  • Page 1 Scopia XT5000 Series Installation Guide Version 3.2 For Solution 7.7, 8.0.x, 8.2...
  • Page 2 Installation Guide for Scopia XT5000 Series Version 3.2, guide is made either by RADVISION Ltd or its agents. May 30, 2013 RADVISION Ltd reserves the right to revise this http://www.radvision.com...

  • Page 3: Table Of Contents

    Connecting Scopia XT Series to Your Network ....................35 Connecting a Computer to the Scopia XT Series ..................36 Selecting the Computer Display Resolution ....................38 Connecting Audio Equipment to the Scopia XT Series ..................39 Installation Guide for Scopia XT5000 Series Version 3.2 Table of Contents | 3...
  • Page 4 Setting the System Name and Language .................84 Adjusting the Image Position ....................85 Configuring Network Settings ....................87 Configuring Gatekeeper Settings ....................89 Setting Basic System Information ........................90 Installation Guide for Scopia XT5000 Series Version 3.2 Table of Contents | 4...
  • Page 5 Enabling the TLS Connection in XT Series ..................147 Enabling Encryption for Videoconferences ....................149 Chapter 8: Troubleshooting the Scopia XT Series Viewing System Information for Customer Support ..................152 Installation Guide for Scopia XT5000 Series Version 3.2 Table of Contents | 5...
  • Page 6 Resolving Camera Issues ..........................160 Resolving IP Address Problems ........................162 Resolving XT Remote Control Unit Problems ....................164 Restoring Default User Settings ........................165 Glossary of Terms for Scopia Solution Installation Guide for Scopia XT5000 Series Version 3.2 Table of Contents | 6...

  • Page 7: Chapter 1: About The Scopia Xt Series

    Using encryption is subject to local regulation. In some countries it is restricted or limited for usage. For more information, consult your local reseller. Figure 1: Scopia XT Series products on page 8 shows the different Scopia XT Series endpoints available. Installation Guide for Scopia XT5000 Series Version 3.2 About the Scopia XT Series | 7...

  • Page 8: About The Models In The Scopia Xt Series Product Line

    7. To easily compare the different Scopia XT Series endpoints, see Comparing Between Scopia XT Series Models on page 12. The Scopia XT Series includes the following models: • Scopia XT5000 Series Installation Guide for Scopia XT5000 Series Version 3.2 About the Scopia XT Series | 8...
  • Page 9 Includes a high-quality camera (10x optical zoom, and an additional 4x digital zoom) – The 3-way Microphone Pod provides superb signal-to-noise ratios. You can also add a second microphone for unparalleled large room coverage. Installation Guide for Scopia XT5000 Series Version 3.2 About the Scopia XT Series | 9...
  • Page 10 PC or Mac. Using a unique control application, you can place calls, join videoconferences, and navigate the system menus with your computer's keyboard and mouse. The XT Remote Control Unit can be used as well. Installation Guide for Scopia XT5000 Series Version 3.2 About the Scopia XT Series | 10...
  • Page 11 Depending on your deployment and the model, you can locally host videoconferences with other endpoints (including H.323, SIP, Scopia XT Desktop clients, Scopia Mobile, and ISDN endpoints, if your Installation Guide for Scopia XT5000 Series Version 3.2 About the Scopia XT Series | 11...

  • Page 12: Comparing Between Scopia Xt Series Models

    Hosting with Can host Can host video- Can host Can host internal MCU video- conferences video- video- conferences (optional) conferences conferences (optional) (optional) (optional) Installation Guide for Scopia XT5000 Series Version 3.2 About the Scopia XT Series | 12...

  • Page 13: Technical Specifications

    14. • For network information of the system, such as network interface cards, see Table 4: Network and security capabilities on page 16. Installation Guide for Scopia XT5000 Series Version 3.2 About the Scopia XT Series | 13...
  • Page 14 H.323, SIP, ISDN (in conjunction with Scopia Gateway) Video codecs H.263, H.263+, H.263++,H.264, H.264 SVC, H.264 High Profile, H.264 High Profile SVC Dual video H.239 (H.323); BFCP (SIP) Installation Guide for Scopia XT5000 Series Version 3.2 About the Scopia XT Series | 14...
  • Page 15 (optional) multipoint call (optional) Up to 6Mbps for 1080p Up to 6Mbps for a point- in a point-to-point call to-point call (720p for XT5000 720) Installation Guide for Scopia XT5000 Series Version 3.2 About the Scopia XT Series | 15...
  • Page 16 2nd GLAN enabled by 2nd GLAN is optional 2nd GLAN enabled by default default (optional for XT5000 720) Firewall Traversal Auto NAT discovery HTTP and STUN H.460.18, H.460.19 Installation Guide for Scopia XT5000 Series Version 3.2 About the Scopia XT Series | 16...

  • Page 17: Chapter 2: Installation Workflow For Scopia Xt Series

    8. Perform the basic required configuration necessary to use the XT Series, such as the network and gatekeeper settings, as described in Performing Basic Configuration on page 82. Installation Guide for Scopia XT5000 Series Version 3.2 Installation Workflow for Scopia XT Series | 17...
  • Page 18 Using encryption is subject to local regulation. In some countries it is restricted or limited for usage. For more information, consult your local reseller. Installation Guide for Scopia XT5000 Series Version 3.2 Installation Workflow for Scopia XT Series | 18...

  • Page 19: Chapter 3: Planning The Topology Of The Scopia Xt Series Deployment

    About the Scopia XT Series on page 7). Scopia XT Executive integrates advanced videoconferencing into a high resolution 24-inch multimedia LED monitor. Installation Guide for Scopia XT5000 Series Version 3.2 Planning the Topology of the Scopia XT Series Deployment | 19...

