Wiznet WIZ110SR User Manual

Serial-to-ethernet gateway
Hide thumbs Also See for WIZ110SR:

Advertisement

Quick Links

WIZ110SR User's Manual
(Version1.0)
©2007 WIZnet Co., Ltd. All Rights Reserved.
☞ For more information, visit our website at
http://www.wiznet.co.kr

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WIZ110SR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wiznet WIZ110SR

  • Page 1 WIZ110SR User’s Manual (Version1.0) ©2007 WIZnet Co., Ltd. All Rights Reserved. ☞ For more information, visit our website at http://www.wiznet.co.kr...
  • Page 2 WIZnet’s Online Technical Support If you have something to ask about WIZnet products, write down your question on Q&A Board in WIZnet website (www.wiznet.co.kr). WIZnet will give an answer as soon as possible. 목 차 Copyright © WIZnet All Rights Reserved...
  • Page 3: Table Of Contents

    4. DEMONSTRATION AND TEST ................19 ................19 ARDWARE NTERFACE “S ” F ............20 ESTING ERIAL TO THERNET UNCTION 5. HARDWARE DESCRIPTION OF WIZ110SR............22 ..................22 ARAMETERS ..................22 PECIFICATION ............22 OARD IMENSIONS AND SSIGNMENT 6. WARRANTY....................25 Copyright © WIZnet All Rights Reserved...
  • Page 4 Figure 10. Firmware uploading window............18 Figure 11. Complete Uploading ............... 18 Figure 12. WIZ110SR Interface ..............19 Figure 13. Device Terminal..............21 Figure 14. WIZ110SR Board Dimension ............23 Figure 15. RJ-45 PIN Assignment .............. 24 Figure 16. RS-232 PIN Assignment............. 24 Tables Table 1.
  • Page 5: Introduction

    1. Introduction WIZ110SR is a gateway module that converts RS-232 protocol into TCP/IP protocol. It enables remote gauging, managing and control of a device through the network based on Ethernet and TCP/IP by connecting to the existing equipment with RS-232 serial interface.
  • Page 6: Specification

    0°C ~ 80°C (Operation), -40°C ~ 85°C (Storage) Humidity 10 ~ 90% Table 1. WIZ110SR Specification 1.3 Products Contents WIZ110SR Board CD (Option / including Firmware, Configuration Tool Program Manual and other related materials) Copyright © WIZnet All Rights Reserved ASRB for SERIAL | 6 page...
  • Page 7: Table 2. Products Contents

    LAN Cable (Option) 5V Power Adaptor (Option) Table 2. Products Contents Copyright © WIZnet All Rights Reserved ASRB for SERIAL | 7 page...
  • Page 8: Wiz110Sr Board

    2.1 Block Diagram Figure 1. Block Diagram WIZ110SR is a protocol converter that transmits the data sent by serial equipment as TCP/IP data type and converts back the TCP/IP data received through the network into serial data to transmit back to the equipment. When the data is received from serial port, it is sent to W5100 by MCU.
  • Page 9: Configuration Tool

    ⓑ Enable Serial Debug Mode : If this mode is checked, you can monitor the status and socket message of WIZ110SR (listen OK, connect fail etc.) through serial terminal. If Debug mode is on, debug message can cause abnormal operation of the serial device. Therefore, just use this mode only for Debug mode.
  • Page 10 ⓔ Subnet : WIZ110SR’s subnet mask ⓕ Gateway : WIZ110SR’s Gateway address ⓖ Server IP/Port : When WIZ110SR is set as “Client mode” or Mixed mode”, server IP and port should be set. WIZ110SR attempts to connect this IP address.
  • Page 11: Figure 3. Tcp Server Mode

    (where WIZ110SR is installed) in order to check the status or provide the commands. In normal time WIZ110SR is on the waiting status, and if there is any connection request from the monitoring center, data communication is processed and connection is closed.
  • Page 12: Figure 5. Udp Mode

    As like TCP Server mode, the Mixed mode is useful for the case that the monitoring center tries to connect to the serial device (in which WIZ110SR is used) to check device status. In addition to this, if any emergency occurs in the serial device, the module will change to...
  • Page 13 ⓛ Direct IP Search Direct IP Search can be used for searching WIZ110SR not installed in the same subnet. If the Direct IP search is checked, the configuration tool use the TCP instead UDP broadcast to search modules. Therefore, network information of the module such as IP address, subnet mask and gateway is required.
  • Page 14: Figure 6. Configuration Tool (Serial Config.)

