • Page 7: Installation

    3 G 2.5 Phase current I (TIG) 14.7 A 16.6 A 1eff Phase current I (MMA) 19.7 A 24.1 A 1eff NOTE! Use the power source in accordance with the relevant national regulations. - 7 - © ESAB AB2011 bh40d1e...
  • Page 8: Operation

    (2). Connect gas inlet nut to a regulated shielding gas supply. Connect the return cable to the remaining welding terminal on the power source. Secure the return cable's contact clamp to the work piece and ensure that there is good contact. - 8 - © ESAB AB2011 bh40d1e...
  • Page 9: Symbols And Control Panels

    5.5.1 Welding current setting The Arc 180 power source has an adjustable welding current from 5 to 180 Amps. The Arc 200 has an adjustable value from 5 to 200 Amps. - 9 - © ESAB AB2011 bh40d1e...
  • Page 10: Striking The Arc

    5.5.5 Joint forms in MMA Butt joint Corner joint Lap joint T joint - 10 - © ESAB AB2011 bh40d1e...
  • Page 11: Electrode Selection

    Select desired welding current level. 5.6.1 Welding current setting The Arc 180 power source has an adjustable welding current from 5 to 180 Amps. The Arc 200 has an adjustable value from 5 to 200 Amps. - 11 - © ESAB AB2011 bh40d1e...
  • Page 12: Striking An Arc "Live Tig- Start

    Power source Check regularly that the welding power source is not clogged with dirt. How often and which cleaning methods apply depend on: welding process arc time placement surrounding environment - 12 - © ESAB AB2011 bh40d1e...
  • Page 13: Welding Torch

    Spare parts may be ordered through your nearest ESAB dealer, see the last page of this publication. DISMANTLING AND SCRAPPING Welding equipment primarily consists of steel, plastic and non-ferrous metals, and must be handled according to local environmental regulations.
  • Page 14: Diagram

    Diagram - 14 - bh40e...
  • Page 15 - 15 - bh40e...
  • Page 16: Order Number

    Arc 180 0700 300 887 Welding power source Buddy Arc 200 0459 839 066 Spare parts list Buddy Arc 180 and Arc 200 The spare parts list is available on the Internet at www.esab.com - 16 - © ESAB AB2011 bh40o...
  • Page 17: Accessories

    ......0700 300 861 17, 4 m - 17 - © ESAB AB2011 bh40a...
  • Page 18 NOTES ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................- 18 - notes...
  • Page 19 NOTES ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................- 19 - notes...
  • Page 20 ESAB Romania Trading SRL ESAB VAMBERK s.r.o. SOUTH AFRICA ESAB Mexico S.A. Bucharest Vamberk ESAB Africa Welding & Cutting Ltd Monterrey Tel: +40 316 900 600 Tel: +420 2 819 40 885 Durbanvill 7570 - Cape Town Tel: +52 8 350 5959...

This manual is also suitable for:

Buddy arc 180