  • Page 20: About The Scopia Xt Series Embedded Mcu

    SD video streams and HD endpoints receive HD video streams. • Both wide-screen (16:9) and standard formats (4:3) are incorporated into the continuous presence (CP) video layout. Installation Guide for Scopia XT5000 Series Version 3.2 Planning the Topology of the Scopia XT Series Deployment | 20...

  • Page 21: Planning The Topology For The Scopia Xt Series With Scopia Xt Desktop

    • The included Scopia XT Desktop provides built-in NAT and firewall traversal functionality, enabling secure remote connections from Scopia Mobile and Scopia Desktop Clients. You can enable this functionality via the XT Series license. Installation Guide for Scopia XT5000 Series Version 3.2 Planning the Topology of the Scopia XT Series Deployment | 21...

  • Page 22: Planning Nat And Firewall Traversal With Scopia Xt Series

    NAT router or firewall and connect with other endpoints seamlessly. This section describes the available methods to incorporate NAT and firewall traversal with XT Series: • Using a Radvision HTTP server or a STUN public server for NAT and firewall traversal When the XT Series hosts a videoconference with endpoints outside the enterprise...
  • Page 23 H.460 is an extension of the H.323 protocol used for NAT and firewall traversal, employing ITU-T standards. The traversal server can be a Scopia PathFinder or a third-party ITU-T compliant server. Installation Guide for Scopia XT5000 Series Version 3.2 Planning the Topology of the Scopia XT Series Deployment | 23...
  • Page 24 The second GLAN is an optional feature for selected models (for details, see Installing and Enabling Licenses which Extend System Functionality on page 76). Installation Guide for Scopia XT5000 Series Version 3.2 Planning the Topology of the Scopia XT Series Deployment | 24...

  • Page 25: Supporting Isdn Connectivity

    The Scopia XT Series supports ISDN connectivity, allowing calls from endpoints to be routed to the relevant videoconference via the Scopia Gateway for ISDN. Installation Guide for Scopia XT5000 Series Version 3.2 Planning the Topology of the Scopia XT Series Deployment | 25...
  • Page 26 ISDN endpoints via the Scopia Gateway for ISDN. Gateway IP Address Enter the IP address of the Scopia Gateway for ISDN used by your organization. 4. Select Save. Installation Guide for Scopia XT5000 Series Version 3.2 Planning the Topology of the Scopia XT Series Deployment | 26...

  • Page 27: Implementing External Api Control

    You can control the XT Codec Unit using the Scopia XT Series API (requires integration with AMX, Creston, or Extron control devices). Contact Radvision customer support to receive the Reference Guide for Scopia XT Series API, which includes the list of commands over the Ethernet interface.
  • Page 28 Desktop Server Scopia XT Desktop Server Scopia Control by sending commands and application or and receiving responses Scopia XT Desktop Server Installation Guide for Scopia XT5000 Series Version 3.2 Planning the Topology of the Scopia XT Series Deployment | 28...
  • Page 29 Cannot send system Optional (TCP) Scopia XT system status alerts status alerts; Scopia Desktop Server Control and Scopia XT Desktop Server cannot function. Installation Guide for Scopia XT5000 Series Version 3.2 Planning the Topology of the Scopia XT Series Deployment | 29...

  • Page 30: Configuring The Tcp Or Udp Port Range On The Scopia Xt Series

    • From the web interface, select Administrator Settings > Networks > Preferences > Dynamic Ports. • From the endpoint interface, select Configure > Advanced > Networks > Preferences > Dynamic Ports. Installation Guide for Scopia XT5000 Series Version 3.2 Planning the Topology of the Scopia XT Series Deployment | 30...
  • Page 31 MCU license and its type. 4. From the web interface only, select Save. Installation Guide for Scopia XT5000 Series Version 3.2 Planning the Topology of the Scopia XT Series Deployment | 31...

  • Page 32: Chapter 4: Prerequisites For Setting Up The System

    To see additional information on designing a videoconferencing room, such as the best lighting for optimal video, see http://blog.radvision.com/videooverenterprise/2010/05/11/ask-the-expert-designing- your-conference-room/. Installation Guide for Scopia XT5000 Series Version 3.2 Prerequisites for Setting up the System | 32...
  • Page 33 • Place chairs so that you and other participants appear in the middle of the monitors. • Place the Microphone Pod at the center of the table, in front of the participants. Installation Guide for Scopia XT5000 Series Version 3.2 Prerequisites for Setting up the System | 33...
  • Page 34 Light should come from the top of the conference table, the front and the rear (for depth of field). If only ceiling light is available, it should contribute to maintain a pleasant environment and generate as less heat as possible. Installation Guide for Scopia XT5000 Series Version 3.2 Prerequisites for Setting up the System | 34...

  • Page 35: Chapter 5: Setting Up The Scopia Xt Series

    • Place the XT Codec Unit anywhere within 5 meter reach of the camera cables. Caution: Do not place the camera on top of the XT Codec Unit. It can cause the system to overheat. Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 35...

  • Page 36: Connecting A Computer To The Scopia Xt Series

    Use a computer to share a presentation or other PC content during a call. This procedure describes how to connect computers that are equipped with a DVI-out or VGA-out connector. Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 36...
  • Page 37 When you share content from the PC during a call, remote participants hear the computer's audio output as well as the audio from the Microphone Pod. Important: The audio input port supports both analog and digital optical audio. Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 37...

  • Page 38: Selecting The Computer Display Resolution

    38 for the list of resolutions supported by the XT Codec Unit. Table 9: DVI input formats supported by XT Codec Unit Name Resolution 1080p 1920x1080 SXGA 1280x1024 HD+ (900p) 1600x900 WSGA 1440x900 UVGA 1280x960 Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 38...