    In order to change the serial configuration of WIZ100SR, this menu can be used. ☞ By clicking the “Setting” button, changed value can be applied. 2.2.3 Option configuration Copyright © WIZnet All Rights Reserved ASRB for SERIAL | 14 page...
  • Page 15: Figure 7. Configuration Tool (Option Config.)

    In order to close the connection, the ‘Close’ command should be given. This function can be used for more than two or more systems to connect to a WIZ110SR module. If one system keeps connection to the WIZ110SR, other systems can not connect to the module.
  • Page 16 When any of three delimiters is satisfied, data can be sent to the Ethernet. Ex) Delimiter: Size=10, Char=0x0D Serial data : 0123456789abc Ethernet data : 0123456789 “abc” data remains in the serial buffer of module ☞ Copyright © WIZnet All Rights Reserved ASRB for SERIAL | 16 page...
  • Page 17: Firmware Upload

    3. Firmware Upload ① Run ‘WIZ100SR/WIZ110SR Configuration Tool’ program, and click “Search” button. ② If the module is properly connected to the network, “Complete searching” message and MAC address will be displayed on the “Board List” as shown in below.
  • Page 18: Figure 9. Open Dialog Box For Uploading

    Figure 9. Open dialog box for uploading ☞ Do not upload any other files except for WIZ110SR firmware file. ⑤ A dialogue box titled “Processing” will be displayed as below. Figure 10. Firmware uploading window ⑥ When uploading is complete, a message box with “Complete Uploading” will be displayed as shown in below figure.
  • Page 19: Demonstration And Test

    Figure 12. WIZ110SR Interface Install the board as below steps. STEP 1: Connect the WIZ110SR to the network by using RJ45 Ethernet cable. STEP 2: Connect the WIZ110SR to the serial device by using Serial cable STEP 3: Connect the power adaptor to WIZ110SR board.
  • Page 20: Testing "Serial To Ethernet" Function

    STEP8: Input any character at the Network Hyper Terminal and check if it is displayed at the Serial Hyper Terminal screen. (Ethernet -> Serial) * Above function can be tested through Device Terminal Program that WIZnet is providing. The program...
  • Page 21: Figure 13. Device Terminal

    Figure 13. Device Terminal Copyright © WIZnet All Rights Reserved ASRB for SERIAL | 21 page...
  • Page 22: Hardware Description Of Wiz110Sr

    5. Hardware Description of WIZ110SR Parameters Power 5V DC / 180mA Dimension 75 x 50 x 17 (L x W x H) Temperature Operating : 0 ~ 80 ℃ Ethernet 10/100 Base-T Ethernet (Auto detection) Serial interface RS-232 Specification 8051 Compliant...
  • Page 23: Figure 14. Wiz110Sr Board Dimension

    75.6mm 62.6mm 44.8mm Figure 14. WIZ110SR Board Dimension Copyright © WIZnet All Rights Reserved ASRB for SERIAL | 23 page...
  • Page 24: Figure 15. Rj-45 Pin Assignment

    Signal Description Not Connected Receive Data Transmit Data Data Terminal Ready Ground Data Set Ready Request To Send Clear To Send Not Connected Figure 16. RS-232 PIN Assignment Copyright © WIZnet All Rights Reserved ASRB for SERIAL | 24 page...
  • Page 25: Warranty

    WIZnet warrants our products and its parts against defects in materials and workmanship under normal use for period of standard ONE(1)YEAR for the WIZ110SR board and labor warranty after the date of original retail purchase. During this period, WIZnet will repair or replace a defective products or part free of charge.
