Exibel BX50 Instruction Manual

Bluetooth Speaker
Art.no 38-6248, 38-6249 Model BX50
Please read the entire instruction manual before using the product
and then save it for future reference. We reserve the right for
any errors in text or images and any necessary changes made
to technical data. In the event of technical problems or other
queries, please contact our Customer Services.
Safety
• The speaker may be used by children aged 8 or over
provided they have been instructed in the safe use of
the product and that they understand the hazards and
risks involved. Cleaning and maintenance may be carried
out by children aged 8 or over, but only under adult
supervision. Keep the speaker out of reach of children
under the age of 8.
• The speaker may be used by persons with reduced
physical, sensory or mental capability, lack of experience
or knowledge which could jeopardise their safety, provided
they have been instructed in the safe use of the product
and understand the hazards involved. Never let children
play with the speaker.
• The speaker should not be taken apart or modified. Never try
to open the casing of the speaker. The casing houses
dangerous current-carrying non-insulated components.
Contact with these can lead to fire or electric shock.
• Do not cover the speaker. Adequate ventilation with a distance
of at least 5 cm between ventilation ports and the surrounding
area is necessary to prevent the speaker from overheating.
• Place the speaker on a stable, flat surface.
• Do not place the speaker where it could fall into water or
other liquids. Do not place any objects containing liquid on
the speaker, such as vases, drinks, etc.
• Do not place the speaker in constant sunlight or near
naked flames such as wood stoves, lit candles, etc.
• The speaker is intended for indoor use only.
• Never subject the speaker to high temperature, dust,
heavy vibration, impacts, damp or moisture.
• Protect your hearing. Listening on high volume for
prolonged periods can lead to permanent hearing loss.
• The speaker must only be repaired by qualified service
technicians.
GREAT BRITAIN - CUSTOMER SERVICE contact number: 0845 300 9799
English
Buttons and functions
1. LED charge indicator
2. LED Bluetooth indicator
3
4
5
3. [ l◄◄ ] Previous track
4. [ ] Answer and end calls
5. [ - ] Decrease volume
6. [ + ] Increase volume
7. [ ►ll ] Play/pause. Hold in for 3 seconds to shut off
the current Bluetooth connection and begin searching for
other devices.
8. [ ►►l ] Next track
e-mail: customerservice@clasohlson.co.uk
1 2 9. [ ON/OFF ] On/off switch
10. USB port for connecting a charge lead
11. AUX IN: 3.5 mm external audio source input socket

Operating instructions

Charging
• Fully charge the battery before using the speaker for
the first time.
6
• Only use the supplied charge lead.
• Connect the included charge lead to the charging port (10)
7
on the Bluetooth speaker and to a computer or other USB
charger.
• The LED indicator will shine red while the battery is
8
charging and change to green when the battery is fully
charged.
• When the battery is almost fully discharged, the speaker
will emit an audible signal and then shut off.
Connecting an external Bluetooth device
1. Turn the speaker on by setting the [ OFF/ON ] switch (9)
to the ON position. The LED indicator will flash red/blue
which indicates that the speaker is detectable for pairing
with other Bluetooth devices.
2. Activate Bluetooth on the device to be paired with the speaker.
3. The speaker will appear on your device as "BX50", select it
and pair it with your device. Refer to the instruction manual
of your device for further clarification if you are unsure.
4. Once connection has been established the blue LED
indicator on the speaker will flash slowly.
internet: www.clasohlson.com/uk
9 10 11