  • Page 39: Connecting Audio Equipment To The Scopia Xt Series

    42 • Connecting the One-Way Microphone Pod and other Analog Microphones on page 43 • Connecting an Analog Sound System on page 45 Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 39...

  • Page 40: About The Microphone Pod

    Figure 19: Options for connecting audio equipment About the Microphone Pod The following Microphone Pods are available for the XT Series: • Three-way Microphone Pod Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 40...
  • Page 41 To connect the Microphone Pod, see Connecting the Three-Way Microphone Pod on page 42 or Connecting the One-Way Microphone Pod and other Analog Microphones on page 43. Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 41...

  • Page 42: Connecting The Three-Way Microphone Pod

    Planning the Optimal Conference Room Setup on page 32. Procedure 1. Connect the Microphone Pod output to the rear panel of the XT Codec Unit. Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 42...
  • Page 43 Figure 21: Connecting the Microphone Pods to the XT Codec Unit 2. (Optional) Connect the second Microphone Pod output to the first Microphone Pod input Figure 22: Connecting an additional 3-way Microphone Pod Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 43...

  • Page 44: Connecting The One-Way Microphone Pod And Other Analog Microphones

    Procedure 1. Connect the one-way Microphone Pod to the analog audio input (Figure 23: Connecting the one-way Microphone Pod on page 45). Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 44...

  • Page 45: Connecting An Analog Sound System

    This is not relevant for the Microphone Pod, which supports echo cancellation automatically. b. If you enabled echo cancellation, configure settings as described in Configuring Analog Audio Connections on page 111. Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 45...
  • Page 46 Insert the green plug into the green analog connector of the XT Codec Unit. b. Insert the white plug into the left audio device connector. c. Insert the red plug into the right audio device connector. Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 46...

  • Page 47: Connecting The Video Equipment To The Scopia Xt Series

    Do not place the camera on top of the XT Codec Unit. It can cause the system to overheat. 2. Remove the camera stabilizing cartons. Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 47...
  • Page 48 Figure 28: Connecting the cables to the XT Codec Unit on page 49: • The HDMI connector to the vertical socket • The power connector to the horizontal socket Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 48...

  • Page 49: Connecting The Optional Usb Camera

    Procedure 1. Connect the USB cable attached to the camera to the upper USB port on the XT Codec Unit: Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 49...

  • Page 50: Connecting The Optional Xt Premium Camera

    The XT Premium Camera kit contains a camera, remote control, power supply, 5-meter DVI-HDVI cable, and 10-meter VISCA cross cable. Procedure 1. Remove the camera stabilizing cartons. Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 50...

  • Page 51: Connecting Cameras For Controlling The Optional Xt Premium Camera With The Xt Remote Control Unit

    Do not place the camera on top of the XT Codec Unit. It can cause the system to overheat. 2. Connect the camera to the DVI Input connector on the XT Codec Unit: Figure 30: Connecting the optional XT Premium Camera for Scopia XT5000 Series Important: If you connect a camera to the DVI-I input, the system manages it as PC content.
  • Page 52 The cable’s maximal allowed length is 15m (50ft). Attach each end of the VISCA Cross cable to an 8-pin mini-DIN male connector. Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 52...

  • Page 53: Connecting The Optional Scopia Xt Camera Switch

    Scopia XT Camera Switch (purchased separately). Multiple cameras are typically used for larger meeting rooms or auditoriums. For example, you may want to zoom one camera to focus on the Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 53...
  • Page 54 USB connector on the XT Codec Unit. Figure 33: Connecting the Scopia XT Camera Switch to the XT Codec Unit Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 54...
  • Page 55 The HDMI connector to the HDMI socket labeled 1 on the Scopia XT Camera Switch. b. The connector for power and serial control to the horizontal socket on the XT Codec Unit. Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 55...
  • Page 56 Unit, you can create a cable of up to 15 meters (50 feet) by attaching each end of the VISCA Cross cable to an 8-pin mini-DIN male connector. Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 56...
  • Page 57 8. Turn on the XT Codec Unit by pressing the power key on the XT Remote Control Unit. This also turns on the Scopia XT Camera Switch. Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 57...

  • Page 58: Connecting A Dvd Or Blu-Ray Player

    The XT Codec Unit features digital inputs and outputs. To connect an analog video device, you need an external analog-to-digital (or vice-versa) video converter. Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 58...

  • Page 59: Installing The Batteries Of The Xt Remote Control Unit

    Radvision has tested and certified these two video converters from Gefen: • GTV-COMPSVID-2-HDMIS, Composite/S-Video to HDMI Scaler • GTV-HDMI-2-COMPSVIDS, HDMI to Composite/S-Video Scaler See the company’s site for documentation. Procedure Connect the analog camera to either the HD CAM or DVI ports, using the Composite/S-Video...
  • Page 60 2. Put the battery in, making sure the battery is positioned correctly. 3. Slide the battery compartment cover back until you hear a click. Installation Guide for Scopia XT5000 Series Version 3.2 Setting up the Scopia XT Series | 60...

  • Page 61: Chapter 6: Initial Configuration

    You can also configure the XT Series from the endpoint itself by first enabling advanced configuration, as described in Maintaining the Scopia XT Series Locally from the Endpoint on page 73. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 61...

  • Page 62: Accessing Xt Series Web Interface

    Figure 40: Logging into the XT Series web interface 2. Enter the username and password. The default username for the web interface is Admin and the default password is 1234. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 62...

  • Page 63: Enabling Remote Management On The Scopia Xt Series

    • From the XT Series web interface, select Administrator Settings > Utilities > Remote Access > Web. • From the endpoint's main menu, select Configure > Advanced > Utilities > Remote Access > Web from the Main menu. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 63...
  • Page 64 This field is only relevant if you set the Enable all addresses field to Enter the IP address or IP addresses of the computers allowed to access Scopia XT Series. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 64...

