Adjusting the 3-Axis Gimbal

The Gimbal mechanism yields maximum rotation and placement as shown below.
Z-Axis: Rotation 355°
1
Y-Axis: Tilting 90°
2
X-Axis: Panning 355°
3
Rotation 355°
1
Tilting 90°
2
Panning 355°
3
Tilting 90° w/ IR LED
2