  • Page 65: Configuring Remote Upgrade Settings

    • From the endpoint's main menu, select Administrator Settings > Utilities > Remote Access > Download. • From the XT Series web interface, select Configure > Advanced > Utilities > Remote Access > Download. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 65...
  • Page 66 Enter the Subnet mask associated with the IP address or group of IP addresses specified above. 3. From the web interface only, select Save. 4. To upgrade the Scopia XT Series, see Administrator Guide for Scopia XT Series. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 66...

  • Page 67: Managing Your Xt Series Locally From The Endpoint

    • Contacts—view, edit, and call contacts in the phonebook • Present—start sharing content from your computer • Control Camera—adjust camera position • Recording—start recording a videoconference • Configure—perform basic configuration and check the system status Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 67...

  • Page 68: Using The Xt Remote Control Unit

    The XT Remote Control Unit has an improved design and increases usability to give you a smoother and more efficient videoconferencing experience. Figure 44: The new XT Remote Control Unit on page 69 describes the functions of the XT Remote Control Unit. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 68...
  • Page 69 Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 69...
  • Page 70 Control Unit repeatedly before entering a digit. To enter text in the XT Series interface, scroll to the input field and enter the required characters. The current input method is displayed in the field you are in: Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 70...

  • Page 71: Pairing An Xt Remote Control Unit With A Xt Codec Unit

    Procedure 1. Access the general settings, as follows: • From the web interface, select Basic Settings > General. • From the endpoint's Main menu, select Configure > General. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 71...
  • Page 72 The code of the XT Remote Control Unit is changed and the Remote Control icon with the new Remote Control code appear at the top-right corner of the screen: Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 72...

  • Page 73: Maintaining The Scopia Xt Series Locally From The Endpoint

    Before you begin Ensure that you have the password to access the Advanced settings. The default password is 1234. Procedure 1. From the endpoint's main menu, select Configure > General. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 73...
  • Page 74 The Advanced section now appears in the Configure screen. 4. Select Configure > Advanced. 5. Enter the password required to access the Advanced settings. The default password is 1234. The Advanced screen appears. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 74...

  • Page 75: Registering And Enabling Your Scopia Xt Series License

    3. If you are enabling licenses with additional features, such as an embedded MCU or higher bandwidth, see Installing and Enabling Licenses which Extend System Functionality on page Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 75...

  • Page 76: Installing And Enabling Licenses Which Extend System Functionality

    You can find the user code (and the serial number) by selecting Configure > About from the Main menu. 3. From your computer's Internet browser, navigate to http://licensing.radvision.com/. 4. Complete the online registration form and enter the serial number (or the user code) AND the product key.
  • Page 77 55111-00917 Scopia Control This option is already included for the XT5000 and is available for the XT5000 720. Enables Scopia XT Series control using the Scopia Control Application (iPad). Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 77...

  • Page 78: Remotely Enabling The License From The Web Interface

    You can also retrieve the user code and serial number by selecting Configure > About from the Main menu. 3. From your computer's Internet browser, navigate to http://licensing.radvision.com/. 4. Complete the online registration form and enter the serial number or the user code and the option key.
  • Page 79 2. From the Home page, select Enable License, or, navigate to Administrator Settings > Utilities > Licenses. Figure 48: Accessing licenses from the Scopia XT Series home page The Licenses page appears. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 79...

  • Page 80: Enabling The License From The Scopia Xt Series Endpoint

    Enabling the License from the Scopia XT Series Endpoint About this task This procedure describes how to enable the software license of an XT Codec Unit via the endpoint's interface. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 80...
  • Page 81 3. Enter the license key you received when registering the product. You can also enter license keys for optional features. 4. Select Activate Licenses. The license is automatically enabled. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 81...

  • Page 82: Performing Basic Configuration

    This is relevant for both new installations, and also after restoring default settings and re-installing software. You can do this procedure from the endpoint itself or from the XT Series web interface. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 82...
  • Page 83 • Configuring Gatekeeper Settings on page 89: If your Scopia XT Series works in conjunction with a gatekeeper, configure gatekeeper-related settings. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 83...

  • Page 84: Setting The System Name And Language

    If you perform this task from the endpoint interface, use the alphanumeric keys of the XT Remote Control Unit (for more information, see Using the XT Remote Control Unit on page 68). Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 84...

  • Page 85: Adjusting The Image Position

    Setting the System Name and Language on page 84. Access the quick setup wizard from the endpoint, as described in Accessing the Quick Setup Procedure on page 82. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 85...
  • Page 86 If the image is centered correctly, skip this procedure and select Next. Figure 53: Examining the image position 2. Press 1 to align the top left corner. Figure 54: Adjusting the image position Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 86...

  • Page 87: Configuring Network Settings

    IP address as the Common Name (CN). For more information, see Securing Connections to the XT Series Using TLS on page 140. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 87...
  • Page 88 If the system gets its IP address automatically, this field displays the assigned DNS server IP address. 3. To configure your gatekeeper's settings, select Next and continue with Configuring Gatekeeper Settings on page 89. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 88...

  • Page 89: Configuring Gatekeeper Settings

    Accessing the Quick Setup Procedure on page 82. Procedure 1. Set the Use Gatekeeper list to Yes. Figure 56: Gatekeeper settings 2. Set the Mode list to Manual. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 89...

  • Page 90: Setting Basic System Information

    1. Access the name and language settings: • From the XT Series web interface, select Basic Settings > Preferences > General. • From the endpoint's main menu, select Configure > General. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 90...

  • Page 91: Modifying The System's Name On The Titlebar

    For more information, see Registering the XT Series to a SIP Server on page 128 and Registering the Scopia XT Series with a Gatekeeper on page 125. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 91...
  • Page 92 You need to enter the PIN required to access the Advanced settings. The default PIN is 1234. Figure 59: Selecting the system name 2. Enter the following settings: Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 92...
  • Page 93 System Name includes characters that are not supported by the hostname standard. Invalid characters are replaced by the - character. 3. From the web interface only, select Save. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 93...

  • Page 94: Setting The Administrator Pin Code For The Xt Series

    2. Enter the current PIN code required to access the Advanced settings in the Old PIN Code field. The default PIN is 1234. 3. Enter your new 4 digit PIN code. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 94...

  • Page 95: Setting Date And Time

    Enter the minutes. Internet time Select Yes to synchronize the system clock with the network clock, thus allowing you to align devices connected to the Internet using NTP. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 95...

  • Page 96: Setting The Time Zone

    You need to enter the PIN required to access the Advanced settings. The default PIN is 1234. 2. Configure settings as described in Table 17: Configuring time zone related settings on page Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 96...

  • Page 97: Remotely Setting Regional Information

    Procedure 1. Access the XT Series web interface, as described in Accessing XT Series Web Interface page 62. 2. Select Administrator Settings > System > Location. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 97...
  • Page 98 (east or west); thus in Japan the system administrator must select manually the correct value related to the geographic location. 4. Select Save. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 98...

  • Page 99: Configuring The Screen Saver To Start Automatically

    4. From the web interface only, select Save. Configuring Video Connections There are a number of settings which affect the way the camera accepts input and the way the monitors display video. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 99...

  • Page 100: Configuring The Camera Connection

    • From the endpoint's main menu, select Configure > Advanced > I/O connections > Cameras > General. • From the XT Series web interface, select Administrator settings > I/O connections > Cameras > General. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 100...
  • Page 101 Figure 64: Configuring general camera settings from the web interface 2. Configure the camera connection as described in Table 19: Configuring general camera settings on page 102: Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 101...
  • Page 102 Bring back to place If enabled, the system stores camera positions when the camera is switched off, and restores this position the next time the camera is switched on. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 102...
  • Page 103 • From the XT Series web interface, select Administrator settings > I/O connections > Cameras. Figure 66: Configuring the camera settings from the web interface 5. Define the following camera settings: Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 103...
  • Page 104 7. Configure the settings described in Table 20: Configuring advanced camera settings on page 104 for each camera you are using. From the web interface only, select Save. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 104...

  • Page 105: Setting Up The Monitor Display Modes

    • From the XT Series web interface, select Administrator settings > I/O connections > Monitor. 2. Configure the general monitor settings as follows: a. Select General to access the general settings. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 105...
  • Page 106 Figure 67: Configuring the general monitor settings from the web interface b. Configure the general settings: Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 106...
  • Page 107 720p, even if the received resolution is higher. c. From the web interface only, select Save. 3. Configure the monitor to show more than one video stream: a. Select PIP-PaP under Monitor. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 107...
  • Page 108 The PaP (Picture and Picture) view shows two images of the same size, presented side by side. For more information about video layouts, see Scopia XT Series User Guide. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 108...

  • Page 109: Configuring Audio Connections

    Part of the initial configuration is ensuring the microphones and speakers are set up correctly, and that there is no noticeable echo across connections in a call or conference. The settings are detailed in these sections: Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 109...

  • Page 110: Configuring The Microphone

    • From the XT Series web interface, select Administrator settings > I/O connections > Audio - Input. 2. Select the microphone you are using, such as POD1 or USB. If you are using a second Microphone Pod, select POD2. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 110...

  • Page 111: Configuring Analog Audio Connections

    4. From the web interface only, select Save. Configuring Analog Audio Connections About this task You must perform this procedure if you are using the analog audio connections: Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 111...
  • Page 112 • Analog always - The audio coming from analog connection is always sent to remote participants, regardless of which video is selected. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 112...

  • Page 113: Configuring Audio Outputs

    The Scopia XT Series allows you to combine audio from various inputs such as the XT Digital Microphone Array Pod, and route it to available audio outputs. The possible combination of inputs and Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 113...
  • Page 114 • From the endpoint's main menu, select Configure > Advanced > I/O connections > Audio - Outputs > General. • From the XT Series web interface, select Administrator settings > I/O connections > Audio - Outputs > General. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 114...
  • Page 115 If enabled, it routes the analog input port to one or more of the system’s audio output channels: HD1, digital audio or analog output. 3. From the web interface only, select Save. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 115...

  • Page 116: Configuring The Echo Canceller

    The AGC reduces the volume if the audio is strong and raises when it is weak. Noise reduction Enables/disables reduction of ambient noise in a conference room (e.g.: coughing, paper rustling, etc.). Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 116...

  • Page 117: Configuring Network Settings

    120 • Enabling NAT and Firewall Traversal with Scopia XT Series on page 122 • Determining the Priority of Audio versus Video Quality on page 124 Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 117...

  • Page 118: Configuring Ip Addresses

    4. Access the IP address settings, as follows: • From the endpoint, select either GLAN 1 or GLAN 2. • From the web interface, select Addresses under GLAN 1 or GLAN 2. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 118...
  • Page 119 140. IP Address If the system gets its IP address automatically, indicates the IP address assigned to the system. Otherwise, enter the system static IP address here. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 119...

  • Page 120: Configuring Network Connectivity

    • From the XT Series web interface, select Administrator Settings > Networks. • From the endpoint's main menu, select Configure > Advanced > Networks. 2. Select Parameters under GLAN. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 120...
  • Page 121 XT Codec Unit selects the Ethernet speed and transmission mode according to the specified values. • Manual: You must configure speed and transmission mode and know the network and remote endpoints requirements. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 121...

  • Page 122: Enabling Nat And Firewall Traversal With Scopia Xt Series

    • From the XT Series web interface, select Administrator Settings > Networks > Preferences > NAT. • From the endpoint's main menu, select Configure > Advanced > Networks > Preferences > NAT. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 122...
  • Page 123 Manual method of setting the system’s firewall/NAT public IP address. Enter the Public IP address for that setting. HTTP discovery - This method uses a Radvision HTTP server to discover the presence of a firewall/NAT and its public IP address (requires the endpoint to have internet access).

  • Page 124: Determining The Priority Of Audio Versus Video Quality

    • From the XT Series web interface, select Administrator Settings > Networks > Preferences > QoS. • From the endpoint's main menu, select Configure > Advanced > Networks > Preferences > QoS. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 124...
  • Page 125 Differentiated Service - For each stream (Audio, Video, Data, Signal) sent to the system, you may define a priority level to fit network capabilities. 3. From the web interface only, select Save. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 125...

  • Page 126: Registering The Scopia Xt Series With A Gatekeeper

    • From the endpoint's main menu, select Configure > Advanced > Protocols > H.323 > General. Figure 78: Configuring H.323 settings from the web interface 2. Set the fields as described in Table 31: Configuring H.323 settings on page 127. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 126...
  • Page 127 4. Select Gatekeeper under H.323. Figure 79: Configuring the Gatekeeper settings from the web interface 5. Set the fields as described in Table 32: Configuring the gatekeeper on page 128. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 127...

  • Page 128: Registering The Xt Series To A Sip Server

    “joesmith” and the SIP server routes the call correctly. To do this, the SIP server must register all endpoints to maintain the mapping list of aliases and endpoints to successfully route calls. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 128...
  • Page 129 • From the XT Series web interface, select Administrator Settings > Protocols > SIP. • From the endpoint's main menu, select Configure > Advanced > Protocols > SIP. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 129...
  • Page 130 Authentication Name If necessary, enter the name for authenticating the XT Series with the SIP Proxy server and SIP Registrar. It can be the same as the User parameter. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 130...

  • Page 131: Configuring Call Settings

    • Call settings, such as defining calls as audio-only, or specifying the call rate • IP settings, such as determining whether the XT Codec Unit checks the source of audio and video data packets Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 131...
  • Page 132 • From the web interface, select Administrator Settings > Calls > Preferences > General. • From the endpoint, select Configure > Advanced > Calls > Preferences > General. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 132...
  • Page 133 If set to Yes allows to change bandwidth used for content and bandwidth (IP) live video (DualVideo/Live bandwidth). DualVideo/Live bandwidth Sets more bandwidth on Live Video or Content. (IP) Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 133...
  • Page 134 If set to Yes, the XT Codec Unit checks the source of the RTP packets (audio, video, and presentation) it receives to verify that it matches the remote endpoint's IP address. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 134...

  • Page 135: Configuring Scopia Xt Series Endpoints To Use An Ldap Directory

    (Figure 84: Viewing and editing contacts in Local LDAP server on page 135). The local LDAP server has a password which can be changed if needed. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 135...
  • Page 136 At least one of these fields h323IdentitytransportDigits <E/164 dial number> must be defined for an h323IdentitytransportNumber <H.323 alias> H.323 endpoint. h323Identityh323-ID <H.323 alias> SIPIdentitySIPURI <URI address of SIP endpoint> SIP endpoints only. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 136...
  • Page 137 • From the endpoint's main menu, select Configure > Advanced > System > LDAP. • From the XT Series web interface, select Administrator Settings > System > LDAP. Figure 85: Configuring LDAP settings from the web interface 2. Select Add Server. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 137...
  • Page 138 Distinguished Name (DN). Some standard components of DN are: domain controller (dc), organizational unit (ou), common name (cn), country (c), state or province (st), locality (l), organization (o). Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 138...
  • Page 139 The filter applied to the LDAP tree, so you view only the relevant contacts. This value is predefined when the LDAP server is an XT Series or Scopia Management. 4. From the web interface only, select Save. Installation Guide for Scopia XT5000 Series Version 3.2 Initial Configuration | 139...

  • Page 140: Chapter 7: Securing Your Scopia Xt Series

    Ensure you have the root certificate of the certificate authority your organization uses. This root certificate is used when uploading signed certificates into the XT Series. Perform Uploading XT Series Certificates on page 143. Installation Guide for Scopia XT5000 Series Version 3.2 Securing your Scopia XT Series | 140...

  • Page 141: Generating A Certificate Signing Request For Xt Series

    1. Access the XT Series web interface, as described in Accessing XT Series Web Interface page 62. 2. Select Administrator Settings > Utilities > Certificates. 3. Enter your organization's details and your email. Installation Guide for Scopia XT5000 Series Version 3.2 Securing your Scopia XT Series | 141...
  • Page 142 Enter the name of your specific department within the organization. Email Enter your email address. 4. Select Create. The CSR is created. 5. Select Download > Download CSR to save the CSR. Installation Guide for Scopia XT5000 Series Version 3.2 Securing your Scopia XT Series | 142...

  • Page 143: Uploading Xt Series Certificates

    Backing Up and Restoring XT Series Certificates on page 145. To delete the certificates, see Backing Up and Restoring XT Series Certificates on page 145. Installation Guide for Scopia XT5000 Series Version 3.2 Securing your Scopia XT Series | 143...
  • Page 144 Select Choose File (next to Step 4) and browse to the signed certificate you received from the CA. b. Select Upload. The certificate is validated and its details appear (Figure 91: Signed certificate from the CA on page 145). Installation Guide for Scopia XT5000 Series Version 3.2 Securing your Scopia XT Series | 144...

  • Page 145: Backing Up And Restoring Xt Series Certificates

    1. Connect a USB key to the upper USB port of the XT Codec Unit (Figure 92: Connecting a USB Key to the XT Codec Unit on page 146). Installation Guide for Scopia XT5000 Series Version 3.2 Securing your Scopia XT Series | 145...

  • Page 146: Deleting Xt Series Certificates

    To secure SIP connections using TLS certificates, your system must have a static IP address, since the system generates the certificate request using its IP address as the Common Name (CN). Installation Guide for Scopia XT5000 Series Version 3.2 Securing your Scopia XT Series | 146...

  • Page 147: Enabling The Tls Connection In Xt Series

    XT Series. Before you begin Upload the required certificates to the XT Series, as described in Uploading XT Series Certificates page 143. Installation Guide for Scopia XT5000 Series Version 3.2 Securing your Scopia XT Series | 147...
  • Page 148 2. Select Administrator Settings > Protocols > SIP. 3. Select Yes from the Use TLS list to accept incoming calls using TLS. Figure 95: Enabling TLS 4. Define the following settings: Installation Guide for Scopia XT5000 Series Version 3.2 Securing your Scopia XT Series | 148...

  • Page 149: Enabling Encryption For Videoconferences

    Important: Using encryption is subject to local regulation. In some countries it is restricted or limited for usage. For more information, consult your local reseller. Installation Guide for Scopia XT5000 Series Version 3.2 Securing your Scopia XT Series | 149...
  • Page 150 2. Select Yes from the Enable encryption field. 3. Set the fields as described in Table 40: Configuring settings for securing calls on page 151. Installation Guide for Scopia XT5000 Series Version 3.2 Securing your Scopia XT Series | 150...
  • Page 151 Length of Prime DH Number This value is always fixed at 1024 bit, which is the standard H.323 value. 4. From the web interface only, select Save. Installation Guide for Scopia XT5000 Series Version 3.2 Securing your Scopia XT Series | 151...

  • Page 152: Chapter 8: Troubleshooting The Scopia Xt Series

    Important: The system serial number also appears on the label at the back of the XT Codec Unit. Procedure 1. View system information as follows: Installation Guide for Scopia XT5000 Series Version 3.2 Troubleshooting the Scopia XT Series | 152...
  • Page 153 2. To view additional system information such as IP addresses and the gatekeeper's registration status from the endpoint, press the Back key and select System Status. Installation Guide for Scopia XT5000 Series Version 3.2 Troubleshooting the Scopia XT Series | 153...

  • Page 154: Resolving Problems With Audio

    Access audio tests as follows: • From the endpoint, select Configure > System Status > Audio > Tests. • From the web interface, select Diagnostics > Audio > Tests. Installation Guide for Scopia XT5000 Series Version 3.2 Troubleshooting the Scopia XT Series | 154...
  • Page 155 Audio G.719 (full band). Solution The endpoint administrator should disable specific audio codec if there is any compliance issue with older endpoints. Installation Guide for Scopia XT5000 Series Version 3.2 Troubleshooting the Scopia XT Series | 155...

  • Page 156: Echo Cancelling On Hdmi Monitors

    If configuring from the endpoint, you must first enable advanced configuration, as described in Maintaining the Scopia XT Series Locally from the Endpoint on page 73. Installation Guide for Scopia XT5000 Series Version 3.2 Troubleshooting the Scopia XT Series | 156...
  • Page 157 • From the endpoint's Main menu, select Configure > System Status > Diagnostics > Audio > Tests. • From the web interface, select Diagnostics > Audio > Tests. Installation Guide for Scopia XT5000 Series Version 3.2 Troubleshooting the Scopia XT Series | 157...

  • Page 158: Resolving Monitor Display Problems

    Verify the power cord of the XT Codec Unit is connected properly at both ends. Solution Verify the monitor’s power cord is connected properly at both ends. Solution Check that the monitor power switch is set to ON. Installation Guide for Scopia XT5000 Series Version 3.2 Troubleshooting the Scopia XT Series | 158...
  • Page 159 Left monitor. Important: You can also adjust the image for the monitor displaying the system menu, in the quick setup Installation Guide for Scopia XT5000 Series Version 3.2 Troubleshooting the Scopia XT Series | 159...

  • Page 160: Resolving Camera Issues

    Change the video source to the correct camera, as described below. Select Control Camera from the Main menu (or from the In-Call menu, during a call) and press ok/menu. Press ok/menu again. Installation Guide for Scopia XT5000 Series Version 3.2 Troubleshooting the Scopia XT Series | 160...
  • Page 161 > Cameras > HD1 from the Main menu. • From the XT Series web interface, select Administrator Settings > I/O connections > Cameras > HD1. Installation Guide for Scopia XT5000 Series Version 3.2 Troubleshooting the Scopia XT Series | 161...

  • Page 162: Resolving Ip Address Problems

    Make sure the GLAN cable is connected properly at both ends: to the network socket and to the GLAN1 port of the XT Codec Unit, as shown in Figure 107: GLAN1 port on page 163. Installation Guide for Scopia XT5000 Series Version 3.2 Troubleshooting the Scopia XT Series | 162...
  • Page 163 From the endpoint's main menu, select Configure > Quick Setup. Press Next several times until the Configure TCP/IP screen appears. Figure 108: Configuring IP address Enter the IP address. Installation Guide for Scopia XT5000 Series Version 3.2 Troubleshooting the Scopia XT Series | 163...

  • Page 164: Resolving Xt Remote Control Unit Problems

    59. When the XT Remote Control Unit's battery power is low, an icon appears in the system menus letting you know that you should replace the battery: • Half-charged Battery • Low Battery Installation Guide for Scopia XT5000 Series Version 3.2 Troubleshooting the Scopia XT Series | 164...

  • Page 165: Restoring Default User Settings

    PIN code is 1234. Procedure 1. From the endpoint's main menu, select Configure > General. Figure 110: Enabling advanced settings 2. Set Show Advanced Settings to Yes. Installation Guide for Scopia XT5000 Series Version 3.2 Troubleshooting the Scopia XT Series | 165...
  • Page 166 6. Select Utilities > Restore System > Factory Defaults. Figure 111: Restoring factory default settings 7. Press ok/menu, and select Yes. The default settings are restored. Installation Guide for Scopia XT5000 Series Version 3.2 Troubleshooting the Scopia XT Series | 166...

  • Page 167: Glossary Of Terms For Scopia Solution

    In H.323, an alias represents the unique name of an endpoint. Instead of dialling an IP address to reach an endpoint, you can dial an alias, and the gatekeeper resolves it to an IP address. Installation Guide for Scopia XT5000 Series Version 3.2 Glossary of Terms for Scopia Solution | 167...
  • Page 168 The range of video layouts depends on the type of media processing supported, typically located in the MCU. Continuous Presence on page 168. Installation Guide for Scopia XT5000 Series Version 3.2 Glossary of Terms for Scopia Solution | 168...

  • Page 169: Dial Plan

    Endpoints include dedicated endpoints, like Scopia XT Executive, software endpoints Installation Guide for Scopia XT5000 Series Version 3.2 Glossary of Terms for Scopia Solution | 169...
  • Page 170 The higher the frame rate, the smoother the video. Full HD Full HD, or Full High Definition, also known as 1080p, describes a video resolution of 1920 x 1080 pixels. Installation Guide for Scopia XT5000 Series Version 3.2 Glossary of Terms for Scopia Solution | 170...
  • Page 171 A gateway is a component in a video solution which routes information between two subnets or acts as a translator between different protocols. For example, a gateway can route data between the headquarters and a partner site, or between two protocols like the Scopia TIP Gateway, Radvision SIP Gateway, or the Scopia TIP Gateway.
  • Page 172 SVC which is an adaptive technology working to improve quality even when only one side supports the standard. H.320 H.320 is a protocol for defining videoconferencing over ISDN networks. Installation Guide for Scopia XT5000 Series Version 3.2 Glossary of Terms for Scopia Solution | 172...
  • Page 173 HTTPS is the secured version of the standard web browser protocol HTTP. It secures communication between a web browser and a web server through authentication of the web site and encrypting Installation Guide for Scopia XT5000 Series Version 3.2 Glossary of Terms for Scopia Solution | 173...
  • Page 174 A location is a physical space (building) or a network (subnet) where video devices can share a single set of addresses. A distributed deployment places these components in different locations, often connected via a VPN. Installation Guide for Scopia XT5000 Series Version 3.2 Glossary of Terms for Scopia Solution | 174...
  • Page 175 Scopia Management can manage a separate set of users for each organization, separate local administrators, separate bandwidth policies etc. all within a single multi-tenant installation. Installation Guide for Scopia XT5000 Series Version 3.2 Glossary of Terms for Scopia Solution | 175...

  • Page 176: Packet Loss

    NetSense NetSense is a proprietary Radvision technology which optimizes the video quality according to the available bandwidth to minimize packet loss. As the available bandwidth of a connection varies depending on data traffic, NetSense's sophisticated algorithm dynamically scans the video stream, and then reduces or improves the video resolution to maximize quality with the available bandwidth.
  • Page 177 IP. It underpins most videoconferencing protocols today, including H.323, SIP and the streaming control protocol known as RTSP. The secured version of RTP is SRTP. Installation Guide for Scopia XT5000 Series Version 3.2 Glossary of Terms for Scopia Solution | 177...
  • Page 178 SIF defines a video resolution of 352 x 240 pixels (NTSC) or 352 x 288 (PAL). This is often used in security cameras and countries. Installation Guide for Scopia XT5000 Series Version 3.2 Glossary of Terms for Scopia Solution | 178...

  • Page 179: Sip Server

    Secure Real-time Transport Protocol (SRTP) adds security to the standard RTP protocol, which is used to send video and audio data between devices in SIP calls using TLS. It offers security via encrypting, authenticating and ensuring message integrity. Installation Guide for Scopia XT5000 Series Version 3.2 Glossary of Terms for Scopia Solution | 179...
  • Page 180 (CP). Using video switching increases the port capacity of the MCU by four times. Installation Guide for Scopia XT5000 Series Version 3.2 Glossary of Terms for Scopia Solution | 180...
  • Page 181 SIP server domain name. For example, <endpoint name>@<SIP server domain name> or user@domain_name.com. URI Dialling Accessing a device via its on page 181. Installation Guide for Scopia XT5000 Series Version 3.2 Glossary of Terms for Scopia Solution | 181...
  • Page 182 External participants can download Scopia Desktop or Scopia Mobile free to access a registered user's virtual room and participate in the videoconference. Installation Guide for Scopia XT5000 Series Version 3.2 Glossary of Terms for Scopia Solution | 182...
  • Page 183 Often a zone is assigned a dial prefix, and usually corresponds to a physical location like an organization's department or branch. Installation Guide for Scopia XT5000 Series Version 3.2 Glossary of Terms for Scopia Solution | 183...
  • Page 184 About Radvision Radvision, an Avaya company, is a leading provider of videoconferencing and telepresence technologies over IP and wireless networks. We offer end-to-end visual communications that help businesses collaborate more efficiently. Together, Radvision and Avaya are propelling the unified communications evolution forward with unique technologies that harness the power of video, voice, and data over any network.

This manual is also suitable for:

Scopia xt4000 seriesScopia xt executive

Table of Contents
